Model #: SU1000RTXL2UA

SmartOnline 1kVA On-Line Double-Conversion UPS, 2U Rack/Tower, 100/110/120V NEMA outlets

Highlights

1000VA / 1kVA / 800 watt on-line double-conversion 2U rack/tower UPS

100/110/120V +/-2% output at 50/60Hz, high efficiency economy mode option

Expandable runtime, Hot-swap batteries; 13.5 in / 34.3cm installed depth

USB, RS232 & EPO ports; support for SNMP/WEB card options

Front panel status LEDs with detailed load and battery metering

2 independently switchable output load banks

NEMA 5-15P input; 5-15R outlets

Description

1000VA on-line, double-conversion UPS system for critical server, network and telecommunications equipment. 2U rackmount form factor with an

installed depth of only 13.5 inches. Extended runtime available with optional BP24V15RT2U (limit 1), BP24V28-2U (limit 1) or BP24V70-3U

(multi-pack compatible) external battery packs. Full-time sine wave 100, 110 or 120V output with +/-2% voltage regulation. Online,

double-conversion Uninterruptible Power Supply (UPS) actively converts raw incoming AC power to DC, then re-converts output back to completely

regulated, filtered AC output. Operates continuously without using battery power during brownouts to 65V and overvoltages to 150V. Highly efficient

operation in optional economy mode saves BTU heat output and energy costs. NEMA 5-15P input plug; NEMA 5-15R output receptacles.

Network-grade AC surge and noise suppression. Zero transfer time between AC and battery operation. Network management interfaces support

simultaneous communications via USB port, DB9 serial port and SNMPWEBCARD slot. Built-in DB9 port offers both enhanced RS-232 enabled

monitoring data, plus contact closure monitoring ability. HID-compliant USB interface enables integration with built-in power management and auto

shutdown features of Windows and Mac OS X.Supports simultaneous detailed monitoring of equipment load levels, self-test data and utility power

conditions via all 3 network interfaces. Includes PowerAlert monitoring software and complete cabling. Emergency Power Off (EPO) interface.

Integrated two-bank PDU switching supports load shedding and remote reboot of connected equipment. 3-stage metered current monitoring and

battery charge status LEDs. LED display panel easily rotates for viewing in rackmount or tower configurations. Dataline surge suppression for

dialup, DSL or network Ethernet connection. Utility power and voltage regulation LEDs. Audible alarm. Self-test. Fault-tolerant auto-bypass mode.

4-post rackmount accessories included; 2-9USTAND tower kit and 2POSTRMKITWM 2-post rack & wallmount accessories available.

Field-replaceable, hot-swappable internal batteries and external battery packs. Attractive all-black color scheme. $250,000 connected equipment

insurance;

Package Includes

SU1000RTXL2Ua Online Double-Conversion UPS System

PowerAlert Software and cabling

Mounting hardware for 4 post rack enclosures

Instruction manual

Features

SmartOnline high performance UPS system is ideal for critical voice, data, medical and industrial network applications

True on-line, double-conversion UPS provides perfectly regulated sine wave output within 2% of 100/110/120V (user selectable) under all

usage conditions

Maintains continuous operation through blackouts, voltage fluctuations and surges with zero transfer time

Highly efficient operation in optional economy mode setting, saving BTU heat output and energy costs

Removes harmonic distortion, fast electrical impulses, frequency variations and other hard to solve power problems not addressed by other

UPS types

Corrects line voltage conditions as low as 65V and as high as 150V back to selectable 100/110/120V (+/-2%) values

Standard internal battery set offers 14 minutes runtime at half load (400W) and 4.5 minutes at full load (800W)

Extended runtime available with optional BP24V15RT2U (limit 1), BP24V28-2U (limit 1) or BP24V70-3U (no limit) external battery packs

Some external battery configurations require the use of Tripp Lite's External Battery Configuration Software (see manual)

Compact rackmount form factor installs using only 2 rack spaces (2U) with a maximum installed depth of only 13.5 inches

Ships with all mounting accessories for 4 post rackmount installation

Optional 2POSTRMKITWM enables 2 post rackmount or wallmount installation

Optional 2-9USTAND accessory enables small-footprint upright tower placement

Fault tolerant electronic bypass maintains utility output during a variety of UPS fault conditions

Network interfaces support simultaneous communications via built-in USB, DB9 serial / contact-closure and SNMPWEBCARD slot

HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X

Included PowerAlert UPS monitoring software supports safe unattended shutdown, monitoring and control via local connected servers, plus

any number of additional servers over IP

UPS interface supports on-battery, low-battery, power-restored, AC-voltage, DC-voltage, output current monitoring, battery charge current,

battery capacity, AC line frequency, timed inverter shutoff, activate self-test, load bank output power control and remote reboot, UPS

nominal voltage adjustment and UPS line to battery power voltage set points

Built-in Emergency Power Off (EPO) interface with cable

NEMA 5-15P input plug/NEMA 5-15R output receptacles

Integrated 2 bank switched PDU enables remote outlet management for load shedding or remote reboot of individual devices (each load

bank consists of one outlet)

Front panel LEDs offer current monitoring and battery charge level information

UPS ships fully assembled in full compliance with DOT regulations, no time consuming connection of internal batteries by user required

Single line TEL/DSL or network Ethernet line surge suppression

$250,000 Ultimate Lifetime Insurance

Specifications

OUTPUT

Output Volt Amp

Capacity (VA)

1000

Output kVA capacity

(kVA)

Output Watt Capacity

(watts)

800

Output power factor 0.8

Crest Factor 3:1

Nominal Output

Voltage(s) Supported

100V; 110V; 120V

Nominal Voltage

details

120V default

Frequency

compatibility

50 / 60 Hz

Frequency

compatibility details

Output frequency matches input nominal on startup, defaults to 60 Hz on cold-start

Output voltage

regulation (line mode)

+/- 2%

Output voltage

regulation (Economy

line mode)

+/- 10%

Output voltage

regulation (Battery

mode)

+/- 2%

Built-in UPS output

receptacles

6 5-15R outlet(s)

Built-in controllable

switched load banks

Two switchable single-outlet 5-15R load banks

Output AC waveform

(AC mode)

Sine wave

Output AC waveform

(battery mode)

Pure Sine wave

INPUT

Rated input current

(at maximum load)

8.6A

Nominal Input

Voltage(s) Supported

100V AC; 110V AC; 120V AC

UPS input connection

type

5-15P

Input circuit breaker 15A

UPS Input cord

length (ft.)

UPS Input cord

length (m)

Recommended

Electrical Service

15A 120V

BATTERY

Full load runtime

(minutes)

4.5 min. (800w)

Half load runtime

(minutes)

14 min. (400w)

Expandable battery

runtime

Extended runtime supported via optional external battery packs

External battery pack

compatibility

BP24V15RT2U (limit 1); BP24V28-2U (limit 1); BP24V70-3U (multi-pack compatible)

DC system voltage

(VDC)

Battery recharge rate

(included batteries)

Less than 6 hours from 10% to 80%

Replacement battery

cartridge (internal

UPS battery

replacement)

RBC92-2U

Battery Access Front panel battery access door

Battery replacement

description

Hot-swappable, user replaceable batteries

VOLTAGE REGULATION

Voltage regulation

description

Online, double-conversion power conditioning

Overvoltage

correction

2% output voltage regulation during overvoltages to 150

Undervoltage

correction

2% output voltage regulation during undervoltages to 80

Severe undervoltage

correction

2% output voltage regulation during undervoltages to 65 (under 70% load only)

LEDS ALARMS & SWITCHES

LED Indicators 14 LEDs indicate line power, online mode, economy/bypass mode, on-battery, overload, battery low, replace battery

and fault status information; 4-LED meter displays load and battery charge levels; LED panel rotates for viewing in

rack/tower formats

Alarms Audible alarm indicates UPS startup, power-failure, low-battery, overload, UPS fault and remote shutdown conditions

Alarm cancel

operation

Power-fail alarm can be silenced using alarm-cancel switch

Switches 2 switches control off/on power status and alarm-cancel/self-test operation

SURGE / NOISE SUPPRESSION

UPS AC suppression

joule rating

510

UPS AC suppression

response time

Instantaneous

UPS Dataline

suppression

1 line TEL/DSL (1 in / 1 out); 10/100Base T Ethernet

EMI / RFI AC noise

suppression

Yes

PHYSICAL

Installation form

factors supported

with included

accessories

4 post 19 inch rackmount (mounting rail kit included)

Installation form

factors supported

with optional

accessories

2 post rackmount (2POSTRMKITWM); Wallmount (2POSTRMKITWM); Tower (2-9USTAND)

Primary form factor Rackmount

UPS / Power Module

dimensions in

primary form factor

(height x width x

depth / inches)

3.5 x 17.5 x 13.5

UPS / Power Module

dimensions in

primary form factor

(height x width x

depth / cm)

8.9 x 44.4 x 34.3

Installed whole

system total rack

space height (rack

spaces)

Secondary form factor Tower (requires 2-9USTAND)

UPS / Power Module

weight (lbs)

UPS / Power Module

weight (kg)

13.2

UPS Shipping

dimensions (height x

width x depth / inches)

9.5 x 20 x 24

UPS Shipping

dimensions (height x

width x depth / cm)

24.1 x 50.8 x 61

Shipping weight (lbs) 41

Shipping weight (kg) 18.6

UPS housing material Steel

Cooling method Fan

ENVIRONMENTAL

Operating

Temperature Range

+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius

Storage Temperature

Range

+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius

Relative Humidity 0 to 95%, non-condensing

AC mode BTU / hr.

(full load)

406.4

AC economy mode

BTU / hr. (full load)

173.6

Battery mode BTU /

hr. (full load)

442.8

AC economy mode

efficiency rating

(100% load)

94%

COMMUNICATIONS

Communications

interface

USB (HID enabled); DB9 Serial; Contact closure; EPO (emergency power off); Slot for SNMP/Web interface

Network monitoring

port description

Supports detailed monitoring of UPS and site power conditions; DB9 port supports RS232 and contact closure

communications

PowerAlert software Included

Communications

cable

USB and DB9 cabling included

WatchDog

compatibility

Supports Watchdog application, OS and hard-reboot restart options for remote applications

LINE / BATTERY TRANSFER

Transfer time No transfer time (0 ms.) in online, double-conversion mode

Low voltage transfer

to battery power

(setpoint)

80V (100% load), 65V (

High voltage transfer

to battery power

(setpoint)

150

SPECIAL FEATURES

Cold Start (startup in

battery mode during

a power failure)

Cold-start operation supported

High availability UPS

features

Automatic inverter bypass; Hot swappable batteries

Green & high

efficiency features

High efficiency economy mode operation; Individually controllable load banks; Schedulable daily hours of economy

mode operation

CERTIFICATIONS

UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Meets FCC Part 15 Category B (EMI)

WARRANTY

Product Warranty

Period (Worldwide)

2-year limited warranty

Connected

Equipment Insurance

(U.S., Canada &

Puerto Rico)

$250,000 Ultimate Lifetime Insurance

Related Items

Optional Products

Product Type Related Model Description Qty.

Extended Warranties WEXT3-500-1500 3-Year Extended Warranty - For Smart Line-Interactive and Online

Tower or Rack models, 1500VA or less

Extended Warranties WEXT5-500-1500 5-Year Extended Warranty - For Smart Line-Interactive and Online

Tower or Rack models, 1500VA or less

External Battery Packs BP24V15RT2U BP24V15RT2U - External Battery Pack for UPS System 1

External Battery Packs BP24V28-2U BP24V28-2U - External Battery Pack for UPS System 1

External Battery Packs BP24V70-3U BP24V70-3U - External Battery Pack for UPS System 1

Power Distribution PDUB15 Dual source Power Distribution Unit / PDU with Manual Transfer Switch

enables Hot-swappable UPS Replacement in Critical Network

Applications

Power Distribution PDUMH15AT Metered PDU with ATS - Power Distribution Unit with dual-input Auto

Transfer Switching

Power Distribution PDUMNV15 Monitored PDU / Power Distribution Unit supports real-time remote

monitoring of load level, voltage and frequency with options for remote

environmental and security monitoring

Power Distribution PDUMV15 Metered PDU / Power Distribution Unit - Safe, reliable power

distribution with digital current meter

Power Distribution PDUMV15NET Switched, Metered PDU with Remote Monitoring - 0U Vertical

Rackmount Power Distribution Unit for Networks with Individually

Switchable Outlets, Current Metering, Remote Monitoring and Control

Rackmount/Wallmount Kits 2POSTRMKITWM Enables 2-Post Rackmount or Wallmount Installation of Select

Rackmount UPS Systems

Shutdown Cable Kits AS400CABLE KIT Power Management Tools - UPS Communication Cable Kit for System

i / AS400 / iSeries Servers

SNMP Accessories ENVIROSENSE Monitors temperature, humidity and contact-closure inputs. (Requires

SNMPWEBCARD or switched PDU.)

SNMP Accessories SNMPWEBCARD For remote monitoring and control via SNMP, Web, or Telnet. 1

SNMP Accessories SRSWITCH Magnetic Door Switch Kit for front and rear doors; requires

ENVIROSENSE

Tower Stands 2-9USTAND Enables Tower Placement of Rackmount UPS Systems 1

UPS Accessories MODBUSCARD For remote monitoring and control via MODBUS protocol 1

UPS Accessories RELAYIOCARD Programmable Relay I/O Card 1

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=2948.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.

Table des matières

Autres manuels Tripp Lite UPS

Tripp Lite

Tripp Lite Medical Grade UPS Systems SMX & OMNIX Manuel utilisateur

Tripp Lite

Tripp Lite SmartPro SMART700 Manuel utilisateur

Tripp Lite

Tripp Lite SmartOnline SU1000XLCD Manuel utilisateur

Tripp Lite

Tripp Lite SM550UNAFTA Manuel utilisateur

Tripp Lite

Tripp Lite SmartPro Series Manuel utilisateur

Tripp Lite

Tripp Lite 120V Input Manuel utilisateur

Tripp Lite

Tripp Lite UPS System AVRX550U Manuel utilisateur

Tripp Lite

Tripp Lite Power Suppy Manuel utilisateur

Tripp Lite

Tripp Lite SU20KRTHWTFASSM Manuel utilisateur

Tripp Lite

Tripp Lite SmartOnline SU750XL Manuel utilisateur

Tripp Lite

Tripp Lite VoIP and Internet Telephony Applications Mode d’emploi

Tripp Lite

Tripp Lite SmartPro SMART3000RMOD2U Manuel utilisateur

Tripp Lite

Tripp Lite Internet Office INTERNET750U Manuel utilisateur

Tripp Lite

Tripp Lite INTERNETOFFICE300 Manuel utilisateur

Tripp Lite

Tripp Lite TM500 Manuel utilisateur

Tripp Lite

Tripp Lite INTERNET OFFICE 350 Manuel utilisateur

Tripp Lite

Tripp Lite SmartPro SMART1500SLTXL Manuel utilisateur

Tripp Lite

Tripp Lite BC Internet Manuel utilisateur

Tripp Lite

Tripp Lite OMNI750ISO Manuel utilisateur

Tripp Lite

Tripp Lite SMART700DV Manuel utilisateur

Tripp Lite

Tripp Lite ECO Series Manuel utilisateur

Tripp Lite

Tripp Lite INTERNET550U Manuel utilisateur

Tripp Lite

Tripp Lite OmniSmart OMNI900LCD Manuel utilisateur

Tripp Lite

Tripp Lite OmniPro 675 Manuel utilisateur

Manuels UPS populaires d'autres marques

Pylontech

Pylontech Victron & Pylontech US5000 Manuel utilisateur

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manuel utilisateur

Mecer

Mecer ME-1000-WTU Manuel utilisateur

Mustek

Mustek PowerMust 530(B) Plus Manuel d'installation et d'exploitation

Emerson

Emerson Liebert NXL series Manuel utilisateur

MAKELSAN

MAKELSAN BOXER SERIES Manuel utilisateur

Block

Block PC-0524-400-0 Manuel utilisateur

CyberPower

CyberPower CP585LCD Manuel utilisateur

Eaton

Eaton 3S Instructions de montage

CyberPower

CyberPower Office Tower Series UPS 1000 Manuel utilisateur

CyberPower

CyberPower BM100 Manuel utilisateur

Best Power

Best Power 610 Manuel utilisateur

Best Power

Best Power Unity/I UT3K Manuel utilisateur

Mustek

Mustek PowerMust 400 Offline Manuel utilisateur

Xantrex

Xantrex Trace 512 UR-UPS Manuel utilisateur

Forza

Forza SL-1501UL Manuel utilisateur

LEGRAND

LEGRAND keor 310081 Manuel utilisateur

ABB

ABB Conceptpower DPA 500 Manuel utilisateur
