Avenview HDM3D-C53X-SET Manuel utilisateur

HDMI LAN Extender up to 100M over

Single CAT5/6

The contents of this document are provided in connection with Avenview Inc. (“Avenview”) products. Avenview makes no representations or warranties with

respect to the accuracy or completeness of the contents of this publication and reserves the right to make changes to specifications and product descriptions at any

time without notice. No license, whether express, implied, or otherwise, to any intellectual property rights is granted by this publication. Except as set forth in

Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and disclaims any express or implied warranty, relating to its products

including, but not limited to, the implied warranty of merchantability, fitness for a particular purpose, or infringement of any intellectual property right.

Reproduction of this manual, or parts thereof, in any form, without the express written permission of Avenview Inc. is strictly prohibited.

Model #: HDM3D-C53X-SET

www.avenview.com|2

Table of Contents

Section 1: Getting Started ...................................................................................................................... 3

1.1 Important Safeguards ............................................................................................................ 3

1.2 Safety Instructions ................................................................................................................. 3

1.3 Regulatory Notices Federal Communications Commission (FCC) ......................................... 4

1.4 Introduction ........................................................................................................................... 4

1.5 Package Contents................................................................................................................... 4

1.6 Before Installation.................................................................................................................. 4

1.7 Device Description & Layout.................................................................................................. 5

1.8 Installation ............................................................................................................................. 6

Section 3: General Troubleshooting....................................................................................................... 6

Section 4: Specifications......................................................................................................................... 7

4.1 PIN & Wiring Standard Definition.......................................................................................... 8

www.avenview.com|3

Section 1: Getting Started

1.1 Important Safeguards

Please read all of these instructions carefully before you use the device. Save this manual for future

reference.

What the warranty does not cover

Any product, on which the serial number has been defaced, modified or removed.

Damage, deterioration or malfunction resulting from:

Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product

modification, or failure to follow instructions supplied with the product.

Repair or attempted repair by anyone not authorized by us.

Any damage of the product due to shipment.

Removal or installation of the product.

Causes external to the product, such as electric power fluctuation or failure.

Use of supplies or parts not meeting our specifications.

Normal wear and tear.

Any other causes which does not relate to a product defect.

Removal, installation, and set-up service charges.

1.2 Safety Instructions

The Avenview HDM-C6IP-SET, HDMI Extender has been tested for conformity to safety regulations and

requirements, and has been certified for international use. However, like all electronic equipment’s, the

HDM-C6IP-SET should be used with care. Read the following safety instructions to protect yourself from

possible injury and to minimize the risk of damage to the unit.

Do not dismantle the housing or modify the module.

Dismantling the housing or modifying the module may result in electrical shock or burn.

Refer all servicing to qualified service personnel.

Do not attempt to service this product yourself as opening or removing housing may expose you to

dangerous voltage or other hazards

Keep the module away from liquids.

Spillage into the housing may result in fire, electrical shock, or equipment damage. If an object or liquid

falls or spills on to the housing, unplug the module immediately.

Have the module checked by a qualified service engineer before using it again.

Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before

cleaning.

www.avenview.com|4

1.3 Regulatory Notices Federal Communications Commission (FCC)

This equipment has been tested and found to comply with Part 15 of the FCC rules. These limits are designed

to provide reasonable protection against harmful interference in a residential installation.

Any changes or modifications made to this equipment may void the user’s authority to operate this

equipment.

1.4 Introduction

HDM-C6IP-SET, HDMI extender set is designed to extend your HD display with the resolutions of 1080p/60Hz

up to 330 feet (100 meters) away from your HDMI or DVI-D source. Thanks to the use of the TCP/IP protocol,

you can transfer your high-definition video over an existing TCP/IP network. See below three examples:

A :-The Tx and Rx units can extend 100 meters over a single CAT5/6 cable connection point to point.

B:-The Tx can be connected to a router to establish a IP address therefore sending 1080p video signals to

multiple Rx connected to the router to the desired displays.

C:- The Tx can be connected to a router with internet to establish a DHCP address therefore sending 1080p

video signals to Rx connected to the router to the desired displays.

Extends HDMI up to 95m/100m over single CAT5E/6

Supports HDMI, EDID, Support HDCP

Supports resolution HDTV / 1080Pp/60Hz, Vesa (1920 x 1080)

Supporting the point to point transmission function currently which can be expanded to the

multi-point to point transmission function.

1.5 Package Contents

Before you start the installation of HDM-C6IP-SET, please check the A. STANDARD package contents.

-HDMI Transmitter x 1

-HDMI Receiver x 1

-Power Adapter (5VDC) x 2

-User Manual

1.6 Before Installation

Put the product in an even and stable location. If the product falls down or drops, it may cause an

injury or malfunction.

Don’t place the product in too high temperature (over 50°C), too low temperature (under 0°C) or high

humidity.

Use the DC power adapter with correct specifications. If inappropriate power supply is used then it

may cause a fire.

www.avenview.com|5

1.7 Device Description & Layout

This product is composed of a Transmitter and a Receiver.

FRONT PANEL & REAR PANEL (Transmitter, HDM-C6IP-S)

1. CAT5E/6: Plug in a Cat-5E/6 cable that needs to be

linked to the receiving unit

3. +5V DC: Connect to 5V DC power supply.

2. SELECT: To pair with the corresponding Receiver

unit.

4. HDMI IN: Connects to a HDMI source with a HDMI

male-male cable.

FRONT PANEL & REAR PANEL (Receiver, HDM-C6IP-R)

1. CAT5E/6: Plug in a Cat-5E/6 cable that needs to be

linked to the receiving unit

3. +5V DC: Connect to 5V DC power supply.

2. SELECT: To pair with the corresponding Transmitter

unit.

4. HDMI OUT: Connects to a HDMI source with a

HDMI male-male cable.

www.avenview.com|6

1.8 Installation

Please ensure all the package contents are all received.

To setup Avenview HDM-C6IP-SET follow these steps for connecting to a device:

1. Connect your HDMI source (such as a Blu-ray Disc player) to Transmitter (HDM-C6IP-S).

2. Connect your HDMI display (such as a LCD TV) to the receiving unit HDM-C6IP-R.

3. Connect your CAT-5E/6 follow the standards of TIA-568BLAN cable between the transmitting and

receiving units.

4. Make sure CAT-5E/6 LAN cable is tightly connected and not loose.

5. Plug in 5V DC power cord to the power jack of the transmitting unit HDM-C6IP-S

6. Plug in 5V DC power cord to the power jack of the receiving unit HDM-C6IP-R.

Section 3: General Troubleshooting

Problem

Possible Solution

No Image

Check if connection to the source and the display are correct.

Ensure that display device supports 480p, 720p and 1080p

resolution

Screen Defects Appear

Check the DVI and HDMI connection

Yellow Light on LAN port flashing

SLOW

Check both units and make sure the TX and RX are not

Reversed

Check the source device is powered ON

Yellow Light on LAN Port flashing

Fast/NO Image

Check Graphics card on PC. This product supports up to 1080p

(1920x1080) resolution.

No Yellow Light on LAN port

Check Network cable only use TIA-568B Standard

Network cable run is out of range

Each Transmitter and Receiver after pairing support only point to point operation. It cannot

support signals broadcasting by HDMI.

Important Before starting the insulation please ensure that all devices are powered OFF

www.avenview.com|7

Section 4: Specifications

Item

Description

Units

HDM3D-C6IP-S

HDM3D-C6IP-R

Unit Description

HDMI 1.3a Transmitter

HDMI 1.3a Receiver

HDMI Compliance

Full HD

HDCP Compliance

Yes

Video Bandwidth

M-JPEG technology to process image compressing GIGABIT (10/1000) OVER LAN

Supported Resolutions

480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz,

1080i@50/60Hz, 1080p@50/60Hz

Resolution and Distance

(24-bit)

Full HD: (1080p)-95meter (295feet) (CAT5e) / 100meter (328feet) (CAT6)

Audio Support

Surround Sound (up to 7.1 Ch) or Stereo Digital Audio

IR Pass-thru

RS-232 Support

Input

1x HDMI

1x RJ45

Output

1x RJ45

1x HDMI + 1x 3.5mm

HDMI Connector

Type A (19 pin female)

RJ45 Connector

WE/SS 8P8C with 2 LED indicators

Power Adapter

2 X DC 5V/1A

Power Consumption

3W Max Each

Dimension L x W x H

110 x 58 x 26mm (4.3” x 2.2” x 1”)

Weight

245g

Environmental

Operating Temperature

32˚~ 104˚F (0˚to 40˚C)

Storage Temperature

-4˚~ 140˚F (-20˚~ 60˚C)

Relative Humidity

20~90% RH (no condensation)

Performance Guide for HDMI over Category Cable Transmission

Performance rating

Type of category cable

Wiring

Shielding

CAT5

CAT5e

CAT6

Solid

Unshielded (UTP)







Shielded (STP)





Stranded

Unshielded (UTP)





Shielded (STP)





Termination

Please use EIA/TIA-568-B termination (T568B) at any time

www.avenview.com|8

4.1 PIN & Wiring Standard Definition

Type A (Receptacle) HDMI

Pin 1

TMDS Data2+

Pin 11

TMDS Clock Shield

Pin 2

TMDS Data2 Shield

Pin 12

TMDS Clock–

Pin 3

TMDS Data2–

Pin 13

CEC

Pin 4

TMDS Data1+

Pin 14

Reserved (N.C. on device)

Pin 5

TMDS Data1 Shield

Pin 15

SCL

Pin 6

TMDS Data1–

Pin 16

SDA

Pin 7

TMDS Data0+

Pin 17

DDC/CEC Ground

Pin 8

TMDS Data0 Shield

Pin 18

+5V Power

Pin 9

TMDS Data0–

Pin 19

Hot Plug Detect

Pin 10

TMDS Clock+

www.avenview.com|9

Disclaimer

While every precaution has been taken in the preparation of this document, Avenview Inc. assumes no liability with respect to the

operation or use of Avenview hardware, software or other products and documentation described herein, for any act or omission of

Avenview concerning such products or this documentation, for any interruption of service, loss or interruption of business, loss of

anticipatory profits, or for punitive, incidental or consequential damages in connection with the furnishing, performance, or use of the

Avenview hardware, software, or other products and documentation provided herein.

Avenview Inc. reserves the right to make changes without further notice to a product or system described herein to improve reliability,

function or design. With respect to Avenview products which this document relates, Avenview disclaims all express or implied warranties

regarding such products, including but not limited to, the implied warranties of merchantability, fitness for a particular purpose, and

non-infringement.

Autres manuels pour HDM3D-C53X-SET

Table des matières

Autres manuels Avenview Extenseur

Avenview

Avenview FO-DP-XX-MM Manuel utilisateur

Avenview

Avenview HDM-C6VWIP-SET Manuel utilisateur

Avenview

Avenview DVI-C5-M-SET Manuel utilisateur

Avenview

Avenview HDMI-C5-3-SET Manuel utilisateur

Avenview

Avenview HBT-C6PLT-R Manuel utilisateur

Avenview

Avenview KVM-C5 Series Manuel utilisateur

Avenview

Avenview W-HDM3D-100-SET Manuel utilisateur

Avenview

Avenview HDMI-C5-3X-SET Manuel utilisateur

Avenview

Avenview FO-HDM2-T4K-SET Manuel utilisateur

Avenview

Avenview FO-DVI-DL-330 Series Manuel utilisateur

Avenview

Avenview HBT2-C6POH-USB-SET Manuel utilisateur

Avenview

Avenview VGA-C5A-R Manuel utilisateur

Avenview

Avenview FO-DP-300-EMI Manuel utilisateur

Avenview

Avenview HDM-C5-3X-SET Manuel utilisateur

Avenview

Avenview FO-DVI-1080X-SET Manuel utilisateur

Avenview

Avenview Cat5 Manuel utilisateur

Avenview

Avenview HBT2-C6BPOC-SET Manuel utilisateur

Avenview

Avenview HDM-C5SP-4 Manuel utilisateur

Avenview

Avenview HDM3D-C53X-SET Manuel utilisateur

Avenview

Avenview FO-HDMI-XX-MM Manuel utilisateur

Avenview

Avenview FO-VGA-DVI Manuel utilisateur

Avenview

Avenview HDM-SHAREPRO-IP Manuel utilisateur

Avenview

Avenview FO-DVI-1080LC-Set Manuel utilisateur

Avenview

Avenview FO-HDMI-SET Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
