MS860 / MS863 Mini-Slot

Laser Bar Code Scanner

Installation and User’s Guide

LOCATIONS

Corporate Headquarters

North America Metrologic Instruments, Inc. Customer Service: 1-800-ID-METRO

90 Coles Road Tel: 856-228-8100

Blackwood, NJ 08012-4683 Fax: 856-228-6673

Email: info@metrologic.com

Internet: www.metrologic.com

European Headquarters

Germany, Metrologic Instruments GmbH Tel: +49 89 89019 0

Middle East and Africa Dornierstrasse 2 Fax: +49 89 89019 200

82178 Puchheim b. Email: [email protected]ic.com

Munich, Germany Germany Email: [email protected]

Spain Metrologic Eria lbérica SL Tel: +34 913 272 400

Julián Camarillo 29, D-1 Fax: +34 913 273 829

Edificio Diapasón Email: [email protected]c.com

28037 Madrid

Italy Metrologic Instruments Italia srl Tel: +39 0 51 6511978

Via Emilia 70 Fax: +39 0 51 6521337

40064 Ozzano dell’Emilia (BO) Email: [email protected]

France Metrologic Eria France SA Tel: +33 (0) 1 48.63.78.78

69 Rue de la Belle Etoile Fax: +33 (0) 1 48.63.24.94

ZI Paris Nord II, BP 50057 Email: [email protected]

95947 – ROISSY CDG CEDEX

United Kingdom Metrologic Instruments UK Limited Tel: +44 (0) 1256 365900

58 Tempus Business Centre Fax: +44 (0) 1256 365955

Kingsclere Road, Basingstoke Email: [email protected].com

Hampshire RG21 6XG

Asia

Singapore Metrologic Asia (Pte) Ltd Tel: 65-6842-7155

No. 8 Kaki Bukit Place Fax: 65-6842-7166

4th Floor Email: inf[email protected]

Singapore 416186

China Metro (Suzhou) Technologies Co., Ltd. Tel: 86-512-62572511

221 Xing Hai Street Fax: 86-512-62571517

Suzhou Industrial Park Email: [email protected]

Suzhou, China

215021

Japan Metrologic Japan Co., Ltd. Tel: 81-03-3839-8511

Matsunoya Building, 6 Floor Fax: 81-03-3839-8519

3-14-8 Higashiueno Email: [email protected]ic.com

Taitou-Ku, Tokyo 110-0015 Japan

South America

Brazil Metrologic do Brasil Ltda. Tel: 55-11-5182-8226

Rua da Paz 2059 Fax: 55-11-5182-8315

CEP 04713-002 Email: [email protected]ic.com

Chácara Santo Antônio

São Paulo, SP, Brasil

Outside Brazil Metrologic South America Tel: 55-11-5182-7273

Rua da Paz 2059 Fax: 55-11-5182-7198

CEP 04713-002 Email: [email protected]c.com

Chácara Santo Antônio

São Paulo, SP, Brasil

in any form or by any means without prior written consent, except by reviewer, who may quote brief passages in a review,

or provided for in the Copyright Act of 1976.

Products and brand names mentioned in this document are trademarks of their respective companies.

iii

TABLE OF CONTENTS

Introduction........................................................................................................... 1

Scanner and Accessories..................................................................................... 2

Scanner Connections to the Host......................................................................... 3

Configuration of the Scanner to the Host System................................................. 4

Cloning Feature.................................................................................................... 5

Version 11 IBM 46xx Scanner .............................................................................. 6

Configuring the MS860-11/MS863-11 Scanner.................................................... 7

Configuring the IBM 46xx ..................................................................................... 8

Version 17 Keyboard Wedge Scanner ................................................................. 9

Connection of an MS860-17 Scanner to a PC.................................................... 10

Optional In-Counter Mounting Options for the MS860........................................ 11

Vertical Stand Kit................................................................................................ 12

Scanner Parts..................................................................................................... 13

The MS860 Touch Plate..................................................................................... 14

Visual Indicators ................................................................................................. 15

Volume Settings ................................................................................................. 19

Labels................................................................................................................. 21

Depth of Field ..................................................................................................... 22

Depth of Field and Symbol Specification ............................................................ 23

Maintenance....................................................................................................... 25

Specifications ..................................................................................................... 26

Default Settings .................................................................................................. 28

Scanner Pinout Connections

Version 1 - for RS-232, OCIA and Light Pen Emulation ................................. 35

Version 2 - for Parallel Communication.......................................................... 36

Version 11 - for RS-485 .................................................................................. 37

Version 17 - for Keyboard Wedge, RS-232 and Light Pen Emulation............. 38

Limited Warranty ................................................................................................ 39

Notices ............................................................................................................... 40

Patents ............................................................................................................... 42

Index................................................................................................................... 43

INTRODUCTION

Metrologic's MS860 and MS863 laser bar code Scanners are high-speed,

aggressive in-counter scanners. Both models have compact, durable housings

for use with applications where counter top space is limited.

The MS860 and MS863 autodiscriminate all standard bar codes. Each model

includes a code-correcting feature (MECCA©) that enables the scanner to decode

damaged or truncated codes on the first pass. Both models can be programmed

by using the bar code menus from the ScanSelect®Programming Guide or by

using Metrologic's ScanSet®IBM®compatible software program.

The MS860 has a brushed stainless steel top plate with an optional universal

adapter plate available for purchase that makes it simple to replace older, larger

flatbed scanners with the smaller MS860. The MS860 also has a unique “Touch-

on” power save mode and easily visible LED indicators mounted on the brushed

stainless steel top plate.

The MS863 has a dark gray plastic top instead of the brushed stainless steel of

the MS860. The MS863 also uses IR activation.An optional hardened glass

window is available for both models.

Metrologic also provides a vertical mounting option, so customers can use the

MS860 or MS863 as a projection scanner.

Each version of the MS860 provides three interface options, with full RS-232

protocol available on every scanner. RS-232, OCIA and Light Pen Emulation are

consolidated into the standard model. For simple PC connectivity, a keyboard

wedge interface is also available. Metrologic also offers a patented Hand-Held

Option, which allows users to connect the MS941 Hand-Held Scanner to the

MS860 or MS863 for greater scanning versatility.

MODEL INTERFACE

MS860-1 MS863-1 RS-232, OCIA, Light Pen Emulation

MS860-2 MS863-2 Parallel Output (OCR A/B)

MS860-11 MS863-11 IBM 46XX - RS-485, RS-232, OCIA

MS860-17 MS863-17 Keyboard Wedge, RS-232, Light Pen

SCANNER AND ACCESSORIES

•MS860 or MS863 Laser Bar Code Projection Scanner

•Installation and User’s Guide ....................................................MLPN 00-02202

•ScanSelect®Scanner Programming Guide ...............................MLPN 00-02186

•Volume Control Card .................................................................MLPN 00-02346

•Installation Plate for MS860 models only ...................................MLPN 45-45471

Optional Accessories

•Power Supply ........................................................................... MLPN 00-6114A

•Communication Cable for Version 1 MS860/MS863 ..................MLPN 51-51505

•Keyboard Wedge and Adapter Cable for the

MS860-17/MS863-17 .................................................................MLPN 45-45927

•Cloning Cable.............................................................................MLPN 51-51544

•Universal Plate for MS860 models only......................................MLPN 45-45474

•Vertical Stand.............................................................................MLPN 45-45472

If any item is missing or to order additional items, contact the dealer, distributor or

call Metrologic’s Customer Service Department at 1-800-ID-METRO or

1-800-436-3876.

SCANNER CONNECTIONS TO THE HOST

To avoid potential problems, do not power up the scanner until the

communication cable is secured to the host.

1. Turn off the host system.

2. Connect the 25-pin D-type connector on the scanner’s head cable to the

communication cable.

3. Connect the other end of the communication cable to the host device.

4. If the scanner will not receive power from a transformer, skip to

Step 5.

If the scanner will receive power from an external power source, check the

AC input requirements of the transformer to make sure the voltage matches

the AC outlet. The outlet must installed near the equipment and be easily

accessible.

5. Plug the transformer into the side of the female D-type connector located on

the communication cable.

6. Plug the transformer into the AC outlet to supply power to the scanner.

7. Power up the host system.

Note: When the scanner first receives power, the LEDs will flash and then

the scanner will beep once. After the scanner performs this start up

sequence, the green LED will remain ON for a specified time

indicating that the laser is ON.

Caution:

To maintain compliance with applicable standards, all circuits connected to the scanner must meet the requirements

for SELV (Safety Extra Low Voltage) according to EN 60950.

To maintain compliance with standard CSA C22.2 No. 950/UL 1950 and norm EN 60950, the power source should

meet applicable performance requirements for a limited power source.

CONFIGURATION OF THE SCANNER TO THE HOST SYSTEM

The MS860/MS863 is shipped from the factory programmed to a set of default

conditions noted in the Default Settings section of this guide and in the

ScanSelect®Scanner Programming Guide provided. The default settings in the

ScanSelect guide have an asterisk that appears before the brief definition next to

the bar code.

Since each host system is unique, the scanner will need to be configured to

match the specific host system’s requirements. If using ScanSet®, refer to the

ScanSet documentation for information on how to configure the scanner.

To configure the MS860/MS863

1. Connect the scanner to the host system (refer to page 3).

2. Enter program mode by scanning the ENTER/EXIT program mode bar code

(the unit will beep three times).

3. Scan the appropriate bar code(s) that appear in the ScanSelect Scanner

Programming Guide.

Note: Reveal only one bar code to the scanner at a time. With your hand,

cover the bar code that is not to be scanned.

4. Exit program mode by scanning the ENTER/EXIT program mode bar code

again.

Note: Non-RS-232 interfaces chosen in Section B of the ScanSelect

Programming Guide do not match the default settings that are loaded

when the same interface is selected with ScanSet.

CLONING FEATURE

The cloning feature is used to program several scanners with the same settings.

To clone a scanner:

1. Turn OFF the power to both scanners by unplugging the transformers.

2. Connect the cloning cable (MLPN 51-51544) between the two scanners.

3. Turn ON the power to both scanners by plugging in the transformers.

4. When each scanner is ready, scan the cloning bar code with the scanner

that has the settings that need to be transferred to the other scanner.

012345 77777 6

CLONING

VERSION 11 IBM 46XX SCANNER

Output Format: IBM RS-485 serial input/output for the 4680 and 4690 (46XX)

point-of-sale terminals

The Version 11 46XX interface can be used in several different ways. Both the

46XX terminal and the scanner must be configured to match each other.

Warning: Power to the scanner and 46XX terminal should be turned off before

making physical connection.

The 4680 and 4690 series terminals have different types of physical ports for

connecting bar code scanners. Scanner ports include Port 5B, Port 17, and

Port 9? (? = A, B, C, or E). A Port 9 type connector is present on all versions of

the 46XX families of terminals. That is one reason why it is the normal point of

connection for Metrologic scanners. Another reason is that there is enough

12 volt power available to operate many Metrologic scanners. If your terminal

configuration requires the use of a different physical port for connecting bar code

scanners, contact Metrologic to get particular adapter cable information.

All devices use a common communications bus inside the 46XX terminal, despite

what port that is in use for the physical connection. Each device has a different

address that it uses when it communicates. The terminal must be configured to

look for a device at a logical address.

The IBM 1520 mode/address was selected as a default because it was the first

IBM 46XX family scanner to support UPC/EAN, Code 39 and Interleaved

2 of 5 (I 2 of 5). The Version 11 scanner formats Codabar, Code 128, and Code

93 using the Code 39 function code designation supported by the IBM device

driver for this scanner type. Other emulation modes currently available are the

IBM 3687-2 Port 17 fixed scanner and the Port 9B IBM 4500 CCD hand-held bar

code reader. The use one of these other emulation modes may be needed

depending on which operating system (4680.OS, 4690.OS, POS/DOS or

DOS/RIPPS) is in use at your site.

Note: The IBM 4683 and IBM 4684 terminals have a good proven track record of

supplying power to Metrologic scanners. The IBM 4693 and IBM 4694

terminals may be restricted from supplying power to certain scanner

models. Specifically, Metrologic currently recommends using an external

power supply for the scanner when connecting to an IBM 4694.

Metrologic has no recommendations at this time for IBM 4693 terminals.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Metrologic Lecteur de codes-barres

Metrologic

Metrologic IS3480 QuantumE Manuel utilisateur

Metrologic

Metrologic Eclipse MS5145 Manuel utilisateur

Metrologic

Metrologic MH941 Manuel utilisateur

Metrologic

Metrologic MS5100 Eclipse Series Manuel utilisateur

Metrologic

Metrologic IS4320-41 ScanKey Manuel utilisateur

Metrologic

Metrologic Cubit MS6520 Series Manuel utilisateur

Metrologic

Metrologic Tire and Rubber Guide de l'utilisateur

Metrologic

Metrologic MK9535-79C5M38 - Metrologic MS9535 VoyagerBT Manuel utilisateur

Metrologic

Metrologic ScanQuest IS4110 Manuel utilisateur

Metrologic

Metrologic 160 Guide de l'utilisateur

Metrologic

Metrologic StratosE MS2122 Manuel utilisateur

Metrologic

Metrologic MS860 Manuel utilisateur

Metrologic

Metrologic StratosS MS2220 Manuel utilisateur

Metrologic

Metrologic MS700i Manuel utilisateur

Metrologic

Metrologic MetroSelect Manuel utilisateur

Metrologic

Metrologic MS9530 Series Manuel utilisateur

Metrologic

Metrologic MS 1690 Focus Series Manuel utilisateur

Metrologic

Metrologic MS9500 Voyager Series Manuel utilisateur

Metrologic

Metrologic MS5100 Eclipse Series Manuel utilisateur

Metrologic

Metrologic MS 1690 Focus Series Manuel utilisateur

Metrologic

Metrologic MS7600 Manuel utilisateur

Metrologic

Metrologic MS1890 Focus Manuel utilisateur

Metrologic

Metrologic IS3480 QuantumE Manuel utilisateur

Metrologic

Metrologic MS9520 Voyager Manuel utilisateur

Manuels Lecteur de codes-barres populaires d'autres marques

POSMicro

POSMicro Datalogic PowerScan D7100 Manuel utilisateur

Marson

Marson MT780 Guide de configuration rapide

NCR

NCR RealPOS Manuel utilisateur

Motorola

Motorola SE3300 Guide de configuration rapide

Element

Element P130BT Manuel utilisateur

Motorola

Motorola Symbol LS3008 Manuel d'installation et d'exploitation

Meec tools

Meec tools OBD-II / VAG Manuel utilisateur

SICK

SICK CLP 100 Manuel utilisateur

Royal Tag SA

Royal Tag SA I-Read Manuel utilisateur

Welch Allyn

Welch Allyn IMAGETEAM 3800 Manuel utilisateur

Meteor

Meteor 8310 Manuel utilisateur

Denso

Denso BHT-500B Manuel utilisateur

Datalogic

Datalogic Heron HD3130 Manuel utilisateur

Motorola

Motorola MP6000 Instructions de montage

Newland

Newland NLS-HR15-BT Manuel utilisateur

ARTDEV

ARTDEV AS-1310 Manuel utilisateur

Aopos

Aopos AS290 Manuel utilisateur

ENS

ENS 367-5455 Manuel utilisateur
