User’s Guide

Powering DRA821 with TPS6594-Q1 and LP8764-Q1

ABSTRACT

This user’s guide can be used as a guide for integrating the TPS6594-Q1 and LP8764-Q1 power management

integrated circuits (PMICs) into a system powering the DRA821 processor.

Table of Contents

1 Introduction.............................................................................................................................................................................2

2 Device Versions...................................................................................................................................................................... 2

3 Processor Connections..........................................................................................................................................................3

4 Supporting Functional Safety Systems................................................................................................................................9

4.1 Achieving ASIL-B System Requirements...........................................................................................................................9

4.2 Achieving up to ASIL-D System Requirements................................................................................................................10

5 Static NVM Settings..............................................................................................................................................................10

5.1 Application-Based Configuration Settings........................................................................................................................10

5.2 Device Identification Settings........................................................................................................................................... 11

5.3 BUCK Settings..................................................................................................................................................................11

5.4 LDO Settings....................................................................................................................................................................13

5.5 VCCA Settings................................................................................................................................................................. 14

5.6 GPIO Settings.................................................................................................................................................................. 15

5.7 Finite State Machine (FSM) Settings............................................................................................................................... 17

5.8 Interrupt Settings..............................................................................................................................................................18

5.9 POWERGOOD Settings...................................................................................................................................................21

5.10 Miscellaneous Settings.................................................................................................................................................. 22

5.11 Interface Settings............................................................................................................................................................23

5.12 Multi-Device Settings..................................................................................................................................................... 23

5.13 Watchdog Settings......................................................................................................................................................... 24

6 Pre-Configurable Finite State Machine (PFSM) Settings.................................................................................................. 24

6.1 Configured States............................................................................................................................................................ 24

6.2 PFSM Triggers................................................................................................................................................................. 27

6.3 Power Sequences............................................................................................................................................................ 29

7 Application Examples.......................................................................................................................................................... 47

7.1 Moving Between States: ACTIVE, MCU, and RETENTION............................................................................................ 47

7.2 Entering and Exiting Standby...........................................................................................................................................48

7.3 Entering and Existing LP_STANDBY............................................................................................................................... 48

7.4 GPIO8 and Watchdog...................................................................................................................................................... 49

8 Additional Resources...........................................................................................................................................................50

9 Revision History................................................................................................................................................................... 50

Trademarks

Jacinto™ is a trademark of Texas Instruments.

All trademarks are the property of their respective owners.

www.ti.com Table of Contents

SLVUBY7A – OCTOBER 2020 – REVISED OCTOBER 2022

Submit Document Feedback

Powering DRA821 with TPS6594-Q1 and LP8764-Q1 1

1 Introduction

This user’s guide defines the power distribution network (PDN) between the TPS6594-Q1 and LP8764-Q1

devices and the DRA821 processor. This document describes the platform power resource connections, digital

control connections, and PMIC sequencing settings to support the different processor state transitions. The

PMIC default non-volatile memory (NVM) settings, internal state transitions, and power sequences are also

defined in this document. This user's guide does not provide information about the electrical characteristics,

external components, package, or the functionality of the PMICs or processor. For such information and the full

specification and any user's guide, application report, or other referenced material, the data sheet specification is

the definitive source.

2 Device Versions

There are different versions of the TPS6594-Q1 and LP8764-Q1 devices available with unique NVM settings

to support different processor solutions. The unique NVM settings for each PMIC device are optimized per

PDN design to support different processors, processing loads, SDRAM types, system functional safety levels,

and end product features - such as low power modes, processor interface levels, SD Card, and so forth. The

NVM settings can be distinguished using the TI_NVM_ID register. In this user guide, each PMIC device is

distinguished by the TI orderable part number, TI_NVM_ID, and TI_NVM_REV values listed in Table 2-1.

Table 2-1. TPS6594-Q1 and LP8764-Q1 NVM Settings and Orderable Part Numbers

PDN USE CASE Orderable Part Number Device Mode TI_NVM_ID TI_NVM_REV

• Up to 4.25 A(1) on the CORE rail

• Up to 4.25 A(1) on the CPU rails

• Up to 3.4 A(1) on the SDRAM, with support for

LPDDR4

• Supports Functional Safety up to ASIL-D level

• Supports low power modes, including MCU-

only, GPIO Retention, and DDR Retention

states

• Supports I/O level of 3.3 V or 1.8 V

• Supports use of SD card

TPS6594141B Primary 0x1B 0x01

LP876441B1 Secondary 0xB1 0x01

(1) TI recommends having 15% margin between the maximum expected load current and the maximum current allowed per each PMIC

output rail.

Introduction www.ti.com

2Powering DRA821 with TPS6594-Q1 and LP8764-Q1 SLVUBY7A – OCTOBER 2020 – REVISED OCTOBER 2022

Submit Document Feedback

3 Processor Connections

This section details how the TPS6594-Q1 and LP8764-Q1 power resources and GPIO signals are connected to

the processor and other peripheral components to support the PDN use case.

Figure 3-1 shows the detailed power mapping between the processor and the TPS6594-Q1 and LP8764-Q1

PMICs. In this configuration, both PMICs use a 3.3 V input voltage. For Functional Safety applications, there

is a protection FET before VCCA that connects to the OVPGDRV pin of the primary PMIC, allowing voltage

monitoring of the input supply to the PMICs.

The VCCA voltage must be the first voltage applied to the PMIC devices. VIO_IN of the PMICs must be supplied

after VCCA. In this configuration, VIO_IN is supplied by the load switch that also supplies the VDDSHVx_MCU

voltage domain of the processor to allow the digital components of the PMIC devices (such as GPIOs) to remain

supplied in MCU-only mode. Additionally, by controlling VIO_IN of both PMICs through this load switch, the

system can also reduce power consumption in GPIO Retention or DDR Retention modes, since the load switch

is disabled.

This PDN supports the use of either a single dual load switch (TPS22966-Q1) with an AEC-100 Grade 2 (-40

to +105°C) temperature rating or two single load switches (TPS22965-Q1) with an AEC-100 Grade 1 (-40 to

+125°C) rating if a higher ambient temperature range is desired. The PDN diagrams of this section also include

a few optional discrete power components to support additional system functions that may be needed. The

TLV70033-Q1 LDO is used to support compliant USB data eye performance by supplying a low noise 3.3 V

for USB 2.0 interface integration. The TLV70018-Q1 LDO is available to support on-board EFUSE programming

on high security SoC PNs. Alternative LDOs can be chosen for SD card dual-voltage I/O support (3.3 V and

1.8 V), TLV7103318-Q1 dual-voltage LDO can be used to enable compliant, dual voltage, high-speed SD card

operations.

www.ti.com Processor Connections

SLVUBY7A – OCTOBER 2020 – REVISED OCTOBER 2022

Submit Document Feedback

Powering DRA821 with TPS6594-Q1 and LP8764-Q1 3

TPS6594-Q1

BUCK2

(3.5A max)

BUCK3

(3.5A max)

BUCK4

(4A max)

BUCK5

(2A max)

LDO1

(500mA max)

LDO2

(500mA max)

LDO3

(500mA max)

LDO4

(300mA max)

LP8764-Q1

BUCK1

(5A max)

Primary PMICSecondary PMIC

Processor Supplies

MAIN PROCESSOR

VDD_CORE

VDDAR_CPU/CORE

VDD_WAKE0

VDDS_DDR_BIAS

1.1V

0.8V

0.85V

MAIN ANALOG

VDDA_1P8_PHYs

VDDA_0P8_PHYs

VDDA_0P8_PLLs/DLLs

VDDA_1P8_PLLs

0.8V

VDDA_3P3_USB

MAIN DIGITAL

VDDSHV0

VDDSHV2

VDDS_MMC0

1.8V

MCU SAFETY ISLAND

VDD_MCU

VDDAR_MCU

VDDSHVx_MCU (1.8V)

System

1.8V

3.3V

VPP_x (EFUSE)

0.85V

1.8V

VDDSHVx_MCU (3.3V)

0.8V

TPS22965-Q1

(load switch, 4A max)

3.3V

1.8V

LPDDR4

VDD1

VDD2

3.3V

VDD_CPU (AVS)

VCCA

OVPGDRV

VCCA

VIO_IN

BUCK1

(3.5A max)

1.8V

BUCK2

(5A max)

BUCK3

(5A max)

BUCK4

(5A max)

0.8V

VDDSHV5

TLV70033-Q1

(LDO, 200mA max)

TLV70018-Q1

(LDO, 300mA max)

TLV7103318-Q1

(dual-LDO, 200mA max)

3.3V

1.8V

1.8V/3.3V

VDDA_x

VDDS_DDR_IO

VDDQ

Octal SPI FLASH

Hyper FLASH

EMMC

VCCQ

VCC

PDN OPTIONS

MCU-only

DDR Retention

GPIO Retention

TPS22965-Q1

(load switch, 4A max)

TPS22965-Q1

(load switch, 4A max)

Figure 3-1. TPS6594-Q1 and LP8764-Q1 Power Connections

The power resource assignments shown in Figure 3-1 enable the support for different processor low-power

modes, including MCU-only mode, GPIO Retention, and DDR Retention. Please use Table 3-1 as a guide to

Processor Connections www.ti.com

4Powering DRA821 with TPS6594-Q1 and LP8764-Q1 SLVUBY7A – OCTOBER 2020 – REVISED OCTOBER 2022

Submit Document Feedback

understand which power resources are required to support different system features. If the system feature listed

is not required, the power resource connection can be removed.

Table 3-1. Power Resources by System Power States

Device PMIC

Resource Processor Domains Power States

Active SoC MCU - only GPIO Retention DDR Retention

TPS6594-Q1

BUCK1 VDDA_x Required Required

BUCK2 VDDSHVx_MCU (1.8V) Required Required

BUCK3 VDD_MCU, VDDAR_MCU Required Required

BUCK4 VDDS_DDR_BIAS,

VDDS_DDR_IO Required Required

BUCK5 VDDA_1P8_PHYs Required

LDO1 N/A Required Required

LDO2 VDDA_0P8_PLLs/DLLs Required

LDO3 VDD_WAKE0 Required Required

LDO4 VDDA_1P8_PLLs Required

LP8764-Q1

BUCK1 VDD_CPU Required

BUCK2 VDDAR_CPU/CORE Required

BUCK3 VDD_CORE,

VDDA_0P8_PHYs Required

BUCK4 VDDS_MMC0 Required

TPS22965-Q1 Load Switch VDDSHVx_MCU (3.3 V) Required Required

TPS22966-Q1 Load Switch 1 VDDSHV0(1) Required

Load Switch 2 VDDSHV2 Required

(1) VDDSHV5 can also be powered by this rail if an SD card is not required in the system.

Figure 3-2 shows the digital control signal mapping between the processor and the PMIC devices. For the two

PMIC devices to work together, the primary PMIC and secondary PMIC must establish an SPMI communication

channel. The SPMI bus allows the TPS6594-Q1 and LP8764-Q1 to synchronize their internal Pre-Configurable

State Machines (PFSM) so that they operate as one PFSM across all power and digital resources. The GPIO_5

and GPIO_6 pins on the TPS6594-Q1 and GPIO_8 and GPIO_9 pins on LP8764-Q1 are assigned for this

functionality. In addition, the LDOVINT pin of the primary PMIC must be connected to the ENABLE input

(GPIO_4 of LP8764-Q1) of the secondary PMIC to correctly initiate the PFSM.

Other digital connections from the TPS6594-Q1 devices to the processor allow support for error monitoring,

processor reset, processor wake up, and system low-power modes. Specific GPIO pins have been assigned to

key signals in order to ensure proper operation during low power modes when only a few GPIO pins remain

operational.

www.ti.com Processor Connections

SLVUBY7A – OCTOBER 2020 – REVISED OCTOBER 2022

Submit Document Feedback

Powering DRA821 with TPS6594-Q1 and LP8764-Q1 5

To support DDR retention low power mode, the following PMIC GPIO functions are required:

1. GPIO_2 and GPIO_3 of LP8764-Q1 connected to an external, low voltage latch to create a sustained control

signal to DDR_RET of the processor. The latch is needed since the PMIC VIO_IN power rail supplying

GPIO_2 and 3 is disabled during DDR Retention state.

2. Sustained GPIO_9 of TPS6594-Q1 connected to the enable input of a 3.3V in-line load switch to the MCU.

3. Sustained GPIO_4 of TPS6594-Q1 with NVM default function set as LP_WKUP1 and mask bit set high to

avoid false triggering until CAN wakeup signal is armed. SW must properly arm CAN PHY so that wakeup

signal is set high and unmask GPIO_4 before entering GPIO Retention state.

GPIO_4 of TPS6594-Q1 is powered by the VRTC internal voltage domain of the PMIC. The LDOVRTC regulator

supplies always-on functions, such as the wake-up function of GPIO_4. This enables GPIO_4 to be used as a

wake-up source in LP_STANDBY when LDO_VINT is turned off.

To support GPIO retention low power mode, the following PMIC GPIO functions are required:

1. Sustained GPIO_7 of LP8764-Q1 connected to the enable input of an in-line load switch to control the 3.3 V

GPIO retention domain.

Additional digital options also include GPIO_10 of TPS6594-Q1, which can be configured by software as a 32

kHz clock output for the processor oscillator input (LFOSC ). There is also the option to disable the watchdog

timer using hardware, by pulling GPIO_8 of TPS6594-Q1 high. Lastly, GPIO_1 of LP8764-Q1 is included in the

power up sequence to enable external regulators, for options such as DDR I/O.

Processor Connections www.ti.com

6Powering DRA821 with TPS6594-Q1 and LP8764-Q1 SLVUBY7A – OCTOBER 2020 – REVISED OCTOBER 2022

Submit Document Feedback

TPS6594-Q1

ENABLE

INTn

nRSTOUT

GPIO_1 (SCL_I2C2)

LP8764-Q1

Primary PMIC

Processor

SoC MAIN CONTROLS

PMIC_WAKE0

MMC1 IO

DDR_RET

SAFETY MCU CONTROLS

Safety MCU GPIO

WKUP_I2C0_SCL/SDA

MCU_PORz

Board

SOC_SAFETY_ERRORn

TPS22965-Q1

Warm Reset

ON REQUEST

SCL_I2C1

SDA_I2C1

GPIO_2 (SDA_I2C2)

GPIO_3 (nERR_SOC)

GPIO_4 (LP_WKUP1)

GPIO_5 (SCLK_SPMI)

GPIO_6 (SDATA_SPMI)

GPIO_7 (nERR_MCU)

GPIO_8 (DISABLE_WDOG)

GPIO_9 (GPO)

GPIO_10 (CLK32OUT)

GPIO_11 (nRSTOUT_SoC)

INTn

GPIO_1 (GPO)

Secondary PMIC

SCL_I2C1

SDA_I2C1

GPIO_2 (GPO)

GPIO_3 (GPO)

GPIO_4 (ENABLE)

GPIO_5 (GPO)

GPIO_6 (GPI)

GPIO_7 (GPO)

GPIO_8 (SCLK_SPMI)

GPIO_9 (SDATA_SPMI)

GPIO_10 (GPO)

LDOVINT VOUT_LDO

MCU_I2C0_SCL/SDA

ENABLE MCU I/O

MCU_SAFETY_ERRORn

PORz

PMIC VOLTAGE DOMAINS

VRTC – 1.8V

VINT – 1.8V

VIO – 1.8V or 3.3V

RESETSTATz

Disable Watchdog

CAN Wakeup

PDN OPTIONS

MCU-only

DDR Retention

GPIO Retention

TLV70033-Q1

TLV70018-Q1

TLV7103318-Q1

EN1

EN2

SET

CLR

TPS6594-Q1, BUCK4

Enable DDR I/O (Optional)

ENABLE MAIN I/O

EN_GPIO_RET

ENABLE USB

ENABLE

EFUSE

ENABLE

3.3V SD

ENABLE 1.8V SD

GPIO_DDR_RET_VAL

GPIO_DDR_RET_CLK

TPS22965-Q1

Figure 3-2. TPS6594-Q1 and LP8764-Q1 Digital Connections

The digital connections shown in Figure 3-2 allow system features including MCU-only mode, GPIO retention

mode, DDR retention mode, and functional safety systems capable of supporting up to ASIL-D. Please use Table

www.ti.com Processor Connections

SLVUBY7A – OCTOBER 2020 – REVISED OCTOBER 2022

Submit Document Feedback

Powering DRA821 with TPS6594-Q1 and LP8764-Q1 7

3-2 as a guide to understand GPIO assignments required for these features. If the feature listed is not required,

the digital connection can be removed. For details on how functional safety related connections help achieve

functional safety system-level goals, see Section 4.

Table 3-2. Digital Connections by System Feature

Device PMIC Digital

Signal System Digital Signal

System Features

Active SoC Functional

Safety MCU - only GPIO

Retention

DDR

Retention

TPS6594-Q1

nPWRON/

ENABLE System ON Request Required

INT(1) Safety MCU GPIO Required

nRSTOUT(1) MCU_PORz Required Required

SCL_I2C1 WKUP_I2C0_SCL Required

SDA_I2C1 WKUP_I2C0_SDA Required

GPIO_1 MCU_I2C0_SCL Required

GPIO_2 MCU_I2C0_SCL Required

GPIO_3 SOC_SAFETY_ERRORn Optional

GPIO_4(2) CAN Wakeup Required Required

GPIO_5 PMIC SPMI CLK Required

GPIO_6 PMIC SPMI DATA Required

GPIO_7 MCU_SAFETY_ERRORn Optional

GPIO_8 (5) Disable Watchdog (3) (3)

GPIO_9 ENABLE MCU I/O Required

GPIO_10(4) WKUP_LFOSC0 Required

GPIO_11(1) SOC_PORz Required Required

LP8764-Q1

INT(1) Safety MCU GPIO Required

SCL_I2C1 WKUP_I2C0_SCL Required

SDA_I2C1 WKUP_I2C0_SDA Required

GPIO_1 Enable DDR I/O (Optional)

GPIO_2(5) External Latch Data Input Required

GPIO_3(5) External Latch Clock Input Required

GPIO_4 TPS6594-Q1 LDOVINT Required

GPIO_5(5) Enable EFUSE

GPIO_6 (5) N/A

GPIO_7 EN_GPIO_RET Required Required

GPIO_8 PMIC SPMI CLK Required

GPIO_9 PMIC SPMI DATA Required

GPIO_10 Enable Main I/O Required Required Required

(1) This pin is open-drain to enable voltage translation to correct voltage level for processor interface.

(2) Software must unmask GPIO_4 before the system expects to trigger a wakeup on this pin.

(3) If it is desired to disable the watchdog through hardware, GPIO_8 is required and must be set high by the time nRSTOUT goes high.

After nRSTOUT is high, the watchdog state is latched and the pin can be configured for other functions through software.

(4) GPIO_10 is set as a general purpose input (GPI) by default to allow processor to boot up before sourcing the 32 kHz to the processor,

since both bootmode and low frequency clock inputs to the processor utilize the same pin.

(5) This GPIO is not required for power sequencing or PMIC functionality and can be configured by software for a different purpose if

desired.

Processor Connections www.ti.com

8Powering DRA821 with TPS6594-Q1 and LP8764-Q1 SLVUBY7A – OCTOBER 2020 – REVISED OCTOBER 2022

Submit Document Feedback

4 Supporting Functional Safety Systems

By using the TPS6594-Q1 and LP8764-Q1 solution to power the DRA821 processor, the system can leverage

the following PMIC functional safety features:

• Independent Power Control of MCU and Main Rails

• Independent Monitoring and Reset for MCU and Main Rails

• Input Supply Monitoring

• Output Voltage and Current Monitoring

• Question & Answer Watchdog

• Fault Reporting Interrupts

• Enable Drive Pin that provides an independent path to disable system actuators

• Error Pin Monitoring

• Internal Diagnostics including voltage monitoring, temperature monitoring, and Built-In Self-Test

Refer to the Safety Manuals of the TPS6594-Q1 and LP8764-Q1 devices for full descriptions and analysis of

the PMIC functional safety features. These functional safety features can assist in achieving up to ASIL-D rating

for a system. Additionally, these features help in achieving the functional safety assumptions utilized by the

processor to achieve up to ASIL-D rating. See the DRA821 Safety Manual for Jacinto™ 7 Processors for a

complete list of functional safety system assumptions.

4.1 Achieving ASIL-B System Requirements

To achieve a system functional safety level of ASIL-B, the following PDN features are available:

• PMIC over voltage and under voltage monitoring on the power resource voltage outputs

• PMIC over-voltage monitoring and protection on the input to the PMIC (VCCA)

• Watchdog monitoring of safety processor

• MCU error monitoring

• MCU reset

• I2C communication

• Error indicator, EN_DRV, for driving external circuitry (optional)

• Read-back of EN_DRV pin

The PDN has an in-line, external power FET between the input supply and PMICs. This FET can quickly isolate

the PMICs when an over-voltage event greater than 6 V is detected on the input supply to protect the system

from being damaged, as shown in Figure 3-1. Note that any power rail connected after the FET can be protected

from an over voltage event. Any power connected upstream from the FET is not protected from over voltage

events. In Figure 3-1 the load switches that supply power to the MCU and Main I/O domains and the discrete

buck supplying the DDR are all connected after the FET to extend the over voltage protection to these processor

domains and discrete power resources.

The PMIC internal over voltage and under voltage monitoring and their respective monitoring threshold levels

can be enabled through I2C after startup. To monitor the load switch voltage that supplies the MCU I/O of the

processor, it is recommended to use the processor POK monitor built into the VDDSHV0_MCU voltage domain.

The PMIC Internal Q&A Watchdog is enabled by default on the TPS6594-Q1 device. Once the device is in

ACTIVE state, the trigger or Q&A watchdog settings can be configured through the secondary I2C in the device.

The steps for configuring the watchdog settings can be found in the TPS6594-Q1 data sheet. Setting the

DISABLE_WDOG signal high on TPS6594-Q1 GPIO_8 disables the watchdog timer if this feature needs to be

suspended or is not required in the system.

GPIO_7 of the TPS6594-Q1 PMIC is configured as the MCU error signal monitoring, and must be enabled

though the ESM_MCU_EN register bit. MCU reset is supported through the connection between the primary

PMIC nRSTOUT pin and the MCU_PORz of the processor. Lastly, there are 2 I2C ports between the TPS6594-

Q1 and the processor. The first is used for all non-watchdog communication, such as voltage level control, and

the second allows the watchdog monitoring to be on an independent communication channel.

There is an option to use the EN_DRV of theTPS6594-Q1 PMIC to indicate an error has been detected and the

system is entering SAFE state. This signal can be utilized if the system has some additional external circuitry

that needs to be driven by an error event. In this PDN, the EN_DRV is not utilized, but available if needed.

www.ti.com Supporting Functional Safety Systems

SLVUBY7A – OCTOBER 2020 – REVISED OCTOBER 2022

Submit Document Feedback

Powering DRA821 with TPS6594-Q1 and LP8764-Q1 9

4.2 Achieving up to ASIL-D System Requirements

For ASIL-C or ASIL-D systems, there are additional features to the ones described in Section 4.1 that can be

utilized. These features include:

• PMIC current monitoring on all output power rails

• Isolation of the MCU and Main power domains of the processor

• SoC reset

The current monitoring is enabled by default for all BUCKs and LDOs for the TPS6594-Q1 and LP8764-Q1

devices. Additionally, Figure 3-1 shows that the MCU domain of the processor is powered by different power

resources of the PMICs than the main power domain of the processor. SoC reset functionality is supported

through the connection of GPIO_11 on TPS6594-Q1, configured as nRSTOUT_SoC, to the PORz pin of the

processor.

Note

Residual voltage checking is available on the PMICs to prevent startup when output rails are not

discharged below 100 mV as may happen under a fault condition. However, this feature is not

enabled in the NVM settings of this PDN to support repetitive power cycling during system software

development.

5 Static NVM Settings

The TPS6594-Q1 and LP8764-Q1 devices consist of fixed registers and configurable registers that are loaded

from the NVM. For all NVM registers, the initial NVM settings that load into the registers are provided in this

section. Note that these initial NVM settings can be changed during state transitions, such as moving from

STANDBY to ACTIVE mode. The full register map, including default values of fixed registers, is located in the

corresponding PMIC data sheet. Empty values indicate that the device does not have the register included. For

example, LP8764-Q1 does not have BUCK5 registers at all and therefore the values for it are empty.

5.1 Application-Based Configuration Settings

In the LP876441B1-Q1 and TPS6594141B-Q1 data sheet, there are multiple application-based configurations

for each BUCK to operate within. Table 5-1 includes the different configurations available:

Supporting Functional Safety Systems www.ti.com

10 Powering DRA821 with TPS6594-Q1 and LP8764-Q1 SLVUBY7A – OCTOBER 2020 – REVISED OCTOBER 2022

Submit Document Feedback

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Texas Instruments Matériel informatique

Texas Instruments

Texas Instruments TVP5154EVM Manuel utilisateur

Texas Instruments

Texas Instruments TPS65981EVM Manuel utilisateur

Texas Instruments

Texas Instruments TLV320AIC12KEVMB-K Manuel utilisateur

Texas Instruments

Texas Instruments TMS320F2837 D Series Manuel utilisateur

Texas Instruments

Texas Instruments Sitara AM1335 Series Manuel utilisateur

Texas Instruments

Texas Instruments DLPLCRC910EVM Manuel utilisateur

Texas Instruments

Texas Instruments TS3USB3031 Manuel utilisateur

Texas Instruments

Texas Instruments bq24650EVM Manuel utilisateur

Texas Instruments

Texas Instruments TMS320DM355 Manuel utilisateur

Texas Instruments

Texas Instruments TPA6141A2 Manuel utilisateur

Texas Instruments

Texas Instruments EV2300 Manuel utilisateur

Texas Instruments

Texas Instruments PGA411-Q1 EVM Manuel utilisateur

Texas Instruments

Texas Instruments TMS320TCI6482 Mode d’emploi

Texas Instruments

Texas Instruments TRIS TMS37122 Manuel utilisateur

Texas Instruments

Texas Instruments SimpleLink CC1312PSIP Manuel utilisateur

Texas Instruments

Texas Instruments TMS320C67X+ DSP Manuel utilisateur

Texas Instruments

Texas Instruments TPS7H4003EVM Manuel utilisateur

Texas Instruments

Texas Instruments ADS61B23EVM Manuel utilisateur

Texas Instruments

Texas Instruments BT-MSPAUDSOURCE-RD Manuel utilisateur

Texas Instruments

Texas Instruments CC1000PP Manuel utilisateur

Texas Instruments

Texas Instruments Chipcon Products CC2431 Manuel utilisateur

Texas Instruments

Texas Instruments LM38020QEVM Manuel utilisateur

Texas Instruments

Texas Instruments TAS3002 Guide d'installation et d'utilisation

Texas Instruments

Texas Instruments DUAL SOCKET PC CARD CONTROLLER PCI1520... Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
