Zortrax M200 Manuel utilisateur

MANUAL

ENTER AN ENVIRONMENT OF

PROFESSIONAL 3D PRINTING

CONTENTS

INTRODUCTION

Thank you for choosing Zortrax M200®

SAFETY

Before you start working with Zortrax M200®

read safety tips

ZORTRAX M200

In the box

Filaments

PREPARATION FOR FIRST USE

Prepare your printer to work

Loading lament

Auto-calibration

SOFTWARE&FIRMWARE

Z-Firmware™ update

Z-Suite® software installation

PRINTING

Start printing

Removing print

Removing support

SUPPORT & MAINTENANCE

Periodic maintenance

Changing the lament

Cleaning the nozzle

Cleaning the platform

Straightening perforated plate

Drive belts maintenance

Drive pulleys maintenance

Lubricating

Extruder maintenance

TROUBLESHOOTING

DICTIONARY

SPECIFICATIONS

Thank you for choosing Zortrax M200®

Zortrax M200® manual allow you to easily and securely install and

congure our product. Keep it in a safe place so you can use it if

needed.

In the Contents you will nd a description of the solutions used

in Zortrax M200® 3D printer. To use current software version,

download latest updates from www.zortrax.com

Lear more about all Zortrax® products. Contact us via email

[email protected]om or go to www.zortrax.com

Information given in all Zortrax® documents and help system

related to this software may change without prior notice. No part

of this manual may be copied, sent over, stored in an information

retrieval systems or translated to any language in any way using any

media (electronic, mechanical, photocopying, recording or other)

without the written permission of Zortrax sp. z o.o.

Zortrax® company may possess patents, copyright, trademarks

and other intellectual property rights for content and documents.

Transmission of this document and other documents is not

tantamount to granting a license to this patents, copyrights,

trademarks and other intellectual property, unless it was explicitly

stated in the written license given by Zortrax sp. z o.o.

INTRODUCTION

Before you start working with Zortrax M200® read safety tips:

• Never touch the model, hotend or platform during printing

process – there is a risk of burns and deformation of model.

Remember to always wait until the printer parts cool down

(~30min.).

• Stay away from workspace during printing process – do not put

hands or any other parts of your body inside the workspace - it

may cause burns and printer damage.

• Always use safety gloves when removing the platform.

• Wear safety glasses when removing the model from the

platform.

• Never touch heated extruder – even with safety gloves.

SAFETY

Caution – these actions may harm you if you won’t follow the instruction.

Wear safety glasses - risk of injury to eyes.

Wear safety gloves - risk of burns.

SAFETY SIGNS USED IN THIS TEXT:

ZORTRAX M200

3D printing is a technology for industry and design.

Using 3D printer in technical and design studios

lowers the costs of prototyping.

The integration of key elements of the printer -

dedicated Z-Suite® software and composition of

the Z-Filaments™ let us create new 3D printing

technology – Layer Plastic Deposition (LPD™). With

LPD™ technology you can create precisely projected

model. Precise layered process of the lament

application makes printed elements suitable for

prototyping models in molding technology.

Zortrax M200®

3D Printer

Filament Spool

Holder Filament Guide Filament

Spool

Build

Platform Power Cable

SD Card

SD Card Reader

Z-Suite®*

Quick Start Guide

Safety

Gloves

Cutting Knife

Scalpel

Allen Keys

Nozzle Key

Nozzle Needle

Pliers

Spatula

Tweezers

Service Grease Safety Glasses

* online

IN THE BOX

Extruder Extruder Cable

Filament

Guide

Power Connector

and Switch

Build Platform Display

Z Axis Screw Control

Knob

Filament Mount

HotendFilament

OVERVIEW

PRINTING MATERIALS OVERVIEW

For Zortrax M200® we use high quality thermoplastic material –

laments. All our materials have carefully selected composition and

properties. We advise you to print with dedicated laments only.

Only Z-Filaments™ guarantee safe and high quality prints.

USING OTHER FILAMENTS THAT DEDICATED

Unlike inkjet printers, printing materials for 3D printers need to be

prepared strictly for a particular model of the machine. Filaments

from all manufacturers have dierent physical and chemical

properties, even at similar terminology.

Using laments from dierent manufacturers you risk printing

problems and extruder clogging – even if you use high quality

laments. Zortrax M200® is adjusted to work with Z-Filaments™

only. Only Z-Filaments™ guarantee safely and trouble-free operation

of your printer. Using laments from other store, than Zortrax

Store, you automatically loose Z-Care 1-st Year Service Program™.

To buy dedicated laments please go to www.zortrax.com/store

* available soon

MATERIAL PROPERTIES

Z-ABS™ Suitable for mechanical

treatment High printing precision Available in a wide range of

colors Suitable for utility models

Z-ULTRAT™ Suitable for mechanical

treatment Durable High quality prints Suitable for large prints

Z-FLEX™*Suitable for mechanical

treatment Elastic Models are exible and elastic For malleable models e.g. seals

Z-PCABS™*Resistant to cracking Highly durable Resistant to high temperature Used for automotive parts

Z-GLASS™*Suitable for mechanical

treatment Fragile Transparent Used for decorative parts

Z-ALU™*Suitable for mechanical

treatment Fragile Unique texture of prints Imitates metal

Z-NYLON™*Elastic, extensile Highly durable Bendable For elements subjected to load

PRINTING MATERIALS OVERVIEW
