DP PCI-to-PS/2
Quick Installation Guide
Introducing the DP PCI-to-PS/2
The DP PCI-to-PS/2 easily add PS/2 ports to your PCI
equipped desktop.
Features and Benefits
• ProvidestwoPS/2portsforPS/2keyboard&mouse
connectivity
• Keeps your PS/2 keyboard and mouse around
longer
• Installs in standard height or low profile system
chassis with included brackets
• Compliant with PCI 2.2 Specification
• Easy plug-n-play installation
System Requirements
• Pentium®-equivalent desktop with an available
PCI slot
• Windows®2000 / XP (32-/64-bit) / Server 2003
(32-/64-bit) / Vista (32-/64-bit)
PackageContents
•DP PCI-to-PS/2 adapter
• Spare low profile bracket
• Quick Installation Guide
2
Layout
PS/2 Mouse
connector
PS/2 Keyboard
connector
Figure 1: Layout
Hardware Installation
Note: For low profile systems, replace the currently
mounted bracket with the included low profile bracket.
General instructions for installing the card are provided
below, since the design of computer cases and
motherboards vary. Refer to your computer’s reference
manual for further information, if needed.
Static Electricity Discharge may permanently damage
your system. Discharge any static electricity build up in
your body by touching your computer case for a few
seconds. Avoid any contact with internal parts and
handle cards only by their external edges.
1. Turn OFF the power to your computer and any
other connected peripheral devices. Unplug the
power cord.
2. Remove your computer cover and install the card in
an available PCI slot.
3
3. Carefully align the card to the selected PCI slot,
push the board down firmly, but gently, until it is
well seated.
4. Replace the slot bracket holding screw to secure the
card.
5. Connect the PS/2 keyboard and/or mouse to the
appropriate PS/2 connector.
6. Replacethecomputercoverandreconnectthepower
cord.
Driver Installation
Just install the board and Windows will automatically
detect and install the correct drivers for it. No additional
driver is necessary.
To Verify Windows Installation
The only way to verify the board works is actually
connecting a device to the PS/2 port.
Note: Keyboard or mouse cannot be use in DOS
using a bootable disk or for entering the system
BIOS. It is not supported.
4
Blank Page
5
Blank Page
6
Blank Page
7
Technical Support and Warranty
QUESTIONS? SIIG’sOnline Support has answers! Simplyvisitour
web site at www.siig.com and click Support. Our online support
database is updated daily with new drivers and solutions. Answers
toyour questionscould be justa fewclicksaway. You canalso submit
questions online and a technical support analysts will promptly
respond.
SIIGoffers a5-year manufacturerwarranty withthis product. Please
see our web site for more warranty details. If you encounter any
problems with this product, please follow the procedures below.
A) If it is within the store's return policy period, please return the
product to the store where you purchased from.
B) Ifyour purchasehas passedthestore's returnpolicy period,please
follow these steps to have the product repaired or replaced.
Step 1: Submit your RMA request.
Go to www.siig.com, click Support, then RMA to submit a
request to SIIG RMA. If the product is determined to be
defective, an RMA number will be issued.
Step 2: After obtaining an RMA number, ship the product.
•Properly pack the product for shipping. All software, cable(s)
and any other accessories that came with the original package
must be included.
•Clearly write your RMA number on the top of the returned
package. SIIG will refuse to accept any shipping package, and
will not be responsible for a product returned without an
RMA number posted on the outside of the shipping carton.
•You are responsible for the cost of shipping. Ship the product
to the following address:
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
RMA #:
•SIIG will ship the repaired or replaced product via Ground
in the U.S. and International Economy outside of the U.S. at
no cost to the customer.
DP PCI-to-PS/2 is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG,
Inc. Microsoft, Windows and Windows Vista are either registered trademarks or trademarks of
MicrosoftCorporationintheUnitedStatesand/orothercountries. Pentiumisaregisteredtrademark
of Intel Corporation. Other names used in this publication are for identification only and may be
trademarksoftheirrespectivecompanies.
July, 2008 Copyright © 2008 by SIIG, Inc. All rights reserved.
About SIIG, Inc.
Foundedin1985,SIIG,Inc.isaleadingcomputerupgrademanufacturer
of I/O connectivity products, including PCIe, PCI & ISA serial and
parallel ports, USB, Serial ATA & UltraATA controllers, FireWire
(1394a/b),networking,sound cards,andotheraccessories. SIIG isthe
premier one-stop source of upgrades.
SIIGproductsoffer comprehensive usermanuals,manyuser-friendly
features, and are backed by an extensive manufacturer warranty.
High-quality control standards are evident by the overall ease of
installation and compatibility of our products, as well as one of the
lowest defective return rates in the industry. SIIG products can be
found in computer retail stores, mail order catalogs, through major
distributors, system integrators, and VARs in the Americas and the
UK, and through e-commerce sites.
PRODUCT NAME
DP PCI-to-PS/2
FCC RULES: TESTED TO COMPLY WITH FCC PART 15, CLASS
B OPERATING ENVIRONMENT: FOR HOME OR OFFICE USE
FCCCOMPLIANCESTATEMENT:
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
THE PARTY RESPONSIBLE FOR PRODUCT COMPLIANCE
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
