Zortrax M200 Manuel d'utilisation

Maintenance Guide

SOURCE:

https://support.zortrax.com/m200-maintenance-guide/

Table Of Content

Main 3

Hotend 4

Platform 5

X/Y Axes; Extruder Guide Rails 6

Extruder 7

Z axis 8

Lifespan of particular components 9

Main

ACTIVITY FREQUENCY

Cleaning the machine, its interior and

surroundings, especially the bottom plate

under the platform

Before each

printing

Cleaning the motherboard and the power

supply unit from dust using compressed air Every 300

working hours

Hotend

ACTIVITY FREQUENCY

Checking if the hotend and the nozzle are

not clogged Before each

printing process

Cleaning the nozzle After finishing

one spool of

material

Checking if the screws that secure the

heater and thermocouple are tightened Every 300

working hours

Platform

ACTIVITY FREQUENCY

Cleaning the perforated plate Before each

printing process

Checking the perforated plate for

deformation Before each

printing process

Calibration Every 200

working hours

Cleaning the heatbed and the underside of

the perforated plate Every 300

working hours

X/Y Axes; Extruder Guide Rails

ACTIVITY FREQUENCY

Checking if the axes and the extruder guide

rails are clean from material remains and

dust

Before each

printing process

Checking the tension of the drive belts on

the X/Y axes Every 300

working hours

Checking the tension of the drive belts

between the motors and the X/Y axes Every 300

working hours

Checking if the screws on the X/Y axes and

the motor pulleys are tightened Every 300

working hours

Checking if the extruder moves freely when

the printer is off Every 300

working hours

Lubricating the X/Y axes and the extruder

guide rails Every 200

working hours

Extruder

ACTIVITY FREQUENCY

Checking if the extruder top cover and the

material guide are properly installed Before each start-

up of the printer

Checking if the material guide is properly

secured to the extruder cable with the

material guide clamps

Before each start-

up of the printer

If you use the HEPA Cover, check if it does

not press the extruder cable Before each start-

up of the printer

Checking if the extruder cable is properly

plugged into the extruder PCB Every 300

working hours

Checking if the extruder PCB is properly

secured to the extruder block Every 300

working hours

Checking if the pins on the extruder cable

connector are clean Every 300

working hours

Checking if the screws that secure the

hotend are not loose, and, if necessary,

tightening them

Every 300

working hours

Removing the material remains and lumps

from the extruder Every 300

working hours

Checking if the fans are working Every 300

working hours

Z axis

ACTIVITY FREQUENCY

Checking if the Z-axis screw and rails are

clean from material remains Before each

printing

Lubricating the Z-axis screw and rails Every 400

working hours

Lifespan of particular components

The table shows an approximate lifespan of parts that are exposed to natural wear and

tear. In order to maintain the printer in good condition and to provide the highest priting

quality, it’s advisable to replace particular components after an appropriate period of

time indicated in the table.

NOTE! The lifespan of particular components highly depends on the type of

filaments you use most often.

Nozzle Hotend Perforated

Plate v2 Extruder

Cable Heater and T

hermocoupleExtruder

Fans 40×40

Every 250

working hoursEvery 350

working hoursEvery 700

working hoursEvery 500

working hours

(when using

Extruder

Printed Cover

v2)

Every 400

working hoursEvery 500

working hours
