Powerware®5115 RM

User’s Guide

500–1500 VA

www.powerware.com

US Patent 6,462,961

Class B EMC Statements

FCC Part 15

NOTE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to

part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and the receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

ICES-003

This Class B Interference Causing Equipment meets all requirements of the Canadian Interference Causing Equipment

Regulations ICES-003.

Cet appareil numérique de la classe B respecte toutes les exigences du Reglement sur le matériel brouilleur du Canada.

Requesting a Declaration of Conformity

Units that are labeled with a CE mark comply with the following harmonized standards and EU directives:

Harmonized Standards: EN 50091-1-1 and EN 50091-2; IEC 950 Second Edition, Amendments A1, A2, A3, and A4

EU Directives: 73/23/EEC, Council Directive on equipment designed for use within certain voltage limits

93/68/EEC, Amending Directive 73/23/EEC

89/336/EEC, Council Directive relating to electromagnetic compatibility

92/31/EEC, Amending Directive 89/336/EEC relating to EMC

The EC Declaration of Conformity is available upon request for products with a CE mark. For copies of the EC

Declaration of Conformity, contact:

Powerware Corporation

Koskelontie 13

FIN-02920 Espoo

Finland

Phone: +358-9-452 661

Fax: +358-9-452 665 68

Powerware and ABM are registered trademarks and X-Slot and ConnectUPS are trademarks of Powerware Corporation.

reproduced in any way without the express written approval of Powerware Corporation.

Special Symbols

The following are examples of symbols used on the UPS to alert you to important information:

Risk of Electric Shock

Do Not Open Cover

CAUTION

CAUTION To reduce the risk of electric shock,

Do not remove cover (or back)

No user-serviceable parts inside

Refer servicing to the factory

RISK OF ELECTRIC SHOCK - Indicates that a risk of electric shock is present and the

associated warning should be observed.

CAUTION: REFER TO OPERATOR’S MANUAL - Refer to your operator’s manual for

additional information, such as important operating and maintenance

instructions.

SAFETY EARTHING TERMINAL - Indicates the primary safety ground.

LOAD ON/OFF - Press the button with this symbol to energize the output

receptacles (indicator illuminates) or to de-energize the output receptacles

(indicator is off).

RJ-45 RECEPTACLE - For 230V models only: this receptacle provides network

interface connections. Do not plug telephone or telecommunications equipment

into this receptacle.

This symbol indicates that you should not discard the UPS or the UPS batteries

in the trash. The UPS may contain sealed, lead-acid batteries. Batteries must be

recycled.

Powerware®5115 Rack-Mount User’s Guide :164201449 Rev A www.powerware.com

TABLE OF CONTENTS

1 Powerware 5115 RM – One of the Best! 1..............................

2 Safety Warnings 3.................................................

3 Installation 19.....................................................

Inspecting the Equipment 19........................................................

UPS Setup 19..................................................................

Mounting the UPS in a 19” Rack 20................................................

Mounting the UPS in a 23” Rack 23................................................

Zero-U Mounting 25...........................................................

Wall-Mount Setup 26..........................................................

Installing the UPS 27.............................................................

4 Operation 29......................................................

Turning the UPS On 29............................................................

Starting the UPS on Battery 29....................................................

Turning the UPS Off 29...........................................................

Standby Mode 30...............................................................

UPS Front Panel 30..............................................................

Initiating the Self-Test 30..........................................................

5 Additional UPS Features 31..........................................

Voltage Configuration 31..........................................................

Network Transient Protector 32.....................................................

Load Segments 33...............................................................

6 Communication 35.................................................

USB Port 35...................................................................

Communication Port 36...........................................................

X-Slot Cards 37.................................................................

7 UPS Maintenance 39...............................................

UPS and Battery Care 39..........................................................

Storing the UPS and Batteries 39..................................................

Replacing Batteries 40............................................................

Table of Contents

ii Powerware®5115 Rack-Mount User’s Guide :164201449 Rev A www.powerware.com

Testing New Batteries 42..........................................................

Recycling the Used Battery 42......................................................

8 Specifications 43..................................................

9 Troubleshooting 47.................................................

Audible Alarms and UPS Conditions 47................................................

Silencing an Audible Alarm 48....................................................

Site Wiring Fault (120V Models Only) 48.............................................

Service and Support 51...........................................................

Powerware®5115 Rack-Mount User’s Guide :164201449 Rev A www.powerware.com

CHAPTER 1

POWERWARE 5115 RM – ONE OF THE BEST!

The Powerware

5115 Rack-Mount (RM) uninterruptible power system

(UPS)isahigh-densitypowerprotection solution ideal for servers,

storage systems, network equipment, and other critical devices.

The slim design and wide range of installation possibilities make the

Powerware 5115 RM the most versatile UPS available. With only 1U

(1.75”) of rack-height, the UPS can be installed in rack-mount,

wall-mount, side-mount (zero U), and bench-top applications.

Providing a true sine wave output, the UPS delivers smooth, continuous

power during normal and battery operation. In addition, the UPS

corrects incoming voltage fluctuations to further protect the connected

equipment from power problems such as power sags and surges.

Powerware 5115 RM – ONE OF THE BEST!

2Powerware®5115 Rack-Mount User’s Guide :164201449 Rev A www.powerware.com

:Network Transient Protector guards your network communications

equipment from surges. Low voltage models can also protect

modems, fax machines, or other telecommunications equipment.

:Optional X-SlotZmodules provide enhanced communication

capabilities for increased power protection and control.

:The Powerware 5115 RM is backed by worldwide agency approvals.

Powerware®5115 Rack-Mount User’s Guide :164201449 Rev A www.powerware.com

CHAPTER 2

SAFETY WARNINGS

Read the following precautions before you install the UPS.

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

This manual contains important instructions that you should follow during installation

and maintenance of the UPS and batteries. Please read all instructions before

operating the equipment and save this manual for future reference.

DANGER

This UPS contains LETHAL VOLTAGES. All repairs and service should be performed

by AUTHORIZED SERVICE PERSONNEL ONLY. There are NO USER

SERVICEABLE PARTS inside the UPS.

WARNING

:This UPS contains its own energy source (batteries). The output receptacles may

carry live voltage even when the UPS is not connected to an AC supply.

:For 200–240V models, the output receptacles may remain electrically live. If the

input power source in your application is wired line-to-neutral (as in most

European applications), the voltage to the output receptacles is 0V. With

line-to-line input wiring, the voltage to the output receptacles is 100–120V

(measured from line-to-ground or line-to-neutral, depending on the UPS wiring).

:Do not remove or unplug the input cord when the UPS is turned on. This removes

the safety ground from the UPS and the equipment connected to the UPS.

:To reduce the risk of fire or electric shock, install this UPS in a temperature and

humidity controlled, indoor environment, free of conductive contaminants. Ambient

temperature must not exceed 40C (104F). Do not operate near water or

excessive humidity (95% max).

:To comply with international standards and wiring regulations, the total equipment

connected to the output of this UPS must not have an earth leakage current

greater than 3.5 milliamperes.

Safety Warnings

4Powerware®5115 Rack-Mount User’s Guide :164201449 Rev A www.powerware.com

CAUTION

:The wall outlet must be within 2 meters of the equipment and accessible to the

operator.

:Batteries can present a risk of electrical shock or burn from high short-circuit

current. The following precautions should be observed: 1) Remove watches, rings,

or other metal objects; 2) Use tools with insulated handles; 3) Do not lay tools or

metal parts on top of batteries; 4) Disconnect charging source prior to connecting

or disconnecting battery terminals.

:Proper disposal of batteries is required. Refer to your local codes for disposal

requirements.

:Never dispose of batteries in a fire. Batteries may explode when exposed to flame.

:Never open or mutilate batteries. Released electrolyte is harmful to the skin and

eyes, and may be extremely toxic.

:Replace batteries with the same number and type of batteries as originally

installed in the UPS.

Sikkerhedsanvisninger

VIGTIGE SIKKERHEDSANVISNINGER

GEM DISSE ANVISNINGER

DENNE BRUGERVEJLEDNING INDEHOLDER VIGTIGE

SIKKERHEDSANVISNINGER

FARE

Denne UPS indeholder LIVSFARLIG HØJSPÆNDING. Alle reparationer og

vedligeholdelse bør kun udføres af en AUTORISERET SERVICETEKNIKER. Ingen af

UPS’ens indvendige dele kan repareres af brugeren.

ADVARSEL!

:Denne UPS indeholder egen energiforsyning (batterier). Udgangsnetstikkene kan

lede strøm, selv når UPS’en ikke er tilsat en AC-energikilde.

:Netledningen må ikke fjernes og stikket må ikke trækkes ud, mens UPS’en er

tændt. Dette fjerner sikkerhedsjorden fra UPS’en og fra det udstyr, der er sat til.

:Installér denne UPS i et temperatur- og fugtighedskontrolleret indendørsmiljø, frit

for ledende forureningsstoffer for at formindske risikoen for brand og elektrisk

stød. Rumtemperaturen må ikke overstige 40C. UPS’en bør ikke betjenes nær

vand eller høj fugtighed (maksimalt 95%).

Table des matières

Autres manuels Powerware UPS

Powerware

Powerware 9305 Manuel d'utilisation

Powerware

Powerware 9125 Manuel utilisateur

Powerware

Powerware 5110 Manuel utilisateur

Powerware

Powerware 9125 Manuel utilisateur

Powerware

Powerware 9355 Manuel utilisateur

Powerware

Powerware 9170+ Manuel utilisateur

Powerware

Powerware 9320 Manuel utilisateur

Powerware

Powerware 9395 Manuel utilisateur

Powerware

Powerware 3105 Manuel utilisateur

Powerware

Powerware 9315 Manuel utilisateur

Powerware

Powerware 3110 Manuel utilisateur

Powerware

Powerware Ferrups FE/QFE UPS Manuel utilisateur

Powerware

Powerware Prestige series 9 Manuel utilisateur

Powerware

Powerware BPIV Manuel utilisateur

Powerware

Powerware 9305 Manuel d'utilisation

Powerware

Powerware 9155 Manuel utilisateur

Powerware

Powerware Ferrups FE/QFE 500VA Manuel utilisateur

Powerware

Powerware 5140 Manuel utilisateur

Powerware

Powerware 700 3000 VA Manuel utilisateur

Powerware

Powerware PowerRite XT Manuel utilisateur

Powerware

Powerware 9390 Manuel utilisateur

Powerware

Powerware 9910 p Series Manuel utilisateur

Powerware

Powerware UPS 1000 - 2200 Manuel utilisateur

Powerware

Powerware Prestige series 9 Manuel utilisateur

Manuels UPS populaires d'autres marques

Pylontech

Pylontech Victron & Pylontech US5000 Manuel utilisateur

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manuel utilisateur

Mecer

Mecer ME-1000-WTU Manuel utilisateur

Mustek

Mustek PowerMust 530(B) Plus Manuel d'installation et d'exploitation

Emerson

Emerson Liebert NXL series Manuel utilisateur

MAKELSAN

MAKELSAN BOXER SERIES Manuel utilisateur

Block

Block PC-0524-400-0 Manuel utilisateur

CyberPower

CyberPower CP585LCD Manuel utilisateur

Eaton

Eaton 3S Instructions de montage

CyberPower

CyberPower Office Tower Series UPS 1000 Manuel utilisateur

CyberPower

CyberPower BM100 Manuel utilisateur

Best Power

Best Power 610 Manuel utilisateur

Best Power

Best Power Unity/I UT3K Manuel utilisateur

Mustek

Mustek PowerMust 400 Offline Manuel utilisateur

Xantrex

Xantrex Trace 512 UR-UPS Manuel utilisateur

Forza

Forza SL-1501UL Manuel utilisateur

LEGRAND

LEGRAND keor 310081 Manuel utilisateur

ABB

ABB Conceptpower DPA 500 Manuel utilisateur
