User’s Guide
AFE79xx SPI Bringup Guide With Xilinx FPGAs
ABSTRACT
This tutorial guides through the process of using Xilinx Vivado and Vitis development environments along
with Texas Instruments supplied custom IP to bring up Serial Peripheral Interface (SPI) and non-timing critical
General-Purpose Outputs (GPOs) for Texas Instruments AFE79xx EVM along with the companion LMK series
clocking chip, thereby enabling an easier integration of the AFE79xx device into a system design. This guide will
demonstrate how to use a Xilinx ZCU102 setup as an example.
Table of Contents
1 Introduction.............................................................................................................................................................................2
2 Prerequisites........................................................................................................................................................................... 2
3 Typical Bare-Metal Design Flow............................................................................................................................................ 3
4 Background.............................................................................................................................................................................4
5 AFE SPI IP Container Pinout..................................................................................................................................................5
6 TI AFE SPI IP Container..........................................................................................................................................................6
7 Create Block Designs With TI AFE SPI IP.............................................................................................................................7
8 Create New Platforms in Vitis ............................................................................................................................................. 11
9 Create New Application Projects in Vitis............................................................................................................................14
10 Build Application Projects................................................................................................................................................. 18
11 Configure the AXI GPIO......................................................................................................................................................19
11.1 Initializing the GPIO........................................................................................................................................................19
11.2 Setting the Direction....................................................................................................................................................... 19
11.3 Setting High or Low for Corresponding Bits................................................................................................................... 19
12 Configure the AXI SPI.........................................................................................................................................................20
13 Create Boot Images to Run on SD Card........................................................................................................................... 21
14 Set up and Power on Hardware.........................................................................................................................................23
15 Set up ZCU102 Board Interface for VADJ_FMC............................................................................................................... 24
16 Debug Application Projects and Set up Vitis Serial Terminal........................................................................................ 26
17 Execute the Application..................................................................................................................................................... 27
Trademarks
All trademarks are the property of their respective owners.
www.ti.com Table of Contents
SBAU412 – NOVEMBER 2022
Submit Document Feedback
AFE79xx SPI Bringup Guide With Xilinx FPGAs 1
Copyright © 2022 Texas Instruments Incorporated
1 Introduction
This user guide is a walk-through of complete hardware and software flow to bring up SPI and GPO with TI
supplied AFE SPI IP. The hardware in this case refers to the AFE SPI IP supplied by TI which uses a Microblaze
processor along with AXI SPI, AXI GPIO, and other required peripherals. Shielding end-customer from the
nuances of this setup is one of the core objectives in packaging these in a single custom IP container.
The specific step-wise objectives are as follows:
• Instantiate TI supplied AFE SPI IP in a Vivado project
• Map the supplied IP's required signals to FPGA IOs
• Import hardware design and building a new Vitis application project for software development
• Compile, link, and download C program to processor along with bit file for FPGA
2 Prerequisites
For effective use of this documentation, ensure to have the following prerequisites:
• Xilinx Vitis IDE v2020.1.0 (or higher)
• Xilinx Vivado v2020.1.0 (or higher)
• Xilinx FPGA board along with TI AFE EVM
• FPGA bit file download/debug programmer
• USB-UART cable for debug terminal
• TI supplied AFE SPI IP
• TI supplied C-APIs
Table 2-1. Prerequisites
TI AFE AFE79xx
Sample Configuration 2T-2R-1FB
Lanes 2 RX lanes (1RX, 1FB) and 2 TX lanes at 5 Gbps
AFE EVM AFE79xx EVM
FPGA Board Xilinx ZCU102 EVM
Introduction www.ti.com
2AFE79xx SPI Bringup Guide With Xilinx FPGAs SBAU412 – NOVEMBER 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated
3 Typical Bare-Metal Design Flow
Create New Project
Add User HDL, Ips, and Constraints
Add TI AFE SPI IP
Interconnect AFE SPI IP with User HDL
Create HDL Wrapper
Generate Output Files
Generate Bit Stream
Export Hardware
Create New Platform Project
(Import Hardware and Create BSP)
Create New C Application
Write the system specific application code
Include C headers and source files from TI
Supplied C-APIs
Initialize AXI Peripherals of
TI AFE SPI IP
Build Application
Configure FPGA
Launch or Run on Hardware
Vivado
Environment
Vitis
Environment
Figure 3-1. Bare-Metal Design Flow
www.ti.com Typical Bare-Metal Design Flow
SBAU412 – NOVEMBER 2022
Submit Document Feedback
AFE79xx SPI Bringup Guide With Xilinx FPGAs 3
Copyright © 2022 Texas Instruments Incorporated
4 Background
This example uses a soft core Microblaze because the Microblaze can be instantiated in most of the Xilinx FPGA
families. The SPI, UART, and GPIO AXI blocks run on relatively lower frequency AXI clocks. As seen in Figure
4-1, the AXI peripherals are controlled by a Microblaze block through smart interconnects.
Figure 4-1. Internal Block Diagram of TI AFE SPI IP
The interconnection of various submodules within this IP block diagram is similar to typical Microblaze
implementations. The HP port of the Microblaze drives AXI peripherals. The clocking of the entire IP is expected
from a 100-MHz differential clock source. This example uses a 100-MHz differential clock source because this
clock is typically available as ‘user clock’ in most FPGA EVMs. All other clock frequencies are derived internally
through a clocking wizard.
Background www.ti.com
4AFE79xx SPI Bringup Guide With Xilinx FPGAs SBAU412 – NOVEMBER 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated
5 AFE SPI IP Container Pinout
Table 5-1. Pinout Signals and Connections
SIGNALS DIRECTION EXTERNAL CONNECTIONS
SPI0_SCLK, SPI0_SDO*, SPI0_SEN Output AFE SPI lines (_SDO* to SDI of AFE)
SPI0_SDI Input AFE SDO
SPI1_SCLK, SPI1_SDO, SPI1_SEN Output LMK SPI lines
RSTZ Output RESETn of AFE
JESD RSTn
JESD TXRST Output JESED IP Cores RSTn and TX Rst
RXD Input UART Terminal TX for debug
TXD Output UART Terminal RX for debug
diff_clock_rtl Input 100-Mhz differential clocking
Reset_rtl Input Reset (Active High) typically connected to FPGA board
reset
www.ti.com AFE SPI IP Container Pinout
SBAU412 – NOVEMBER 2022
Submit Document Feedback
AFE79xx SPI Bringup Guide With Xilinx FPGAs 5
Copyright © 2022 Texas Instruments Incorporated
6 TI AFE SPI IP Container
By default, custom and user-added IPs are not visible in IP catalog of Vivado. The locations for these IPs must
be configured manually. To configure the IP locations manually, follow these steps:
1. Open the Project Manager menu and click Settings (see Figure 6-1).
Figure 6-1. Project Manager Settings
2. Click the + icon to add the location of TI provided IP (see Figure 6-2).
Figure 6-2. Adding IP Repository
TI AFE SPI IP Container www.ti.com
6AFE79xx SPI Bringup Guide With Xilinx FPGAs SBAU412 – NOVEMBER 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated
7 Create Block Designs With TI AFE SPI IP
The IP is expected to be used only within a block design. Users can create a new block design or instantiate the
IP within an existing one. To create a new block design with the IP, follow these steps:
1. Open the IP INTEGRATOR menu and click Create Block Design (see Figure 7-1).
Figure 7-1. Creating Block Design
2. Enter the desired design name (see Figure 7-2) and keep the other two options as defaults. Click OK.
Figure 7-2. Naming of Block Design
3. Click the IP Catalog tab and notice the User Repository header (see Figure 7-3). The header appears only if
the inclusion of the IP repository is done correctly, as explained in previous steps.
www.ti.com Create Block Designs With TI AFE SPI IP
SBAU412 – NOVEMBER 2022
Submit Document Feedback
AFE79xx SPI Bringup Guide With Xilinx FPGAs 7
Copyright © 2022 Texas Instruments Incorporated
Figure 7-3. User Repository
4. Double-click AFE79xx SPI Configurator to launch the Add IP window.
5. Click Add IP to Block Design (see Figure 7-4).
Figure 7-4. Adding IP to Block Design
6. The AFE SPI IP shows up in the block design (see Figure 7-5) if the previous steps were followed correctly.
Create Block Designs With TI AFE SPI IP www.ti.com
8AFE79xx SPI Bringup Guide With Xilinx FPGAs SBAU412 – NOVEMBER 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated
Figure 7-5. Final Diagram
The required IOs from the IP must be brought to the top-level file in the FPGA hdl design hierarchy. To do this,
first make the required IOs as external. To make the required IOs as external, right-click the individual IOs of
interest and select Make External (see Figure 7-6).
Figure 7-6. Making IOs External
In the above implementation example, the bare minimum required IOs are brought out as external.
The block design must then be validated for any errors and output products to generate. To validate the block
diagram, right-click the block design under the Design Sources header.
www.ti.com Create Block Designs With TI AFE SPI IP
SBAU412 – NOVEMBER 2022
Submit Document Feedback
AFE79xx SPI Bringup Guide With Xilinx FPGAs 9
Copyright © 2022 Texas Instruments Incorporated
Similarly, right-click the View Instantiation Template to use as a reference for wiring this block design on the top
level hdl (see Figure 7-7).
Figure 7-7. TI SPI Configurator Pinout
The IOs from the top level hdl which are connected to this IP must be declared in a Constraints file for them to
be mapped to the hardware design, specific FPGA pins, and the correct IO levels.
The above steps complete the hardware design using TI AFE SPI IP.
Create Block Designs With TI AFE SPI IP www.ti.com
10 AFE79xx SPI Bringup Guide With Xilinx FPGAs SBAU412 – NOVEMBER 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated
