SIIG IO1037 Manuel utilisateur

Single-Serial PC Card

Quick Installation Guide

04-0254A

Introducing the

Single-Serial PC Card

The Single-Serial PC Card adds one high-speed serial port (RS232)

into your notebook computer to connect various types of serial

devices.

Keys Features and Benefits

• Works with notebook computers with one Type II/III PC

Card/CardBus slot

• Fast 16550 UART supports baud rates up to 115.2Kbps

• Built-in 16-byte FIFO buffer to speed up data transfer

• Provides one RJ45-to-serial (DB9) removable cable for device

connections

• Works with various types of RS232 serial devices including

modems, PDAs, label printers, bar code scanners, digital

cameras, and more

System Requirements

•Pentium or equivalent notebook computer with an available

CardBus slot

• Windows 98/98SE/ME/2000/XP

Package Contents

•One Single-Serial PC Card

•RJ45 to 9-pin serial port cable

•Driver diskette

•This quick installation guide

Hardware Installation

Generalinstructionsforinstallingthecardareprovidedbelow,since

thedesignofnotebookcomputersmayvary. Refertoyoursystem’s

reference manual for further information, if needed.

1. Power off your notebook computer and any other connected

peripheral devices.

2. Insert the PC Card into the PC Card slot of your notebook

computer with its 68-pin connector facing the slot. Make sure

it is inserted all the way in for a solid connection.

3. Plug the RJ45-to-9-pin serial port cable into the Single-Serial PC

Card.

4. Power on your notebook computer.

Figure 1. Inserting PC Card

Software Installation

Throughout driver installation, you may be prompted to insert your

Windows installation CD. Some files on this CD are neccessary to

complete the driver installation. Please insert the CD when

prompted and follow on-screen instructions.

Windows 98/98SE Driver Installation

1. At the Add New Hardware Wizard click Next.

2. Select Search for the best driver for your device

(Recommended), click Next.

3. Insert the driver diskette. Choose Floppy disk drives,

uncheck the other boxes, then click Next.

4. Click Next, then Finish.

5. Remove the driver diskette, then click Yes to restart.

Windows ME Driver Installation

1. At the Add New Hardware Wizard, choose Automatic search

for a better ...

2. Insert the driver diskette, click Next, then click Finish.

3. Remove the driver diskette and restart Windows to complete.

Windows 2000 Driver Installation

1. At the Found New Hardware Wizard, click Next.

2. Choose Search for a suitable driver ..., and click Next.

3. Insert the driver diskette, check Floppy disk drives, clear all

other check boxes, and click Next.

4. Click Next and Finish.

5. Remove the driver diskette and restart Windows to complete.

Windows XP Driver Installation

1. At the Found New Hardware Wizard, select Install the

software automatically (Recommended), insert the driver

diskette, then click Next.

2. At the Software Installation window, click Continue

Anyway. Our driver has been thoroughly tested in Windows for

stability. This message appears because Microsoft has not tested this

product through WHQL certification.

3. Click Finish.

4. Remove the driver diskette and restart Windows to complete.

To verify successful driver installation:

1. Check Device Manager to verify successful driver installation.

Windows 98/98SE/ME: From the main desktop, right click My

Computer, then click Properties. Click Device Manager tab.

Windows 2000/XP: Right click My Computer, then click

Manage. Click Device Manager.

2. Double click Ports (Com&LPT), find PCMCIA RS232-550...,

and double click it to display it's properties. In the next

window This device is working properly will display when

the installation is successful.

Changing the COM Port Assignment

Windows 2000/XP

1. Right click My Computer. Click Manage, then click Device

Manager.

2. Double click Ports (Com&LPT). Click PCMCIA RS232-550...,

then click Properties.

3. Click Port Settings, then Advanced.

4. Click the COM Port Number drop down box, scroll to an

available COM port settings then select it.

5. After selecting the new COM port setting click OK to save

your changes.

Windows 98/98SE/ME

COM Port Assignment is not adjustable in Windows 98/98 SE/

ME.

Technical Support

QUESTIONS? SIIG’s Online Support has the answers! Simply

visit our web site at

www.siig.com

and click on SUPPORT. Our

online support database is updated daily with new drivers and

solutions. The answers to your problems could be just a few clicks

away.

Return Merchandise Authorization (RMA)

SIIG warrants to the original buyer of the product that the

hardware is free of defects in materials and workmanship for a

period of one, two or five years from the date of purchase. If your

product fails to be in good working order during the warranty

period, you may return it to SIIG for repair or replacement at SIIG's

option.

To return the product, you need to follow these steps:

Step 1: Contact SIIG's RMA Department

To obtain an RMA number, SIIG's RMA Department can be

reached by phone at(510)413-5333or fax at(510)657-5962or email

at[email protected].In order to issue an RMA number, the product

serial number is required. This number can be found on the side

of the box and on the back of the product.

Step 2: Complete the RMA form

• Fill out your Return Merchandise Authorization (RMA) form,

and include it in the package with the product.

• Properly pack the product for shipping. All software, cable(s)

and other accessories that came with the original package

must be included.

• Clearly write your RMA number on the top of the returned

package and on the accompanying RMA form.

SIIG will refuse to accept any shipping package, and will not

be responsible for a product returned without an RMA

number posted on the outside of the shipping carton.

Step 3: Ship the Product

You are responsible for the cost of shipping back to SIIG at the

following address:

SIIG, Inc. RMA#_______________

6078 Stewart Ave.

Fremont, CA 94538

SIIG will ship the repaired or replaced product via UPS Ground

PRODUCT NAME MODEL NUMBER

Single-Serial PC Card IO1037

FCC RULES: TESTED TO COMPLY WITH FCC PART 15, CLASS B

OPERATING ENVIRONMENT: FOR HOME OR OFFICE USE

FCC COMPLIANCE STATEMENT:

This device complies with part 15 of the FCC Rules. Operation is subject to

the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

FCC NOTICE:

This equipment has been tested and found to comply with the limits for a

ClassBdigitaldevice,pursuantto part 15oftheFCCRules.These limits are

designed to provide reasonable protection against harmful interference in a

residentialinstallation.Thisequipmentgenerates,uses,andcanradiateradio

frequency energy and if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications.

However,thereisnoguaranteethatinterferencewillnotoccurinaparticular

installation. If this equipment does cause harmful interference to radio and

television reception, which can be determined by turning the equipment off

andon,theuserisencouragedtotrytocorrecttheinterferencebyoneormore

of the following measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and the receiver

• Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected

• Consult the dealer or an experienced radio or TV technician for help

Caution:

Any changes or modifications not expressly approved by the party

responsibleforcompliancecouldvoidtheuser'sauthoritytooperate

this equipment

THE PARTY RESPONSIBLE FOR

PRODUCT COMPLIANCE

SIIG, Inc.

6078 Stewart Ave.

Fremont, CA 94538-3152

Single-Serial PC Card is a trademark of SIIG, Inc.

SIIG and SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are

registered trademarks of Microsoft Corporation. Pentium is a registered trademark of Intel

Corporation. Othernamesusedinpublicationareforidentificationonlyandmaybetrademarks

of their respective companies.
