Lilin IPC0122WP3 Manuel utilisateur
IPC0422E / IPC0422WE
1080P HD Covert Dome (WIFI) IP Camera
66-IPC0122CSM
Quick Installation Guide
IPC0122P3 / IPC0122WP3
1080P HD Covert (WIFI) IP Camera
CAUTION
Do not drop or strike this equipment
Do not install the equipment near any naked flames or heat
sources
Do not expose this unit to rain, moisture, smoke or dust
environment
Do not cover the opening of the cabinet with cloth and plastic
or to install this unit in poor ventilated places. Allow 10cm
between this unit and its surroundings
Do not continue to operate the unit under abnormal conditions
such as detection of smoke, strange smell or no display on
screen while power is turned on
Do not touch the power connection with wet hands
Do not damage the power cord or leave it under pressure
Do not operate this unit near magnet, speaker system, etc., to
avoid unnecessary magnetic interference
Connection cables should be grounded properly
The ITE is to be connected only to PoE networks without
routing to the outside plant.
L’ITE ne doit être connecté que sur un réseau PoE sans routage
vers l’alimentation extérieure.
-1-
English
Product Overview
①Indicator LEDs
Green: System status display.
Orange: SD status display.
Red: Alarm status display.
②RJ-12 Image Sensor Unit Input Connector
③Detection Sensor Input Connector (optional)
④Micro SD Card Slot
⑤Reset Key
Unit: mm
-2-
English
⑥Wi-Fi Antenna Plug (Wi-Fi Model Only)
⑦QR Scan Button (Wi-Fi Model Only)
1.Press and hold the button for 2–5 seconds to enter the QR
Scan Mode.
2.Press and hold the button for more than 6 seconds to enable
the AP mode.
⑧DC12V Power Input Jack (DC12V± 10%)
⑨Live Video Output RCA Jack
⑩Audio Input 3.5mm Phone Jack
⑪Audio Output 3.5mm Phone Jack
⑫Alarm In/Out and RS-485 Terminal
⑬RJ-45 Network Connector and Indicator LEDs
Green (LINK): Network connection. LED remains lit while
connection is in place.
Orange (ACT): Data communications. This LED should continue
to blink.
⑭Straight Mounting Bracket
○
15 Image Sensor Unit
○
16 RJ-12 Cable
○
17 Wi-Fi Antenna (2.4GHz) (Wi-Fi Model Only)
○
18 Image Sensor Unit (Dome Model Only)
Installation
Main Unit Installation
Please use a screwdriver to fixe the iron plates to the bottom base
-3-
English
(FIG.1), insert the provided screws (M4.0 x 25, wooden screw)
through the holes marked as "a," and secure the main unit to the
desired position (FIG.2).
Image Sensor Unit Installation
1. Drill a 5mm hole in the panel or on the wall (FIG.3).
2. Pull off the protector and attach the mounting bracket to the
panel (FIG.4).
3. Insert the sensor unit into the bracket (FIG.5), and secure the
unit with the screw. Ensure that the cone of the sensor unit is
flush with the panel (FIG.6).
-4-
English
Image Sensor Unit Installation (Dome Model)
1. To remove the bracket, loosen the screws on the left and right
sides of the sensor with a hex wrench (FIG.7), and remove the
three screw hole plugs off the bracket (FIG.8).
2. Follow the installation diagram and fit the screws to bracket
mounting holes marked as “a” (FIG.9) to secure the bracket to
any desired location. Then, attach the rubber plugs to their
original positions (FIG.10).
-5-
English
3. Connect the image sensor to the camera unit, and adjust the
angle of the lens (FIG.11).
4. To secure the upper housing and lens, tighten the screws on
the left and right sides of the lens with a hex wrench (FIG.12)
-6-
English
System Architectures
To connect the Covert IP Camera to the network, please deploy one
of the following system architectures:
(1). Use a DC12V power adapter and a network switch to connect to
the network.
(2). Use a PoE network switch to connect to the network.
(3). Use a PoE power injector and a network switch to connect to the
network.
(4). Use a DC12V power source to connect to the network through a
Wi-Fi router. (Wi-Fi model only)
-7-
English
Wi-Fi Setting Indicator (Wi-Fi Model)
QR SCAN MODE
STATUS, SD, and ALARM are
all lit
Enter the QR Scan Mode
STATUS and SD remains lit,
and ALARM is off
Scanning and recognizing the
QR code
STATUS remains lit, and SD
and and ALARM are off
Wi-Fi network connected
successful and AP router login
completed
AP MODE
STATUS is blinking
Activating AP mode
STATUS ALARM
SD
-8-
English
How to Activate Connection in the AP Mode
1.Use a Wi-Fi enabled computer or smartphone to configure the Wi-
Fi IPCAM.
2.Search for a Wi-Fi IPCAM with an SSID of “IPCam-the last 6 digits
of MAC.” E.g., Wi-Fi MAC = 00-0F-FC-57-49-74, SSID = IPCam-
574974
3.A password is required to connect to the Wi-Fi IPCAM. The default
password is pass1234.
4.When connected, the default IP address of the AP mode is
192.168.15.1. You can use an Internet browser to change Wi-Fi
settings with this IP address.
Emergency Factory Default
To restore the hardware to factory default settings, please follow
these steps:
1.Press and hold “RESET Key” for 10 seconds and release.
2.Wait for about 40 seconds, and the network LED light should turn
off, and go back on again.
3.The camera is now restored to factory default settings, and will
reboot automatically.
4.Search for the IP device using the IPScan software.
5.Start the IP device via an Internet browser.
6.Enter the default username “admin” and password “pass” to
operate.
NOTE: For your convenience, the IP address will revert to the default
setting of 192.168.0.200.
