Avenview HBT2-C6POH-USB-SET 4K60 HDMI/Audio over CAT6 TX/RX Kit, USB & PoE - 328'

VIDEO WALLS VIDEO PROCESSORS

VIDEO MATRIX SWITCHES

EXTENDERS SPLITTERS WIRELESS

CABLES & ACCESSORIES

Control Your Video

4K@60 HDMI/Audio over CAT5e/6/7

Extender with USB and 48V PoE

The contents of this document are provided in connection with Avenview Inc. (“Avenview”) products. Avenview makes no representations or

warranties with respect to the accuracy or completeness of the contents of this publication and reserves the right to make changes to specifications

and product descriptions at any time without notice. No license, whether express, implied, or otherwise, to any intellectual property rights is granted

by this publication. Except as set forth in Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and disclaims

any express or implied warranty, relating to its products of Avenview Inc. is strictly prohibited.

Model #: HBT2-C6POH-USB-SET

Military Residential

Medical Aviation

Education Industrial

Corporate House Of Worship

www.avenview.com

Product Application & Market Sectors

www.avenview.com Page

TABLE OF CONTENTS

1. GETTING STARTED ..........................................................................................................................1

1.1 IMPORTANT SAFEGUARDS..............................................................................................................1

1.2 SAFETY INSTRUCTIONS ..................................................................................................................1

1.3 REGULATORY NOTICES FEDERAL COMMUNICATIONS COMMISSION (FCC) ........................... 2

2. INTRODUCTION ..............................................................................................................................3

2.1 PACKAGE CONTENTS .....................................................................................................................4

2.2 BEFORE INSTALLATION...................................................................................................................4

2.3 APPLICATION DIAGRAM..................................................................................................................5

2.4 PANEL DESCRIPTION.......................................................................................................................6

2.4.1 Input Panel (Transmitter, HBT2-C6POH-USB-S) Front...........................................................6

2.4.2 Input Panel (Transmitter, HBT2-C6POH-USB-S) Rear............................................................6

2.4.3 Input Panel (Receiver, HBT2-C6POH-USB-R) Front................................................................7

2.4.4 Input Panel (Receiver, HBT2-C6POH-USB-R) Rear ..................................................................7

3. IR EXTENDERS ..................................................................................................................................8

4. INSTALLATION (HBT2-C6POH-USB-SET) .....................................................................................9

5. GENERAL TROUBLESHOOTING.....................................................................................................9

6. CABLE SPECIFICATION ..................................................................................................................10

7. SPECIFICATIONS .............................................................................................................................11

www.avenview.com Page

SECTION 1: GETTING STARTED

1.1 IMPORTANT SAFEGUARDS

Please read all of these instructions carefully before you use the device. Save this manual for future reference.

What the warranty does not cover

•Any product, on which the serial number has been defaced, modified or removed.

•Damage, deterioration or malfunction resulting from:

•Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product modification, or failure to

follow instructions supplied with the product.

•Repair or attempted repair by anyone not authorized by us.

•Any damage of the product due to shipment.

•Removal or installation of the product.

•Causes external to the product, such as electric power fluctuation or failure.

•Use of supplies or parts not meeting our specifications.

•Normal wear and tear.

•Any other causes which does not relate to a product defect.

•Removal, installation, and set-up service charges.

1.2 SAFETY INSTRUCTIONS

The HBT2-C6POH-USB-SET, HDMI Extender over Signal CAT5/6 with HDBaseT-Lite Technology has been tested for

conformance to safety regulations and requirements, and has been certified for international use. However, like all electronic

equipments, the HBT2-C6POH-USB-SET should be used with care. Read the following safety instructions to protect yourself

from possible injury and to minimize the risk of damage to the unit.

!Do not dismantle the housing or modify the module.

!Dismantling the housing or modifying the module may result in electrical shock or burn.

!Refer all servicing to qualified service personnel.

!Do not attempt to service this product yourself as opening or removing housing may expose you to dangerous voltage

or other hazards

!Keep the module away from liquids.

!Spillage into the housing may result in fire, electrical shock, or equipment damage. If an object or liquid falls or spills on

to the housing, unplug the module immediately.

!Have the module checked by a qualified service engineer before using it again.

!Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before cleaning.

1. GETTING STARTED

www.avenview.com Page

1.3 REGULATORY NOTICES FEDERAL COMMUNICATIONS COMMISSION (FCC)

This equipment has been tested and found to comply with Part 15 of the FCC rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation.

Any changes or modifications made to this equipment may void the user’s authority to operate this equipment.

Warning symbols Description

ONLY USE THE PROVIDED POWER CABLE OR POWER

ADAPTER SUPPLIED. DO NOT TAMPER WITH THE

ELECTRICAL PARTS. THIS MAY RESULT IN ELECTRICAL

SHOCK OR BURN.

DO NOT TAMPER WITH THE UNIT. DOING SO WILL

VOID THE WARRANTY AND CONTINUED USE OF THE

PRODUCT.

THE VIDEO BOARDS ARE VERY SENSITIVE TO STATIC.

PLEASE ENSURE IF RACK MOUNTED OR INSTALLED ON A

SURFACE, IT SHOULD BE IN A GROUNDED ENVIROMENT.

www.avenview.com Page

2. INTRODUCTION

Avenview HBT2-C6POH-USB-SET HDMI and Audio over Single CAT5e/6/7 Transmitter and Receiver set can send

uncompressed audio/video along with controls, IP and USB data over a single run of CAT5e/6/7 cable up to 100m. It has the

added benefit of control through built-in RS-232 and IR ports. With LAN ports allowing network connection and external

digital and analog audio capability that gives users the convenience of additional audio connection. HBT2-C6POH-USB-SET

also allows the connection of any USB host, enabling a USB connection to up to 2 USB ports, giving the Receiver the ability to

act like a USB hub. The 48V PoE design can power the Receiver (Rx) from the Transmitter (Tx), eliminating the need for a

separate power supply for the Receiver. Also, the ultra-thin mechanical designs allow flexibility mounting position saving

more space.

FEATURES:

• Supports HDBaseT 2.0 specification over a single CAT6/7 cable up to

• 100m/328ft and CAT5e cable up to 90m/295ft;

• Receiver features 2 USB 2.0 ports to control any USB peripheral device;

• HDMI (with 3D & 4K2K@60 -YUV420 support), HDCP 2.2 and DVI compatible;

• HDBaseT 5Play™ convergence: High-Definition (HD) Video and Audio, 100BaseT Ethernet, PoE and

Control (Bidirectional IR/RS-232 pass-through);

• Supports pass-through of HD audio formats: LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, Dolby Digital

Plus, Dolby TrueHD, Dolby Atmos and DTSHD Master Audio;

• Supports optical sampling rate up to 48kHz;

• Supports Ethernet network connection;

• Supports external analog and digital audio transmission;

• Supports RS-232 baud rate from 110~115200bps.

NOTE: The QUALITY and TRANSMISSION of the video signals depends

on the characteristics and quality of the UTP cables. Higher resolutions

and longer transmission distances require low skew cables (<25ns/100m)

for best performance.

Unshielded CAT6 with metal RJ-45 connectors is recommended.

www.avenview.com Page

2.1 PACKAGE CONTENTS

Before you start the installation of the Extender/Splitter, please check the package contents.

1HBT2-C6POH-USB-SET X 1

2POWER ADAPTER (+48V 0.83A DC) X2

USER’S MANUAL X 1

2.2 BEFORE INSTALLATION

•Put the product in an even and stable location. If the product falls down or drops, it may cause an injury or malfunction.

•Don’t place the product in too high temperature (over 50°C), too low temperature (under 0°C) or high humidity.

•Use the DC power adapter with correct specifications. If inappropriate power supply is used then it may cause a fire.

•Do not twist or pull by force ends of the UTP cable. It can cause malfunction.

IR BLASTER

BLUE PHOENIX (Power)

PHOENIX CONTACT

MOUNTING BRACKETS

X 1

3IR EXTENDER X 1

www.avenview.com Page

2.3 APPLICATION DIAGRAM

www.avenview.com Page

2.4 PANEL DESCRIPTION

2.4.1 Input Panel (Transmitter, HBT2-C6POH-USB-S) Front

1. DC 48V and POWER LED: Plug the 48V DC power

supply into the unit and connect the adaptor to an AC

outlet. Green LED will illuminate.

2. AUDIO IN L/R: Connect to audio source

such as PC or CD player for audio

signal sending to Receiver’s AUDIO OUT L/R.

3. IR IN 2: Connect to the supplied IR Extender cable

for IR signal reception.

2.4.2 Input Panel (Transmitter, HBT2-C6POH-USB-S) Side

145 6

145

USB: Connect from PC or Laptop for data

transmit to or control from the Receiver’s USB

slots.

RS-232 IN TX/RX: Connect to a PC or Laptop with

USB to RS 232 cable for the transmission of RS-232

commands. For receiving command from Receiver side,

the TX and RX pin must be reversed.

SWITCH: This is reserved for firmware update use

only. Switch this deep switch to left for firmware

update use, under normal operation, leave the

switch on right.

1. LAN: Connect to an internet or network connection.

Yellow LED illuminates representing link with

Receiver is established, Blinking irregularly indicates

link error.

2. OPT. OUT: Connect to speaker/amplifier for

audio signal output from Receiver’s OPTICAL

IN.

3. ARC OUT OFF/ON SWITCH: Audio Return

Channel on/off switch*.

HDMI IN: Connect to HDMI source device such

as a DVD or Blu-ray player.

CAT5e/6/7 OUT: Connect to the Receiver unit with a

single CAT5e/6/7 cable for transmission of all data

signals. Green LED will illuminate to indicate PoE

activated.

Left

5LJKt

Note:

When ARC switch to ON, depending on the connected devices of the HDMI OUT & Optical in, the ARC input/output

transmission distance may vary. It is recommended to use a 2 meters cable to ensure the best audio quality.
