Texas Instruments TVP5158 Manuel utilisateur

TVP5158 Evaluation Module

User's Guide

Literature Number: SLEU108

November 2009

2SLEU108–November 2009

Submit Documentation Feedback

1 Description ......................................................................................................................... 6

1.1 Functional Overview .................................................................................................... 6

1.2 Notational Conventions ................................................................................................. 6

2 Board Level Description ....................................................................................................... 7

2.1 Analog Video/Audio Inputs ............................................................................................. 7

2.2 Analog Video/Audio Outputs ........................................................................................... 7

2.3 Digital Video/Audio Outputs to DaVinci HD EVM ................................................................... 8

2.4 Digital Video/Audio Cascade Output/Input ........................................................................... 8

2.5 I2C Configuration Options .............................................................................................. 8

2.6 Test Points and Jumpers ............................................................................................... 8

3 System Level Description ..................................................................................................... 9

4 Required Hardware and Equipment ..................................................................................... 10

5 Hardware Setup ................................................................................................................. 10

5.1 Setup for TVP5158EVM Stand-Alone Configuration .............................................................. 10

5.2 Setup for TVP5158EVM with DaVinci HD EVM ................................................................... 11

6 Software Installation .......................................................................................................... 14

7 TVP5158EVM Evaluation Procedures ................................................................................... 17

7.1 Stand-Alone Operation - Non-Interleaved Digital Video Output Modes ........................................ 17

7.2 Evaluation Using the DaVinci HD EVM ............................................................................. 19

7.3 Evaluation of Pixel-Interleaved Digital Video Output Modes ..................................................... 24

8 VCC Software in Depth ....................................................................................................... 25

8.1 VCC Main Window ..................................................................................................... 25

8.2 Register Map Editor ................................................................................................... 25

8.3 Property Sheets ........................................................................................................ 26

8.4 Video Decoder Select and Write Enables .......................................................................... 27

8.5 Example TVP5158 Property Pages ................................................................................. 28

9 Troubleshooting ................................................................................................................ 34

9.1 Troubleshooting Guide ................................................................................................ 34

10 TVP5158 EVM Schematics .................................................................................................. 38

SLEU108–November 2009 Table of Contents

www.ti.com

List of Figures

1 TVP5158 EVM Block Diagram ............................................................................................ 7

2 TVP5158EVM System Level Block Diagram............................................................................ 9

3 Location of TVP5158EVM Video/Audio Inputs ........................................................................ 11

4 TVP5158EVM Software Setup Wizard ................................................................................. 15

5 Select Installation Folder ................................................................................................. 15

6 Confirm Installation........................................................................................................ 16

7 Installation Complete...................................................................................................... 16

8 VCC Configuration ........................................................................................................ 18

9 Specifying Cascaded Devices ........................................................................................... 18

10 USB Device Not Found Error Message ................................................................................ 18

11 Real-Time Polling Enable ................................................................................................ 19

12 VCC Main Window - Set for Communication to All Decoders....................................................... 19

13 System Initialization for Analog Component YPbPr Video Output.................................................. 19

14 Browse to Command File ................................................................................................ 21

15 System Initialization for Line-Interleaved Modes...................................................................... 22

16 mcvip_test Demo Application Menu .................................................................................... 23

17 System Initialization for Pixel Interleave Modes....................................................................... 24

18 TVP5158 Register Map Editor........................................................................................... 25

19 VCC Main Window – Configured for Broadcast Write Access (default)............................................ 28

20 VCC Main Window – Configured for Single Video Decoder Write Access ........................................ 28

21 TVP5158 Output Formatter Property Page With Decoder 1 Selected ............................................. 30

22 TVP5158 Output Formatter Property Page With Decoder 4 Selected ............................................. 31

23 TVP5158 Noise Reduction and Auto Contrast Property Page ...................................................... 32

24 TVP5158 Audio Property Page (Seen Only When Decoder 1 is Selected) ....................................... 32

25 TDM I2S Audio Data Configuration ..................................................................................... 33

26 TVP5158 Video Format Property Page................................................................................. 37

27 THS8200 Input Controls / Status Property Page...................................................................... 37

28 Schematics (1 of 8)........................................................................................................ 39

29 Schematics (2 of 8)........................................................................................................ 40

30 Schematics (3 of 8)........................................................................................................ 41

31 Schematics (4 of 8)........................................................................................................ 42

32 Schematics (5 of 8)........................................................................................................ 43

33 Schematics (6 of 8)........................................................................................................ 44

34 Schematics (7 of 8)........................................................................................................ 45

4List of Figures SLEU108–November 2009

Submit Documentation Feedback

www.ti.com

List of Tables

1 TVP5158EVM Jumper Descriptions...................................................................................... 8

2 Jumper Settings for Stand-Alone Configuration....................................................................... 11

3 Hardware Modifcation for I2S Audio to DM6467 ...................................................................... 12

4 Jumper Settings for DaVinci HD EVM as TVP5158 I2C Master .................................................... 13

5 Jumper Settings for PC USB Interface as TVP5158 I2C Master ................................................... 13

6 Jumper Settings for a Cascaded TVP5158EVM ...................................................................... 14

7 Recommended DM6467 Clock Frequencies .......................................................................... 19

8 VCC Main Menu Summary............................................................................................... 25

9 VCC Register Map Editor Controls...................................................................................... 26

10 Property Sheet Controls.................................................................................................. 26

11 Property Sheet Button Controls ......................................................................................... 27

12 Editing Tools vs Video Decoder Write Enables ....................................................................... 28

13 Troubleshooting Setup and General Issues ........................................................................... 34

14 Troubleshooting with THS8200 and CompositeVideo Output....................................................... 34

15 Troubleshooting with DM6467 DaVinci HD EVM...................................................................... 35

16 Troubleshooting I2C Connections and Cascaded EVMs............................................................. 35

SLEU108–November 2009 List of Tables

User's Guide

SLEU108–November 2009

TVP5158 Evaluation Module

1 Description

The TVP5158EVM evaluation module is a printed circuit board designed for evaluation of the TVP5158

Four-Channel PAL/NTSC Video Decoder. The TMS320DM6467 DVEVM (digital video evaluation module)

can be used with the TVP5158EVM as a back-end video processor. This user guide outlines the

necessary hardware and software setup required to provide full evaluation of the TVP5158.

1.1 Functional Overview

TVP5158EVM is powered by a single 5-V universal supply. The TVP5158EVM allows the user to have up

to four composite video inputs and up to four audio inputs. Analog YPbPr component video output is

supported for non-interleaved video modes. Digital video is output to the DaVinci HD EVM in a single or

dual ITU-R BT.656 configuration or in ITU-R BT.601 (16-Bit) configuration for evaluation of line-interleaved

modes.

The TVP5158EVM uses one PC USB port to provide I2C communication with the TVP5158, THS8200

Video/Graphics Triple DAC and the TLV320DAC32 Stereo Audio DAC devices on the TVP5158EVM. The

Video Control Center (VCC) application software is provided for control and evaluation of the

TVP5158EVM. A VT100 terminal program is required to connect to the DaVinci HD EVM via UART to

send Linux shell commands to control the DSP.

1.2 Notational Conventions

This document uses the following conventions.

The TMS320DM6467 Digital Video Evaluation Module is usually referred to as the DaVinci HD EVM.

The TMS320DM6467 Digital Media System-on-Chip is usually referred to as the DM6467.

6TVP5158 Evaluation Module SLEU108–November 2009

Submit Documentation Feedback

www.ti.com

Board Level Description

2 Board Level Description

Figure 1 shows the various features available on the TVP5158EVM.

Figure 1. TVP5158 EVM Block Diagram

2.1 Analog Video/Audio Inputs

The TVP5158EVM makes use of all the available inputs on the TVP5158 decoder, including four CVBS

video inputs and four analog audio inputs. Connector J1 has four analog video (CVBS) inputs (yellow RCA

jacks) and four analog audio inputs (white RCA jacks).

2.2 Analog Video/Audio Outputs

The TVP5158EVM has a THS8200 Video/PC Graphics Triple DAC and a TLV320DAC32 audio DAC on

the board so that the user can evaluate video and audio performance using a single EVM setup. The

THS8200 Video/Graphics Triple DAC takes the video output from DVO port A of TVP5158 and outputs

analog YPbPr video signals to component output connector J4. The TLV320DAC32 Stereo Audio DAC

takes digital audio output from TVP5158 and outputs analog audio to the head phone jack J5.

SLEU108–November 2009 TVP5158 Evaluation Module

Board Level Description

www.ti.com

2.3 Digital Video/Audio Outputs to DaVinci HD EVM

The TVP5158EVM has two dedicated connectors which match the digital video/audio input connectors on

the DaVinci HD EVM. Connector J9 includes a 16-bit video data bus (buffered data from DVO_A and

DVO_B of TVP5158), OCLK_P, OCLK_N, I2C and interrupts. The connector J10 includes BCLK, LRCLK

and SD_R/SD_M outputs from TVP5158. Samtec HQCD cables are required to connect TVP5158EVM

digital video and audio signals to the DaVinci HD EVM.

2.4 Digital Video/Audio Cascade Output/Input

The TVP5158EVM has two connectors for video/audio cascade mode test. The connector J2 is for

video/audio cascade output, which includes buffered data from the DVO_A and DVO_B video output ports

and audio cascade output from TVP5158. The connector J3 is for video/audio cascade input, which

includes video input data to the DVO_C and DVO_D video ports and audio cascade input from a lower

cascaded stage TVP5158 device.

2.5 I2C Configuration Options

The TVP5158EVM uses one PC USB port for I2C communication. The I2C bus master can be changed

based on jumper settings. Control is via the PCB USB interface (VCC application controls TVP5158), via

the DaVinci EVM (DSP driver software controls TVP5158) or via the cascade input/output connectors J3

or J2.

2.6 Test Points and Jumpers

Various test points are available on the TVP5158EVM for the user. This includes the various power

supplies as well as a few GND test points. The user can also use J2/J3 for primary test-point headers to

access video/audio data, video/audio clocks, I2C and GND.

There are several jumpers available on the TVP5158EVM that configure I2C address select, I2C control

configuration, clock source selection and I2S source select. Each jumper is set by default in its preferred

state for the TVP5158EVM. Next to each jumper on the TVP5158EVM is the silkscreen that describes the

various jumper configurations. If the I2C address is changed on the TVP5158EVM while the

TVP5158EVM is powered up, then that device will not recognize the new I2C address. The reset button

on the TVP5158EVM must be pressed and the VCC application must be exited, restarted, and

re-configured for the new I2C address. Table 1 shows the TVP5158EVM jumper settings.

Table 1. TVP5158EVM Jumper Descriptions

Jumper Description of Function Default

Designator

TVP5158 I2C address selection (I2C_A0)

W0 1-2

1-2: Low

2-3: High

TVP5158 I2C address selection (I2C_A1)

W1 1-2

1-2: Low

2-3: High

TVP5158 I2C address selection (I2C_A2)

W2 1-2

1-2: Low

2-3: High

I2C SDA source selection

1-2: USB controls I2C

W3 1-2

2-3: DaVinciHD controls I2C

OFF: Control by another EVM for cascade mode.

I2C SCL source selection

1-2: USB controls I2C

W4 1-2

2-3: DaVinciHD controls I2C

OFF: Control by another EVM for cascade mode.

8TVP5158 Evaluation Module SLEU108–November 2009

Submit Documentation Feedback

www.ti.com

System Level Description

Table 1. TVP5158EVM Jumper Descriptions (continued)

Jumper Description of Function Default

Designator

Clock source selection

W5 1-2

1-2: Crystal

2-3: Clock from another EVM for cascade mode

I2C EEPROM

W6 ON

ON: Use EEPROM (MUST ALWAYS BE ON)

W7 I2C SCL connection for audio DAC ON

W8 I2C SDA connection for audio DAC ON

I2S input selection for audio DAC

W9 2-3

1-2: TVP5158 mixing output to audio DAC (SD_M)

2-3: TVP5158 record output to audio DAC (SD_R)

3 System Level Description

The system block diagram illustrated in Figure 2 provides an example of how the TVP5158EVM may be

used for evaluation. Typically, the analog video/audio input is provided by a video source such as a

pattern generator or a DVD player running a test DVD. The TVP5158EVM is configured with the 5-V

supply and the USB cable provided.

The TVP5158EVM analog video output is standard definition component video (YPbPr). These outputs

are then fed into a high-end or studio-quality NTSC/PAL monitor.

The user can also connect the TVP5158EVM to a DaVinci HD EVM and then output combined video from

the DaVinci HD EVM to a 1080i HD monitor.

Figure 2. TVP5158EVM System Level Block Diagram

SLEU108–November 2009 TVP5158 Evaluation Module

Required Hardware and Equipment

www.ti.com

4 Required Hardware and Equipment

The required hardware and equipment are as follows:

• Windows-based PC with Windows XP or later

• Video sources (security camera, pattern generator, DVD player, etc.)

• Display monitor that supports

– 1080i component YPbPr video (50 and 60 Hz)

– 480i and 576i component YPbPr video

• Audio amplifier/speakers or headphones

• TVP5158EVM (provided)

– Cables to provide up to four composite video and up to four audio line inputs

– Component Video (YPbPr) cable for output

– USB cable (provided)

– Universal 5-V power supply (100 to 240 VAC in, 5 VDC/3.0 A out) (provided)

• DaVinci HD EVM

– Two Samtec HQCD cables

– Component video (YPbPr) cable for output

– RS-232 null MODEM cable

– Universal 5-V power supply (100 to 250 VAC in, 5 VDC/5.0 A out)

5 Hardware Setup

The following sections describe the hardware setup for evaluation of the TVP5158.

5.1 Setup for TVP5158EVM Stand-Alone Configuration

For evaluation of video quality, comb filter, noise reduction, auto-contrast and other features, the

TVP5158EVM can be setup in a stand-alone configuration. Analog video and audio sources are input to

TVP5158. TVP5158 outputs digital video as ITU-R BT.656 or ITU-R BT.601 non-interleaved video to the

THS8200 PC Graphics/Video Triple DAC. Component Video YPbPr from the THS8200 is output in 480i or

576i format to a video monitor. To setup the stand-alone configuration, make the following connections:

1. Analog video sources to TVP5158EVM composite video inputs (see Figure 3)

2. Analog audio sources to TVP5158EVM audio line inputs (see Figure 3)

3. Analog component YPbPr video out from TVP5158EVM to video monitor

4. Stereo audio headphone output from TVP5158EVM to audio amplifier/speakers or headphones

5. USB cable from PC to TVP5158EVM. A green LED should be lit indicating that the EVM is ready for

communication on the USB.

6. 5-V power supply to the dc jack on the TVP5158EVM

10 TVP5158 Evaluation Module SLEU108–November 2009

Submit Documentation Feedback

Table des matières

Autres manuels Texas Instruments Matériel informatique

Texas Instruments

Texas Instruments TMS320F2807 Series Manuel utilisateur

Texas Instruments

Texas Instruments TMAG5170D Manuel utilisateur

Texas Instruments

Texas Instruments TMS34010 Manuel utilisateur

Texas Instruments

Texas Instruments TMS320C6201 Manuel utilisateur

Texas Instruments

Texas Instruments TMS320C6711D Manuel utilisateur

Texas Instruments

Texas Instruments ADS61B23EVM Manuel utilisateur

Texas Instruments

Texas Instruments LDC3114-Q1 Manuel utilisateur

Texas Instruments

Texas Instruments MSP-FET430 Manuel utilisateur

Texas Instruments

Texas Instruments TMS320C642x DSP Manuel utilisateur

Texas Instruments

Texas Instruments MSP430FG4618 Manuel utilisateur

Texas Instruments

Texas Instruments Tiva TM4C123G Manuel utilisateur

Texas Instruments

Texas Instruments DRV830x Rev D. Manuel utilisateur

Texas Instruments

Texas Instruments INA234EVM Manuel utilisateur

Texas Instruments

Texas Instruments TPA6135A2 EVM Manuel utilisateur

Texas Instruments

Texas Instruments TMS320C6457 Manuel utilisateur

Texas Instruments

Texas Instruments DRV603EVM Manuel utilisateur

Texas Instruments

Texas Instruments TI SITARA ARM Manuel utilisateur

Texas Instruments

Texas Instruments TMS320DM357 Manuel utilisateur

Texas Instruments

Texas Instruments TAS5707EVM Manuel utilisateur

Texas Instruments

Texas Instruments ADS41 Series Manuel utilisateur

Texas Instruments

Texas Instruments TVP5154EVM Manuel utilisateur

Texas Instruments

Texas Instruments DUAL SOCKET PC CARD CONTROLLER PCI1520... Manuel utilisateur

Texas Instruments

Texas Instruments TMDXEVM6472 Manuel utilisateur

Texas Instruments

Texas Instruments TPS65941515-Q1 Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
