ZALMAN CNPS9500 AT Manuel utilisateur

User’s Manual

CNPS9500 AT

www.ZALMAN.com

V 2.0

To ensure safe and easy installation,

please read the following precautions.

Intel Socket 1156/775 CPU

Core i7

Core i5

Core 2 Quad

Core 2 Duo

Core 2 Extreme

Dual Core Pentium

Pentium D

Pentium 4

Celeron D

.COM

1. Precautions

2. Speciﬁcations

Model

Spec. CNPS9500 AT

Material Pure Copper

Weight 530g

Dimensions 85(L) Ⅹ112(W) Ⅹ125(H)㎜

Fan

Bearing-type 2 Ball-Bearing

RPM 1,300rpm ±30% ~ 2,650rpm ±10%

Noise Level 18.0dBA ±10% ~ 27.5dBA ±10%

Input Voltage 12V

Fan Function PWM Control, Auto Restart

1) Use and keep product away from reach of children and pets.

2) Do not ingest the Thermal Grease, and avoid its contact with skin and

eyes. If contact is made with skin, wash off with water. If ingested or

irritation persists, seek medical attention.

3) To prevent possible injuries, gloves must be worn while handling this

product.

4) Excessive force exerted on the fan may cause damage to the fan and/

or system.

5) Avoid inserting objects or hands into the fan while it is in operation to

prevent product damage and injuries.

6) Check the components list and condition of the product before

installation. If any problem is found, contact the retailer to obtain a

replacement.

7) Zalman Tech Co., Ltd. is not responsible for any damages due to

overclocking.

8) During transportation of the system, the cooler must be removed.

Zalman is not responsible for any damages that occur during the

transport of a system.

9) Product design and speciﬁcations may be revised to improve quality

and performance.

Disclaimer) Zalman Tech Co., Ltd. is not responsible for any damages due

to external causes, including but not limited to, improper use,

problems with electrical power, accident, neglect, alteration,

repair, improper installation, or improper testing.

.COM

3. Components

User’s Manual

WashersClip Support Fixing Bolts

Nuts

Clip Support

Clip Clip Fixing Bolts

Cooler Thermal Grease

.COM

4. Installation Requirements

1) Space Requirements

2) Air Guide Removal

3) Cooler Orientation

The cooler’s installation requires unobstructed space with dimensions of 90㎜

(width), 115㎜(length), 135㎜(height), and the CPU as a central reference point.

Please check if components such as ODDs and PSU protrude into the required

space.

Air guides on enclosures must be removed, before the cooler’s installation, for

they protrude into the cooler’s required space.

It is recommended that the cooler be installed so that air ﬂows from the cooler toward

the enclosure’s rear exhaust fan.

90㎜

135㎜

115㎜

.COM

1) Clip Support Installation

2) Thermal Grease Application

Install the Clip Support to the motherboard according to the Socket-type.

Clear off any particles or residue from the CPU’s surface then spread

(outwards from center) a thorough layer of Thermal Grease on the CPU

and the base of the cooler.

5. Installation

Nut

Washer

Bolt (silver)

Clip Support

M/B

Socket 1156

Socket 775

▶Please make note of the Lever Slot’s direction when

installing the Clip Support.

Caution

.COM

3) Cooler Installation

4) Fan Connector

Insert the Clip Fixing Bolts to the Clip’s Installation Holes and fasten with a

screwdriver.

Connect the Fan Connector to the motherboard’s PWM fan header (4-Pin).

M/B

.COM

GS1000 / GS1000SE

•E-ATX / Standard ATX / microATX Compatible

* Supports Intel Dual Xeon server motherboards

•UP to 6 Hot Swap HDD Bays

* GS1000(3 Standard / 3 Optional)

* GS1000 SE(Optional)

•Tool-Free HDD Installation

•Airﬂow Optimized Design

•Vibration Absorbing HDD Dampers and Feet

•The World’s First Roller Rails for Smooth

& Easy PSU Installation

•Cable Compartment Behind the Motherboard

for Cable Management

•Dedicated Fan Compartment for Fanless PSU Users

•Up to a Total of 8 HDD Bays

* 2 Adaptors & Bezels included for use of two 5.25”bays as 3.5”Internal(HDD)/

External(FDD) Bays

GT1000

•High-End Gaming Enclosure Built with Sturdy

All Aluminum Panels

•Three Tool-Free Hinged Magnetic Panels

(2 Left, 1 Right) for Easy Installation and

Access to Components

•Tool-Free Installation of Disk Drives,

Fan Controlles, Audio Interfaces etc.

•Accommodates up to 6 Hard Drives

•Luxurious and Cool Aesthetics.

•Color Option: Black (Red LED Fans),

Titanium (Blue LED Panel).

For more information, please visit our website.
