Ruijie RG-S6100 Series Switches

S6100_RGOS 12.6(2)B1101

Release Notes

Document Version: V1.1

Date: April 10, 2023

All rights are reserved in this document and this statement.

Any reproduction, excerption, backup, modification, transmission, translation or commercial use of this document

or any portion of this document, in any form or by any means, without the prior written consent of Ruijie Networks

is prohibited.

Trademark and are owned by Ruijie Networks.

All other trademarks or registered trademarks mentioned in this document are owned by their respective owners.

Disclaimer

The products, services, or features you purchase are subject to commercial contracts and terms. Some or all of

the products, services or features described in this document may not be within the scope of your purchase or

use. Unless otherwise agreed in the contract, Ruijie Networks does not make any express or implied statement

or guarantee for the content of this document.

Due to product version upgrades or other reasons, the content of this document will be updated from time to

time. Ruijie Networks reserves the right to modify the content of the document without any notice or prompt.

This manual is for reference only. Ruijie Networks endeavors to ensure content accuracy and will not shoulder

any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.

Release Notes Version Information

Preface

Intended Audience

This document is intended for:

Network engineers

Technical support and servicing engineers

Network administrators

Technical Support

Ruijie Networks Website: https://www.ruijienetworks.com/

Technical Support Website: https://ruijienetworks.com/support

Case Portal: https://caseportal.ruijienetworks.com

Community: https://community.ruijienetworks.com

Technical Support Email: [email protected]

Skype: [email protected]

Conventions

1. Conversions

Convention

Description

Bold font

Commands, command options, and keywords are in bold font.

Italic font

Arguments for which you supply values are in italic font.

[ ]

Elements in square brackets are optional.

{ x | y | z }

Alternative keywords are grouped in braces and separated by

vertical bars.

[ x | y | z ]

Optional alternative keywords are grouped in brackets and

separated by vertical bars.

&<1-n>

The argument before the sign (&) can be input for consecutive 1- n

times.

Double slashes at the beginning of a line of code indicate a

comment line.

2. Signs

The signs used in this document are described as follows:

Release Notes Version Information

Warning

An alert that calls attention to important rules and information that if not understood or followed can result in

data loss or equipment damage.

Caution

An alert that calls attention to essential information that if not understood or followed can result in function

failure or performance degradation.

Note

An alert that contains additional or supplementary information that if not understood or followed will not lead to

serious consequences.

Specification

An alert that contains a description of product or version support.

Release Notes Version Information

1 Version Information

Version Number

RGOS12.6(2)B1101

Applicable Products

S6120-24XMG4XS4VS-UP-H

S6120-48XMG4VS2QXS-UP-H

S6110-24MG4VS-UP

S6110-48MG4VS2QXS-UP

Category

Official Release

Customers

Global customers

Release Date

April 10, 2023

Baseline Version

RGOS 12.6(2)B1302

Reason for Release

New arrivals of multi-GE series products are officially released.

Use the show version detail command to check the version number.

Ruijie#show version detail

System description : Ruijie 10G Ethernet Switch(S6120-24XMG4XS4VS-UP-H) By

Ruijie Networks

System start time : 2023-02-10 17:42:22

System uptime : 06:22:37:54

System hardware version : 1.00

System software version : S6100_RGOS 12.6(2)B1101

System patch number : NA

System software number : M20102304042023

System serial number : G1RW31900033B

System boot version : 1.4.27(Master) 1.4.27(Slave)

System rboot version : 1.1.39

System core version : 4.4.178-dirty

Module information:

Slot 1/0 : S6120-24XMG4XS4VS-UP-H

System uptime : 06:22:37:53

Hardware version : 1.00

Boot version : 1.4.27(Master) 1.4.27(Slave)

Rboot version : 1.1.39

Software version : S6100_RGOS 12.6(2)B1101

Software number : M20102304042023

Serial number : G1RW31900033B

Slot 2/0 : S6120-48XMG4VS2QXS-UP-H

System uptime : 06:22:37:54

Hardware version : 1.00

Release Notes Version Information

Boot version : 1.4.27(Master) 1.4.27(Slave)

Rboot version : 1.1.39

Release Notes Release Record

2 Release Record

Note

After the version was released, the upgrade file may be released (identified by ID) because bugs were found

and resolved.

Release Date

Upgrade File

Description

February 17, 2023

S6100_RGOS12.6(2)B1101_10141008_install.bin

Pilot release for new RG-

S6100 series multi-GE

switches

April 10, 2023

S6100_RGOS12.6(2)B1101_install.bin

Official release for new

RG-S6100 series multi-GE

switches

Release Notes Hardware Support

3 Hardware Support

Note

The hardware version number is rounded to the first decimal place. The numeral in the second decimal place

does not affect software version support.

Hardware Type

Hardware Model

Version Number

Chassis

S6120-24XMG4XS4VS-UP-H

1.x

Chassis

S6120-48XMG4VS2QXS-UP-H

1.x

Chassis

S6110-24MG4VS-UP

1.x

Chassis

S6110-48MG4VS2QXS-UP

1.x

Note

For details, see Hardware Installation and Reference Guide.

Release Notes Resolved Issues

4 Resolved Issues

Notice

For details about the preceding bugs, see Warning Notice.

Release Notes Remaining Issues

5 Remaining Issues

Bug ID

761952

Description

When configuring the VLAN ID range-based selective QINQ, there should be no

more than 8 VLAN IDs in each range. For example, for the C-TAG based QINQ,

the command dot1q outer vid 20 register inner vid 1-8,1-10,12-15 successfully

configures two VLAN ID ranges (range 1-8 and range 12-15), and range 1-10 fails

to be configured.

Workaround

Perform integrated service planning to avoid assigning discrete VLANs to different

services.

Release

RGOS12.5(4)B1102

Bug ID

881776

Description

On Ruijie Cloud, the port rate options of a 25 Gbps port include 1000 Mbps.

However, the actual 25 Gbps port on the switch does not support the 1000

Mbps port rate.

When the port rate of a 25 Gbps port on Ruijie Cloud is configured as

10Gbps/25G Gbps, a succes message will be displayed on the Ruijie Cloud,

but the configruation does not take effect on the switch.

Workaround

Do not configure the port rate of a 25 Gbps port on Ruijie Cloud.

Release

RGOS12.5(4)B1102

Bug ID

873037

Description

The cross-chip bandwidth of S6110-48MG4VS2QXS-UP and S6120-

48XMG4VS2QXS-UP-H is 50 Gbps. That is, the two 25G ports form a 50G

aggregate interface and forward traffic in load balancing mode.

The default mode is enhanced load balancing:

1. Load balancing based on source and destination MAC addresses for Layer 2

packets without IP headers

2. Load balancing based on source and destination IP addresses for Layer 3

packets with IP headers

Packet forwarding through the HG port across chips has the following restrictions:

1. If the packets contain same Layer 2 source and destination MAC addresses or

same Layer 3 source and destination IP addresses, the packets will be forwarded

by one HG port and the maximum forwarding bandwidth is 25 Gbps.
