Lilin IPG1052ES Manuel utilisateur

Instruction Manual

IPG1052ES

MERIT LILIN ENT. CO., LTD

http://www.meritlilin.com

Day & Night 5MP HD IP Camera

IMPORTANT SAFEGUARDS

GRAPHIC SYMBOL EXPLANATION

The lightning flash with arrowhead symbol, within an equilateral

triangle, is intended to alert the user to the presence of

uninsulated "dangerous voltage" within the product's enclosure

that may be of sufficient magnitude to constitute a risk of electric

The exclamation point within an equilateral triangle is intended

to alert the user to the presence of important operating and

maintenance (servicing) instructions in the literature

shock to persons.

accompanying the unit.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION：

TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK)

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

CAUTION

RISK OF EXPLOSION IF BATTERY IS REPLACED

BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING

TO THE INSTRUCTIONS

CAUTION

Do not drop or strike this equipment.

Do not install the equipment near any naked flames or heat

sources.

Do not expose this unit to rain or excessive moisture, avoid

smoke and dust.

Do not cover cloth or to install this unit in poorly ventilated

places.

Do not continue to operate if there appears to be fault.

Do not touch the power connection with wet hands.

Do not damage the power cord or leave it under pressure.

Sensitive electronics inside are vulnerable to excessive shock.

Excessive heat could damage this unit.

Please the camera in an environmental housing for protection.

If the camera gets wet, unplug it and have it checked by

qualified service personnel.

This may lead to overheating.

If the unit ceases to function, contact qualified service

personnel for help.

Risk of short circuit or electric shock.

Risk of fire or shock circuit.

CONGRATULATIONS

Thank you for purchasing this D/N Megapixel HD IP Camera. You

now own one of the many fine network products we manufactured.

This product has been carefully inspected under rigid quality

control and should reach you in perfect condition. With reasonable

care, it will provide years of reliable performance.

We recommend that you read this installation and operation

manual thoroughly before installing and operation your new

system.

Here you will find all the information you need to set up and use

the system. If any questions are not answered in the manual,

please contact your dealer.

Before proceeding, please read and observe all instructions and

warnings contained in this manual. Retain this manual with the

original bill of sale for future reference and, if necessary, warranty

service.

When unpacking your new camera, check for missing or damaged

items. If any item is missing, or if damage is evident,

I . Contact your dealer for

assistance.

DO NOT

NSTALL OR OPERATE THIS PRODUCT

IPG1052ES series is an 5MP Day&Night HD IP Camera, built-in

H.264 AVC(Advanced Video Coding) video compression. H.264

AVC video compression engine supports high definition video

quality, 5MP(2592x1944) resolution, bandwidth efficiency with

PPPoE and DDNS.

Also it provides higher bit rate of internet and diverse alarm

functions such as movement video detection e-mail or FTP.

Moreover, IPG1052ES series can do remote surveillance with

iPad, iPhone or Android cell phone. The software R&D engineer

can use HTTP protocol(HTTPAPI) or ONVIF protocol to develop

related software, and integrate them with existing application

software system.

IPG1052ES series is ideal solution for remote video monitoring

via internet.

Executive Summary

PART DESCRIPTION & DIMENSION

122mm

50mm

SD CARD

EXTINGND

DIN

COM

RS485++5V

RESET

LAN

VIDEO OUT

POWER DC12V

AUDIO INAUDIO OUT

70mm

14 8

N O. .

RS485-

1. LENS MOUNT CAP

FOCAL LENGTH ADJUSTMENT RING AND LOCKING SCREW

MICROPHONE

AUTO IRIS CONNECTOR(DC Type)

Supplies control signals to an auto iris lens(jack not supplied).

6. POWER LED

Power ON/OFF indicator.

7. LIVE VIDEO RCA JACK

Plug the video input of monitor to the RCA jack and adjust focus and zoom.

8. RESET KEY

To restore the server to factory default setting.

9. RJ-45 NETWORK CONNECTOR AND INDICATOR LEDS

Green(LINK): While cable of network is connecting the LED is light.

Orange(ACT): When data is communicating, the LED is flashed.

(This network camera support PoE.)

10. AUDIO INPUT 3.5mm PHONE JACK

Can be accessed by an external microphone or audio input signal.

(Choose from the audio settings menu to switch)

Prevent damages to the image sensor and to keep dust away.

Use this ring to adjusts the back-focal distance or picture focus. Rotate this

ring clockwise or counterclockwise for a CS-mount lens.

Built-in highly sensitive capacitive microphone.

4. LIGHT SENSOR

Day and night function auto mode detect.

11. AUDIO OUTPUT 3.5mm PHONE JACK

12. DC12V POWER INPUT JACK

DC12V ( 10%) power input.

13. SD CARD SLOT

This network camera is compliant with SD/SDHC card.

14. ALARM IN/OUT, EXTIN & RS-485 TERMINAL

+5V COM. GND

N.O. DIN

1 2 3 4 5 6

EXTIN

+5V Output: Max. output 50mA.

N.O./COM.: Max. load +60V/100mA.

DIN terminal can be set either N.O. (normally open) or N.C. (normally

close) mode.

EXTIN: IR cut removable external control input.

IR CUT REMOVABLE EXTERNAL CONTROL SETUP

Access into web page setup menu, under schedule menu, enable External

Control option.

External input mode: normally open(NO) or normally closed(NC) mode is

selectable.

External input dwell: may select 1, 2, 5, 10, 15, 20, 30 seconds delay time

interval to avoid wrong operation caused by headlight

of the front light.

RS485+

RS485-

AUDIO INPUT MODE SETUP

Access into web page setup menu, under audio adjustment setup menu,

may select Audio Input mode to either camera front microphone or rear's

Audio In (Line IN).

INSTALLATION

The lens must be either a C or CS mount type. The protrusion behind the

mounting surface must be within the following limits:

SUITABLE LENSES

C - mount lens CS - mount lens

9mm or less 4mm or less

FITTING THE LENS

Remove the lens mount cap.

Screw in the C mount ring(not supplied), until it is secured. When using a

CS mount lens skip step2.

Screw in the lens, until it is secured.

Insert the lens plug in the AUTO IRIS connector, when fitting a manual-

iris lens, skip step4.

Adjust the focal length by turning the focal length adjustment ring.

(Using hexagon screw driver, loose and tighten the screw.)
