Lilin IMEGAPRO LD2122E Manuel utilisateur

Instr uction Manual

66-IPD2122CSE

IPD2122ES / LD2122E

MERIT LILIN ENT. CO., LTD

http://www.meritlilin.com

D/N

1080P HD Dome IP Camera

IMPORTANT SAFEGUARDS

GRAPHIC SYMBOL EXPLANATION

The lightning flash with arrowhead symbol, within an equilateral

triangle, is intended to alert the user to the presence of

uninsulated "dangerous voltage" within the product's enclosure

that may be of sufficient magnitude to constitute a risk of electric

The exclamation point within an equilateral triangle is intended

to alert the user to the presence of important operating and

maintenance (servicing) instructions in the literature

shock to persons.

accompanying the unit.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION：

TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK)

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

CAUTION

RISK OF EXPLOSION IF BATTERY IS REPLACED

BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING

TO THE INSTRUCTIONS

CAUTION

Do not drop or strike this equipment.

Do not install the equipment near any naked flames or heat

sources.

Do not expose this unit to rain or excessive moisture, avoid

smoke and dust.

Do not cover cloth or to install this unit in poorly ventilated

places.

Do not continue to operate if there appears to be fault.

Do not touch the power connection with wet hands.

Do not damage the power cord or leave it under pressure.

Sensitive electronics inside are vulnerable to excessive shock.

Excessive heat could damage this unit.

Please the camera in an environmental housing for protection.

If the camera gets wet, unplug it and have it checked by

qualified service personnel.

This may lead to overheating.

If the unit ceases to function, contact qualified service

personnel for help.

Risk of short circuit or electric shock.

Risk of fire or shock circuit.

CONGRATULATIONS

Thank you for purchasing this D/N 1080P HD Dome IP Camera.

You now own one of the many fine network products we

manufactured. This product has been carefully inspected under

rigid quality control and should reach you in perfect condition.

With reasonable care, it will provide years of reliable performance.

We recommend that you read this installation and operation

manual thoroughly before installing and operation your new

system.

Here you will find all the information you need to set up and use

the system. If any questions are not answered in the manual,

please contact your dealer.

Before proceeding, please read and observe all instructions and

warnings contained in this manual. Retain this manual with the

original bill of sale for future reference and, if necessary, warranty

service.

When unpacking your new camera, check for missing or damaged

items. If any item is missing, or if damage is evident,

I . Contact your dealer for

assistance.

DO NOT

NSTALL OR OPERATE THIS PRODUCT

IPD2122ES & LD2122E series is an 2 megapixel (Day&Night)

1080P HD IP Camera, built-in H.264 AVC(Advanced Video

Coding) video compression. H.264 AVC video compression

engine supports high definition video quality, 1080P(1920x1080)

resolution, bandwidth efficiency with PPPoE and DDNS.

Also it provides higher bit rate of internet and diverse alarm

functions such as movement video detection e-mail or FTP.

Moreover, IPD2122ES & LD2122E series can do remote

surveillance with iPad, iPhone or Android cell phone. The

software R&D engineer can use HTTP protocol(HTTPAPI) or

ONVIF protocol to develop related software, and integrate them

with existing application software system.

IPD2122ES & LD2122E series is ideal solution for remote video

monitoring via internet.

Executive Summary

Unit: mm

PART DESCRIPTION & DIMENSION

1RJ-45 Network Cable (Support PoE)

DC12V Power Input Jack (DC12V 10%)

Base

Fix Ring

Inside Cover

Outside Cover

Lens

Reset Key

To restore the server to factory default setting.

Network Indicator LEDs

Green(LINK): Network cable connected, this LED lit.

Orange(ACT): Data communications, this LED flashes.

120

102

INSTALLATION

1. Put the provided screws (M3.0 x 25, wooden screw) through the holes marked as "a",

and fix the base in the desired area (FIG.1).　

120°

FIG. 1

2. The direction of the lens is adjustable through the adjustable Pan/Tilt brackets and

rotatable round bracket for Azimuth. The lens can be adjusted easily by hand without

using screw driver. Please refer to FIG.2.

PAN

AZIMUTH

TILT

BRACKET

FIG. 2

3. Put on the inside cover first, and followed by put on the dome cover.

Then tighten the fix ring(FIG.3).

b b

c c

FIG. 3

Inst r u ct i on Man ua l

IPD2122ES / LD2122E

D/N1080PHD DomeIP Camera

1080P HD DomeIP Camera

1. D/N 1080P HD Dome

IP Camera　

2. Instruction Manual

3. CD Software Pack

IPD552EX2.2/4.2 N/P

Full HD H.264 IP Cameras

INSTRUCTION MANUAL

PRODUCTION COMPONENTS

For connecting IPD2122ES & LD2122E Series to the network, please follow one of the

system architectures:

(1). Use DC12V power adapter and network switch connected to a network.

SYSTEM ARCHITECTURES

LAN LAN / Internet

Non-PoE Switch

1080P HD Dome

IP Camera

DC12V Adaptor

For the convenience of users, restore the factory default settings will revert to the

default IP address 192.168.0.200.

NOTE

EMERGENCY FACTORY DEFAULT

To restore the server to factory default settings, please:

1. Hold Reset Key for 10 second.

2. The network LED lights turn off after about 40 seconds, then lit.

3. The server board reboots itself.

4. Using IPScan scanning for the IP address of the IP device.

5. Launch Internet browser for the IP address of the IP device.

6. Type default username "admin" and password "pass" for enter web interface of the IP

device.　

PoE+(30W)

Switch

LAN LAN / Internet

(2). Use with PoE of the network switch connected to the network.

(3). Use PoE power injector and the network switch connected to the network.

LAN LAN / Internet

Non-PoE Switch

LAN

PoE+(30W)

Power Injector

1080P HD Dome

IP Camera

1080P HD Dome

IP Camera
