Model #: SMART5000TEL3U

SmartPro 5kVA Line Interactive Sine Wave UPS, SNMPWEBCARD option, 3U Rack/Tower, USB, Serial, EPO,

208V

Highlights

5kVA / 5000VA line interactive 3U rack/tower UPS; Sine wave output

208V nominal output during inputs of 174-282V; Supports 600VA 120V output

USB, Serial, EPO & optional SNMP/Web card monitoring options

97% line-mode efficiency; Hot-swappable internal batteries

NEMA L6-30P input; 2 NEMA 5-15R, 2 L6-20R & 1 L6-30R outlets

Description

Tripp Lite's SMART5000TEL3U intelligent, line interactive UPS protects server, networking and telecommunications equipment from blackouts,

voltage fluctuations and surges in a compact rackmount housing. Completely self-contained UPS system occupies only 3 rack spaces (3U) in a

standard 19 inch rack, making this model one of the smallest 5kVA UPS systems available. Included accessories support mounting 4 post rack

enclosures. Large capacity 5000 VA/3750 watt UPS system accepts raw AC input, adjusting output to regulated 208V levels. One pair of 120V

outlets support up to 600VA monitors and other low voltage accessories. Includes slot for internal SNMP/web card, plus 2 DB9 and 2 USB

enhanced monitoring ports for unattended shutdown, remote control and monitoring of UPS system and power data. Five outlets (two L6-20R, one

L6-30R and two 5-15R) allow the connection of high current 20 and 30 amp 208V connectors and up to two 120V devices (max 600VA at 120V).

Package Includes

SMART5000TEL3U UPS System

PowerAlert Software and cabling

Mounting hardware

Instruction manual

Features

Large 5000VA/3750-watt output capacity accommodates solitary large loads or multiple low-power loads

High power density 5kVA power module occupies only 3 rack spaces (3U)

16 minutes half-load runtime (with a continuous load 2500VA; much longer runtime available at smaller loads)

Line-interactive voltage regulation corrects severe brownouts and overvoltages without using battery power

High voltage output supports 208V server, internetworking and telecom applications

Pair of 120V outlets supports up to 600VA for standard 120V monitors, voicemail and other low-power networking devices

Five total outlets (two L6-20R, one L6-30R and two 5-15R)

Diagnostic LEDs provide visual indication of 17 separate performance conditions

Included PowerAlert Software provides e-mail or pager notification of power problems and simultaneous automatic unattended shutdown of

multiple servers

4 built-in communications ports (2 USB/2 DB9) for remote monitoring and unattended shutdown

Slot for SNMP/web card (part#: SNMPWEBCARD) and environmental sensor (part#: ENVIROSENSE) for remote communications in large

IP environments

Emergency Power Off (EPO) interface for emergency shutoff in large facilities

Hot-swappable/user-replaceable batteries allow on-site battery replacement through the front panel without powering off connected

equipment or removing the UPS from the rack

UPS ships fully assembled and ready for installation; no time-consuming user battery connections required

Specifications

OUTPUT

Output Volt Amp Capacity

(VA)

5000

Output kVA capacity (kVA) 5

Output Watt Capacity

(watts)

3750

Output kW capacity 3.8

Output power factor 0.8

Nominal Output Voltage(s)

Supported

120V; 208V

Nominal Voltage details 120V output is limited to 600VA / 450 watts (maximum)

Frequency compatibility 60 Hz

Output voltage regulation

(line mode)

208 & 120V (-6%, +20%)

Output voltage regulation

(Battery mode)

+/- 5%

Built-in UPS output

receptacles

2 5-15R outlet(s); 2 L6-20R outlet(s); 1 L6-30R outlet(s)

Output receptacle details 120V 5-15R outlets are limited to 600VA / 450 watts (maximum)

Output circuit breaker 20A double pole breaker supports L6-20R outlets, 5A breaker supports 5-15R outlets, L6-30R outlet is

unbreakered

Output AC waveform (AC

mode)

Sine wave

Output AC waveform

(battery mode)

Pure Sine wave

INPUT

Rated input current (at

maximum load)

24A

Nominal Input Voltage(s)

Supported

208V AC

UPS input connection type L6-30P

UPS Input cord length (ft.) 10

UPS Input cord length (m) 3

Recommended Electrical

Service

30A 208V

Phase Single-Phase

BATTERY

Full load runtime (minutes) 8.5 min. (3750w)

Half load runtime (minutes) 20 min. (1875w)

DC system voltage (VDC) 48

Battery recharge rate

(included batteries)

Less than 4 hours from 10% to 90%

Replacement battery

cartridge (internal UPS

battery replacement)

RBC94-3U (quantity 3)

Battery Access Front panel battery access door

Battery replacement

description

Hot-swappable, user replaceable batteries

VOLTAGE REGULATION

Voltage regulation

description

Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 167 to 260

Overvoltage correction Input voltages between 228V and 260V are reduced by 12%

Undervoltage correction Input voltages between 167V and 194V are boosted by 12%

LEDS ALARMS & SWITCHES

LED Indicators 5 LEDs indicate line power, battery power, overload, voltage regulation and battery low/replace status

Alarms Audible alarm indicates power-failure, overload and low-battery conditions

Alarm cancel operation Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate

low-battery status

Switches 2 Switches control off/on power status and alarm-cancel/self-test operation

SURGE / NOISE SUPPRESSION

UPS AC suppression joule

rating

1020

UPS AC suppression

response time

Instantaneous

EMI / RFI AC noise

suppression

Yes

PHYSICAL

Installation form factors

supported with included

accessories

4 post 19 inch rackmount

Installation form factors

supported with optional

accessories

2 post rackmount (2POSTRMKITWM); Tower (2-9USTAND)

Primary form factor Rackmount

UPS / Power Module

dimensions in primary form

factor (height x width x

depth / inches)

5.25 x 17.5 x 25

UPS / Power Module

dimensions in primary form

factor (height x width x

depth / cm)

13.3 x 44.4 x 63.5

Rack Height 3U

Secondary form factor Tower (requires 2-9USTAND)

UPS / Power Module weight

(lbs)

143.3

UPS / Power Module weight

(kg)

65.1

UPS Shipping dimensions

(height x width x depth /

inches)

11.2 x 23 x 31.5

UPS Shipping dimensions

(height x width x depth / cm)

28.6 x 58.4 x 80

Shipping weight (lbs) 181.9

Shipping weight (kg) 82.6

Cooling method Fan

UPS housing material Steel

ENVIRONMENTAL

Operating Temperature

Range

+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius

Storage Temperature Range +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius

Relative Humidity 0 to 95%, non-condensing

AC mode BTU / hr. (full

load)

366

COMMUNICATIONS

Communications interface USB; DB9 Serial; EPO (emergency power off); Slot for SNMP/Web interface

Network monitoring port

description

Supports detailed monitoring of UPS and site power conditions

PowerAlert software Included

Communications cable USB and DB9 cabling included

WatchDog compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications

LINE / BATTERY TRANSFER

Transfer time 7 milliseconds (AC to Battery), 1 millisecond (Battery to AC)

Low voltage transfer to

battery power (setpoint)

167

High voltage transfer to

battery power (setpoint)

260

SPECIAL FEATURES

Grounding lug Back panel grounding lug

Cold Start (startup in

battery mode during a

power failure)

Cold-start operation supported

High availability UPS

features

Hot swappable batteries

Green & high efficiency

features

Greater than 95% efficiency - GREEN UPS

CERTIFICATIONS

UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Meets FCC Part 15 Category A (EMI)

WARRANTY

Product Warranty Period

(Worldwide)

2-year warranty, 3 year with registration. Note: registration is required for 3-year warranty.

Connected Equipment

Insurance (U.S., Canada &

Puerto Rico)

$250,000 Ultimate Lifetime Insurance

Related Items

Optional Products

Related Model Description Qty.

SNMPWEBCARD For remote monitoring and control via SNMP, Web, or Telnet. 1

ENVIROSENSE Monitors temperature, humidity and contact-closure inputs. (Requires SNMPWEBCARD

or switched PDU.)

U022-010 10-ft. USB2.0 A/B Gold Device Cable

(A Male to B Male)

DTEL2 Network Surge Suppressor - Essential protection for data and communication lines 1

DCATV Network Surge Suppressor - Essential protection for TV/VCR coaxial lines 1

DNET1 Network Surge Suppressor - Essential protection for data and communication lines 1

WEXT5-5000TEL 5-Year Extended Warranty - For SMART5000TEL3U only 1

2-9USTAND Enables Tower Placement of Rackmount UPS Systems 1

MODBUSCARD For remote monitoring and control via MODBUS protocol 1

2POSTRMKITHD Enables 2-Post Rackmount Installation of 3U and Larger UPS, Transformer and Battery

Pack Components

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3035.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
