Avenview HDM3D-C5SP-4 Manuel utilisateur

VIDEO WALLS VIDEO PROCESSORS

VIDEO MATRIX SWITCHES

EXTENDERS SPLITTERS WIRELESS

CABLES & ACCESSORIES

AV Connectivity, Distribution And Beyond...

1x4 HDMI Extender / Splitter

Single CAT5 with 3D Support and

Local Output

The contents of this document are provided in connection with Avenview Inc. (“Avenview”) products. Avenview makes no representations or

warranties with respect to the accuracy or completeness of the contents of this publication and reserves the right to make changes to specifications

and product descriptions at any time without notice. No license, whether express, implied, or otherwise, to any intellectual property rights is granted

by this publication. Except as set forth in Avenview Standard Terms and Conditions of Sale, Avenview assumes no liability whatsoever, and disclaims

any express or implied warranty, relating to its products of Avenview Inc. is strictly prohibited.

Model #: HDM3D-C5SP-4

Military Residential

Medical Aviation

Education Industrial

Corporate House Of Worship

www.avenview.com

Product Application & Market Sectors

www.avenview.com Page 3

TABLE OF CONTENTS

1. GETTING STARTED ..........................................................................................................................1

1.1 IMPORTANT SAFEGUARDS..............................................................................................................1

1.2 SAFETY INSTRUCTIONS ..................................................................................................................1

1.3 REGULATORY NOTICES FEDERAL COMMUNICATIONS COMMISSION (FCC) ........................... 2

2. INTRODUCTION ..............................................................................................................................3

2.1 PACKAGE CONTENTS .....................................................................................................................3

2.2 BEFORE INSTALLATION...................................................................................................................4

2.3 PANEL DESCRIPTION.......................................................................................................................5

2.3.1 Front Panel .................................................................................................................................5

2.3.2 Rear Panel...................................................................................................................................5

2.3.3 Bottom Panel..............................................................................................................................5

3. EDID LEARNING ...............................................................................................................................6

4. INSTALLATION..................................................................................................................................6

5. GENERAL TROUBLESHOOTING.....................................................................................................7

5. SPECIFICATIONS ...............................................................................................................................8

6. HDMI PIN DEFINITION ....................................................................................................................9

www.avenview.com Page 1

SECTION 1: GETTING STARTED

1.1 IMPORTANT SAFEGUARDS

Please read all of these instructions carefully before you use the device. Save this manual for future reference.

What the warranty does not cover

•Any product, on which the serial number has been defaced, modified or removed.

•Damage, deterioration or malfunction resulting from:

•Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product modification, or failure to

follow instructions supplied with the product.

•Repair or attempted repair by anyone not authorized by us.

•Any damage of the product due to shipment.

•Removal or installation of the product.

•Causes external to the product, such as electric power fluctuation or failure.

•Use of supplies or parts not meeting our specifications.

•Normal wear and tear.

•Any other causes which does not relate to a product defect.

•Removal, installation, and set-up service charges.

1.2 SAFETY INSTRUCTIONS

The Avenview HDM3D-C5SP-4 HDMI Extender / Splitter over CAT5 with Full 3D Support has been tested for conformance to

safety regulations and requirements, and has been certified for international use. However, like all electronic equipment’s, the

HDM3D-C5SP-4 should be used with care. Read the following safety instructions to protect yourself from possible injury and to

minimize the risk of damage to the unit.

!Do not dismantle the housing or modify the module.

!Dismantling the housing or modifying the module may result in electrical shock or burn.

!Refer all servicing to qualified service personnel.

!Do not attempt to service this product yourself as opening or removing housing may expose you to dangerous voltage

or other hazards

!Keep the module away from liquids.

!Spillage into the housing may result in fire, electrical shock, or equipment damage. If an object or liquid falls or spills on

to the housing, unplug the module immediately.

!Have the module checked by a qualified service engineer before using it again.

!Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before cleaning.

1. GETTING STARTED

www.avenview.com Page 2

1.3 REGULATORY NOTICES FEDERAL COMMUNICATIONS COMMISSION (FCC)

This equipment has been tested and found to comply with Part 15 of the FCC rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation.

Any changes or modifications made to this equipment may void the user’s authority to operate this equipment.

Warning symbols Description

ONLY USE THE PROVIDED POWER CABLE OR POWER

ADAPTER SUPPLIED. DO NOT TAMPER WITH THE

ELECTRICAL PARTS. THIS MAY RESULT IN ELECTRICAL

SHOCK OR BURN.

DO NOT TAMPER WITH THE UNIT. DOING SO WILL

VOID THE WARRANTY AND CONTINUED USE OF THE

PRODUCT.

THE VIDEO BOARDS ARE VERY SENSITIVE TO STATIC.

PLEASE ENSURE IF RACK MOUNTED OR INSTALLED ON A

SURFACE, IT SHOULD BE IN A GROUNDED ENVIROMENT.

www.avenview.com Page 3

2. INTRODUCTION

The Avenview HDM3D-C5SP-4 HDMI over Single CAT5 with Full 3D Support Distribution Amplifier with Local Output provides

the most flexible solution by which the high definition video and high quality audio can be transmitted to different locations over

a long distance. These devices can cascade, allowing you to extend HDMI compliant displays almost anywhere. The input HDMI

source can be duplicated and distributed to up to 4 HDMI enable displays through cost effective Cat-5/6 cables and RJ-45 to

HDMI mini-extenders HDM3D-C5-R-M or Long Range HDM-C53X-R aka HDM3D-C53X-R. With the built in equalization, the

input HDMI cable can be extended up to 20 meters (66 feet) long under Full HD, and make the overall transmission distance

superior than regular HDMI splitters or matrix switches in the market. With use of Long Range Receiver, HDMI signal can be

extended to 50 meters (165 feet).

- Supports HDMI Deep Color & Full 3D

- HDMI

- HDCP compliant

- Regenerates the HDMI signal

- HDMI local output

- Supports default HDMI EDID and has the ability to learn the EDID of the displays

- Extends up to 20m (66ft) of input HDMI cable with Mini Receiver

- Extends up to 50m (165ft) (720p / 1080i) of output CAT5/6 cable with Long Range Receiver

- Extends up to 40m (130ft) (1080p) of output CAT5/6 cable with Long Range Receiver

- Pure unaltered uncompressed 7.1ch digital HDMI over LAN cable transmission

- Allows cascading

- Perfectly integrated with other HDM-C5XD Series products

2.1 PACKAGE CONTENTS

Before you start the installation of the Extender/Splitter, please check the package contents.

1HDM3D-C5SP-4 X 1

2POWER ADAPTER (+5VDC, 4A) X1

3USER’S MANUAL X 1

www.avenview.com Page 4

2.2 BEFORE INSTALLATION

•Put the product in an even and stable location. If the product falls down or drops, it may cause an injury or malfunction.

•Don’t place the product in too high temperature (over 50°C), too low temperature (under 0°C) or high humidity.

•Use the DC power adapter with correct specifications. If inappropriate power supply is used then it may cause a fire.

•Do not twist or pull by force ends of the UTP cable. It can cause malfunction.

www.avenview.com Page 5

2.3 PANEL DESCRIPTION

2.3.1 Front Panel

2.3.2 Rear Panel

2.3.3 Bottom Panel

1. Power LED 2. Signal LED

3. Power Jack 4. HDMI Input

5. HDMI Local Output 6. CAT 5/6/7 Output 1 – 4

7. SW1: EDID Mode 8. SW2: EDID – Full HD Selection

9. SW3: EDID – Audio Selection 10. SW4: 3D/2D Selection

3 4 5 6

www.avenview.com Page 6

3. EDID LEARNING

1. Power up the HDM3D-C5SP-4. Connect to HDMI OUTPUT with the display you want the HDM3D-C5SP-4 to learn

its EDID.

2. To learn the display’s EDID for source device connected to HDMI OUTPUT, Set SW1 to left Position. Power on and

wait for about 2-3 seconds to complete the EDID learning process; the users do not need to power cycle again or even

twice while plugging on different displays.

Left Position Right Position

SW1 DEFAULT EDID EDID LEARNING

SW2 FULL HD HD

SW3 AUDIO-MULTI CHANNEL AUDIO – 2 CHANNEL

SW4 3D 2D

- The instant switching is enabled only when the video and audio setting of the source has been adjusted to

“Auto” or “Pass Through”

4. INSTALLATION

To setup Avenview HDM3D-C5SP-4 follow these steps for connecting to a device:

1. Turn off all devices including monitors / TV

2. Connect to a HDMI source (such as a Blu-Ray Disc player) to HDMI Input of HDM3D-C5SP-4

3. Connect the receiver HDM-C53X-R or HDM-C5-R-M to HDM3D-C5SP-4 from RJ45 Out with CAT5 / CAT6 cable

4. Plug in 5V 4A DC Power (supplied).

5. Power on the HDMI display

6. Power on HDMI Sources.

www.avenview.com Page 7

5. GENERAL TROUBLESHOOTING

PROBLEM POSSIBLE SOLUTION

NO IMAGE •Check if connection to the source and the display are correct.

•Ensure that display device supports 480p, 720p and 1080p resolution

SCREEN DEFECTS

APPEAR

•This product supports up to 1080p resolution.

•Check the HDMI connection

•If outputting from a PC. Check the maximum resolution range of the graphics card.

EQUALIZER SET-

TINGS

•Please check the RX (Receiver) Dial Mode to ensure it is on Min or gradually increase

it to Max until the video appears.

WARNING

Do Not Over Power The Eq Signal Strength

When Adjusting The Eq Please Ensure A Slow Clockwise

Turn From Min-Max

Stop Once The Picture/Audio Is Working Properly

Do Not Continue To Turn Dial.

Persistance Will Cause An Over Power Condition Of The Signal

And May Affect Long Term Reliability.

Thank You.
