SIIG JJ-E02211-S1 Manuel utilisateur

DP CyberParallel

Dual PCIe

Installation Guide

04-0964A

Introduction

The DP CyberParallel Dual PCIe adds 2 high-

speed parallel ports to PCI Express enabled

systems and supports EPP/ECP and SPP

(standard) parallel port modes.

Features and Benefits

•PCI Express 1-lane (x1) I/O card works

with PCI Express slots with different lane

width

•Two parallel ports support ECP, EPP PS2

and SPP modes and works with various

types of parallel devices

• Supports various types of Windows®- based

application software

System Requirements

•PCI Express enabled system with an

available PCI Express slot

•Windows®

8 (32-/64-bit) / 7 (32-/64-bit) /

Vista (32-/64-bit) / XP (32-/64-bit) / Server

2003 & 2008 (32-/64-bit) / Server 2008 R2

/ 2000

Package Contents

•DP CyberParallel Dual PCIe host card

• FP bracket DB25 ribbon cable (plugged on

the board)

• LP bracket DB25 ribbon cable

• Spare low profile bracket for host card

• Driver CD

• Installation guide

Figure 1

*Note: When connecting the DB25 ribbon

cable to Parallel Port 2 (P2), position the

ribbon cable so the stripe is on the side

nearest to the slot bracket, see Figure 1.

Parallel Port

1 (P1)

Parallel Port

2 (P2)*

Stripe

Layout

pin 1

Hardware Installation

Note: For low profile systems, replace the

currently mounted bracket with the included

low profile bracket.

General instructions for installing the card are

provided below. Since the design of computer

cases and motherboards vary, refer to your

computer's reference manual for further

information, if needed.

Static Electricity Discharge may permanently

damage your system. Discharge any static

electricity build up in your body by touching

your computer case for a few seconds. Avoid any

contact with internal parts and handle cards

only by their external edges.

1. Turn OFF the power to your computer.

2. Unplug the power cord and remove the

computer cover.

3. Remove the slot bracket from an available

PCIe slot.

4. If you need the second parallel port, connect

the DB25 connector bracket now and

remove another slot bracket cover from an

available PCIe slot. Skip this step if you

need only one parallel port.

5. Carefully align the card to the selected PCIe

slot, push the board down firmly, but gently,

until it is well seated.

6. Replace the slot bracket holding screw to

secure the card.

7. Mount the second parallel port and secure

it with the slot bracket holding screw. Skip

this step if you need only one parallel port.

8. Replace the computer cover and reconnect

the power cord.

Software Installation

This section provides the steps on how to install

the DP CyberParallel Dual PCIe drivers. Please

make sure the board is installed before proceeding

with the driver installation.

Windows 8 (32-/64-bit) / 7 (32-/64-bit) /

Vista (32-/64-bit) / Server 2008 (32-/64-bit) /

Server 2008 R2

1. Insert the driver CD. Close the CD autoplay

box if prompted.

2. Check in Device Manager.

For Windows 8 / 7: Right click Computer,

click Manage, then click Device Manager.

For Windows Vista: Right click Computer,

click Manage, click Continue, then click

Device Manager.

For Windows Server 2008 / 2008 R2: Right

click Computer, click Manage, double click

Diagnostics, then click Device Manager.

Right click Computer, click Manage, click

Device Manager.

3. Right click PCI Parallel Port, click Update

Driver Software.

4. Click Browse my computer for updated

software.

For 32-bit: Type D:\32bit, click Next.

(Change D: to match your CD-ROM drive

letter)

For 64-bit / 2008 R2: Type D:\64bit, click

Next. (Change D: to match your CD-ROM

drive letter)

5. At Windows has successfully updated

your driver software, click Close.

6. Go back to Device Manager, right click PCI

Parallel Port, then click Update Driver

Software.

7. Repeat steps 4& 5, then restart the computer

to complete the installation.

Windows XP (32-/64-bit) / Server 2003 (32-/

64-bit)

1. Click Cancel at the Found New Hardware.

2. Insert the driver CD. Close the CD autoplay

box if prompted.

3. Right click My Computer, click Manage,

click Device Manager.

4. Click Update Driver...

5. Select Install from a list or specific location

(Advanced), then click Next.

6. Check Include this location in the search,

uncheck the other box.

For 32-bit: Type D:\32bit, click Next.

(Change D: to match your CD-ROM drive

letter)

For 64-bit: Type D:\64bit, click Next.

Change D: to match your CD-ROM drive

letter)

7. At Completing the Hardware Update

Wizard, click Finish.

8. Go back to Device Manager, right click PCI

Parallel Port.

9. Repeat steps 4 - 7, then restart the computer

to complete the installation.

Windows 2000

1. Insert the driver CD. Close the CD autoplay

box if prompted.

2. At the Found New Hardware Wizard, click

Next.

3. Select Search for a suitable driver for my

device (recommended), then click Next.

4. Select Specify the location, uncheck the

other boxes, then click Next.

5. Type D:\32-bit, click OK, then click Next

(Change D: to match your CD-ROM drive

letter)

6. At Completing the Found New Hardware

Wizard, click Finish, then restart the

computer to complete the installation.

To Verify Windows Installation

1. Check in Device Manager to verify

installation.

For Windows 8 / 7: Right click Computer,

click Manage, then click Device Manager.

For Windows Vista: Right click Computer,

click Manage, click Continue, then click

Device Manager.

For Windows XP / Server 2003 / 2000: Right

click My Computer, click Manage, click

Device Manager.

For Windows Server 2008 / 2008 R2: Right

click Computer, click Manage, double click

Diagnostics, then click Device Manager.

2. Double click Ports (COM & LPT), two PCI

ECP Parallel port... should be displayed.

Changing Parallel Port

Some parallel port devices need a specific LPT in

order to function properly. If your device works,

do not make any changes.

1. For Windows 8 / 7 / XP / 2003 / 2000: Right

click Computer or My Computer, click

Manage, then click Device Manager.

For Windows Vista: Right click Computer,

click Manage, click Continue, then click

Device Manager.

For Server 2008 / 2008 R2: Right click

Computer, click Manage, double click

Diagnostics, then click Device Manager.

2. Double click Ports (COM & LPT), then

double click the PCI ECP Parallel port you

want to change.

3. Click Port Settings tab.

4. Click the down arrow next to the LPT Port

Number box, then select a parallel port that

is not in use.

5. Click OK to save the changes.
