Panasonic AV-HS04M5 Manuel utilisateur

FRANÇAIS DEUTSCH ENGLISHITALIANOESPAÑOL

РУССКИЙ

日本語

Before operating this product, please read the instructions carefully and save this

manual for future use.

Operating Instructions

DVI/Analog Output board

Model No. AV-HS04M5

01.AV-HS04M5English.indd101.AV-HS04M5English.indd1 2007/10/0118:33:322007/10/0118:33:32

1 (E)

indicates safety information.

Safety precautions

WARNING:

• TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE

THIS APPARATUS TO RAIN OR MOISTURE.

• THE APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING

AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL

BE PLACED ON THE APPARATUS.

CAUTION:

TO REDUCE THE RISK OF FIRE OR SHOCK HAZARD AND ANNOYING

INTERFERENCE, USE THE RECOMMENDED ACCESSORIES ONLY.

CAUTION:

TO REDUCE THE RISK OF FIRE OR SHOCK HAZARD, REFER CHANGES OF

SWITCH SETTINGS INSIDE THE UNIT TO QUALIFIED SERVICE PERSONNEL.

ENGLISH VERSION

The lightning flash with arrowhead symbol, within an equilateral triangle,

is intended to alert the user to the presence of uninsulated “dangerous

voltage” within the product’s enclosure that may be of sufficient

magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert

the user to the presence of important operating and maintenance

(service) instructions in the literature accompanying the appliance.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).

NO USER SERVICEABLE PARTS INSIDE.

REFER TO SERVICING TO QUALIFIED SERVICE PERSONNEL.

01.AV-HS04M5English.inddSec1:101.AV-HS04M5English.inddSec1:1 2007/10/0118:33:392007/10/0118:33:39

2 (E)

ENGLISH

This class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe A est conforme à la norme

NMB-003 du Canada.

For CANADA

FCC Note:

This equipment has been tested and found to comply with the limits for a class A

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy, and if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at

his own expense.

Warning:

To assure continued FCC emission limit compliance, the user must use

only shielded interface cables when connecting to external units. Also, any

unauthorized changes or modifications to this equipment could void the user’s

authority to operate it.

indicates safety information.

Safety precautions

01.AV-HS04M5English.inddSec1:201.AV-HS04M5English.inddSec1:2 2007/10/0118:33:392007/10/0118:33:39

3 (E)

indicates safety information.

Safety precautions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near

water.

6) Clean only with dry cloth.

7) Do not block any ventilation

openings. Install in accordance with

the manufacturer's instructions.

8) Do not install near any heat sources

such as radiators, heat registers,

stoves, or other apparatus (including

amplifiers) that produce heat.

9) Do not defeat the safety purpose

of the polarized or grounding-type

plug. A polarized plug has two

blades with one wider than the

other. A grounding-type plug has

two blades and a third grounding

prong. The wide blade or the third

prong are provided for your safety.

If the provided plug does not fit into

your outlet, consult an electrician for

replacement of the obsolete outlet.

10) Protect the power cord form being

walked on or pinched particularly

at plugs, convenience receptacles,

and the point where they exit from

the apparatus.

11) Only use attachments/accessories

specified by the manufacturer.

12) Use only with the cart,

stand, tripod, bracket,

or table specified by

the manufacturer, or

sold with the apparatus.

When a cart is used, use caution

when moving the cart/apparatus

combination to avoid injury from tip-

over.

13) Unplug this apparatus during

lightning storms or when unused for

long periods of time.

14) Refer all servicing to qualified

service personnel. Servicing is

required when the apparatus has

been damaged in any way, such

as power-supply cord or plug is

damaged, liquid has been spilled

or objects have fallen into the

apparatus, the apparatus has been

exposed to rain or moisture, does

not operate normally, or has been

dropped.

Read these operating instructions carefully before using the unit. Follow the safety

instructions on the unit and the applicable safety instructions listed below. Keep

these operating instructions handy for future reference.

IMPORTANT SAFETY

INSTRUCTIONS

01.AV-HS04M5English.inddSec1:301.AV-HS04M5English.inddSec1:3 2007/10/0118:33:392007/10/0118:33:39

4 (E)

ENGLISH

Information on Disposal for Users of Waste Electrical & Electronic Equipment

(private households)

This symbol on the products and/or accompanying documents means that used

electrical and electronic products should not be mixed with general household

waste.

For proper treatment, recovery and recycling, please take these products to

designated collection points, where they will be accepted on a free of charge

basis. Alternatively, in some countries you may be able to return your products to

your local retailer upon the purchase of an equivalent new product.

Disposing of this product correctly will help to save valuable resources and prevent any

potential negative effects on human health and the environment which could otherwise arise

from inappropriate waste handling.

Please contact your local authority for further details of your nearest designated collection

point.

Penalties may be applicable for incorrect disposal of this waste, in accordance with national

legislation.

For business users in the European Union

If you wish to discard electrical and electronic equipment, please contact your dealer or

supplier for further information.

Information on Disposal in other Countries outside the European Union

This symbol is only valid in the European Union.

If you wish to discard this product, please contact your local authorities or dealer and ask for

the correct method of disposal.

Safety precautions

01.AV-HS04M5English.inddSec1:401.AV-HS04M5English.inddSec1:4 2007/10/0118:33:392007/10/0118:33:39

5 (E)

Contents

Safety precautions ......................... 1

Introduction ..................................... 5

Accessory ....................................... 5

Precautions for use ........................ 6

Name of each part .......................... 7

Mounting ......................................... 8

Connections .................................. 11

Appearance ................................... 12

Specifications ............................... 13

Introduction

When this board is installed in the AV-HS400N/E multi format line switcher, it enables one

DVI-I output line and one analog output line to be supported.

Any of five signals (PGM, PVW, AUX, KEYOUT and multi view display) can be selected

as the output signals of each of the two lines.

Accessory

Operating instructions .................. 1

01.AV-HS04M5English.inddSec1:501.AV-HS04M5English.inddSec1:5 2007/10/0118:33:392007/10/0118:33:39

6 (E)

ENGLISH

Precautions for use

Handle carefully.

Do not drop the product, or subject it to strong shock or vibration.

Use the product in an ambient temperature of 32 °F to 104 °F

(0 °C to 40 °C).

Avoid using the product at a cold place below 32 °F (0 °C) or at a hot place above

104 °F (40 °C) because extremely low or high temperature will adversely affect the

parts inside.

Power off before connecting or disconnecting cables.

Before plugging or unplugging the cables, be sure to switch power off.

Avoid humidity and dust.

Avoid using the product at a humid, dusty place because much humidity and dust will

cause damage to the parts inside.

When the product is to be discarded

When the product is to be discarded at the end of its service life, ask a specialized

contractor to dispose of it properly in order to protect the environment.

01.AV-HS04M5English.inddSec1:601.AV-HS04M5English.inddSec1:6 2007/10/0118:33:402007/10/0118:33:40

7 (E)

Name of each part

DVI-I

PbY DVI / ANALOG OUTPUTS



DVI-I output connectors [DVI OUTPUTS]

When connected to the SLOT1 option output connector: OUTPUT3

When connected to the SLOT2 option output connector: OUTPUT5

Analog output connectors [ANALOG OUTPUTS]

When connected to the SLOT1 option output connector: OUTPUT4

When connected to the SLOT2 option output connector: OUTPUT6

Setting switches

Switch no. Off On Factory setting

1 Reserved — — Off

2 Reserved — — Off

3 Reserved — — Off

4 Reserved — — Off

5 Reserved — — Off

6 Reserved — — Off

7 Reserved — — Off

8 Reserved — — Off

Use switches no. 1 to 8 at the “off” (factory setting) position.

01.AV-HS04M5English.inddSec1:701.AV-HS04M5English.inddSec1:7 2007/10/0118:33:402007/10/0118:33:40

8 (E)

ENGLISH

Mounting

Install this board in the multi-format live switcher AV-HS400N/E.

<Notes>

Be sure to ask the store or dealer where you purchased the product for assistance

with mounting and removal.

Set to OFF and unplug the power connector before mounting and removal.

Before handling this board, touch a metal part of the AV-HS400N/E to discharge the

static electricity from the human body.

An anti-static wrist strap is recommended for safety. Failures may be caused if you

touch this board while you are still charged with static electricity.

Keep the metal parts of this board free of contact with other metal parts.

Be sure to mount the blank panel installed with the AV-HS400N/E, after removing this

board.

When installing or removing this board, take care not to hurt yourself on the edges

and metal parts of the boards.

Turn off the power of the AV-HS400N/E, and unplug the power cord.

Loosen the two screws of SLOT1 or SLOT2 on the output side at the rear of the AV-

HS400N/E, and remove the blank panel.

Screw

Blank panel

Screw

SLOT2

SLOT1

01.AV-HS04M5English.inddSec1:801.AV-HS04M5English.inddSec1:8 2007/10/0118:33:402007/10/0118:33:40

9 (E)

Mounting

Align the board with the guide rails, and insert it slowly.

Insert it all the way in. Take care not to use force to insert the board because the

connectors may be damaged in the process.

Attach the board using the two screws.

Screw

After connecting the necessary cables, plug in the power cord, and turn on the power.

01.AV-HS04M5English.inddSec1:901.AV-HS04M5English.inddSec1:9 2007/10/0118:33:422007/10/0118:33:42

Autres manuels pour AV-HS04M5

Table des matières

Autres manuels Panasonic Matériel informatique

Panasonic

Panasonic WJ-PB85D01 Manuel utilisateur

Panasonic

Panasonic MTM86627 Manuel utilisateur

Panasonic

Panasonic MN101L Series Manuel utilisateur

Panasonic

Panasonic PanaXSeries MN1030 Series Manuel utilisateur

Panasonic

Panasonic CZ-CBPCC2 Manuel utilisateur

Panasonic

Panasonic WJ-HXE400 Manuel utilisateur

Panasonic

Panasonic ET-MCYDV100 Manuel utilisateur

Panasonic

Panasonic 2SA1790J Manuel utilisateur

Panasonic

Panasonic AJ-YAC77P Manuel utilisateur

Panasonic

Panasonic CF-VEBC21Un Manuel utilisateur

Panasonic

Panasonic CF-BAM1024U Manuel utilisateur

Panasonic

Panasonic 2SC4691G Manuel utilisateur

Panasonic

Panasonic TY-FB11DHD Manuel utilisateur

Panasonic

Panasonic TY-SB01DL Manuel utilisateur

Panasonic

Panasonic 2SC1318A Manuel utilisateur

Panasonic

Panasonic WJPB65E01E - NETWORK BOARD FOR WJSX650 Manuel utilisateur

Panasonic

Panasonic 2SA1791G Manuel utilisateur

Panasonic

Panasonic Panaboard UB-5320 Manuel utilisateur

Panasonic

Panasonic UP0KG8DG Manuel utilisateur

Panasonic

Panasonic MICROCOMPUTER MN103S Instructions d'installation et d'utilisation

Panasonic

Panasonic FP2 Series Manuel utilisateur

Panasonic

Panasonic 2SC4626J Manuel utilisateur

Panasonic

Panasonic Panaboard UB-5310 Manuel utilisateur

Panasonic

Panasonic CY-EM100N Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur

Advantech

Advantech ASMB-935 Series Manuel utilisateur
