AWS BLADE-50 Manuel utilisateur

American Weigh Scales, Inc.

BLADE-50

BLADE-400

BLADE-550

BLADE-1000

User Manual

BLADE Series

Digital Pocket Scale

Blade Series Manual

Thank you for purchasing the American Weigh

BLADE-Series digital scale. Please read all operating

instructions carefully before use. This electronic scale

is a precision instrument. With normal care and proper

treatment, it will provide years of reliable service.

Never load the scale with more than the maximum

capacity. Overloading will permanently damage it!

Avoid any exposure to extreme heat or cold. Your

scale works better when operated at normal room

temperature. Always allow the scale to acclimate to

normal room temperature for at least one hour before

use.

Give your scale sufcient warm up time. Usually

30-60 seconds before calibration to give the internal

components a chance to stabilize.

Keep your scale in a clean environment. Dust, dirt,

moisture, vibration, air currents and a close distance to

other electronic equipment can all cause an adverse

effect on the reliability and accuracy of your scale.

Handle with care. Gently apply all items to be weighed

onto tray top. Although this scale is designed to be

quite durable, try to avoid rough treatment as this may

permanently damage the internal sensor.

Avoid shaking, dropping or otherwise shocking the

scale. This is a precision instrument and must be

handled with extreme care.

Only operate the scale on a stable, vibration free

surface.

I. OPERATION

Place Scale on a horizontal at surface.

1. Press [ON/OFF] key.

2. Wait until "0.0” is displayed.

3. Put the object(s) on the weighing platform.

4. Using the [MODE] key, you can switch between the

weighing units.

II. TARE WEIGHING

1. Turn on scale as described above.

2. Place the "tare item" on the platform.

3. Press [TARE] and wait until "0.0" is displayed.

4. Add the "net-weight-item".

III. CALIBRATION

Calibration is NOT required before rst use. Only

calibrate if scale is not weighing properly.

**Make sure you use the correct calibration weight for

your scale or the calibration will not be accurate**

BLADE-50: 50g calibration weight

BLADE-400: 400g calibration weight

BLADE-550: 500g calibration weight

BLADE-1000: See section IV.Blade1000

Calibration Procedures

1. Turn ON the scale.

2. Press and hold the [MODE] key until “CAL” is dis-

played. Release the [MODE] key.

3. Press [MODE] again. Now the display will read

“CAL” and the required calibration weight will ash 3

times.

4. Place the required calibration weight for your scale

on the center of platform. Wait 3-4 seconds. The LCD

will display “PASS”.

5. Remove the weight and press [ON/OFF] to turn off

the scale. Finished! Repeat if necessary.

IV. BLADE1000 Calibration Procedures

You will need a 1000g (1kg) calibration weight.

1. Turn on the scale by pressing [ON/OFF] key.

2. Wait until the LCD displays “0.0” then press and

HOLD the [MODE] key for 3 seconds. The LCD will

display “CAL”. You can now release the [MODE] key.

3. Press [MODE] key again, the LCD will display “CAL”

and “1000.0”.

4. Add 1000g calibration weight, the display will show

“PASS” and return to normal weighing mode.

5. Put away the calibration weight and press [ON/OFF]

to turn off the scale. Finished! Repeat if necessary.

V. TROUBLESHOOTING

The primary reasons for inaccuracy or malfunction

are low batteries, incorrect calibration, overload or

operating on an unstable surface. Please keep this in

mind and maintain and operate your scale properly.

This scale is a precise instrument and must be

handled with the utmost care and caution.

[Display] Elimination of errors

Nothing, Battery-Symbol, [lo] or [88888]

Change the batteries.

[OUE2] Recalibrate the scale as shown above.

[EEEEE] You are overloading the scale. Remove the

excessive load immediately!

[LLLLL] The delicate weighing load cells have

been damaged by misusing the scale

(i.e. it was shocked, dropped or

overloaded). You can try recalibrating the

scale. If the load cell has not been

damaged too much it will work

again after recalibration.

[UNST] Use the scale in a more stable position

Model Blade-400 Blade-550 Blade-1000 Blade-50

Capacity 400g

14.11oz

12.86ozt

257.2dwt

550g

19.40oz

17.68ozt

353.7dwt

1000g

35.27oz

32.15ozt

643.1dwt

50g

1.764oz

250ct

771.5gn

Resolution 0.1g

0.01oz

0.01ozt

0.1dwt

0.01g

0.001oz

0.05ct

0.1gn (0.2gn

minimum)

Weighing Units g, oz, ozt, dwt g, oz, ct, gn

Calibration Weight (not Included) 400g 500g 1000g 50g

Platform Dimensions (inches) 2.75 x 2.75 (Stainless Steel )

Scale Dimensions (inches) 3.75 x 3.75 x 0.75

Power 2 x AAA Batteries (included)

Gross Weight 0.45 lb 0.51 lb 0.45 lb

Specications
