MERIT LILIN ENT. CO., LTD
http://www.meritlilin.com
INSTRUCTION MANUAL
D/N CMOS HD VARI-FOCAL DOME IP CAMERA
66-IPD112CSE
IPD112ESX3
IMPORTANT SAFEGUARDS
GRAPHIC SYMBOL EXPLANATION
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of
uninsulated "dangerous voltage" within the product's enclosure
that may be of sufficient magnitude to constitute a risk of electric
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
shock to persons.
accompanying the unit.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION
Do not drop or strike this equipment.
Do not install the equipment near any naked flames or heat
sources.
Do not expose this unit to rain or excessive moisture, avoid
smoke and dust.
Do not cover cloth or to install this unit in poorly ventilated
places.
Do not continue to operate if there appears to be fault.
Do not touch the power connection with wet hands.
Do not damage the power cord or leave it under pressure.
Sensitive electronics inside are vulnerable to excessive shock.
Excessive heat could damage this unit.
Please the camera in an environmental housing for protection.
If the camera gets wet, unplug it and have it checked by
qualified service personnel.
This may lead to overheating.
If the unit ceases to function, contact qualified service
personnel for help.
Risk of short circuit or electric shock.
Risk of fire or shock circuit.
120
113
98
67
LINK ACT
IPD112ESX is an indoor HD IP camera built-in H.264 AVC(Advanced Video Coding) video
compression. H.264 AVC video compression engine supports high Definition video quality,
720P resolution, bandwidth efficiency with PPPoE and DDNS.
Also it provides higher bit rate of internet and diverse alarm functions such as external alarm
or movement video detection e-mail or FTP. Moreover, IPD112ESX can do remote surveillance
with Java or Windows Mobile cell phone. The software R&D engineer can use HTTP protocol
(HTTPAPI) to develop related software, and integrate them with existing application software
system.
Executive Summary
1
Part Description & Dimension
Unit : mm
RJ-45 Network Cable
Indicator LEDs
LINK: While cable of network is connecting the LED is light.
ACT: When data is communicating, the LED is flashed.
Base
Fix Ring
DC POWER INPUT (DC12V 10%) JACK
Inside Cover
Dome Cover
Lens
Live Video RCA Jack
Reset Key
To restore the server to factory default setting.
Installation
2
1. Put the provided screws (M3.0 x 25, wooden screw) through the holes marked as "a",
and fix the base in the desired area (FIG.1).
2. The direction of the lens is adjustable through the adjustable Pan/Tilt brackets and
rotatable round bracket for Azimuth. The lens can be adjusted easily by hand without
using screw driver. Please refer to FIG.2.
a
a
a
FIG. 1
65
120
PAN
AZIMUTH
TILT
FIG. 2
IRIS LEVER VR
SCREW DRIVER
BRACKET
FOCUS ADJUSTMENT
ZOOM ADJUSTMENT
bb
cc
3. An extra RCA jack for easy installation. Plug the video input of monitor to the RCA jack
and adjust focus and zoom.
After finished, unplug the RCA jack. Please refer to FIG.3.
4. Adjust DC iris level by turning the iris level VR. Please refer to FIG.2.
ATTENTION: Adjust this VR with care so as not to cause damage to the unit.
5.Putontheinsidecoverfirst,andfollowedbyputonthedomecover.
Then tighten the fix ring(FIG.4).
FIG. 3
FIG. 4
3
6. Other wires installation like connecting audio in/output, video output and alarm in/out
with connector, please follow instruction as below:
Untighten the three screws to take
off the cover of bottom.
Audio In/Out
Alarm In/Out
To connect with wire accessory.
Take wire through the hole, and
configure the cover of bottom.
Tighten the three screws to fix the
cover of bottom.
Wire & Power Adaptor Accessory (99-IPD112WR) are option product.
NOTE
4
Alarm In/Out Terminal Pin Assignment
+5V OUT
N.O.
COM
INPUT
GND
(+5V OUT, 100m A max.)
(Alarm Output, Normal Open)
(Alarm Output, Common)
(Alarm Input)
(Alarm Ground)
ALARM
/VIDEO AUDIO
LAN
DC12V
Product Components
1. D/N CMOS HD Vari-Focal Dome IP Camera
2. Instruction manual
INSTRUCTION MANUAL
D/N CMOS HD VARI-FOCAL DOME IP CAMERA
IPD112ESX3
System Architectures
For connecting IPD112ESX to the network, please follow one of the system architectures:
(1). Hardware Installation using a PoE Switch.
IPD112ESX
PoE Switch
PC
LAN LAN / Internet
(2). Hardware Installation using a non-PoE Switch.
5
IPD112ESX
PoE Power Injector
PC
LAN LAN / Internet
AC
Non-PoE Switch
IPD552EX2.2/4.2 N/P
H.264 AVC IP Cameras
INSTRUCTION MANUAL
LAN
3. Wire & Power Adaptor Accessory
(99-IPD112WR, Option product)
4. CD Software Pack
6
(3). Hardware Installation using DC12V Adaptor.
IPD112ESX PC
LAN LAN / Internet
Non-PoE Switch
Emergency Factory Default
To restore the server to factory default settings, please:
1. Hold Reset Key for 10 second.
2. The network LED lights turn off after about 20 seconds, then lit.
3. The server board reboots itself.
4. Using IPScan scanning for the IP address of the IP device.
5. Launch Internet browser for the IP address of the IP device.
6. Type default username "admin" and password "pass" for enter web interface of the IP
device.
For convenient purpose, IP address resets to default IP address, 192.168.0.200, after
performing Load Default operation.
NOTE
Specifications
7
Lens
Pick Up Element
Effective Pixels
Chip Size
Scanning System
Infrared Cut Filter
Min. Illumination
White Balance
Back Light Compensation
Electrical Shutter
Live Video Output
Operating Temperature
Dimension
Weight
Power Input Voltage
Power Consumption
Model No.
Focal Length
Iris
AngleofView
H
V
D
3~9mm
IPD112ESX3
F1.2
1/4" Progressive scan CMOS sensor
1280(H) x 800(V) = 1,024,000(pixel)
3.88mm(H) x 2.43mm(V)
Progressive Scan
Auto / Schedule / Day(Color) / Night(Mono)
Color: 2Lux at F1.2 / Mono: 0.4Lux at F1.2
Auto / 3200K / 4700K / 5600K / 6500K / 7500K / 9300K
Auto
1/60s ~ 1/20,000s
CVBS 1.0Vp-p , 75ohm
-10 ~ +40 (14 ~ 104 )
144 x 86mm
520g
DC12V 10% / PoE (IEEE 802.3af compliant)
DC12V, 6W / PoE, 7.5W
62.3 ~ 21.2
45.8 ~ 15.9
79.7 ~ 26.5
Design and specification are subject to change without notice.
