Ruijie Reyee RG-ES106D-P Manuel d'installation et d'exploitation

RG-ES106D-P,RG-ES126S-LP,RG-ES110D-P,

RG-ES118S-LP,RG-ES116G, RG-ES124GD

Series Switch

Hardware Installation and Reference Guide

Document

Version: V1.2

Date: 2023-02-15

All rights arereservedin this documentandthis statement.

Without the priorwritten consentof Ruijie Networks,anyorganizationorindividual shall notreproduce,extract,

back up, modify, or propagatethe content of this documentinany mannerorin anyform, or translateit into

other languagesoruse some orallparts of the documentforcommercial purposes.

,, andother Ruijie networks logos are

trademarks ofRuijieNetworks.

All othertrademarks orregistered trademarks mentionedinthis documentare owned bytheir respective

owners.

Disclaimer

The products,services,orfeatures you purchasearesubjecttocommercialcontracts andterms,andsomeor

allof the products,services,orfeatures describedinthis document maynot be available for you to purchaseor

use.Except for the agreementinthe contract,RuijieNetworks makes no explicitorimplicitstatementsor

warranties withrespecttothe content of this document.

The content of this documentwill be updatedfrom timeto timedue to productversionupgrades orother

reasons,Ruijie Networksreserves the rightto modifythe content of the documentwithoutanynotice or prompt.

This manualis designedmerelyas auserguide.RuijieNetworks has triedits bestto ensuretheaccuracyand

reliabilityof the content whencompiling this manual,butit does notguaranteethat the content of the manual is

completelyfree of errors or omissions,and all the information in this manual doesnotconstituteanyexplicit or

implicitwarranties.

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide

Preface

Thank you for usingourproducts.This manual willguideyouthroughtheinstallation ofthe device.

This manual describes the functional and physical features and provides the device installation steps, hardware

troubleshooting,moduletechnicalspecifications,andspecifications and usageguidelines forcables andconnectors.

Audience

It is intended fortheusers whohave some experiencein installingand maintaining networkhardware.At thesame time,

it is assumedthatthe users arealreadyfamiliarwiththe relatedterms and concepts.

Obtaining Technical Assistance

Ruijie Networks website:https://www.ruijienetworks.com/

Technicalsupportwebsite:https://ruijienetworks.com/support

Caseportal:https://caseportal.ruijienetworks.com

Community:https://community.ruijienetworks.com

Technicalsupportemail:service_rj@ruijienetworks.com

Skype: service_rj@ruijienetworks.com

Related Documents

Document

Description

ConfigurationGuide

Describes network protocols and related mechanisms that

supported bythe product,with configurationexamples.

Command Reference

Describes the related configuration commands, including

command modes, parameter descriptions, usage guides, and

relatedexamples.

Conventions

1. GUI Symbols

Interface

symbol

Description

Example

Boldface

1. Button names

2. Window names, tab name, field name

andmenuitems

3. Link

1. Click OK.

2. Select Config Wizard.

3. Click the Download File link.

Multi-level menus items

ChooseSystem >Time.

2. Signs

The signs used in this documentaredescribed as follows.

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide

Warning

An alert that calls attention to importantrules and information thatif not understood orfollowed can resultin

data loss orequipmentdamage.

Caution

An alert that calls attention to essential information thatifnot understood orfollowed can resultin function

failureor performancedegradation.

Note

An alert that contains additional orsupplementaryinformation thatifnot understood orfollowed will notlead to

serious consequences.

Specification

An alert that contains adescription ofproductor version support.

1 Product Overview

The RG-ES100series switchesincludethefollowingmodels.

Model

10/100Base-TX Auto-sensing

Ethernet Port

10/100/1000Base-T

Auto-sensing

Ethernet Port

1000Base-X SFP

Port

Console

Port

RG-ES106D-P

6 (ports 1–4supportPoE/PoE+)

N/A

RG-ES126S-LP

24(ports 1–24supportPoE/PoE+)

1 (combo)

N/A

RG-ES110D-P

8 (ports 1–8supportPoE/PoE+)

N/A

RG-ES116G

N/A

RG-ES124GD

N/A

RG-ES118S-LP

16 (ports 1–16supportPoE/PoE+)

2 (combo)

N/A

1000Base-Tis backward compatiblewith100Base-TXand 10Base-T.

The SFP ports cannotbe backward compatible with 100Base-FX.

1.1 RG-ES106D-P

Technical Specifications

Model

RG-ES106D-P

Ports

Six 10/100Base-TXauto-sensingEthernetports

Ports 1–4 supportPoE/PoE+.

Power Supply

AC input

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide

Rated voltage range: 100V AC to 240 V AC

Maximum voltage range: 90V AC to 264 V AC

Frequency: 50/60 Hz

Rated current: 1.5 A

Adapter output

Rated voltage range: 51V DC

Rated current range:1.25 A

EEE

Not supported

PoE

PoE/PoE+ support

Ports 1 to4 support PoE/PoE+with themaximum power outputof 30W per port.Ports 5–6do

not supportPoEor PoE+.

The overall maximum outputpowerofPoE or PoE+ is 58 W.

Power

Consumption

Less than7 W with noPoE load

Less than 67 W withPoE full load

Operating

Temperature

0°C to 45°C (32°Fto 113°F)

Storage

Temperature

-40°C to +70°C (-40°F to +158°F)

Operating Humidity

10%to 90%RH

Storage Humidity

5% to 95% RH

Port Mode

Switchover in threemodes:

1. Flow Control On

2. Flow Control Off

3. Port Isolation

When port isolation is enabled, ports 1-4are isolated from each other, but can communicate

with ports 5 and6.

Fan

Not supported

Temperature

Warning

Not supported

Accessing Optical

Module Information

Not supported

Certification

Earth Leakage

Current

≤1.5 mA

Dimensions

(W x D x H)

100mm x 100mm x 26 mm (3.94in. x 3.94 in. x 1.02 in.)

Weight

(With Package)

0.66 kg (1.46lbs)

Device operationin a residential environmentmaycauseradio interference.

Product Appearance

The RG-ES106D-P provides six 10/100Base-TX auto-sensing Ethernet ports on the front panel, and a port mode

switchoverbutton, a system status LED,a powersocket,and a grounding poleontheback panel.

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide

Figure 1-1 Appearanceof the RG-ES106D-P

Front Panel

Figure 1-2 Front Panel of the RG-ES106D-P

Note:

1. Electrical port status LED

2. PoE status LED

3. 10/100Base-TXPoE port

4. 10/100Base-TXauto-sensing Ethernetport

5. Nameplate on the bottom of the device

Back Panel

Figure 1-3 Back Panel of the RG-ES106D-P

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide

Note:

1. Port mode switchoverbutton

2. System status LED

3. DC powersocket

4. Grounding pole

Heat Dissipation

The RG-ES106D-P adopts natural heat dissipation, therebyensuring normal operation. You must maintain aminimum

clearance of100mm (3.94in.)aroundthe RG-ES106D-P.Itis recommendedthatyou clean the RG-ES106D-Ponceevery

3 months to avoid dustfrom blockingvents.

LEDs

LED

Panel Identification

State

Meaning

System status LED

PWR

Off

The switchis poweredoff.

Solidgreen

The switchis operational.

RJ45 port status LED

Upper leftcornerofthe

port

Off

The port is not connected.

Solidgreen

The port is connectedat a rate of 10/100 Mbps.

Blinking green

The port is receiving or sending traffic at a rateof

10/100Mbps.

RJ45PoE status LED

Upper leftcornerofthe

port

Off

PoE does notsupplypower.

Solidgreen

PoE is operational.

1.2 RG-ES126S-LP

Technical Specifications

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide

Model

RG-ES126S-LP

Ports

Ports 1 to 24are 10/100Base-TXauto-sensing Ethernetports,andsupportPoE/PoE+.

Ports 25and 26 are 10/100/1000Base-Tauto-sensing Ethernetports, anddonotsupportPoE

or PoE+.

Port 26Fis a 1000Base-XSFPport multiplexedwith port 26 as a combo port,and theSFPport

is preferred.

Power Supply

AC input

Rated voltage range: 100V AC to 240 V AC

Maximum voltage range: 90V AC to 264 V AC

Frequency: 50/60 Hz

Rated current: 4 A (max.)

EEE

Not supported

PoE

PoE/PoE+ support

Ports 1to24support PoE/PoE+withthemaximum power outputof30W perport.Ports 25and

26 donot supportPoE or PoE+.

The overall maximum outputpowerofPoE or PoE+ is 180 W.

Power

Consumption

Less than 10 W withno PoE load

Less than 220 W with PoE full load

Operating

Temperature

0°C to 45°C (32°Fto 113°F)

Storage

Temperature

-40°C to +70°C (-40°F to +158°F)

Operating Humidity

10%to 90%RH

Storage Humidity

5% to 95% RH

Port Mode

Sswitchoverin threemodes:

1. Flow Control On

2. Flow Control Off

3. Port Isolation

When portisolationis enabled,ports 1to22 are isolated from eachother,butcancommunicate

with ports 25, 26, and 26F.

Fan

Supported

Temperature

Warning

Not supported

Accessing Optical

Module Information

Not supported

Certification

Earth Leakage

Current

≤1.5 mA

Dimensions

(W x D x H)

440mm x 208mm x 44 mm (17.32in. x 8.19 in. x 1.73 in.)

Weight

(With Package)

3 kg (6.61 lbs)

Device operationin a residential environmentmaycauseradio interference.

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide

Product Appearance

The RG-ES126S-LP provides twenty-four 10/100Base-TX auto-sensing Ethernet ports, two 10/100/1000Base-T auto-

sensingEthernetports,one1000Base-XSFPport,system status LEDs,a portmodeswitchoverbutton on thefrontpanel,

anda powersocketand a grounding poleontheback panel.

Figure 1-4 Appearance of the RG-ES126S-LP

Front Panel

Figure 1-5 Front Panel of the RG-ES126S-LP

Note:

1. PoE overload LED

2. System status LED

3. Port status LED

4. PoE status LED

5. Port mode switchoverbutton

6. 10/100Base-TXauto-sensing Ethernetport

7. 10/100/1000Base-Tauto-sensing Ethernetport

8. 10/100/1000Base-Tcombo port

9. Nameplate onthebottom of the device

Back Panel

Figure 1-6 Back Panel of the RG-ES126S-LP

Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide

Note:

1. Grounding pole

2. AC powersocket

Heat Dissipation

TheRG-ES126S-LPadopts fans forheatdissipation,therebyensuring normaloperation.You mustreserve 10 cmdistance

space atboth sides andthe backplane ofthecabinet toallowairflow. Itis recommended thatyou cleantheRG-ES126S-

LP onceevery 3 months toavoid dustfrom blockingvents.

LEDs

LED

Panel Identification

State

Meaning

System status LED

PWR

Off

The switchis poweredoff.

Solidgreen

The switchis operational.

PoE overloadLED

PoE-max

Off

The overall PoE output does not reach the

maximum power.

Solidgreen

The overall PoE output reaches the maximum

power.

RJ45 port status LED

Link/Act

(1–24,25, 26/26F)

Off

The port is not connected.

Solidgreen

The port is connected at a rate of 10/100/1000

Mbps.

Blinking green

The port is receiving or sending traffic at a rateof

10/100/1000Mbps.

RJ45PoE status LED

PoE (1–24)

Off

PoE does notsupplypower.

Solidgreen

PoE is operational.

1.3 RG-ES110D-P

Technical Specifications

Model

RG-ES110D-P

Ports

Eight 10/100Base-TXauto-sensing Ethernetports (autoMDI/MDIX), andPoE/PoE+ support

Two 10/100/1000Base-Tauto-sensingEthernetports (autoMDI/MDIX)

Power Supply

AC input

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Ruijie Changer

Ruijie

Ruijie RG-S6910-3C Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-MF2920U Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S6510-48VS8CQ Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-NBS5200 Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S6510-32CQ Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S6110 Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-PF2920-DPBOX-P Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-CS83 Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S6910-3C Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S7600 Series Manuel d'installation et d'exploitation

Ruijie

Ruijie XS-S1960-10GT2SFP-P-H Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-ES200 Series Manuel utilisateur

Ruijie

Ruijie RG-N18000-XH Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S7800C Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S6580-48CQ8QC Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S6000C-48GT4XS-E Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-IF2920U-12GT1XS-DC Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S6920-4C Series Manuel d'installation et d'exploitation

Ruijie

Ruijie RG-S5000-E Series Comment utiliser

Ruijie

Ruijie RG-S3250E Series Manuel utilisateur

Ruijie

Ruijie RG-ES08 Manuel utilisateur

Ruijie

Ruijie RG-S6250-48XS8CQ Series Manuel d'installation et d'exploitation

Ruijie

Ruijie S8600E Series Mode d'emploi

Ruijie

Ruijie RG-S2924GT/8SFP-XS-P Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur

Cabletron Systems

Cabletron Systems GIGAswitch GSR-16 Manuel utilisateur
