Panasonic TY-FB10HD Manuel utilisateur

1 Safety Precautions 2

1.1. General Guidelines 2

2 Prevention of Electrostatic Discharge (ESD) to

Electrostatically Sensitive (ES) Devices 3

3 About lead free solder (PbF) 4

4 Replacement 5

5 Connection 6

6 Circuit Board Layout 8

6.1. HSB-Board 8

7 Block and Schematic Diagram 11

7.1. Schematic Diagram Notes 11

rights reserved. Unauthorized copying and

distribution is a violation of law.

TY-FB10HD

TY-FB10HDC

7.2. HSB-Board Block Diagram 12

7.3. HSB-Board (1 of 3) Schematic Diagram 13

7.4. HSB-Board (2 of 3) Schematic Diagram 14

7.5. HSB-Board (3 of 3) Schematic Diagram 15

8 Exploded Views & Replacement Parts List 17

8.1. Parts Location (1) 17

8.2. Parts Location (2) 18

8.3. Replacement Parts List Notes 19

8.4. Mechanical Replacement Parts List 20

8.5. Electrical Replacement Parts List 21

HD-SDI Terminal Board with Audio

CONTENTS

Page Page

ORDER NO. ITD0709065CE

B34 Canada: D10

1 Safety Precautions

1.1. General Guidelines

1. When conducting repairs and servicing, do not attempt to modify the equipment, its parts or its materials.

2. When wiring units (with cables, flexible cables or lead wires) are supplied as repair parts and only one wire or some of the wires

have been broken or disconnected, do not attempt to repair or re-wire the units. Replace the entire wiring unit instead.

3. When conducting repairs and servicing, do not twist the Faston connectors but plug them straight in or unplug them straight out.

4. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or

damaged by the short circuit.

5. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly

installed.

6. After servicing, make the following leakage current checks to prevent the customer from being exposed to shock hazards.

1.1.1. Leakage Current Cold Check

1. Unplug the AC cord and connect a jumper between the two prongs on the plug.

2. Measure the resistance value, with an ohmmeter, between the jumpered AC plug and each exposed metallic cabinet part on

the equipment such as screwheads, connectors, control shafts, etc. When the exposed metallic part has a return path to the

chassis, the reading should be between 1MWand 5.2MW.

When the exposed metal does not have a return path to the chassis, the reading must be .

Figure 1

1.1.2. Leakage Current Hot Check (See Figure 1.)

1. Plug the AC cord directly into the AC outlet. Do not use an isolation transformer for this check.

2. Connect a 1.5kW, 10 watts resistor, in parallel with a 0.15µF capacitors, between each exposed metallic part on the set and a

good earth ground such as a water pipe, as shown in Figure 1.

3. Use an AC voltmeter, with 1000 ohms/volt or more sensitivity, to measure the potential across the resistor.

4. Check each exposed metallic part, and measure the voltage at each point.

5. Reverse the AC plug in the AC outlet and repeat each of the above measurements.

6. The potential at any point should not exceed 0.75 volts RMS. A leakage current tester (Simpson Model 229 or equivalent) may

be used to make the hot checks, leakage current must not exceed 1/2 milliamp. In case a measurement is outside of the limits

specified, there is a possibility of a shock hazard, and the equipment should be repaired and rechecked before it is returned to

the customer.

TY-FB10HD / TY-FB10HDC

2 Prevention of Electrostatic Discharge (ESD) to

Electrostatically Sensitive (ES) Devices

Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called

Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and

semiconductor "chip" components. The following techniques should be used to help reduce the incidence of component damage

caused by electrostatic discharge (ESD).

1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on your

body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD wrist strap,

which should be removed for potential shock reasons prior to applying power to the unit under test.

2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as alminum

foil, to prevent electrostatic charge buildup or exposure of the assembly.

3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.

4. Use only an anti-static solder removal device. Some solder removal devices not classified as "anti-static (ESD protected)" can

generate electrical charge sufficient to damage ES devices.

5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.

6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most

replacement ES devices are packaged with leads electrically shorted together by conductive foam, alminum foil or comparable

conductive material).

7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material

to the chassis or circuit assembly into which the device will be installed.

Caution

Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.

8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise hamless motion such as the brushing

together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity (ESD) sufficient to

damage an ES device).

TY-FB10HD / TY-FB10HDC

3 About lead free solder (PbF)

Note: Lead is listed as (Pb) in the periodic table of elements.

In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder.

The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu).

That is Tin (Sn), Silver (Ag) and Copper (Cu) although other types are available.

This model uses Pb Free solder in it’s manufacture due to environmental conservation issues. For service and repair work, we’d

suggest the use of Pb free solder as well, although Pb solder may be used.

PCBs manufactured using lead free solder will have the PbF within a leaf Symbol PbF stamped on the back of PCB.

Caution

Pb free solder has a higher melting point than standard solder. Typically the melting point is 50 ~ 70 °F (30~40°C) higher.

Please use a high temperature soldering iron and set it to 700 ± 20 °F (370 ± 10 °C).

Pb free solder will tend to splash when heated too high (about 1100 °F or 600 °C).

If you must use Pb solder, please completely remove all of the Pb free solder on the pins or solder area before applying Pb

solder. If this is not practical, be sure to heat the Pb free solder until it melts, before applying Pb solder.

After applying PbF solder to double layered boards, please check the component side for excess solder which may flow onto

the opposite side. (see figure below)

Suggested Pb free solder

There are several kinds of Pb free solder available for purchase. This product uses Sn+Ag+Cu (tin, silver, copper) solder.

However, Sn+Cu (tin, copper), Sn+Zn+Bi (tin, zinc, bismuth) solder can also be used.

TY-FB10HD / TY-FB10HDC

4 Replacement

TY-FB10HD / TY-FB10HDC

5 Connection

TY-FB10HD / TY-FB10HDC

6 Circuit Board Layout

6.1. HSB-Board

CBD

HSB-BOARD (FOIL SIDE)

TXNHSB10XYT

TY-FB10HD

HHH-BOARD TXNHSB10XYT

Parts Location

HSB-BOARD

IC3404 C-3

IC3405 B-4

IC3407 C-3

IC3411 C-4

IC3501 D-3

IC3504 A-4

Q3605 D-4

TRANSISTOR

SDI THRU

SDI INPUT

TNPA4263 HSB

JK301 JK302

SW301

IC405

FL505

C632

C321

IC404

C404

C530

C315

C328

C338

L302

Q605

D502

D601

C515

D503

FL504

C339

D504 C327

C516

C313

IC501

IC504

D501

C325

IC411

IC407

C341

C634

C491

C492

C493

C495

C496

C497

C301

C302

C308

C502

C506

C314

C316

C317

C318

C319

C510

C512

C514

C322

C323

C324

C326

C329

C330

C332

C527

C333

C334

C529

C336 C337

C340

C350

C353

C360

C361

C601

C412

C413

C414

C415

C416

C611

C612

C613

C614

C421

C422

C423

C424

C618

C425

C426

C427

C428

C429

C621

C622

C623

C430

C624

C431

C432

C433

C434

C628

C435

C436

C631

C633

C444

C407

C409

C411

C607

C608

R425

R427

R429

R430

R449

R450

R451

R455

R467

R312

R508

R509

R316

R322

R328

R329

R502

R503

R504

R505

R506

R507

R381

R382

R383

R384

R387

R388

L301

L601

L602

L401

L402

L403

L404

L405

L406

R419

R611

R612

R420

R421

R422

R621 R622

R623

R624

R625

R431

R626

R432

R627

R433

R628

R434

R435

R437

R439

R631

R632

R440

R442

R443

R444

R445

R446

R447

R448

R641

R642

R643

R644

R452

R453

R454

R460

R461

R462

R463 R464

R465

R466

R468

R473

R474

R476

R477

R491

R492

R493

R494

R301

R302 R303

R309

R313

R317

R318

R319

R320

R321

R327

R331

R356

R357

R364

R365

R366

R367

R368

R373

R374

R377

R378

R601 R602

R603

R604

R605

R606

R607 R608

R510

R511

C537

PbF

ORDER NO.

A40

A39

B39

B40

1011

TY-FB10HD / TY-FB10HDC

CBD

HSB-BOARD (COMPONENT SIDE)

TXNHSB10XYT

TY-FB10HD

HHH-BOARD TXNHSB10XYT

Parts Location

HSB-BOARD

IC3302 C-2

IC3303 C-2

IC3304 C-3

IC3305 D-3

IC3306 B-3

IC3307 C-2

IC3310 B-4

IC3401 B-3

IC3402 D-3

IC3403 C-3

IC3406 B-3

Q3301 B-2

Q3601 B-2

Q3602 B-4

Q3603 B-2

Q3604 B-4

TRANSISTOR

IC3408 C-4

IC3409 B-2

IC3410 B-2

IC3502 A-3

IC3503 A-2

TP3301 B-1

TP3401 C-4

TP3402 C-4

TP3403 A-4

TP3501 A-4

VR3301 B-2

VOLMUE

CR NO.3

SDI INPUT

4:M_SD/HD

3:AUTO/MANU

2:S352_CHK

1:LVDS_CLK

TNPA4263

HSB

C627

C351 IC503

IC310

IC410

D303

IC502

C524

SW301

C312

R409

R402

FL508

X401

Q603

IC304

C518

C523

C311

R404

FL509

C603

IC306

Q602

C528

IC408

IC402

C521

R415

FL506

Q601

C536

JK301

X301

D304

IC406

IC401

R401

Q604

FL507

VR301

C509

C533

C507

C602

C526

R408

C513

IC409

IC403

R406

FL502

C625

Q301

R405

C406

FL501

C617

C606

IC303

JK302

R403

C520

R407

C408

FL503

C352

C511

C615

C410

IC307

IC302

IC305

TP501

TP402

TP301

TP403

TP401

GND

SDI THRU

D_ERR

LOCK

C441

C442

C443

C445

C446

C447

C494

C305

C306

C501

C503

C504

C310

C505

C508

C320

C517

C519

C522

C525

C331

C335

C531

C532

C534

C535

C347

C354

C355

C401

C402

C403

C405

C604

C605

C417

C616C626

R423

R424

R426

R428

R441

R310

R311

R353

R501

R379

R380 R385

R386

R418

R610

R629

R436

R438

R630

R469

R470

R471

R472

R475

R478

R480

R481

R482

R483

R484

R485

R304

R305

R306

R307

R308

R314

R315

R323

R324

R325

R326

R521

R522

R523

R524

R330

R525

R332

R333

R334

R335

R336

R337

R338

R339

R340

R341

R342

R343

R344

R345

R346

R347

R348

R349

R350

R351

R352

R354

R355

R360

R361

R362

R363

R369

R370

R371

R372

R375R376

R410

R411

R609

R416 R417

R613

R614

R633

R634

PbF

REVERSEFOR ORDERNO.SEE

A39

A40

B39

B40

20 21

41 60

TY-FB10HD / TY-FB10HDC

Autres manuels pour TY-FB10HD

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Panasonic Matériel informatique

Panasonic

Panasonic ET-MDNFB10 Manuel utilisateur

Panasonic

Panasonic WJ-MPU855 Manuel utilisateur

Panasonic

Panasonic KXF-9R4C Manuel utilisateur

Panasonic

Panasonic UB-5335 Manuel utilisateur

Panasonic

Panasonic ET-MDNDP10C Manuel utilisateur

Panasonic

Panasonic UP0KG8DG Manuel utilisateur

Panasonic

Panasonic Panaboard UB-5310 Manuel utilisateur

Panasonic

Panasonic AW-360B10 Manuel utilisateur

Panasonic

Panasonic TY-FB10HMD - Monitor Terminal Expansion... Guide de l'utilisateur

Panasonic

Panasonic KX-TVP120C Manuel utilisateur

Panasonic

Panasonic 2SA2174J Manuel utilisateur

Panasonic

Panasonic 2SA1309A Manuel utilisateur

Panasonic

Panasonic Ramsa WU-SX05 Manuel utilisateur

Panasonic

Panasonic ET-MDNDP10 Manuel utilisateur

Panasonic

Panasonic TY-FB11DD - Monitor Terminal Expansion Board Manuel utilisateur

Panasonic

Panasonic PanaXSeries MN103S65G Manuel utilisateur

Panasonic

Panasonic WJ-MPU850 Manuel utilisateur

Panasonic

Panasonic MICROCOMPUTER MN103S Manuel utilisateur

Panasonic

Panasonic CF-BAW0512AU Manuel utilisateur

Panasonic

Panasonic PAW-FC Manuel

Panasonic

Panasonic 2SA1532 Manuel utilisateur

Panasonic

Panasonic AJ-YA931G Manuel utilisateur

Panasonic

Panasonic 2SC3934 Manuel utilisateur

Panasonic

Panasonic KX-TVM50 Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur

Advantech

Advantech ASMB-935 Series Manuel utilisateur
