NT6861

8-Bit Microcontroller for Monitor

1V2.0

Features

n40 pin DIP & 42 pin SDIP package

nOperating Voltage Range: 4.5V to 5.5V

nCMOS technology for low power consumption

nCrystal oscillator or ceramic resonator* available

n6502 8-bit CMOS CPU core

n8MHz operation of frequency

n4/8/12/16/24K bytes ROM are available

n256 bytes of RAM (which stores EDID for DDC1/2B)

nOne 8-bit pre-loadable base timer

n14 channels of 8 bit PWM outputs:

6 channel with 5V open drain and 8 channel with 12V

open drain

n2 channel A/D converters with 6-bit resolution

n24 bi-directional I/O port pins and 1 I/P pin

nHsync/Vsync signal processor

nHardware sync signals polarity & freq. evaluator

nBuilt-In I2C bus interface

nSupporting VESA DDC1/2B function

nSix-interrupt sources

- INTV (Vsync INT)

- INTE (External INT with rising edge trigger)

- INTMR (Timer INT )

-INTA (Slave Address Matched INT)

- INTD (Shift Register INT)

- INTS (SCL GO-LOW INT)

nHardware watch-dog timer function

General Description

NT6861 is a monitor component µC for auto-sync and

digital controlled applications. It contains a 6502

8-bit CPU core, 256 bytes of RAM used as working RAM

and stack area, 24K bytes of ROM maximum for

programming, 14-channel 8-bit PWM D/A converters, 2-

channel A/D converters for key detection saving I/O pins,

one 8 bit pre-loadable base timer, internal Hsync and

Vsync signals processor providing mode detection,

watch-dog timer preventing system from abnormal

operation, and an I2C bus interface.

Users can store EDID data in the 128 bytes of RAM for

DDC1/2B, so that users can save the cost of dedicated

EEPROM for EDID. Half frequency output function can

save external one-shot circuit. All of these designs create

savings in component costs.

*The frequency deviation of ceramic resonator has

+/- 6% maximum.

NT6861

Pin Configuration

[OE] DAC2

DAC1

DAC0

[DB7] P27

[VPP] RESET

GND

OSCO

OSCI

[CE] P14

[A10] P12/HALFHO

[A9] P11/AD1

[A8] P10/AD0

P20 [DB0]

P07/HSYNCO [A7]

P31/SCL [A13]

DAC4 [MODE0]

DAC3 [PGM]

HSYNCI

VSYNCI/INTV/ [A14]

NT6861

16 25

P15

[A11] P13/HALFHI

P16/INTE

DAC5 [MODE1]

DAC6 [MODE2]

DAC7

P21 [DB1]

P22 [DB2]

P06/VSYNCO [A6]

P05/DAC13 [A5]

P04/DAC12 [A4]

P03/DAC11 [A3]

P02/DAC10 [A2]

P01/DAC9 [A1]

P00/DAC8 [A0]

P30/SDA [A12][DB6] P26

[DB5] P25

[DB4] P24

[DB3] P23

* [ ]: OTP Mode

[OE] DAC2

DAC1

DAC0

[VPP] RESET

GND

OSCO

OSCI

P15

[A11] P13/HALFHI

[A9] P11/AD1

[A8] P10/AD0 P00/DAC8 [A0]P16/INTE P01/DAC9 [A1]

P02/DAC10 [A2]

P03/DAC11 [A3]

P04/DAC12 [A4]

P06/VSYNCO [A6]

P07/HSYNCO [A7]

DAC6 [MODE2]

DAC5 [MODE1]

DAC4 [MODE0]

DAC3 [PGM]

HSYNCI

VSYNCI/INTV

DAC7 [A14]

NT6861U

16 27

[CE] P14

[A10] P12/HALFHO

[DB7] P27

[DB6]P26

[DB5] P25

[DB4] P24

[DB3] P23

P05/DAC13 [A5]

P31/SCL [A13]

P30/SDA [A12]

P20 [DB0]

P21 [DB1]

P22 [DB2]

* [ ]: OTP Mode

Block Diagram

Timing Generator

CPU core

6502

Interrupt

Controller

H/V Sync Signals

Processor

SRAM + STACK

256 Bytes

Watch Dog Timer

PWM DACs

I/O Ports

OSCI

OSCO

VDD

GND

HSYNCI

INTE

SCL

SDA

DAC0 - DAC7

P00 - P07

P10 - P15

P20 - P27

VSYNCO

A/D Converter AD0 - AD1

8 Bit Base Timer

P30 - P31

IIC BUS

P16

HSYNCO

HALFHI

HALFHO

DAC8 - DAC13

VSYNCI/INTV

Program ROM

4/8/12/16/24K Bytes

NT6861

Pin Descriptions

Pin No.

40 Pin 42 Pin Designation Reset Init. I/O Description

1 1 DAC2 OOpen drain 12V, D/A converter output 2

22DAC1 OOpen drain 12V, D/A converter output 1

3 3 DAC0 OOpen drain 12V, D/A converter output 0

4 4 RESET ISchmitt trigger input pin, low active reset*

5 5 VDD PPower

6 7 GND PGround

7 8 OSCO OCrystal OSC output

8 9 OSCI ICrystal OSC input

9 10 P15 I/O Bi-directional I/O pin

10 11 P14 I/O Bi- directional I/O pin

11 12 P13/HALFHI P13 I/O Bi- directional I/O pin, shared with half hsync input

12 13 P12/HALFHO P12 I/O Bi- directional I/O pin, shared with half hsync output

13 14 P11/AD1 P11 I/O Bi- directional I/O pin, shared with A/D converter channel

1 input

14 15 P10/AD0 P10 I/O Bi- directional I/O pin, shared with A/D converter channel 0

input

15 16 P16/INTE P16 ISchmitt trigger input pin with internal pull high,sharedwith

external Rising-edge trigger interrupt

16 - 23 17 - 24 P27 - P20 I/O Bi- directional I/O pin, push-pull structure with high current

drive/sink capability

*This RESET pin must be pulled high by external pulled-up resistor (5KΩsuggestion), or it will stay low

voltage to reset system all the time.

NT6861

Pin Descriptions (continued)

Pin NO.

40 Pin 42 Pin Designation Reset Init. I/O Description

24 25 P30/SDA P30 I/O Open drain 5V Bi-direction I/O pin P30, shared with SDA pin of

I2C bus schmitt trigger buffer

25 26 P31/SCL P31 I/O Open drain 5V Bi-direction I/O pin P31, shared with SCL pin of

I2C

bus schmitt trigger buffer

26 27 P00/DAC8 P00 I/O Bi-directional I/Opin,sharedwithopen drain5VD/Aconverter

output 8

27 28 P01/DAC9 P01 I/O Bi-directional I/Opin,sharedwithopen drain5VD/Aconverter

output 9

28 29 P02/DAC10 P02 I/O Bi-directional I/Opin,sharedwithopen drain5VD/Aconverter

output 10

29 30 P03/DAC11 P03 I/O Bi-directional I/Opin,sharedwithopen drain5VD/Aconverter

output 11

30 31 P04/DAC12 P04 I/O Bi-directional I/Opin,sharedwithopen drain5VD/Aconverter

output 12

31 32 P05/DAC13 P05 I/O Bi-directional I/Opin,sharedwithopen drain5VD/Aconverter

output 13

32 33 P06/VSYNCO P06 I/O Bi- directional I/O pin, shared with vsync out

33 34 P07/HSYNCO P07 I/O Bi-directional I/O pin, shared with hsync out

34 35 DAC7 OOpen drain 12V, D/A converter output

35 36 DAC6 OOpen drain 12V, D/A converter output

36 38 DAC5 OOpen drain 12V, D/A converter output

37 39 DAC4 OOpen drain 12V, D/A converter output

38 40 DAC3 OOpen drain 12V, D/A converter output

39 41 HSYNCI IDebouncing & Schmitt trigger input pin for video horizontal

sync signal, internal pull high, shared with composite sync

input

40 42 VSYNCI/INTV VSYNCI IDebouncing & Schmitt trigger input pin for video vertical sync

signal, intermally pull high, shared with external interrupt

source

-6NC

-37 NC

NT6861

Functional Descriptions

1. 6502 CPU

The 6502isan8-bit CPUthatprovides56 instructions,decimalandbinary arithmetic,thirteenaddressingmodes, trueindexing

capability, programmable stack pointer with variable length stack, a wide selection of addressable memory, and interrupt input

options.

The CPU clock cycle is 4MHz (8MHz system clock divided by 2). Refer to 6502 data sheet for more details.

Accumulator A

Index Register Y

Index Register X

7 0

Stack Pointer SP

NStatus Register P

Carry

Zero

IRQ Disable

Decimal Mode

BRK Command

Overflow

Negative

Program Counter PCH

815

7 0

PCL

1 = TRUE

1 = Result ZERO

1 = DISABLE

1 = TRUE

1 = NEG

1 = TRUE

1 = BRK

V B DIZC

Figure 1. 6502 CPU Registers and Status Flags

NT6861

2. Instruction set list

Instruction Code Meaning Operation

ADC Add with carry A + M + C→A, C

AND Logical AND A •M →A

ASL Shift left one bit C ←M7 •••M0 ←0

BCC Branch if carry clears Branch on C = 0

BCS Branch if carry sets Branch on C = 1

BEQ Branch if equal to zero Branch on Z = 1

BIT Bit test A •M, M7 →N, M6 →V

BMI Branch if minus Branch on N = 1

BNE Branch if not equal to zero Branch on Z = 0

BPL Branch if plus Branch on N = 0

BRK Break Forced Interrupt PC+2↓PC↓

BVC Branch if overflow clears Branch on V = 0

BVS Branch if overflow sets Branch on V = 1

CLC Clear carry 0 →C

CLD Clear decimal mode 0 →D

CLI Clear interrupt disable bit 0 →I

CLV Clear overflow 0 →V

CMP Compare accumulator to memory A −M

CPX Compare with index register X X −M

CPY Compare with index register Y Y −M

DEC Decrement memory by one M −1→M

DEX Decrement index X by one X −1→X

DEY Decrement index Y by one Y −1→Y

EOR Logical exclusive-OR A ⊕M →A

INC Increment memory by one M + 1→M

INX Increment index X by one X + 1→X

INY Increment index Y by one Y + 1→Y

NT6861

Instruction set list (continued)

Instruction Code Meaning Operation

JMP Jump to new location (PC+1) →PCL, (PC+2) →PCH

JSR Jump to subroutine PC + 2↓, (P+1) →PCL, (PC+2) →PCH

LDA Load accumulator with memory M →A

LDX Load Index register X with memory M →X

LDY Load Index register Y with memory M →Y

LSR Shift right one bit 0 →M7•••M0 →C

NOP No operation No operation (2 cycles)

ORA Logical OR A + M →A

PHA Push accumulator on stack A ↓

PHP Push status register on stack P ↓

PLA Pull accumulator from stack A ↑

PLP Pullstatusregisterfromstack P ↑

ROL Rotate left through carry C ←M7•••M0 ←C

ROR Rotate right through carry C →M7•••M0 →C

RTI Return from interrupt P ↑, PC ↑

RTS Return from subroutine PC ↑, PC+1→PC

SBC Subtract with borrow A −M −C→A, C

SEC Set carry 1 →C

SED Setdecimalmode 1 →D

SEI Set interrupt disable status 1 →I

STA Store accumulator in memory A →M

STX Store index register X in memory X →M

STY Store index register Y in memory Y →M

TAX Transfer accumulator to index X A →X

TAY Transfer accumulator to index Y A →Y

TSX Transfer stack pointer to index X S →X

TXA Transfer index X to accumulator X →A

TXS Transfer index X to stack Pointer X →S

TYA Transfer index Y to accumulator Y →A

* Refer to 6502 programming data book for more details.

NT6861

3. RAM: 256 X 8 bits

256 X 8-bit SRAM is used for data memory and stack. The RAM addressing range is from $0080 to $017F. From $0100 to

$017F is used as the EDID data buffer when activating DDC1/2B mode transmission. The contents of RAM are undetermined

at power-up and are not affected by system reset. Software programmers can allocate stack area in the RAM by setting stack

pointerregisterS.Becausethe 6502 default stack pointer is$01FF,programmersmustsetregister S to FFH when startingthe

program, so the stack area will map $01FF - $0180 to $00FF - $0080.

as; LDX #$FF

TXS

RAM

Unused

$0000

$0080

$0100

$00FF

$A000

$FFFF

stack pointer

$FFFE

$FFFD

$FFFC RST-L

RST-H

IRQ-L

IRQ-H

RESET vector

IRQ vector

$017F

EDID

$0180

(4/8/12/16/24K Bytes)

ROM

$0025

System Registers

Unused

$BFFF

NT6861

4. System Registers

Addr. Register INIT Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0

$0000 PT0 FFH P07 P06 P05 P04 P03 P02 P01 P00 RW

$0001 PT1 7FH -P16 P15 P14 P13 P12 P11 P10 RW

$0002 PT2DIR FFH P27OE P26OE P25OE P24OE P23OE P22OE P21OE P20OE W

$0003 PT2 FFH P27 P26 P25 P24 P23 P22 P21 P20 RW

$0004 PT3 03H - - - - - - P31 P30 RW

$0005 MD CON 07H -

INSEN

HSEL

S/C

MD1/ 2

$0006 HV CON 2FH HCNTOV VCNTOV HSYNCI VSYNCI HPOLI VPOLI

HPOLO

VPOLO

$0007 HCNT L 00H HCL7 HCL6 HCL5 HCL4 HCL3 HCL2 HCL1 HCL0 R

$0008 HCNT H 00H - - - - HCH3 HCH2 HCH1 HCH0 R

$0009 VCNT L 00H VCL7 VCL6 VCL5 VCL4 VCL3 VCL2 VCL1 VCL0 R

$000A VCNT H 00H - - - - VCH3 VCH2 VCH1 VCH0 R

$000B SYNCON FFH NOHALF ENHALF -FRUN FRFREQ HALFPOL ENH ENV W

$000C ENDAC FFH ENAD1 ENAD0 ENDK13 ENDK12 ENDK11 ENDK10 ENDK9 ENDK8 W

$000D AD0 REG C0

HCEND CSTA AD05 AD04 AD03 AD02 AD01 AD00 R

$000E AD1 REG 00H - - AD15 AD14 AD13 AD12 AD11 AD10 R

$000F IEX 00H - - IEINTS IEINTD IEINTA IEINTR IEINTE IEINTV W

NT6861

System Registers (continued)

Addr. Register INIT Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0

$0010 IRQX 00H - - IRQINTS IRQINTD IRQINTA IRQINTR IRQINTE IRQINTV R

$0011 CLR FLG 00H CLRHOV CLRVOV CLRINTS CLRINTD CLRINTA CLRINTR CLRINTE CLRINTV W

$0012 CLR WDT -0 1 0 1 0 1 0 1 W

$0013 II ADR FFH AR7 AR6 AR5 AR4 AR3 AR2 AR1 -W

$0014 II DAT 00H SR7 SR6 SR5 SR4 SR3 SR2 SR1 SR0 RW

$0015 II STS 08H - - START

START STOP

STOP

ENDDC TRX RXAK -R

$0016 BT 00H BT7 BT6 BT5 BT4 BT3 BT2 BT1 BT0 W

$0017 BT CON 03H - - - - - - TBS ENBT W

$0018 DACH0 80H DKVL7 DKVL6 DKVL5 DKVL4 DKVL3 DKVL2 DKVL1 DKVL0 RW

$0019 DACH1 80H DKVL7 DKVL6 DKVL5 DKVL4 DKVL3 DKVL2 DKVL1 DKVL0 RW

$001A DACH2 80H DKVL7 DKVL6 DKVL5 DKVL4 DKVL3 DKVL2 DKVL1 DKVL0 RW

$001B DACH3 80H DKVL7 DKVL6 DKVL5 DKVL4 DKVL3 DKVL2 DKVL1 DKVL0 RW

$001C DACH4 80H DKVL7 DKVL6 DKVL5 DKVL4 DKVL3 DKVL2 DKVL1 DKVL0 RW

$001D DACH5 80H DKVL7 DKVL6 DKVL5 DKVL4 DKVL3 DKVL2 DKVL1 DKVL0 RW

$001E DACH6 80H DKVL7 DKVL6 DKVL5 DKVL4 DKVL3 DKVL2 DKVL1 DKVL0 RW

$001F DACH7 80H DKVL7 DKVL6 DKVL5 DKVL4 DKVL3 DKVL2 DKVL1 DKVL0 RW

$0020 DACH8 80H DKVL7 DKVL6 DKVL5 DKVL4 DKVL3 DKVL2 DKVL1 DKVL0 RW

$0021 DACH9 80H DKVL7 DKVL6 DKVL5 DKVL4 DKVL3 DKVL2 DKVL1 DKVL0 RW

$0022 DACH10 80H DKVL7 DKVL6 DKVL5 DKVL4 DKVL3 DKVL2 DKVL1 DKVL0 RW

$0023 DACH11 80H DKVL7 DKVL6 DKVL5 DKVL4 DKVL3 DKVL2 DKVL1 DKVL0 RW

$0024 DACH12 80H DKVL7 DKVL6 DKVL5 DKVL4 DKVL3 DKVL2 DKVL1 DKVL0 RW

$0025 DACH13 80H DKVL7 DKVL6 DKVL5 DKVL4 DKVL3 DKVL2 DKVL1 DKVL0 RW

Note:The line above a writable signal name indicate an active lowsignal

The dash line in these control register indicate an undefined bit

The address of control register from $0026 to $007F are not used.

Table des matières

Autres manuels Novatek Microcontrôleur

Novatek

Novatek NT6862-5 Series Manuel utilisateur

Manuels Microcontrôleur populaires d'autres marques

AMS

AMS AS7261 Demo Kit Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266 SDK Guide de configuration

Nuvoton

Nuvoton ISD61S00 ChipCorder Mode d’emploi

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manuel utilisateur

Texas Instruments

Texas Instruments Chipcon CC2420DK Manuel utilisateur

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manuel utilisateur

NEC

NEC 78GK0S/K 1+ Series Instructions d'installation et d'utilisation

Mikroe

Mikroe SEMITECH N-PLC Click Instructions d'installation et d'utilisation

Intel

Intel Agilex Manuel utilisateur

Cypress

Cypress CY4607 HX2VL Manuel utilisateur

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manuel utilisateur

Texas Instruments

Texas Instruments TMS320F2837 D Series Manuel utilisateur

CYPRES

CYPRES CY14NVSRAMKIT-001 Manuel utilisateur

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266EX Mode d'emploi

Abov

Abov AC33M8128L Manuel utilisateur

Laird

Laird BL654PA Manuel utilisateur

Silicon Laboratories

Silicon Laboratories C8051F800 Manuel utilisateur
