User's Guide

SLVUAJ7–October 2015

bq50002 Wireless Power TX EVM

The bqTESLA™ wireless power transmitter evaluation module from Texas Instruments is a high-

performance, easy-to-use development module for the design of wireless power solutions. The bq50002

evaluation module (EVM) provides all the basic functions of a Qi-compliant, wireless charger pad. The 5-V

input, single coil transmitter enables designers to speed the development of their end-applications. The

EVM supports both the Qi WPC 1.0, WPC 1.1, and WPC 1.2 receivers and will support output power up to

5 W.

Contents

1 Applications................................................................................................................... 2

2 bq50002EVM-607 Electrical Performance Specifications.............................................................. 2

3 Modifications.................................................................................................................. 3

4 Connector and Test Point Descriptions................................................................................... 3

4.1 Input/Output Connections.......................................................................................... 3

4.2 Test Point Descriptions ............................................................................................ 4

5 Schematic and Bill of Materials ............................................................................................ 8

6 Test Setup................................................................................................................... 11

6.1 Equipment.......................................................................................................... 11

6.2 Equipment Setup.................................................................................................. 12

6.3 EVM Procedure.................................................................................................... 13

7 bq50002EVM-607 Assembly Drawings and Layout ................................................................... 18

8 Reference ................................................................................................................... 20

List of Figures

1 bq50002EVM-607 Schematic .............................................................................................. 8

2 Connections of the EV2400 kit ........................................................................................... 13

3 bqStudio Window........................................................................................................... 14

4 Device ID.................................................................................................................... 14

5 Efficiency vs Power, bq50002EVM-607 TX and bq51013BEVM-764 Receiver.................................... 16

6 Start Up...................................................................................................................... 16

7 Thermal Performance...................................................................................................... 17

8 Assembly Top............................................................................................................... 18

9 Inner Layer 1................................................................................................................ 19

10 Inner Layer 2................................................................................................................ 19

11 Bottom Layer................................................................................................................ 20

List of Tables

1 bq50002EVM-607 Electrical Performance Specifications.............................................................. 2

2 Bill of Materials............................................................................................................... 9

bqTESLA is a trademark of Texas Instruments.

Avid is a registered trademark of Avid Technology, Inc..

SLVUAJ7–October 2015 bq50002 Wireless Power TX EVM

Applications

www.ti.com

1 Applications

The bq50002EVM-607 evaluation module demonstrates the transmitter portion of the bqTESLA™ wireless

power system. This transmitter EVM is a complete transmitter-side solution that powers a bqTESLA

receiver. The EVM requires a single 5-V power supply capable of up to 2.0 A to operate and combines the

transmitter electronics, input power circuit, LED indicators, and the transmitting coil on the single printed-

circuit board (PCB). The open design allows easy access to key points of the electrical schematic.

This EVM has the following features:

• Qi-Certified WPC 1.2 solution for 5-W operation

• 5-V input and fixed operation voltage

• Enhanced Foreign Object Detection (FOD)

• WPC 1.2 FOD

• Transmitter-coil mounting pad providing the correct receiver interface

• Highly-integrated analog front end including LDO, FETs, drivers, current sense amplifier, and de-

modulation circuit

• Standard WPC A11-type transmitter coil with no magnet

• LED and audio indication of power transfer

2 bq50002EVM-607 Electrical Performance Specifications

Table 1 provides a summary of the EVM performance specifications. All specifications are given for an

ambient temperature of 25°C.

Table 1. bq50002EVM-607 Electrical Performance Specifications

Parameter Notes and Conditions Min Typ Max Unit

Input Characteristics

VIN Input voltage 4.5 5 5.5 V

IIN Input current VIN = Nom, IOUT = 1 A at 5 V 1.4 A

Input no-load current VIN = Nom, IOUT = 0 A 165 mA

Input stand-by current VIN = Nom 4 mA

Output Characteristics – Receiver bq51013BEVM-764

VOUT Output voltage VIN = Nom, IOUT = 1 A , VOUT = 5 V 4.95 5.00 5.04 V

Output ripple VIN = Nom, IOUT = 1.0 A, VOUT = 5 V 200 mVPP

IOUT VIN = Min to Max VIN = Min to Max, VOUT = 5 V 0 1.5 A

Systems Characteristics

FSSwitching frequency During power transfer 110 205 kHz

ηpk Peak efficiency VIN = Nom, P Out RX = 3 W 74 %

ηFull-load efficiency VIN = Nom, IOUT = Max 71 %

2bq50002 Wireless Power TX EVM SLVUAJ7–October 2015

Submit Documentation Feedback

www.ti.com

Modifications

3 Modifications

See the datasheet (SLUSBW1) when changing components.

FOD – R27 threshold and R26 FOD_Cal (see Section 6.3.9)

4 Connector and Test Point Descriptions

4.1 Input/Output Connections

The connection points are described in Section 4.1.1 through Section 4.1.4.

4.1.1 J1 – VIN

Input power 5 V ±500 mV, return at J3.

4.1.2 J2 – USB Input

USB input connection.

4.1.3 J3 –GND

Return for input power, input at J1.

4.1.4 J4 – Serial Interface

I2C interface connection to communicate with the IC. Used with bqStudio tool to monitor behavior

SLVUAJ7–October 2015 bq50002 Wireless Power TX EVM

Connector and Test Point Descriptions

www.ti.com

4.2 Test Point Descriptions

The test points are described in Section 4.2.1 through Section 4.2.56.

4.2.1 TP1 – CS+

Current sense amplifier positive input.

4.2.2 TP2 – CS–

Current sense amplifier negative input.

4.2.3 TP3 – VIN

Input power, 5 V ±500 mV.

4.2.4 TP4 – GND

Return for input power.

4.2.5 TP5 –DMIN1

Modulation signal input from coil for DEMOD Channel 1.

4.2.6 TP6 –SW1

Switch node of the half bridge MOSFETs.

4.2.7 TP7 – GND

Low-noise ground test point (TP).

4.2.8 TP8 –Low-Noise Analog Ground

Low-noise ground TP.

4.2.9 TP9 – GND

Low-noise ground TP.

4.2.10 TP10 – GND

Low-noise ground TP.

4.2.11 TP11 – PGND

Return for SW1.

4.2.12 TP12 – DMIN2

Modulation signal input from coil for DEMOD Channel 2.

4.2.13 TP13 – PEAK

Peak detection.

4.2.14 TP14 – SW2

Switch node of the half-bridge MOSFETs.

4bq50002 Wireless Power TX EVM SLVUAJ7–October 2015

Submit Documentation Feedback

www.ti.com

Connector and Test Point Descriptions

4.2.15 TP15 – BP3

Output of 3-V LDO.

4.2.16 TP16 – TANK

Coil signal at junction between transmitter coil and resonant capacitors.

4.2.17 TP17 – PGND

Return for SW2.

4.2.18 TP18 – PWM1/CLK

Input to control half-bridge MOSFETs connected to SW1 when PWM_CTRL is high. The operating

frequency/pulse width changes up or down depending on every rising edge of this periodic signal when

PWM_CTRL is low.

4.2.19 TP19 – PWM2/UPDN

Input to control half-bridge MOSFETs connected to SW2 when PWM_CTRL is high. Increase or decrease

power transfer when PWM_CTRL is low.

4.2.20 TP20 – CSO

Output of the current sense amplifier.

4.2.21 TP21 – DMOUT1

Demodulated 2-kHz bit stream from demodulation channel 1.

4.2.22 TP22 – DMOUT2

Demodulated 2-kHz bit stream from demodulation channel 2.

4.2.23 TP23 – BUZZ

DC output when power transfer is started. Can be used to drive a DC style buzzer or LED. See data sheet

for more information.

4.2.24 TP24 – LED_B

Status indication, typically RED.

4.2.25 TP25 – LED_A

Status indication, typically GREEN.

4.2.26 TP26 – LED_C

Status indication, typically ORANGE.

4.2.27 TP27 – LED_MODE

LED mode selection.

4.2.28 TP28 – T_SENSE

Temperature sensing for safety shutdown.

SLVUAJ7–October 2015 bq50002 Wireless Power TX EVM

Connector and Test Point Descriptions

www.ti.com

4.2.29 TP29 – FOD_CAL

FOD calibration.

4.2.30 TP30 – FOD_THR

FOD threshold.

4.2.31 TP31 – V_SENSE

Input voltage sense.

4.2.32 TP32 – FLIM

Leave floating to conform to WPC specification 205-kHz maximum operating frequency.

4.2.33 TP33 – ILIM

ILIM can be used to restrict the input current in order to operate with a limited input voltage source. Leave

this pin open if no fixed current limit should be used.

4.2.34 TP34 – Reserved IC Pin 5

Unused.

4.2.35 TP35 – Unused IC Pin 7

Leave this pin open.

4.2.36 TP36 – Unused IC Pin 25

Leave this pin open.

4.2.37 TP37 – Unused IC Pin 27

Leave this pin open.

4.2.38 TP38 - Unused IC Pin 17

Leave this pin open.

4.2.39 TP39 - Unused IC Pin 6

Leave this pin open.

4.2.40 TP40 - Unused IC Pin 24

Leave this pin open.

4.2.41 TP41 - Unused IC Pin 26

Leave this pin open.

4.2.42 TP42 - Unused IC Pin 18

Leave this pin open.

4.2.43 TP43 – CLK_IN

CLK_OUT signal from the internal oscillator of the bq50002.

6bq50002 Wireless Power TX EVM SLVUAJ7–October 2015

Submit Documentation Feedback

www.ti.com

Connector and Test Point Descriptions

4.2.44 TP44 – MODE

Control of frequency/pulse width of the internal generated oscillator signal.

4.2.45 TP45 – SDA

I2C data.

4.2.46 TP46 – SCL

I2C clock.

4.2.47 TP47 – 3-V Rail Resistor Divider

4.2.48 TP49 – Floating Test Point

4.2.49 TP50 – Floating Test Point

4.2.50 TP51 – GND

4.2.51 TP52 - Floating Test Point

4.2.52 TP53 - Floating Test Point

4.2.53 TP54 – GND

4.2.54 TP55 – Floating Test Point

4.2.55 TP56 – Floating Test Point

4.2.56 TP57 – GND
