MERIT LILIN ENT. CO., LTD

http://www.meritlilin.com

INSTRUCTION MANUAL

VANDAL RESISTANT CAMERA

PIH-2222/2226/2242/2246

66-222CSE

VANDAL RESISTANT VARI-FOCAL CAMERA

PIH-2322X/2326X/2342X/2346X

IMPORTANT SAFEGUARDS

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK)

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

GRAPHIC SYMBOL EXPLANATION

The lightning flash with arrowhead symbol, within an equilateral

triangle, is intended to alert the user to the presence of

uninsulated "dangerous voltage" within the product's enclosure

that may be of sufficient magnitude to constitute a risk of electric

The exclamation point within an equilateral triangle is intended

to alert the user to the presence of important operating and

maintenance (servicing) instructions in the literature

shock to persons.

accompanying the unit.

PART DESCRIPTION & DIMENSION

BASE

DOME COVER

Unit mm

136.0

55.0

99.5

HOLE PLUG

SIDE HOLE

INSTALLATION

2. Put the provided screws (M3.0 x 25, wooden screw) through

the holes marked as "a", and fix the base in the desired area

(FIG.1).

1. Please use the enclosed screw driver to untighten the 4

tamper-proof screws on the dome cover.

3. Firstly, put video cable and power cable through a pipe with

1/2" PT at one end (FIG.2), and connect the cables to the

terminal block on the PCB accordingly and then screw the

pipe to the side hole (FIG.3, please make sure the connection

between the pipe and the side hole is watertight.).

Pipe is not provided.NOTE :

6. Adjust DC iris level by turning the iris level VR.

Please refer to FIG.5.

ATTENTION: Adjust this VR with care so as not to cause

damage to the unit.

7. Put on the dome cover first. Then tighten the tamper-proof

screws (FIG.7).

4. The direction of the lens is adjustable through the adjustable

Pan/Tilt brackets and rotatable round bracket for Azimuth.

The lens can be adjusted easily by hand without using screw

driver. Please refer to FIG.4(PIH-222 /224 ) and FIG.5

(PIH-232 X/234 X).

5. An extra RCA jack for easy installation. Plug the video input

of monitor to the RCA jack and adjust focus and zoom.

After finished, unplug the RCA jack. Please refer to FIG.6.

FIG. 1

VIDEO OUT

VIDEO GND

POWER

INPUT

FIG. 3

FIG. 2

FIG. 4 (PIH-222 / 224 )

BRACKET

TILT

FIG. 5 (PIH-232 X / 234 X)

TILT

PAN

BRACKET

ZOOM ADJUSTMENT

FOCUS ADJUSTMENT

IRIS LEVER VR

SCREW DRIVER

AZIMUTH

PAN

AZIMUTH

FIG. 6

FIG. 7

Alternative cabling positions

2. Put the video cable and power cable through the bottom

hole and connect them to the terminal block on the PCB

accordingly. Please refer to INSTALLATION Step3 for water-

resistant installation.

3. Fix the cable with cable clamp.

1. Untighten the hole plug on the bottom of the base and screw

it to the side hole.

VIDEO OUT

VIDEO GND

POWER

INPUT

VANDAL RESISTANT COLOR DOME CAMERA

Model No.

Power Input Voltage

System

Sync. Mode

Pick Up Element

Effective Pixels

Chip Size

Scanning System

Resolution

Minimum Illumination

S/N Ratio

Auto Gain Control

Aperture Correction

Power Consumption

Shutter

Back Light Compensation

Video Output

Gamma Characteristic

Lens

Operating Temperature

Weight

Dimension

DC12V ( 10%)

NTSC or PAL

Internal

1/3" Super HAD CCD Sensor

5.59mm (H) x 4.68mm (V)

2 1 Interlace

540TV Lines

0.5Lux (F1.8)

More Than 50dB (AGC OFF)

36dB Variable Gain

Horizontal , Vertical

2.2W

1/60(1/50)S ~ 1/100,000S(Auto)

Auto

CVBS 1.0Vp-p , 75ohm

=0.45

-10 ~ +50 (14 ~ 122 )

Base : 136 x 55mm , Dome : 91.8

768(H) x 494(V) [NTSC]

752(H) x 582(V) [PAL]

15.734KHz / 59.94Hz [NTSC]

15.625KHz / 50Hz [PAL]

Horizontal & Vertical

Sync. Frequency

Focal Length

Iris

Angleofview

3.6mm 6.0mm

F2.0 F1.8

Option lens 8.0mm lens.

Design and specifications are subject to change without notice.

White Balance ATW

1200g

3.6mm 6.0mm

F2.0 F1.8

54.5 33.1

73 44.5

92 56

54.5 33.1

73 44.5

92 56

510(H) x 492(V) [NTSC]

500(H) x 582(V) [PAL]

380TV Lines

0.2Lux (F1.8)

IP Rating

IP68

PIH-2242 3.6 PIH-2242 6PIH-2222 3.6 PIH-2222 6

SPECIFICATIONS

Vandal Proof

Withstand a blow from a 10 lbs sledgehammer

VANDAL RESISTANT DUAL VOLTAGE COLOR DOME CAMERA

Model No.

Power Input Voltage

System

Sync. Mode

Pick Up Element

Effective Pixels

Chip Size

Scanning System

Resolution

Minimum Illumination

S/N Ratio

Auto Gain Control

Aperture Correction

Power Consumption

Shutter

Back Light Compensation

Video Output

Gamma Characteristic

Lens

Operating Temperature

Weight

Dimension

DC12V ( 10%) or AC24V ( )10%

NTSC or PAL

Internal

1/3" Super HAD CCD Sensor

5.59mm (H) x 4.68mm (V)

2 1 Interlace

540TV Lines

0.5Lux (F1.8)

More Than 50dB (AGC OFF)

36dB Variable Gain

Horizontal , Vertical

2.5W (DC12V) , 2.0W (AC24V)

1/60(1/50)S ~ 1/100,000S(Auto)

Auto

CVBS 1.0Vp-p , 75ohm

=0.45

-10 ~ +50 (14 ~ 122 )

Base : 136 x 55mm , Dome : 91.8

768(H) x 494(V) [NTSC]

752(H) x 582(V) [PAL]

15.734KHz / 59.94Hz [NTSC]

15.625KHz / 50Hz [PAL]

Horizontal & Vertical

Sync. Frequency

Focal Length

Iris

Angleofview

3.6mm 6.0mm

F2.0 F1.8

Option lens 8.0mm lens.

Design and specifications are subject to change without notice.

White Balance ATW

1200g

3.6mm 6.0mm

F2.0 F1.8

54.5 33.1

73 44.5

92 56

54.5 33.1

73 44.5

92 56

510(H) x 492(V) [NTSC]

500(H) x 582(V) [PAL]

380TV Lines

0.2Lux (F1.8)

IP Rating

IP68

PIH-2246 3.6 PIH-2246 6PIH-2226 3.6 PIH-2226 6

Vandal Proof

Withstand a blow from a 10 lbs sledgehammer
