SLLU224B–August 2015–Revised March 2018

DP159RSB Evaluation Module

Aardvark is a trademark of Total Phase, Inc.

All other trademarks are the property of their respective owners.

User's Guide

SLLU224B–August 2015–Revised March 2018

DP159RSB Evaluation Module

This document describes how to use and configure the DP159RSBEVM along with recommendations for

system hardware implementation. These recommendations are only guidelines and it is the designer’s

responsibility to consider all system characteristics and requirements. Engineers should refer to the

datasheet for technical details such as device operation, terminal description, and so forth.

Contents

1 Overview...................................................................................................................... 2

1.1 What is the DP159? ................................................................................................ 2

1.2 What is the DP159RSBEVM?..................................................................................... 2

1.3 What is Included in the DP159RSBEVM?....................................................................... 2

1.4 DP159RSBEVM Board............................................................................................. 3

2 Hardware Description ....................................................................................................... 3

2.1 Video Connectors for DP159 Ports............................................................................... 4

2.2 Enable/Reset........................................................................................................ 4

2.3 Power................................................................................................................. 4

2.4 Jumper Configuration .............................................................................................. 5

2.5 Component Population Configuration............................................................................ 6

2.6 Local I2C Access Through J5 ..................................................................................... 6

2.7 Local I2C Access Through USB Interface via TUSB3410 .................................................... 7

2.8 Rsadj Potentiometer .............................................................................................. 10

3 Quick Start Guide .......................................................................................................... 10

4 References.................................................................................................................. 10

5 EVM Bill of Materials....................................................................................................... 11

6 EVM Schematics .......................................................................................................... 13

7 EVM Layout................................................................................................................. 20

List of Figures

1 DP159RSBEVM Board...................................................................................................... 3

2 DP159RSBEVM Block Diagram ........................................................................................... 3

3 Register Status / Control Tab .............................................................................................. 7

4 Eye Scan Tab ................................................................................................................ 8

5 Sample Eyescan at HDMI2.0 Raw ........................................................................................ 9

6 Sample Eyescan at HDMI2.0 Interpreted................................................................................. 9

7 HDMI Input Connectors ................................................................................................... 13

8 DP159RSB.................................................................................................................. 14

9 HDMI TX Connector ....................................................................................................... 15

10 DP159RSBEVM Select Options.......................................................................................... 16

11 Reset ........................................................................................................................ 17

12 1.1- and 3.3-V Regulators ................................................................................................ 18

13 TUSB3410................................................................................................................... 19

14 Layer 1 (Top) ............................................................................................................... 20

15 Layer 2 (GND).............................................................................................................. 20

16 Layer 3 (Power) ............................................................................................................ 21

Overview

www.ti.com

2SLLU224B–August 2015–Revised March 2018

Submit Documentation Feedback

DP159RSB Evaluation Module

17 Layer 4 (Power) ............................................................................................................ 21

18 Layer 5 (GND).............................................................................................................. 22

19 Layer 6 (Bottom)............................................................................................................ 22

List of Tables

1 Jumper Settings.............................................................................................................. 5

2 Aardvark I2C (J5) Pin-Out................................................................................................... 6

3 DP159 Target I2C Address ................................................................................................. 7

4 DP159RSBEVM Bill of Materials......................................................................................... 11

1 Overview

1.1 What is the DP159?

The DP159 is a Dual-Mode DisplayPort to Transition Minimized Differential Signal (TMDS) retimer

supporting Digital Video Interface (DVI) 1.0 and High Definition Multimedia Interface (HDMI) 1.4b and 2.0

output signals. The DP159 supports the Dual-Mode Standard version 1.1 type 1 and type 2 through the

DDC link. The DP159 supports data rates up to 6 Gbps per data lane to support UltraHD (4K x 2K / 60

Hz) 8 bits per color high resolution video and HDTV with 16-bit color depth at 1080p (1920 x 1080 / 60

Hz). The DP159 can automatically configure itself as a redriver at data rates < 1.0 Gbps or as a retimer

above this data rate.

1.2 What is the DP159RSBEVM?

The DP159RSBEVM is a PCB created to help customers evaluate the DP159 device for video

applications. This EVM can also be used as a hardware reference design for implementation of the DP159

in the RSB package. PCB design/layout files can be provided upon request to provide PCB design

illustrations of the routing/placement rules.

Please note that the EVM design supports both the standard DP159 application and a DP159-thru-HDMI

application, so it contains many components that would not be needed by a typical DP159 application. A

separate reference design specific to the DP159 is available for customers.

1.3 What is Included in the DP159RSBEVM?

The major components of the EVM are as follows:

• DP159RSB

• Standard DP sink connector (connects to source)

• Standard HDMI source connector (connects to sink)

• DC power regulators

• I2C programming interface for external I2C host connection

• USB interface (I2C utility available)

DP159

(40-Pin RSB)

DP Connector Top

HDMI Connector

IN0P/N

IN1P/N

IN2P/N

IN3P/N

TMDS_D2P/N

TMDS_D1P/N

TMDS_D0P/N

TMDS_CLKP/N

AUXP/N DDC_SCL/SDA

AARDVARK

Connector

SCL_CTL

SDA_CTL

5-V

DONGLE

5-V to 3.3-V

LDO

3.3-V to 1.1-V

LDO

USB2

Connector

TUSB3410

www.ti.com

Overview

SLLU224B–August 2015–Revised March 2018

DP159RSB Evaluation Module

1.4 DP159RSBEVM Board

Figure 1 illustrates the DP159RSBEVM board.

Figure 1. DP159RSBEVM Board

2 Hardware Description

Figure 2 shows the DP159RSBEVM block diagram.

100-Ωdifferential impedance for HDMI and DP differential pairs.

Figure 2. DP159RSBEVM Block Diagram

Hardware Description

www.ti.com

4SLLU224B–August 2015–Revised March 2018

Submit Documentation Feedback

DP159RSB Evaluation Module

2.1 Video Connectors for DP159 Ports

The EVM has a DP connection for the source and a HDMI connection for the sink. J2 is a standard DP

connector (Molex 47272-0001). P2 is a standard HDMI connector (Molex 4715-10001). There is a third

video connection on the board for a HDMI source (P1), this function is not installed on the

DP159RSBEVM.

2.2 Enable/Reset

There are three device enable/reset options to use with the EVM:

A. Supervisor circuitry option

This is the default configuration on the DP159RSBEVM. The enable (EN) signal is held low until the

power good (PG) from the 3.3-V voltage regulator reaches a stable high-voltage level then released

high.

B. RC timing option

C26 external capacitor and internal resistor are used to control the EN ramp time after the device is

powered on. C26 is a Do Not Install (DNI option) by default. C26 needs to be installed and R77 needs

to be uninstalled to enable this option.

C. External control option

A push button (SW1) is provided for manual control of the DP159’s EN/OE input.

2.3 Power

A DC power jack (J9) to accept a 5-V wall power adapter is provided on the EVM. The DC power jack

(CUI Inc. PJ-202AH) has an inner diameter of 2.1 mm and an outer diameter of 5.5 mm. The tip of the +5-

V power supply must be positive. A +5-V power supply of at least 1.5 A that meets the given requirements

can be used to power the DP159RSBEVM. Power is provided to the EVM from the 5-V wall power adapter

when SW2 is set to position 1.

CAUTION

Care should be taken to not plug in any power source higher than the

configured voltage (5 V).

Alternately, it is possible to power the EVM by connecting a USB Micro cable from J13 to a USB host and

setting SW2 to position 3.

www.ti.com

Hardware Description

SLLU224B–August 2015–Revised March 2018

DP159RSB Evaluation Module

2.4 Jumper Configuration

Jumpers are provided to operate the device/EVM in different configurations. Table 1 lists the jumper

settings.

Table 1. Jumper Settings

Jumper Signal Name Description Default Config

J1 HPD_SRC JP 1-2 for DP159 thru HDMI NC

JP 2-3 NOT USED

NC for DP159

J3 I2_EN_PIN JP 1-2 for I2C ENABLE NC

JP 2-3 for PIN STRAP

NC – PIN STRAP (internal pulldown)

J4 SCL JP 1-2 for USB IF TO I2C JP 1-2: USB I2C Interface

JP 2-3 for EXT IF TO I2C

NC – N/A

J6 SDA JP 1-2 for USB IF TO I2C JP 1-2: USB I2C Interface

JP 2-3 for EXT IF TO I2C

NC – N/A

J7 HDMI_SEL_TEST_A1 JP 1-2 for: NC

• I2C Addr bit A1 = 1, when I2C_EN = H

• Test mode, when I2C_EN = L

JP 2-3 for:

• I2C Addr bit A1 = 0, when I2C_EN = H

• Normal mode, when I2C_EN = L

NC for weak internal pulldown (normal

mode)

J8 VSADJ JP 1-2 for 6.5 kΩJP 1-2: Default of 6.5 kΩ

JP 2-3 for adjustable resistance

NC – N/A

J10 SLEW_CTL JP 1-2 for fastest data rate NC

JP 2-3 for 20 ps slow

NC for 40 ps slow

J12 EQ_SEL_A0 JP 1-2 for: NC

• I2C Addr bit A0 = 1, when I2C_EN = H

• Fixed EQ at 14 dB, when I2C_EN = L

JP 2-3 for:

• I2C Addr bit A0 = 0, when I2C_EN = H

• Fixed EQ at 7.5 dB, when I2C_EN = L

NC for adaptive EQ

J15 PRE_SEL JP 1-2 NOT USED JP 2-3

JP 2-3 for –2.5 dB

NC for 0 dB

Hardware Description

www.ti.com

6SLLU224B–August 2015–Revised March 2018

Submit Documentation Feedback

DP159RSB Evaluation Module

2.5 Component Population Configuration

To allow the DP159RSBEVM to support both the default DP input as well as a HDMI test input, there are

many components that need to be removed, placed, or modified depending on the board configuration.

Here’s a summary of the default component configuration for the DP159RSBEVM. In addition, the unused

HDMI receptacle is depopulated.

Function Reference Designator DP159RSBEVM

Differential Pair - IN C11, C12, C13, C14, C15, C16, C24,

C25 populated with 0.1 µF

Differential Pair - HDMI IN R14, R15, R18, R19, R20, R21, R22,

R23 not populated

SDA / SCL - HDMI R16, R17, R24, R25, R134, R135 not populated

Differential Pair - DP IN R112, R109, R111, R108, R110, R107,

R106, R105 populated with 0 Ω

SDA / SCL / HPD - DP R33, R31, R32 (R126, R136, R140,

R141 - snoop) populated with 0 Ω

Pullup Differential Pair HDMI IN R1, R2, R3, R4, R6, R7, R8, R9 populated, but not

connected

2.5.1 HPD Snoop Option

To accommodate systems that do not properly resend DDC commands after HPD goes low, we have

implemented a HPD snoop mode on the DP159RSBEVM. This mode allows the HPD line to be routed

around the DP159, but remain connected to the DP159 on the sink side to allow the DP159 to snoop its

state. This snoop mode is disabled by default on the DP159RSBEVMs.

• Pop R131, no pop R129, R130, R139 for HPD on

• No pop R131, pop R129, R130, R139 for HPD snoop only

2.5.2 DDC Snoop Option – not Available for DP159RSB REV B

To accommodate systems that do not properly support clock stretching on the DDC lines, we have

implemented a snoop mode on the DP159RSBEVM. This mode allows the DDC lines to be routed around

the DP159RSB, but remain connected to the DP159RSB on the sink side to allow the DP159RSB to

snoop the DDC traffic. This snoop mode is disabled by default on the DP159RSB REV B1 EVMs.

• Pop R126, R136, R140, R141. No pop R31, R32 – DP159RSB, DDC snoop only

• Pop R31, R32. No pop R126, R136, R140, R141- DP159RSB, DDC on

2.6 Local I2C Access Through J5

Access to DP159’s local I2C signals is provided via the J5 input connector. Note that I2C signal levels

should be at 3.3 V when I2C interface is accessed through the connector.

A standalone external I2C host can be connected via J5 for debug and control purposes. An example of an

external I2C Host controller is the Total Phase Aardvark™ I2C/SPI Host Adapter (Total Phase Part#:

TP240141). Sample scripts for this I2C Host controller are provided by request.

Table 2. Aardvark I2C (J5) Pin-Out

J5 pin # Description J5 pin

#Description

1 SCL_CTL 2 GND

3 SDA_CTL 4 NC

5 NC 6 NC

7 NC 8 NC

9 NC 10 GND

www.ti.com

Hardware Description

SLLU224B–August 2015–Revised March 2018

DP159RSB Evaluation Module

(1) The target I2C address for DP159 can be modified by the EVM jumper settings.

Table 3. DP159 Target I2C Address(1)

DP159 I2C Target Address

Bit 7 (MSB) Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 (W/R)

A6 A5 A4 A3 A2 A1 A0

1 0 1 1 1 1 0 0/1

2.7 Local I2C Access Through USB Interface via TUSB3410

Access to DP159’s local I2C signals is also provided through the TUSB3410 on the DP159RSBEVM using

a USB TI Utility called Eye Scan. To use the utility:

• Install the Eye Scan software from Texas Instruments

• J6 must be set to SDA – SDA_USB

• J4 must be set to SCL – SCL_USB

• Attach USB micro cable to J13 and to the host computer

NOTE: The USB connection should be made prior to installing any DP or HDMI cables.

• Start the Eye Scan software

Figure 3 shows the Register Status / Control tab.

Figure 3. Register Status / Control Tab

Confirm that the SN65DP149/159/TMDS171/181 Interface is present and selected at the top. If it is not,

check the USB connection and confirm that the driver is loaded in Device Manager. It may take a moment

for the USB driver to load, if the DP159RSB does not appear, hit the Refresh button. This tab can be used

to read and write the status and control registers of the device.

Hardware Description

www.ti.com

8SLLU224B–August 2015–Revised March 2018

Submit Documentation Feedback

DP159RSB Evaluation Module

Figure 4 shows the Eye Scan tab.

Figure 4. Eye Scan Tab

To run an Eye Scan, select the Eye Scan tab, select the relevant lanes, and press scan. Note that Eye

Scan cannot be performed when the device is in retimer mode, it does not function in redriver mode.

www.ti.com

Hardware Description

SLLU224B–August 2015–Revised March 2018

DP159RSB Evaluation Module

Note that at HDMI 2.0 speeds there is a bug that causes invalid eyescan results. Results that look like

this:

Figure 5. Sample Eyescan at HDMI2.0 Raw

Should be interpreted as this:

Figure 6. Sample Eyescan at HDMI2.0 Interpreted

Hardware Description

www.ti.com

10 SLLU224B–August 2015–Revised March 2018

Submit Documentation Feedback

DP159RSB Evaluation Module

2.8 Rsadj Potentiometer

The default Rsadj value on the DP159RSBEVM is 6.5 kΩ. The optimal value for an application may vary

from 4.7 kΩto 7 kΩ. To allow customers to test the effects of various Rsadj values, there is a

potentiometer on the EVM at R76. The Rsadj value can be varied by turning the knob and setting J8 to

[2,3].

3 Quick Start Guide

The following steps provide quick start instructions:

1. Connect USB cable from J13 to a USB host, set SW2 to 3. LED D2 should light up.

Option: Apply 5-V power to J9, set SW2 to 1. LED D2 should light up.

2. If using external I2C adapter instead of pin straps, please configure the DP159 at this step using J5 or

through the USB interface.

3. Plug in a DP source using a standard DP cable into J2 (Standard DP connector).

4. Plug in an HDMI video sink device into P2 (standard HDMI connector) using a standard HDMI cable.

5. Video output on HDMI sink should be observed.

4 References

1. DP159 Data Sheet

2. Aardvark Adapter User Manual

3. High-Definition Multimedia Interface Specification Version 1.4b.

4. High-Definition Multimedia Interface Specification Version 2.0.

Autres manuels pour DP159RSB

Table des matières

Autres manuels Texas Instruments Unité de contrôle

Texas Instruments

Texas Instruments DRV591 Manuel utilisateur

Texas Instruments

Texas Instruments TWL6032 Manuel utilisateur

Texas Instruments

Texas Instruments TA 5 1 Q15B5EVM-K Series Manuel utilisateur

Texas Instruments

Texas Instruments TPS54980EVM-022 Manuel utilisateur

Texas Instruments

Texas Instruments BQ24180 Manuel utilisateur

Texas Instruments

Texas Instruments AM263P Series Manuel utilisateur

Texas Instruments

Texas Instruments DAC81408EVM Manuel utilisateur

Texas Instruments

Texas Instruments AWR1443 Manuel utilisateur

Texas Instruments

Texas Instruments UCC28740EVM-525 Manuel utilisateur

Texas Instruments

Texas Instruments TPS65988EVM Manuel utilisateur

Texas Instruments

Texas Instruments TPS54325 Manuel utilisateur

Texas Instruments

Texas Instruments DRV2625 Haptics BoosterPack Manuel utilisateur

Texas Instruments

Texas Instruments LM74700DDFEVM Manuel utilisateur

Texas Instruments

Texas Instruments HSS-MOTHERBOARDEVM Manuel utilisateur

Texas Instruments

Texas Instruments TSW40RF8 Series Manuel utilisateur

Texas Instruments

Texas Instruments TAS2770 Manuel utilisateur

Texas Instruments

Texas Instruments TPA4411 Manuel utilisateur

Texas Instruments

Texas Instruments DLP LightCrafter 3010 Gen2 Manuel utilisateur

Texas Instruments

Texas Instruments TSW12QJ1600 Manuel utilisateur

Texas Instruments

Texas Instruments TRF7960A Manuel utilisateur

Texas Instruments

Texas Instruments WiLink WL 1MOD Series Manuel utilisateur

Texas Instruments

Texas Instruments TAS3251 Manuel utilisateur

Texas Instruments

Texas Instruments TAS6424R-Q1 Manuel utilisateur

Texas Instruments

Texas Instruments THS1030/31EVM Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
