Life Span VULCAN Manuel utilisateur

VULCAN

TREADMILL

OWNER’S

MANUAL

Product may vary slightly from the item pictured due to model upgrades

Read all instructions carefully before using this product. Retain this owner’s manual for future

reference.

NOTE: This manual may be subject to updates or changes. Up to date manuals are available through our website at www.lifespanfitness.com.au

Vulcan

TABLE OF CONTENTS

1. IMPORTANT SAFETY INSTRUCTIONS 3

2. IMPORTANT ELECTRICAL INFORMATION 5

3. IMPORTANT OPERATING INSTRUCTIONS 6

4. ASSEMBLY INSTRUCTIONS 7

5. FOLDING INSTRUCTIONS 12

6. OPERATION GUIDE WITH PROGRAM CHART 14

7. EXERCISE GUIDE 20

8. MAINTENANCE INSTRUCTIONS 22

9. EXPLODED DIAGRAM 29

10. PARTS LIST 30

11. WARRANTY 32

Vulcan

1. IMPORTANT SAFETY INSTRUCTIONS

WARNING - Read all instructions before using this treadmill.

It is important your treadmill receives regular maintenance to prolong its useful life. Failing to

regularly maintain your treadmill may void your warranty.

Danger –To reduce the risk of electric shock disconnect your treadmill from the electrical outlet prior to

cleaning and/or service work.

DO NOT USE AN EXTENSION CORD: DO NOT ATTEMPT TO DISABLE THE GROUNDED PLUG BY

USING IMPROPER ADAPTERS OR IN ANY WAY MODIFY THE CORD SET.

Install the treadmill on a flat level surface with access to a 220-240 volt (50/60Hz), grounded outlet.

Do not operate treadmill on deeply padded, plush or shag carpet. Damage to both carpet and

treadmill may result.

Do not block the rear of the treadmill. Provide a minimum of 1 metre clearance between the rear of

the treadmill and any fixed object.

Place your unit on a solid, level surface when in use

When running, make sure the plastic clip is fastened on your clothing. It is for your safety, should

you fall or move too far back on the treadmill.

Keep hands away from all moving parts.

Never operate the treadmill if it has a damaged power cord or plug. When damaged, these must be

replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a

hazard.

Keep the cord away from heated surfaces.

Do not operate where aerosol spray products are being used or where oxygen is being

administered. Sparks from the motor may ignite a highly gaseous environment.

Never drop or insert any object into any openings.

The treadmill is intended for in-home use only and is not suitable for commercial environments.

To disconnect, turn all controls to the off position, remove the safety key, and then remove the plug

from the outlet.

Vulcan

The pulse sensors are not medical devices. Various factors, including the user’s movement, may

affect the accuracy of heart rate readings. The pulse sensors are intended only as exercise aids in

determining heart rate trends in general.

Use the handrails provided; they are for your safety.

Wear proper shoes. High heels, dress shoes, sandals or bare feet are not suitable for use on your

treadmill. Quality athletic shoes are recommended to avoid leg fatigue.

Before undertaking any type of exercise program, it is recommended that you consult a doctor.

Injuries to health may result from incorrect or excessive training.

This appliance is not intended for use by persons (including children) with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge, unless they have been given

supervision or instruction concerning use of the appliance by a person responsible for their safety.

WARNING heat rate monitoring systems may be inaccurate. If you feel faint stop exercising

immediately.

Children should not be allowed on or around the equipment, even when not in use.

Children should be supervised to ensure that they do not play with this machine

Loose-fitting clothing or jewellery that could become an entanglement hazard should not be worn.

Training shoes should be worn when using the equipment.

Equipment must be used on a level and stable surface.

All fixings should be checked before the equipment is used.

All literature relating to the use of the equipment should be retained for future reference.

Recommended operating temperature: 5-40°C

Remove the safety key after use to prevent unauthorized treadmill operation.

Vulcan

2. IMPORTANT ELECTRICAL INFORMATION

WARNING!

Route the power cord away from any moving part of the treadmill including the elevation mechanism

and transport wheels.

NEVER remove any cover without first disconnecting AC power.

NEVER expose this treadmill to rain or moisture. This treadmill is not designed for use outdoors,

near a pool, or in any other high humidity environment.

This is a high-power item; please do not share the same outlet with other high power machines such

as, fridges, air conditioning etc. Please choose an outlet exclusively for the machine and make sure

the fuse is 10A.

Vulcan

3. IMPORTANT OPERATING INSTRUCTIONS

Understand that changes in speed and incline do not occur immediately. Set your desired speed on

the computer console and release the adjustment key. The computer will obey the command

gradually.

Use caution while participating in other activities while walking on your treadmill, such as watching

television, reading, etc. These distractions may cause you to lose balance or stray from walking in

the centre of the belt; which may result in serious injury.

In order to prevent losing balance and suffering unexpected injury, never mount or dismount the

treadmill while the belt is moving. This unit starts with at a very low speed. Simply standing on the

belt during slow acceleration is proper after you have learned to operate this machine.

Always hold on to handrail while making control changes.

A safety key is provided with this machine. Remove the safety key will stop the walking belt

immediately; the treadmill will shut off automatically. Inserting the safety key will reset the display.

Do not use excessive pressure on console control keys. They are precision set to function

properly with little finger pressure.

Replace any defective components immediately. The machine must be kept out of use until repaired.

Belt wear-in period: all treadmills make a certain type of thumping noise due to the belt riding over

the rollers, especially new treadmills. This noise will diminish over time, although may not completely

go away. The belt will stretch over time, causing it to ride smoother over the rollers.

Vulcan

4. ASSEMBLY INSTRUCTIONS

III

Tool Bag

VII

Safety Key

Vulcan

PART LIST

DES.

Specification

Qty.

Main frame

1PC

Computer

1PC

III

Right/Left armrest inside cover

2 PCS

Right/Left base cover

2 PCS

Oil bottle

1PC

Tool bag

1SET

VII

Safety Key

1PC

VIII

User manual

1PC

Vulcan

STEP 1:

1. Open the carton

2. Extract the parts listed above

3. Place the Main Frame onto level ground

Warning: Use 2 people to remove treadmill from the box to avoid accidents.

STEP 2:

1. Fold the treadmill upright as shown above. You will need a second person to hold the treadmill

upright while you assemble it.

2. Secure the Right/Left upright (4L) (5R) to the base frame with:

- 2pcs M8*20mm bolt (88)

- 2pcs φ8 washer (87)

- 4pcs M8*60mm bolt (12)

- 4pcsφ8 flat washer (29)

- 4pcs lock nut (27)

3. Connect the Right/Left upright (4L) (5R) with the base frame (1) and tighten bolts.

4. Check the upright is tighten, then use 2pcs bolt (25) to secure the Right/Left base cover (54L)

(55R) on the Right/Left upright (4L) (5R).

Vulcan

STEP 3:

1. Use 2pcs M8*45mm bolt (13), 2pcs φ8 flat washer (29) to connect the Right/Left upright (4L) (5R) with the

armrest. Tighten all bolts.

2. Then use 4pcs bolt (22) to secure the Right/Left armrest inside cover (56L) (57) on the Right/Left upright

(4L) (5R).

STEP 4:

1. Connect the signal line.

2. Put the fixed seat below the computer into the hole of the fixed tube. Connect the display screen on

the computer frame with 2pcs M6*20mm bolt (88). Tighten all bolts.
