Sanus New VisionMount VMT15 Manuel utilisateur

Places ultra-thin flat-panel TVs just .77" from the wall

The new HDpro™VMT15 Super Slim tilting mount places LCD, plasma

and LED TVs just .77" from the wall for an incredibly thin appearance, and

it offers technologies not found on other ultra-thin mounts. With fingertip

tilt, finding the perfect TV viewing angle is effortless—angle adjustments

can be made with the touch of a finger. The VMT15 also features ProSet™

technology for post-installation height and level adjustments, and the

ClickStand™mechanism holds TVs away from the wall, making cable

access as easy as possible.

Convenient quick-release tabs

on mounting brackets stay

hidden, but easily pull down to

unlock TV from wall plate for

cable access

Super Slim tilting mount

sits just .77" from wall to

complement the sleek look

of ultra-thin TVs

Innovative ClickStand™mechanism

holds TV away from wall for easy

cable access

VMT15-B1 shown

MODEL VMT15-B1

www.sanus.com • 800.359.5520

Lateral shift allows TV to move left and

right for perfect placement, even with

off-center studs

ProSet™post-installation height

and leveling adjustments allow

TV to be perfectly positioned

after hanging

Fingertip tilt allows easy

TV angle adjustments

with the touch of a finger

Tilting

NEW visioNmouNt®

Super Slim Tilting Mount

MODEL VMT15 Tilting Mount for 26" – 46" TVs

PRODUCT DIMENSIONS (w x d x h)

24.1" x .77" x 17.3"

61.2 x 2 x 43.8 cm

PACKAGE DIMENSIONS (w x d x h)

32.6" x 2.6" x 8.7"

82.9 x 6.5 x 22.1 cm

PACKAGE WEIGHT

7.9 lbs / 3.6 kg

TV SIZE/WEIGHT CAPACITY

26" – 46" / 100 lbs

66 – 116 cm / 45 kg

PROFILE

.77" / 2 cm

FINISH

Black – VMT15

•Super Slim tilting mount sits just .77" from wall to complement the sleek look of

ultra-thin TVs

•ProSet™post-installation height and leveling adjustments allow TV to be perfectly

positioned after hanging

•Convenient quick-release tabs on mounting brackets stay hidden, but easily pull

down to unlock TV from wall plate for cable access

•Lateral shift allows TV to move left and right for perfect placement, even with

off-center studs

•Fingertip tilt allows easy TV angle adjustments with the touch of a finger

•Innovative ClickStand™mechanism holds TV away from wall for easy cable access

MASTER PACK QUANTITY

MASTER PACK DIMENSIONS

(w x d x h)

25" x 16.7" x 9.1"

63.5 x 42.5 x 23 cm

MASTER PACK WEIGHT

33.4 lbs / 15.2 kg

LIST PRICE

$149.99

AVAILABLE

August 25, 2010

UPC

793795521958

www.sanus.com • 800.359.5520

VMT15-B1 SHOWN

NEW visioNmouNt®

Super Slim Tilting Mount

Super Slim design ProSet™adjustments Quick-release tabs

Fingertip tilt ClickStand™ mechanismLateral shift

MOUNTING PATTERN 100x100

200x100

200x200

300x200

400x200

500x200

300x300

400x300

400x400

500x400

600x400

800x400

Universal » Width: 147 – 571.5 mm

    a a a a a a a a a   a 

Height: 15 – 410 mm
