Powerware 9155 Manuel utilisateur

9155

USER’S GUIDE

UPS

8–15 kVA

www.powerware.com

Class A EMC Statements

FCC Part 15

NOTE This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference when the equipment is operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference in which case the user will be

required to correct the interference at his own expense.

ICES-003

This Class A Interference Causing Equipment meets all requirements of the Canadian Interference

Causing Equipment Regulations ICES-003.

Cet appareil numérique de la classe A respecte toutes les exigences du Reglement sur le matériel

brouilleur du Canada.

IEC 62040-2

Some configurations are classified under IEC 62040-2 as “Class-A UPS for Unrestricted Sales

Distribution.” For these configurations, the following applies:

WARNING This is a Class A-UPS Product. In a domestic environment, this product may cause radio

interference, in which case, the user may be required to take additional measures.

VCCI Notice

Powerware, ABM, and FERRUPS are registered trademarks and X-Slot, ConnectUPS, and Powerware Hot

Sync are trademarks of Eaton Power Quality Corporation.

Greenlee is a registered trademark of Greenlee Textron. Modbus is a registered trademark of Modicon.

document may be reproduced in any way without the express written approval of Eaton Corporation.

Requesting a Declaration of Conformity

Units that are labeled with a CE mark comply with the following harmonized standards and EU

directives:

쑺Harmonized Standards: IEC 62040-1-1 and IEC 62040-2; IEC 60950 Third Edition

쑺EU Directives:

73/23/EEC, Council Directive on equipment designed for use within certain

voltage limits

93/68/EEC, Amending Directive 73/23/EEC

89/336/EEC, Council Directive relating to electromagnetic compatibility

92/31/EEC, Amending Directive 89/336/EEC relating to EMC

The EC Declaration of Conformity is available upon request for products with a CE mark. For copies of

the EC Declaration of Conformity, contact:

Eaton Power Quality Oy

Koskelontie 13

FIN-02920 Espoo

Finland

Phone: +358-9-452 661

Fax: +358-9-452 665 68

Special Symbols

The following are examples of symbols used on the UPS to alert you to important

information:

RISK OF ELECTRIC SHOCK - Indicates that a risk of electric shock is present and the

associated warning should be observed.

CAUTION: REFER TO OPERATOR’S MANUAL - Refer to your operator’s manual

for additional information, such as important operating and maintenance instructions.

This symbol indicates that you should not discard the UPS or the UPS batteries in the

trash. This product contains sealed, lead-acid batteries and must be disposed of

properly. For more information, contact your local recycling/reuse or hazardous waste

center.

This symbol indicates that you should not discard waste electrical or electronic

equipment (WEEE) in the trash. For proper disposal, contact your local recycling/reuse

or hazardous waste center.

Powerware®9155 UPS (8–15 kVA) User’s Guide S164201553 Rev D www.powerware.com

Table of Contents

1Introduction 1...............................................

2 Safety Warnings 5............................................

3 UPS Setup 9.................................................

Inspecting the Equipment 9.................................................

Floor Loading 10...........................................................

Clearances 10.............................................................

Unloading the Cabinet(s) 11.................................................

Selecting an Installation Option 14............................................

4 UPS Only Installation 15.......................................

5 Input Isolation Transformer Installation 21......................

6 UPS-Mounted Bypass Switch Installation 29......................

Maintenance Bypass/Power Distribution Module Setup 29........................

Wiring the MBM/PDM 32....................................................

7 Wall-Mounted Bypass Switch Installation 39.....................

Wall-Mounted Bypass Switch Setup 40........................................

Wiring the Wall-Mounted Bypass Switch 41....................................

8 Stabilizing the Cabinet 49......................................

9 Extended Battery Module Installation 51........................

10 Communication 53............................................

Installing Communication Options and Control Terminals 54......................

Communication Options 57..................................................

DB-9 Communication Port 57..............................................

X-Slot Cards 58..........................................................

LanSafe Power Management Software 60....................................

Table of Contents

ii Powerware®9155 UPS (8–15 kVA) User’s Guide S164201553 Rev D www.powerware.com

Control Terminals 61.......................................................

Remote Emergency Power-off 62...........................................

Relay Contacts 63........................................................

Programmable Signal Inputs 63............................................

11 Operation 65..................................................

Control Panel Functions 65..................................................

Changing the Language 66................................................

Display Functions 66.....................................................

User Settings 68.........................................................

UPS Startup 70............................................................

Maintenance Bypass Startup 70............................................

Internal Bypass Startup 71................................................

Normal Mode Startup 72.................................................

Starting the UPS on Battery 74.............................................

Configuring the UPS for EBMs 75.............................................

UPS Shutdown 76..........................................................

12 UPS Maintenance 77...........................................

UPS and Battery Care 77....................................................

Storing the UPS and Batteries 77...........................................

When to Replace Batteries 78................................................

Recycling the Used Battery 78................................................

Using the UPS-Mounted Maintenance Bypass Switch 79..........................

Using the Wall-Mounted Bypass Switch 82.....................................

13 Specifications 85..............................................

14 Troubleshooting 91............................................

Typical Alarms and Conditions 91.............................................

Silencing the Alarm 93......................................................

Service and Support 93.....................................................

Two-Year Limited Warranty 94...............................................

Extended Ten-Year Pro-Rated Limited Warranty 96..............................

Load Protection Guarantee 99...............................................

Powerware®9155 UPS (8–15 kVA) User’s Guide S164201553 Rev D www.powerware.com

Chapter 1 Introduction

The Powerware®9155 is a double-conversion, split-phase, online

uninterruptible power system (UPS) for protecting computer systems and

other intelligent devices. It is ideal for protecting essential information

technology and electrical engineering infrastructure in corporate,

telecom, health care, banking, and industrial applications.

The UPS provides a steady, well-regulated power supply for your

computing and communications equipment, while protecting it from the

frequent irregularities that are inherent in commercially available power.

Voltage spikes, power surges, brownouts, and power failures have the

potential to corrupt critical data, destroy unsaved work sessions, and in

some instances, damage expensive hardware.

With the Powerware 9155, you can safely eliminate the effects of

electrical line disturbances and guard the integrity of your systems and

equipment. Figure 1 shows the Powerware 9155 UPS and an optional

Extended Battery Module (EBM).

Figure 1. The Powerware 9155 UPS and EBM (2-High Cabinets Shown)

Introduction

2Powerware®9155 UPS (8–15 kVA) User’s Guide S164201553 Rev D www.powerware.com

Providing outstanding performance and reliability, the Powerware 9155’s

unique benefits including the following:

쑺OnlineUPSdesignwithpuresinewaveoutput.TheUPSfiltersand

regulates incoming AC power and provides consistent power to your

equipment without draining the battery.

쑺More wattage in less space with a 0.9 power factor – protecting more

equipment and leaving more room for expansion.

쑺Support for Powerware Hot Synctparalleling of multiple modules for

redundancy or extra capacity.

쑺Input current total harmonic distortion (THD) of less than five

percent, using active input power factor correction.

쑺ABM®technology that uses advanced battery management to increase

battery service life, optimize recharge time, and provide a warning

before the end of useful battery life.

쑺Up to four hours of extended runtime with added EBMs.

쑺Advanced power management with the Powerware Software Suite CD

for graceful shutdowns and power monitoring.

쑺Emergency shutdown control through the Remote Emergency

Power-off (REPO) port.

쑺Start-on-battery capability for powering up the UPS even if utility

power is not available.

쑺Standard communication options with a DB-9 serial port, relay output

contacts, and programmable signal inputs.

쑺Optional X-Slottcards enhance communication capabilities for

increased power protection and control.

쑺Backed by worldwide agency approvals.

Introduction

Powerware®9155 UPS (8–15 kVA) User’s Guide S164201553 Rev D www.powerware.com

The following options for the Powerware 9155 are available:

쑺Maintenance Bypass Module (MBM)

The optional MBM is installed on the UPS rear panel and is used to

bypass the UPS during maintenance or servicing. The Maintenance

Bypass switch on the MBM provides a Make-Before-Break (MBB)

wrap-around bypass for UPS service without shutting down the load.

쑺Power Distribution Module (PDM)

The optional PDM provides the same functionality as the MBM and

also comes equipped with several different types of output

receptacles.

쑺Wall-Mounted Bypass Switch

The optional wall-mounted bypass switch is used to bypass the UPS

during maintenance or servicing, providing wrap-around bypass for

UPS service without shutting down the load.

쑺Parallel Tie Cabinet

A parallel system with up to three UPSs can be installed to provide a

parallel capacity and/or redundant system. This load sharing system

provides more capacity than a single UPS and can provide backup,

depending on the load and configuration. In addition, when one UPS

is taken out of service for maintenance or is not operating properly, a

redundant UPS continues to supply uninterrupted power to the critical

load. A parallel Powerware Hot Sync Computer Area Network (CAN)

Bridge Card provides connectivity for system metering and operational

mode control. The parallel system consists of two to three UPSs, each

with a parallel CAN Bridge Card, and a parallel tie cabinet. Refer to

the Powerware 9155 Parallel UPS (8–15 kVA) User’s Guide for more

information.

쑺Input Isolation Transformer

The optional input isolation transformer is located at the bottom of a

3-high UPS model. The input isolation transformer provides a neutral

from a 208V or 240V input source with 240V output and can be wired

to the UPS or to an MBM/PDM.

쑺Seismic Kit

The seismic kit secures the UPS and optional EBMs for Zone 4 seismic

installations.

Introduction

4Powerware®9155 UPS (8–15 kVA) User’s Guide S164201553 Rev D www.powerware.com

Autres manuels pour 9155

Table des matières

Autres manuels Powerware UPS

Powerware

Powerware 5140 Manuel utilisateur

Powerware

Powerware 9335 Manuel utilisateur

Powerware

Powerware 5125 9910 P18 Manuel utilisateur

Powerware

Powerware 300 VA Manuel utilisateur

Powerware

Powerware Ferrups FE/QFE 500VA Manuel utilisateur

Powerware

Powerware 5140 Manuel utilisateur

Powerware

Powerware 9315 Manuel utilisateur

Powerware

Powerware 9125 Manuel utilisateur

Powerware

Powerware BPIV 30 kVA Manuel utilisateur

Powerware

Powerware 9315 Manuel utilisateur

Powerware

Powerware 9125 PowerPass Manuel utilisateur

Powerware

Powerware 9120 Manuel utilisateur

Powerware

Powerware Prestige series 9 Manuel utilisateur

Powerware

Powerware 9125 Manuel utilisateur

Powerware

Powerware 5105 Manuel utilisateur

Powerware

Powerware 9315s Manuel utilisateur

Powerware

Powerware PowerRite XT Manuel utilisateur

Powerware

Powerware 8 - 15 kVA Manuel utilisateur

Powerware

Powerware 3110 Manuel utilisateur

Powerware

Powerware Plus 80 Mode d’emploi

Powerware

Powerware 9395 Manuel utilisateur

Powerware

Powerware 9125 Manuel utilisateur

Powerware

Powerware 9355 Manuel utilisateur

Powerware

Powerware 9305 Manuel d'utilisation

Manuels UPS populaires d'autres marques

Pylontech

Pylontech Victron & Pylontech US5000 Manuel utilisateur

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manuel utilisateur

Mecer

Mecer ME-1000-WTU Manuel utilisateur

Mustek

Mustek PowerMust 530(B) Plus Manuel d'installation et d'exploitation

Emerson

Emerson Liebert NXL series Manuel utilisateur

MAKELSAN

MAKELSAN BOXER SERIES Manuel utilisateur

Block

Block PC-0524-400-0 Manuel utilisateur

CyberPower

CyberPower CP585LCD Manuel utilisateur

Eaton

Eaton 3S Instructions de montage

CyberPower

CyberPower Office Tower Series UPS 1000 Manuel utilisateur

CyberPower

CyberPower BM100 Manuel utilisateur

Best Power

Best Power 610 Manuel utilisateur

Best Power

Best Power Unity/I UT3K Manuel utilisateur

Mustek

Mustek PowerMust 400 Offline Manuel utilisateur

Xantrex

Xantrex Trace 512 UR-UPS Manuel utilisateur

Forza

Forza SL-1501UL Manuel utilisateur

LEGRAND

LEGRAND keor 310081 Manuel utilisateur

ABB

ABB Conceptpower DPA 500 Manuel utilisateur
