Metrologic IS3480 QuantumE Manuel utilisateur

work may be reproduced, transmitted, or stored in any form or by any means

without prior written consent, except by reviewer, who may quote brief

passages in a review, or provided for in the Copyright Act of 1976.

Trademarks

Metrologic is a registered trademark of Metrologic Instruments, Inc.

Products identified in this document are hereby acknowledged as

trademarks, registered or otherwise, of Metrologic Instruments, Inc. or their

respective companies.

TABLE OF CONTENTS

Introduction

Product Overview ............................................................................................. 1

Scanner and Accessories................................................................................. 2

Scanner Components....................................................................................... 4

Cable Removal................................................................................................. 4

Caution and Serial Number Labels................................................................... 5

Mounting Specifications ................................................................................... 5

Maintenance..................................................................................................... 5

Installation

RS232, RS232 TTL, Light Pen or Laser Emulation .......................................... 6

IBM 46xx or OCIA ............................................................................................ 7

Keyboard Wedge.............................................................................................. 8

Stand-Alone Keyboard ..................................................................................... 9

Low Speed USB (Integrated).......................................................................... 10

Notes for Laser Emulation.............................................................................. 11

Scanner Operation

Configurable Primary and Secondary Scan Pattern Modes ........................... 12

Configurable Button Functions ....................................................................... 12

Sweet Spot Mode ........................................................................................... 17

Indicators

Audible ....................................................................................................... 18

Visual ......................................................................................................... 19

Failure ........................................................................................................ 20

Depth of Field Specifications

Normal Scan Zone ..................................................................................... 21

Reduced Scan Zone................................................................................... 22

Depth of Field by Bar Code Element Width

Normal Scan Zone ..................................................................................... 23

Reduced Scan Zone................................................................................... 24

iii

TABLE OF CONTENTS

IR Activation Range........................................................................................ 25

Troubleshooting Guide ....................................................................................... 26

Design Specifications ......................................................................................... 30

Applications and Protocols ................................................................................. 32

Default Settings - Communication Parameters................................................... 33

Upgrading the Flash ROM Firmware.................................................................. 38

Scanner and Cable Terminations ....................................................................... 39

Regulatory Compliance

Safety ............................................................................................................. 43

EMC ............................................................................................................... 44

Limited Warranty ................................................................................................ 46

Patents ............................................................................................................... 47

Index .................................................................................................................. 48

Office Locations and Contact Information .......................................................... 50

INTRODUCTION

QuantumE

®is a miniature, omni-directional scanning engine with optional single-

line scanning capability. The self-contained device is fully enclosed eliminating

the need for an external window or custom enclosure. It is designed for use in

OEM equipment such as price lookup systems and kiosks. Its slim design makes

it ideal for integration and use with flat-screens.

Key Product Features

•Fully Automatic Scanning Operation

•Custom Configurable Scan Pattern

•User-Replaceable Single Cable Interface to Host (PowerLink Compatible)

•Decoding of All standard 1D, RSS-14, RSS Limited and

Expanded Bar Codes.

•Data Editing

•7 Beeper Tones

•Configurable Depth of Field

•Flash - Upgradeable Firmware

•CodeGate®

•Sunrise 2005 Compliant

SCANNER INTERFACE

IS3480-9 OCIA and RS232 Transmit/Receive

IS3480-11 IBM 46xx and Full RS232

IS3480-38 RS232 Low Speed USB,

Keyboard Emulation or Serial Emulation

IS3480-41 RS232/Light Pen Emulation

IS3480-47 Keyboard Wedge, Stand-Alone Keyboard and

RS232 Transmit/Receive

IS3480-104 RS232 TTL, Laser Emulation

INTRODUCTION

Scanner and Accessories

BASIC KIT COMPONENTS

Part No. Description

IS3480 QuantumEScanner

00-02026 IS3480 Installation and User’s Guide *

00-02407 MetroSelect®Configuration Guide *

* Guides also available for download at www.metrologic.com.

OPTIONAL ACCESSORIES

Part No. Description

AC to DC Power Transformer - Regulated 5.2VDC @ 1A output.

46-00525 90VAC to 255VAC United States, Canada and Japan

46-00526 90VAC to 255VAC Continental European

46-00527 90VAC to 255VAC United Kingdom

46-00528 90VAC to 255VAC Australia

46-00529 90VAC to 255VAC China

46-00530 90VAC to 255VAC India

54-54000-3

(default)

PowerLink cable with built in power jack

2.1m (7') straight cord, short strain relief

53-53000-3

(optional)

PowerLink cable with built in power jack

2.7m (9') coiled cord, long strain relief

** Contact a Metrologic customer service representative for additional

information on the MVC cable series and the host connections available.

MVC** Metrologic Voltage Converter Cable ±12VDC to +5.2VDC

Other items may be ordered for the specific protocol being used. To order additional items,

contact the dealer, distributor or call Metrologic’s customer service department at

1-800-436-3876.

INTRODUCTION

Scanner and Accessories

OPTIONAL ACCESSORIES

Part No. Description

54-54002x-3 Keyboard Wedge PowerLink cable

54-54020x-3 Stand Alone Keyboard PowerLink cable

54-54235x-N-3 Low Speed USB Non-Locking Communication Cable

2.8 m (9.2') straight cord, short strain relief

35-35959 Utility Flex Cable, 20 mm (0.8") Length

54-54249x-N-3 Communication Cable, Host end Not Terminated

203 mm (8") straight cord, short strain relief

REPLACEMENT PARTS

Part No. Description

36-01822x-3 Rubber Utility Seal

Other items may be ordered for the specific protocol being used. To order additional items,

contact the dealer, distributor or call Metrologic’s customer service department at

1-800-436-3876.

INTRODUCTION

Scanner Components

Figure 1a. Scanner Components

ITEM NO. DESCRIPTION

1 Utility Connector Located Under Rubber Seal

The rubber seal protecting the utility connector should only be

removed if the utility connector is to be used.

2 10-Pin RJ45, Female Socket

3 Blue, White and Yellow LED Indicators

4 Red Output Window (Laser Aperture)

5 Pin Hole for Cable Release

6 Speaker

7 Three M2.5 x 0.45 Threaded Mounting Points

8 Two M2.5 x 0.45 Threaded Mounting Points

9 Button

Cable Removal

1. Locate the small ‘pin-hole’ on the side of the

QuantumEnear the cable (item 5 in figure 1a).

2. Bend an ordinary paperclip into the shape shown.

3. Insert the paperclip (or other small metallic pin)

into the ‘pin-hole’.

4. You will hear a faint ‘click’ when the cable lock is

released. Pull gently on the strain-relief of the

PowerLink cable to remove it from the scanner.

Figure 1b.

INTRODUCTION

Caution and Serial Number Labels

Figure 2.

Caution

To maintain compliance with applicable standards, all circuits connected to the

scanner must meet the requirements for SELV (Safety Extra Low Voltage) according

to EN/IEC 60950-1.

To maintain compliance with standard CSA C22.2 No. 60950-1/UL 60950-1 and norm

EN/IEC 60950-1, the power source should meet applicable performance requirements for a

limited power source.

Mounting Specifications

Figure 3.

Maintenance

Smudges and dirt can interfere with the proper scanning of a bar code. The

output window should be routinely cleaned with glass cleaner sprayed onto a lint

free, non-abrasive cleaning cloth.

INSTALLATION

RS232, RS232 TTL, Light Pen or Laser Emulation

1. Turn off the host device.

2. Plug the male 10-pin RJ45 end

of the PowerLink cable into the

10-pin socket on the IS3480.

3. Connect the 9-pin female end of the

PowerLink cable to the host device.

Note: Skip to step 6 if receiving

power from the host device.

4. Plug the external power supply into

the power jack on the PowerLink

cable.

Check the AC input

requirements of the power

supply to make sure the

voltage matches the AC

outlet. The outlet must be

located near the equipment

and be easily accessible.

5. Connect AC power to the transformer.

6. Turn on the host device.

When the scanner first receives power, the blue LED will turn on;

the scanner will simultaneously beep once and flash the white LED.

Plugging the scanner into the serial port of the PC does not

guarantee that scanned information will appear at the PC.

A software driver and correct configuration setting are also required

for proper communication to occur.

See page 5.

Figure 4.
