Advantech PWS 472 Manuel utilisateur

PWS 472

Product manual

Operation manual

Version 1.0

Ⅰ

Matters needing attention

Battery precautions

Battery life depends on the type of battery and how it is used. The

battery life can be extended by avoiding the battery in a state that is

completely electrically powered, which is prone to damage the battery.

A few full discharges are more damaging than often charging the

batteries. Charging a part of the battery does not damage the battery,

because lithium batteries have no memory function. Keep the batteries

in a cool state and avoid overheating. If you want to place a long time,

make the battery charge at about 40% percent. Avoid the battery long

time completely no electricity or long time placement, because the

battery power will be exhausted, the resulting damage will make it more

life than normal use of battery life shortened by half.

Battery charging considerations

The ambient temperature has a great relationship to the lithium

battery charging, and the battery charging efficiency is the highest in

ambient or slightly cooler temperature. Charging the battery between

10 ℃ to 45 ℃, exceeding this range of charging may cause damage to

the battery and shorten its service life.

Note: Do not charge the battery in the temperature environment below

0 ℃ because it increases the internal resistance of the battery and

increases the heat of the battery so that the battery is unstable and

unsafe. Please use the battery temperature test charging device to

ensure that the charging is carried out within a safe temperature range.

In addition, in order to protect the batteries, avoid swelling, please

use battery thermal protection to ensure that batteries will not charge

at temperatures exceeding 50 ℃.

Storage and security considerations

Rechargeable lithium Batteries If they are not used for a few months, the battery's

power will be exhausted by the depletion of the internal resistance. If this happens,

fill the battery with electricity before you use it. The storage temperature of lithium

batteries is between-20 ℃ to 60 ℃, the higher the storage temperature, the faster the

battery consumption, so it is best to store the batteries below room temperature.

Laser safety precautions

Do not direct the laser line to the naked eye to prevent damage.

Catalog

Matters needing

atten

tion...........................................................

................Ⅰ

1. Parts ................................................................................................... 1

2. Introduction......................................................................................... 1

2.1 Product overview..................................................................... 2

2.2 SIM card and SD card installation.................................... 3

2.3 Battery charging..................................................................... 3

2.4 Data transfers between PC.................................................... 4

2.5 Check the battery and enter the power use menu........... 4

3. Basic operation ............................................................................... 6

3.1 Application program............................................................... 6

3.2 Barcode scanner...............................................................9

3.3 WiFi Roam ........................................................................... 9

3.4 RFID Sensing........................................................................... 10

4. Product specification ................................................................. 11

PWS 472 terminal USB Connecting line

(Standard USB to Micro USB)

Power adapter

Battery

Wristband

1. Parts

2. Introduction

PWS-472 based on Android development, with four core processors and

5-inch high-resolution screen, the use of industrial grade design and

development with waterproof, dustproof, anti-fall, can replace the large

capacity batteries, with more than 8 hours of endurance. At the same

time support GPS/Beidou, RFID (NFC), 1D/2D barcode scanning and other

functions. PWS-472 can be widely used in medical, retail, warehouses,

factories and electricity, land, surveying, forestry and other

industries.

2.1

Product overview

1. Main screen 7. Microphone

2. Push-button 8. Scan engine

3. Power button 9. Camera

4. Scan button 10. Fill-in light

5. Receiver 11. Battery cover 13. Back cover screw

6. LED lamp 12. Speaker

08. Scan window 14. MicroUSB Interface

2.2

SIM

card

and

card

installation

Assembly of batteries, SD cards and SIM cards

1. Use a screwdriver counterclockwise to loosen the two screws on the

battery lid.

2. Open the rear cover and remove the battery。

3. You can now use the Micro SD card slot and the SIM card slot.

（SIM card support Mobile/Unicom 4G）

4.Insert SIM/SD Card

SIM/SD card metal contact face downward, referring to the fuselage card

slot insert diagram, along the SIM/SD card groove to push into the

smooth.

SIM Card

micro SD Card

2.3

Battery charging

1. Connect the device's USB connector to the charger。

（Note: Battery charging temperature 0 ° C to 40 ° C）

2. Connect the micro USB connector on the other end of the connector

to the micro USB port at the bottom of the device.

3. Plug the AC charger into the power outlet.

2.4 Data transfers between PC

1. Connect a standard USB connector to the PC's USB port.

2. Connect the micro USB connector in the connector to the micro USB port

at the bottom of the device.

3. To make it easier to synchronize with your PC, you can download mobile

management software from the Android Market.

2.5Check the battery and enter the power use menu

1 On the main screen, click the button.

2Enter settings

3 Select battery.

Basic operation

3.1 Application program

How do I open the application

interface?

On the main screen, click button

can.

How to connect WiFi, BT?

Click "Settings"-"WLAN" in your application to open WiFi and select the

network you want to connect to. In the application, tap Settings-Bluetooth

to open Bluetooth, and then select the device that you want to connect to

the pairing.

How do I create a shortcut to an

application on the main screen?

1 On the main screen, click button.

2 Touch selects an app icon press and hold, and then open the main screen.

3 Drag the icon to the main screen page you want, and then loosen your finger.

How do I change the system language

of a device?

Click Settings in the Application-language and IME-language to select the

system language, supported languages are English, Simplified Chinese,

Traditional Chinese, Japanese, Spanish, German, French, and so on.

Call function

Call Processing/dial-up call

1 On the main screen，click dial

button.

2 Select dial interface

3 Enter the phone number for the listener, and then click the call. To

remove a number, click the Delete button.

Hang up

• Click Hook button.
