Life Span TR7000iM Manuel utilisateur
Life’s short. Live longer.
Commercial Treadmill
Owner’s Manual for TR7000iM
Congratulations on Purchasing Your LifeSpan Treadmill!
At LifeSpan we take pride in the quality, safety, and reliability of our products as
well as the professionalism of our sales support and customer service teams.
Making it our number one priority that you have an exceptional experience
using our products.
To support the quality of our products we pre-assemble parts on the
manufacturing line whenever possible to reduce the number of steps and
complexity of customer assembly, independently certify our products to comply
with the latest industry Safety Standards, and use state of the art production
processes and quality components.
Then we back LifeSpan products with excellent warranties and a responsive
customer service department making it simple and easy to get assistance
should the need arise.
This attention to quality, our high standard for customer service and focus on
innovation has earned LifeSpan numerous awards and consistent praise from
independent review groups, industry authorities and you, the consumer.
Thanks for choosing LifeSpan.
Welcome
Please thoroughly read this manual before you assemble or operate your treadmill.
Neither LifeSpan nor its representatives can accept responsibility for any damages or injury
incurred as a result of information presented in this manual except under the terms of the
product warranty.
Contents
About Your Treadmill.................................................................................................4
Specications
Unique Features
Warranty, Registration
Safety First...................................................................................................................... 11
Children and Pets
Safety Tips
Safety Key
Proper Grounding
Assembling Your Treadmill................................................................................. 16
Exploded View & Hardware
Assembly Instructions
Console Basics.............................................................................................................. 34
Console Overview
Readout Display
Operating Keyboard
Contents
Operations...................................................................................................................... 41
Home Screen
Personal Settings
Bluetooth Speaker, Chest Strap and Arm Band
Quick Start
Manual Program
Preset Programs
Custom User Set-Up Programs
Heart Rate Control Programs
Summary Screen
Screencasting
Equipment Settings
Program Proles
Preset Program Operation
Maintenance and Tips............................................................................................ 40
Heart Rate Monitoring
Hand Pulse Sensors, Chest Strap
Belt Lubrication
Moving the Treadmill
Cleaning
Belt Tensioning, Belt Alignment
Troubleshooting
4
About Your Treadmill
Specications
Console
Display
18.5" Colorful Touch screen and Touch panel,
showing workout progress, and simultaneous
display of all readouts.
Readouts Program name, date and time, speed, incline,
distance, calories, steps, heart rate, and pace
Programs
Two heart rate control programs, and 42 programs
grouped by exercise motivation type for weight loss,
healthy living, and sports
Quickstart Yes
USB Ports 1 USB port for mobile device charging
Bluetooth Sync workout data with LifeSpan Club app
Heart Rate Grip pulse and BT Heart rate
Media Holder Book, magazine, and tablet computer holder
Emergency Stop
Mechanical safety clip, when detached, immediately
turns o power, bringing the treadmill to a gentle
stop
Units of Measure Standard and metric settings
Language Support English
Treadmill
Belt Size 22” W x 62” L (56cm W x 157.5cm L)
Drive Motor 5.0 HP Continuous Duty AC
Belt Type Multi-ply polyester belt with PVC non-slip surface
Incline Motor 1000 lbs. (453.6 kg) thrust
Rollers 3.0” (7.5cm) crown rollers keep belt centered
Speed 0.5 - 12 MPH (0.8 - 20 KPH)
Incline -3 to +12
Deck Suspension Independent shock absorbers
5
About Your Treadmill
Treadmill (Cont.)
Deck 1” (2.54cm) melamine laminated reversible deck
medium-density ber board
Dimensions: 80.5” L x 36.5” W x 61” H
(204.5 L x 93.2 W x 154.9 H cm)
Step-Up Height: 9.5" (24 cm)
Max. User Weight: 400 lbs. (181.4 kg)
Net Weight: 434 lbs. (197 kg)
Gross Weight 480 lbs. (218 kg) (including Medical Handrails)
Certications CE/ETL US and CA /FCC Class SB EN 20957-1,
EN 957-6
Included Accessory
Medical Handrails 42” high x 35” wide. 1.25” diameter steel tubing in
black powder coating
7
Intelli-Guard™
Walk condently knowing your safety is assured with Intelli-Guard™.
Step away from your treadmill for more than twenty seconds and your
treadmill’s belt will automatically glide to a smooth stop.
Intelli-Step™
Never miss a stride with Intelli-Step™. Your steps are automatically
calculated with meticulous precision, displaying immediate feedback.
USB Charging Port
Charges most of your mobile devices. 5V, 0.5A Power Output.
Unique Features
As a leader in the tness industry, LifeSpan has developed a number of unique
features in our treadmills making them more engaging, safer and easier to use.
Learn more about how to use these features in the Personal Settings sections
of this Owner’s Manual.
About Your Treadmill
8
Warranty
Your LifeSpan treadmill/bike desk comes with the following limited warranty
valid in North America. If you are outside of this area contact your local
authorized LifeSpan dealer.
LifeSpan warrants that the equipment it manufactures is free from defects in
materials and workmanship under normal use and services. The periods above
are based on the date of purchase. During these periods, LifeSpan will repair
or replace any defective part. Free labor is included on all parts that are not
normally assembled or replaced by the customer within the labor period.
If within the time frames specied above, any part fails to operate properly,
login to our website at www.LifeSpanFitness.com, click on “Customer Service”
and complete the form to request assistance or call 877.654.3837 x4 for a
Customer Service Agent (please note that certain kinds of service should only be
performed by a qualied service technician).
LifeSpan reserves the right to make changes and improvements to our products
without incurring any obligations to similarly alter any product purchased.
In order to insure our product warranty and to ensure the safe and ecient
operation of your LifeSpan product, only authorized parts can be used. The
warranty is void if any parts other than those provided by LifeSpan are used.
About Your Treadmill
Treadmill Usage - 6 Hrs/Day
Treadmill Frame Lifetime 10 Years
Motor Lifetime 5 Years
Parts 5 Years 5 Years
Labor 2 Years 1 Year
COMMERCIALRESIDENTIAL
9
Exclusions and Limitations:
• This warranty does not apply to any defects caused by negligence,
misuse, improper assembly, or maintenance, accident, or “act of God.”
• This warranty does not apply to discoloration of paints or plastics.
• LifeSpan shall not be responsible for incidental or consequential
damages.
• This warranty is non-transferable form the original owner.
Registration
You must register your LifeSpan product before a warranty claim can be
processed. To complete your registration online go to www.lifespantness.
com/support/registration. Registration must be completed withing 60 days
of delivery to activate the product warranty. Product warranties are not valid
unless the registration is properly completed within 60 days.
About Your Treadmill
11
Safety First
When using exercise equipment, basic precautions should always be followed,
including:
• Never drop or insert any object into any opening. If an object falls into
an opening, turn the power o and unplug the power cord from the
outlet. Remove the object or call customer service at 877.654.3837 x4.
• Never operate this treadmill if it has been damaged or partially
submersed in water.
• To reduce the risk of electric shock, unplug the treadmill from the wall
outlet when not in use, before performing any maintenance, or before
moving the treadmill.
• Do not use outdoors or in areas of high humidity or extreme
temperature changes.
• Do not lean against or climb on the treadmill.
• Do not operate where aerosol spray products are being used or where
oxygen is being administered.
• Never place the power cord under carpeting or place any object on top
of the cord, this may pinch or damage the cord causing re damage or
personal injury.
• Use this exercise product for its intended use as described in this
Owner’s Manual. Do not use attachments that are not recommended by
LifeSpan.
• Do not leave your treadmill running while not in use.
Children and Pets
• Keep children from playing on your treadmill at all times.
• When in use children and pets should be kept at least 10 feet (3m) away.
• This treadmill can be used by children ages 12 years and above and
persons with reduced physical, sensory or lack of experience and
knowledge if they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the hazards involved.
• Cleaning and user maintenance shall not be made by children without
supervision.
