Secura QLF210 Manuel utilisateur

QLF

210

INSTRUCTION MANUAL

We’ll Make It Stress-Free

If you have any questions along the way, just give us a call.

1-800-359-5520. We’re ready to help!

IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE

1 Does your TV weigh more than 110 lbs. (49.8 kg) including accessories?

—

Perfect!

Yes

—

This mount is NOT compatible. Visit secura-av.com or call 1-800-359-5520 (UK: 0800-056-2853) to ﬁnd a compatible mount.

2 What is

your wall

made of?

3 Do you

have all

the tools

needed?

4 Ready to begin?

Please read through these instructions completely to be sure you’re comfortable with this easy install process. Also check your TV owner’s manual to

see if there are any special requirements for mounting your TV.

If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product, contact Customer

Service at 1-800-359-5520 (UK: 0800-056-2853).

CAUTION: Avoid potential personal injuries and property damage!

●This product is designed for use in wood stud, solid concrete, and concrete block walls - DO NOT install into drywall alone

●The wall must be capable of supporting ﬁve times the weight of the TV and mount combined

●Do not use this product for any purpose not explicitly speciﬁed by manufacturer

●Manufacturer is not responsible for damage or injury caused by incorrect assembly or use

110 lbs.

(49.8 kg)

Solid concrete

or concrete

block?

Perfect!

Drywall with

wood studs?

Perfect!

CAUTION:

DO NOT

install into

drywall alone

Unsure?

Call Customer Service:

1-800-339-5520

(UK: 0800-056-2853)

Wood Stud Install

Concrete Install

Tape

Measure Pencil Level Screw

driver

Electric

Drill

Socket

Wrench

Stud

Finder Awl Wood

Drill Bit

Masonry

Drill Bit Hammer

3/8 in.

(10 mm)

1/2 in.

(13 mm) 7/32 in.

(5.5 mm)

Before getting started, let’s make sure this mount is perfect for you!

Dimensions in. [mm]

TV INTERFACE

WALL PLATE

TV INTERFACE - OPTION 2

TOP VIEW - EXTENDED

TOP VIEW - RETRACTED

SIDE VIEW - EXTENDED

SIDE VIEW - RETRACTED

3-D

610mm

24.02in

400mm

15.75in

265mm

10.43in

200mm

7.87in

80mm

3.15in

9mm

.35in

145mm

5.71in

200mm

7.87in

200mm

7.87in

100mm

3.94in

ESTIMATED 55"

25deg 25deg

185mm

7.28in

269.5mm

10.61in

5deg

15deg

84.5mm

3.33in

NOTE: TV shifts 7.28 in. (18.5 cm) to the right

or left when in the home position. Consider this

when selecting the location of your wall mount.

M6 x 12mm M6 x 35mm

M8 x 16mm M8 x 35mm

M8 x 20mm

M8 x 14mm M6 / M8 22mm

NOTE: Not all hardware included will be used.

WARNING: This product contains small items that could be a choking hazard if swallowed.

Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to

your dealer; contact Customer Service. Never use damaged parts!

Supplied Parts and Hardware

STEP 1 Parts and Hardware

Horizontal TV

Bracket

TV Plate

Wall Plate

Vertical TV

Bracket

TV Screws

Washers

Spacers

Screws (TV Plate)

TV Bracket

Screws

11 x4

08 x4

07 x4

06 x8

10 x4

09 x4

12 x4

13 x4

04 x2

05 x2

02 x1

01 x1

03 x2

Adjustments

.695 x .350 x.075 in.

5/16 x 2¾ in.

STEP 2 Parts and Hardware

4mm

5mm

Hex Keys

Lag Bolts

Lag Bolt Washers

15 x3

14 x3

For concrete installations ONLY

CAUTION: Do not use in drywall or wood

16 x3

Anchors (Concrete) Ux10x60R

17 x1

18 x1

STEP 1 Attach TV Bracket to TV

1.2 Measure Your TV Hole (VESA) Pattern1.1 Prepare the TV Plate

Measure the width and height of your TV hole (VESA) pattern in mm.

Record your measurements:

Separate TV bracket 01 from wall plate 02 by removing the two screws

03 using hex key 17 .

NOTE:

Save the screws 03 and wall plate 02 for later installation.

inches

xHeight

Width mm mm

inch dimensions are approximate

75 mm = 7.5 cm ≈ 3 in.

100 mm = 10 cm ≈ 4 in.

200 mm = 20 cm ≈ 7 7/8 in.

300 mm = 30 cm ≈ 11 3/4 in.

400 mm = 40 cm ≈ 15 3/4 in.

600 mm = 60 cm ≈ 23 5/8 in.

01 03

These smaller hole patterns only use TV plate 01 .

Do not use TV brackets 04 and 05 , and four screws 06 .

Assemble TV plate 01 onto TV brackets 04 as illustrated.

Secure with four screws 06 , using hex key 18 as shown.

100 x 100

200 x 200

300 x 400

400 x 400

600 x 400

100

200

1.3 Assemble Your TV Bracket

Determine which TV bracket configuration to use, A or B based

on your TV hole (VESA) pattern measurements.

Dimensions in mm

TV Hole (VESA)

Pattern (in mm)

TV Hole (VESA)

Pattern (in mm)

06 18

04 01

200

Standard configurations

are shown. For special

applications, or if you

are uncertain about your

hardware selection,

contact Customer Service

at 1-800-359-5520.

1.4 Screw Diameter 1.5 Determine Spacers and Screw Length

a:Use no spacers for:

Flat back TVs (AND TV

closer to the wall).

CAUTION:

Verify adequate

thread engagement with your

screw/washer/spacer combination

AND TV bracket.(STEP 1.3)

-Too short will not hold the TV.

-Too long will damage the TV.

Too Short Too Long

Correct

b:Spacers supplied for:

●Round (irregular) back TVs

●Extra space needed (for cables

or inset mounting holes)

FLAT BACK ROUND BACK CABLES INSET HOLES

Hand thread screws into

the threaded inserts on the

back of your TV to determine

which screw diameter (M6,

or M8) to use.

1.6 Attach TV Bracket to TV *

Position TV plate 01 over your TV hole pattern and secure using your selection: (a) screw/washer or (b) screw/washer/spacer.

CAUTION: Avoid potential personal injuries and property damage! DO NOT use power tools for this step. Tighten the screws only

enough to secure the TV bracket to the TV. DO NOT overtighten the screws.

For TV Hole

(VESA) Patterns

07 08 09

10 11

aFlat Back

bIrregular Back / Extra Space

0101

100 x 100

200 x 200

1.6 Attach TV Bracket to TV *

07 08 09

10 11

Slide TV brackets 05 onto the ends of the TV bracket assembly (TV plate 01 and TV bracket 04 ) as shown.

Center all pieces horizontally and vertically over your TV hole pattern and secure together using four screws 06 using hex key 18 .

Secure the entire assembly to your TV using your selection: (a) screw/washer or (b) screw/washer/spacer.

CAUTION: Avoid potential personal injuries and property damage!

DO NOT use power tools for this step. Tighten the screws only enough to

secure the TV bracket to the TV. DO NOT overtighten the screws. aFlat Back

bIrregular Back / Extra Space

01 04

For TV Hole

(VESA) Patterns

300 x 400

400 x 400

600 x 400
