Silvercrest WIRELESS SOCKET SET Manuel utilisateur

IAN 284705

OUTDOOR WIRELESS SOCKET SET

Operation and Safety Notes KAUKO-OHJATTAVA

ULKOPISTORASIA

Käyttö- ja turvaohjeet

AUSSEN-FUNKSTECKDOSEN-SET

Bedienungs- und Sicherheitshinweise

FJÄRRSTYRDA ELUTTAG

FÖR UTOMHUSBRUK

Bruksanvisning och säkerhetsanvisningar

LAUKUI SKIRTŲ NUOTOLINIO

VALDYMO KIŠTUKINIŲ LIZDŲ

RINKINYS

Nurodymai dėl valdymo ir saugumo

GB Operation and Safety Notes Page 5

FI Käyttö- ja turvaohjeet Sivu 23

SE Bruksanvisning och säkerhetsanvisningar Sidan 39

LT Nurodymai dėl valdymo ir saugumo Puslapis 55

DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 71

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the

device.

Käännä ennen lukemista kuvallinen sivu esiin ja tutustu seuraavaksi laitteen kaikkiin toimintoihin.

Vik ut bildsidan och ha den till hands när du läser igenom anvisningarna och gör dig bekant med

apparatens/maskinens funktioner.

Prieš skaitydami išlankstykite lapą su paveikslėliais ir susipažinkite su visomis prietaiso funkcijomis.

Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen

Funktionen des Gerätes vertraut.

Master

ON OFF

5GB

Table of contents

Legend of pictograms used .................................................................Page 6

Introduction ................................................................................................Page 7

Proper handling...........................................................................................Page 7

Scope of supply ..........................................................................................Page 7

Control elements.........................................................................................Page 7

Technical data.............................................................................................Page 8

Safety ............................................................................................................Page 9

Safety advice ..............................................................................................Page 9

Safety instructions for batteries/rechargeable batteries.......................Page 11

Setting up.....................................................................................................Page 12

Preparing the remote control.....................................................................Page 12

Setting up the remote-controlled socket ...................................................Page 13

Setting-up operation..............................................................................Page 15

Using the radiocontrolled socket...............................................................Page 15

Using the remote-control............................................................................Page 15

Troubleshooting...........................................................................................Page 16

Cleaning........................................................................................................Page 18

Disposal ........................................................................................................Page 18

Guarantee and service..........................................................................Page 19

Guarantee ...................................................................................................Page 20

Service address...........................................................................................Page 20

Declaration of conformity ..........................................................................Page 20

Manufacturer...............................................................................................Page 21

6 GB

Legend of pictograms used

Volt (AC voltage) Caution! Fire hazard!

Hertz (frequency)

Do not dispose of

electric appliances in

household rubbish!

Watt (eﬀective power)

Improper battery

disposal harms the

environment!

Observe warnings and

safety instructions!

Micro-switch with contact

opening <3mm

Beware of electric shock!

Danger to life! EU-compliant

IP44

Protected against water

spray and penetration by

solid foreign bodies

≥ 1mm diameter

7GB

Introduction

Outdoor Wireless

Socket Set

 Introduction



Proper handling

The radio-controlled socket set is

suitable for switching electrical de-

vices outside on and oﬀ by remote

control. Any modiﬁcation to the

device shall be considered as im-

proper use and can lead to consid-

erable risk of accident. The manu-

facturer will not accept liability

for loss or damage arising from

improper use. The appliance is not

intended for commercial use.



Scope of supply

After you have unpacked this set,

please check to make sure all the

contents are complete.

2 Remote-controlled sockets

RCR DP3 3711-A IP44 DE 3726

1 4-channel remote control

RCT DS1 CR-A 3726

1 Button cell CR 2032, lithium 3V

(for remote control)

1 Set of operating instructions



Control elements

Remote control RCT DS1

CR-A 3726 (fig. A):

1Power indicator light

2Channel ON/OFF button

Channel A, B, C, D

8 GB

Introduction

3Master ON/OFF switch

4Battery compartment lid

Remote-controlled socket

RCR DP3 3711-A IP44 DE

3726 (Fig. B):

5Cover

6Child-protected socket



Technical data

Wireless Socket Set

RC DP3 0201-A DE 3726

Remote control RCT DS1

CR-A 3726:

Battery: CR 2032,

lithium 3V

Frequency band: 433.05MHz -

434.79MHz

Radio frequency: 433.92MHz

Max. transmitting

power: 5 dBm

Licensing: The system is li-

censed for gen-

eral use, is free

of charge and

does not require

registration.

Range: Depending on

the circumstanc-

es approx. 40 m

under optimum

circumstances.

Remote-controlled socket

RCR DP3 3711-A IP44 DE

3726 suitable for

outdoor use (IP 44):

Rated voltage:

230 V~, 50 Hz

Breaking capacity:16A, 3,680W

Standby power

consumption: < 0.7 W

9GB

Introduction/Safety

Transmission

frequency: 433.92 MHz

Advice: The radio-controlled sock-

ets have a child protection socket

6, which signiﬁcantly increases

safety at home. The contacts are

protected in such a way that chil-

dren cannot stick needles or other

sharp objects into them and thus

get an electric shock. Nevertheless,

please keep the device out of the

reach of children at all times.

 Safety

Safety advice

Read these operating instructions

and safety advice carefully. Look at

the diagram page and familiarise

yourself with all functions of the de-

vice before starting it up for the ﬁrst

time.

Avoid danger to life from

electric shock!

Connect remote-controlled

sockets to earthed 230-volt

mains electrical outlet sockets

only.

Avoid overloading the device.

Overloading can cause a ﬁre

hazard or damage to the de-

vice. The maximum capacity is

approx. 3,680W per radio-

controlled socket.

CAUTION! Do not expose

the device to direct sunlight.

Please contact the service de-

partment immediately opera-

tional faults arise.

Do not open the device on any

account. All necessary repairs

10 GB

Safety

should only be carried out by

the service department or a

specialist electrical workshop

Before cleaning always discon-

nect the device from the mains

supply. In this case always

remove the radio-controlled

electrical outlet socket from the

mains wall socket and remove

all plugs from the device.

Do not have one radio-con-

trolled electrical outlet socket

inserted behind the other.

Do not use any additional child

protection devices for the

radio-controlled sockets. The

connection between the plug

and the radio-controlled socket

could be impaired and risk

from overheating then arises.

The radio-controlled sockets

already have a child protection

device which prevents children

from putting any objects into

the socket.

Ensure that the outlet is in-

stalled close to the connected

product, is easily accessible

and that the product is not

operated while covered.

If the device malfunctions,

switch it oﬀ immediately.

These instructions are a compo-

nent of the device. If you pass

the device on to a third party,

these instructions must also be

handed on.

Do not switch the wireless sock-

ets erratically or unattended.

11GB

Safety

instructions for

batteries/

rechargeable

batteries

DANGER TO LIFE! Keep

batteries/rechargeable batteries

out of reach of children. If acci-

dentally swallowed seek imme-

diate medical attention.

DANGER OF

EXPLOSION!

Never recharge

non-rechargeable batteries.

Do not short-circuit batteries/

rechargeable batteries and/or

open them. Overheating, ﬁre

or bursting can be the result.

Never throw batteries/recharge-

able batteries into ﬁre or water.

Do not exert mechanical loads

to batteries/rechargeable

batteries.

Risk of leakage of batteries/

rechargeable batteries

Avoid extreme environmental

conditions and temperatures,

which could aﬀect batteries/

rechargeable batteries, e.g.

radiators/direct sunlight.

Avoid contact with the skin, eyes

and mucous membranes. In the

event of contact with battery

acid, thoroughly ﬂush the aﬀected

area with plenty of clean water

and seek immediate medical

attention.

WEAR PROTEC-

TIVE GLOVES!

Leaked or damaged

batteries/rechargeable batteries

can cause burns on contact

with the skin. Wear suitable
