Tripp Lite IO700NAFTA Manuel utilisateur

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: IO700NAFTA

Internet Office UPS System - NAFTA assembled version of the all-in-one SOHO solution

Highlights

700VA tower UPS

Maintains 120V nominal output during blackouts

Workstation optimized features include USB port, single line TEL / DSL line

surge suppression and three surge-only outlets

Space saving right-angle input plug

Input: NEMA 5-15P (120V 15A) / Output: 6 NEMA 5-15R (120V)

2 year product warranty / $150,000 Ultimate Lifetime Insurance (USA, Puerto

Rico & Canada only)

Description

Tripp Lite's IO700NAFTA standby UPS system offers surge suppression and long-lasting battery support for personal computers, internetworking

equipment and other sensitive electronics. Internal UPS circuits support entry-level PC systems for up to 45 minutes during power failures and

brownouts so that connected equipment can be shut down without data loss. Offers complete desktop power protection in an attractive gray tower

configuration. Includes 3 battery-supported outlets for computer, monitor and one vital system peripheral, plus 3 additional surge suppression-only

outlets for printers and other system accessories not requiring battery support. HID-compliant USB port enables optional unattended system

shutdown without data loss in the case of extended power failure; USB cable included. HID compliant USB port enables integration with built-in

power management and auto shutdown features of Windows and Mac OS X. PowerAlert software available via FREE download from

es.tripplite.com. Built-in RJ45 TEL/Ethernet suppression jacks protect modem, fax machine, cordless phone or other peripheral with a standard

single-line tel/DSL or data line connection. Built-in audible alarm and 3 front panel LEDs indicate line power status, battery power status and battery

low/replace status. 700VA/425W power handling ability supports entry-level PCs, network workstations, point-of-sale equipment, small business

phone systems, audio/video equipment and home theater systems. Offers 3 min. battery runtime with a full load of 700VA and 11 min. with a half

load of 350VA. Supports user battery replacement via built-in access panel. 2-year warranty. $150,000 connected equipment insurance (USA &

Canada only).

Applications

Entry-level PCs, networked workstations, point-of-sale equipment, small business phone systems, audio/video equipment and home theater systems.

Package Includes

IO700NAFTA Standby UPS System

USB and phone cable

Instruction manual with warranty information

Features

IO700NAFTA standby UPS system offers UPS battery support, plus complete AC and tel/DSL line surge suppression

Supports entry-level PC systems for up to 45 min. during brownouts and power failures to enable a safe system shutdown

Supports a max load of 700VA/425W for 3 min.

Supports a half load of 350VA/215W for 11 min.

Supplies battery-derived AC output during brownouts starting at 99V, user adjustment allows fine tuning of brownout response to any setting

from 83V to 99V

Attractive gray tower configuration

Includes 3 battery-supported outlets plus 3 additional surge suppression-only outlets, and 6-ft. AC line cord (all NEMA 5-15)

HID-compliant USB port enables unattended shutdown without data loss during extended power failures; includes USB cable

HID-compliant USB port enables integration with built-in power management and auto shutdown features of Windows and Mac OS X

USB interface supports timed inverter shutoff after unattended shutdown

PowerAlert software available via FREE download from es.tripplite.com

Supports Tripp Lite's WatchDog software application to restore unresponsive programs by automatically restarting them, and rebooting

completely locked computers by automatically switching UPS power off and back on again

Built-in phone/Ethernet suppression jacks protect modem, fax machine or other peripheral with a dialup,DSL, or data line connection

Built-in audible alarm and 3 front panel LEDs indicate line power, battery power and battery low/replace status

700VA/425W power handling ability supports a variety of computer, internetworking, telecom and consumer electronics equipment

Supports hot-swap battery replacement via built-in access panel

Compatible with 120V/60Hz applications for USA, Canada, Mexico and more

2-year manufacturer's warranty

$150,000 connected equipment insurance (USA & Canada only)

Specifications

SYSTEM OVERVIEW

Voltage compatibility 120V AC

Frequency

compatibility

60Hz

OUTPUT

Output VA 700

Output watts 425

Output nominal

voltage

120V AC

Output voltage

regulation

BATTERY MODE: PWM sine wave output 120V +/-5%

Output frequency

regulation

LINE MODE: Passes line frequency of 60Hz +/-10%

Outlet quantity / type 6 NEMA 5-15R

INPUT

Maximum input

amps

12A / 1440 watts

Input connection

type

NEMA 5-15P

Input cord length 6 ft., 14 gauge

Recommended

Electrical Service

15A 120V

BATTERY

Full load runtime 3 minutes (700VA)

Half load runtime 11 minutes (350VA)

DC system voltage 12V DC

Typical battery

lifespan

3-6 years, depending on usage

Battery recharge rate 2-4 hours to 90%

Replacement

Battery Cartridge

RBC51

LEDS ALARMS & SWITCHES

Front panel LEDs 3 front panel LEDs indicate line power status, battery power status and battery low/replace status

Alarms Audible alarm with 15-second delay sounds to indicate loss of utility power. Alarm can be silenced by pressing front

panel alarm cancel button. Once silenced, alarm will re-sound when approximately 2 minutes runtime remain.

Switches Includes 2 front panel switchesâone main on/off power switch and one dual function "alarm cancel" / "self test" button

SURGE / NOISE SUPPRESSION

AC surge

suppression

510 joules

AC suppression

response time

Instantaneous

Dataline suppression Tel/DSL/Ethernet

EMI / RFI AC noise

suppression

Yes

PHYSICAL

Shipping weight (lbs) 21

Shipping weight (kg) 9.5

Shipping

Dimensions

(HWD/in)

14 x 8.5 x 10.5

Shipping

Dimensions

(HWD/cm)

35.56 x 21.6 x 26.7

Unit weight (lbs) 19

Unit weight (kg) 8.6

Unit Dimensions

(HWD/in)

10.75 x 5.25 x 7.25

Unit Dimensions

(HWD/cm)

27.3 x 13.3 x 18.4

Material of

construction

PVC

Form factors

supported

Tower

Cooling method Convection

Battery Access Battery access door allows user replacement of UPS batteries. Hot-swappable battery replacement supported.

ENVIRONMENTAL

Relative Humidity 0 to 95%, non-condensing

Storage Temperature +5 to +122 degrees Fahrenheit

Operating

Temperature

+32 to +104 degrees Fahrenheit

COMMUNICATIONS

Network monitoring

port

USB (HID)

Software and

cabling included

USB cabling included, PowerAlert software available for free download at www.tripplite.com

WatchDog

compatibility

Yes, compatible with Tripp Lite's Watchdog system service to restore operation to locked equipment through soft reboot

of application / OS or hard power off/on reboot of connected equipment - ideal for unattended kiosk applications

LINE / BATTERY TRANSFER

Transfer time from

line power to battery

mode

2-4 milliseconds

Low voltage transfer

to battery power

Switches to battery power as line voltage decreases to 99 volts or less. Resets to line power mode as line voltage

increases to 104V or higher. Back panel potentiometer allows users to adjust brownout response to any voltage

between 83 and the 99 volt factory preset.

High voltage

transfer to battery

power

Yes

SPECIAL FEATURES

Cold Start Yes, inverter can be "cold started" to enable temporary AC output during a power failure

Appearance Attractive gray tower UPS

CERTIFICATIONS

Certifications Tested to UL1778 (USA), Tested to CSA (Canada), FCC Class B (emissions), NOM (Mexico), FCC Part 68 / Industry

Canada (telecommunications), SASO (Saudi Arabia), RoHS compliant

WARRANTY

Product Warranty

Period 2-year product warranty

Connected

Equipment Coverage

$150,000 connected equipment insurance (USA & Canada only)

Optional Coverage 3-5 year warranties, plus next day and on-site warranty coverage available. Contact Tripp Lite for additional information.

Related Items

Audio Cables

CT120 Instant-Read- AC Outlet Circuit Tester Qty: [optional]

Extended Warranties

WEXT3-INTERNET 3-Year Extended Warranty - For Internet Office Models Qty: [optional]

WEXT5-INTERNET 5-Year Extended Warranty - For Internet Office Models Qty: [optional]

Software

WATCHDOGSW WatchDog Service Monitoring / Reboot Software Qty: [optional]

Surge Protectors

DTEL2 Network Surge Suppressor - Essential protection for data and communication lines Qty: [optional]

DNET1 Network Surge Suppressor - Essential protection for data and communication lines Qty: [optional]

DCATV Network Surge Suppressor - Essential protection for TV/VCR coaxial lines Qty: [optional]

USB Hubs/Accessories

U022-010 USB Cable - 10-ft. USB 2.0 AB Gold Device Cable Qty: [optional]

Wallmount Bracket

UPSWM Wallmount Bracket and installation accessories (4 washers, 4 screws, 1 Velcro safety strap) Qty: [optional]

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3526.
