Life Span CHASER Manuel utilisateur

NOTE: This manual may be subject to updates or changes. Up to date manuals are available through our website at www.lifespanfitness.com.au

Product may vary slightly from the item pictured due to model upgrades

Read all instructions carefully before using this product. Retain this owner’s manual for

future reference.

CHASER OWNER’S MANUAL

CHASER

TABLE OF CONTENTS

1. IMPORTANT SAFETY INSTRUCTIONS 3

2. IMPORTANT ELECTRICAL INFORMATION 5

3. IMPORTANT OPERATING INSTRUCTIONS 5

4. ASSEMBLY INSTRUCTIONS 6

5. FOLDING INSTRUCTIONS 10

6. OPERATION GUIDE WITH PROGRAM CHART 11

7. EXERCISE GUIDE 16

8. MAINTENANCE INSTRUCTIONS 18

9. EXPLODED DIAGRAM 26

10.PARTS LIST 27

11.TROUBLE SHOOTING GUIDE 28

12.WARRANTY 31

CHASER

1. IMPORTANT SAFETY INSTRUCTIONS

WARNING - Read all instructions before using this treadmill.

It is important your treadmill receives regular maintenance to prolong its useful life. Failing to

regularly maintain your treadmill may void your warranty.

Danger –To reduce the risk of electric shock disconnect your treadmill from the electrical outlet prior

to cleaning and/or service work.

DO NOT USE AN EXTENSION CORD: DO NOT ATTEMPT TO DISABLE THE GROUNDED PLUG BY

USING IMPROPER ADAPTERS OR IN ANY WAY MODIFY THE CORD SET.

Install the treadmill on a flat level surface with access to a 220-240 volt (50/60Hz), grounded

outlet.

Do not operate treadmill on deeply padded, plush or shag carpet. Damage to both carpet and

treadmill may result.

Do not block the rear of the treadmill. Provide a minimum of 1 metre clearance between the rear

of the treadmill and any fixed object.

Place your unit on a solid, level surface when in use

When running, make sure the plastic clip is fastened on your clothing. It is for your safety,

should you fall or move too far back on the treadmill.

Keep hands away from all moving parts.

Never operate the treadmill if it has a damaged power cord or plug. When damaged, these must

be replaced by the manufacturer, its service agent or similarly qualified persons in order to

avoid a hazard.

Keep the cord away from heated surfaces.

CHASER

Do not operate where aerosol spray products are being used or where oxygen is being

administered. Sparks from the motor may ignite a highly gaseous environment.

Never drop or insert any object into any openings.

The treadmill is intended for in-home use only and not suitable for long term running.

To disconnect, turn all controls to the off position, remove the safety key, and then remove the

plug from the outlet.

The pulse sensors are not medical devices. Various factors, including the user’s movement,

may affect the accuracy of heart rate readings. The pulse sensors are intended only as exercise

aids in determining heart rate trends in general.

Use the handrails provided; they are for your safety.

Wear proper shoes. High heels, dress shoes, sandals or bare feet are not suitable for use on

your treadmill. Quality athletic shoes are recommended to avoid leg fatigue.

Before undertaking any type of exercise program, it is recommended that you consult a doctor.

Injuries to health may result from incorrect or excessive training.

This appliance is not intended for use by persons (including children) with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge, unless they have been

given supervision or instruction concerning use of the appliance by a person responsible for

their safety.

WARNING heat rate monitoring systems may be inaccurate. If you feel faint stop exercising

immediately.

Children should not be allowed on or around the equipment, even when not in use.

Children should be supervised to ensure that they do not play with this machine

Loose-fitting clothing or jewellery that could become an entanglement hazard should not be

worn.

Equipment must be used on a level and stable surface.

All fixings should be checked before the equipment is used.

All literature relating to the use of the equipment should be retained for future reference.

CHASER

Recommended operating temperature: 5-40°C

Remove the safety key after use to prevent unauthorized treadmill operation.

2. IMPORTANT ELECTRICAL INFORMATION

WARNING!

Route the power cord away from any moving part of the treadmill including the elevation

mechanism and transport wheels.

NEVER remove any cover without first disconnecting AC power.

NEVER expose this treadmill to rain or moisture. This treadmill is not designed for use outdoors,

near a pool, or in any other high humidity environment.

This is a high-power item; please do not share the same outlet with other high power machines

such as, fridges, air conditioning etc. Please choose an outlet exclusively for the machine and

make sure the fuse is 10A.

3. IMPORTANT OPERATING INSTRUCTIONS

Understand that changes in speed and incline do not occur immediately. Set your desired

speed on the computer console and release the adjustment key. The computer will obey the

command gradually.

Use caution while participating in other activities while walking on your treadmill, such as

watching television, reading, etc. These distractions may cause you to lose balance or stray

from walking in the centre of the belt; which may result in serious injury.

In order to prevent losing balance and suffering unexpected injury, never mount or dismount the

treadmill while the belt is moving. This unit starts with at a very low speed. Simply standing on

the belt during slow acceleration is proper after you have learned to operate this machine.

Always hold on to handrail while making control changes.

CHASER

A safety key is provided with this machine. Removing the safety key will stop the walking belt

immediately; the treadmill will shut off automatically. Inserting the safety key will reset the

display.

4. ASSEMBLY INSTRUCTIONS

PART LIST

DES

Specification

Qty

DES.

Specification

Qty

Main frame

Bolt

M8*45

#5 Allen wrench

Safety key

Bolt

M8*16

Oil bottle

Lock washer

MP3 wire

ASSEMBLY TOOLS:

#5 Allen wrench 5mm 1pc

#6 Allen wrench 6mm 1pc

Wrench s/screw Driver S=13, 14, 15 1pcs

Notice: Do not connect power before completing assembly.

CHASER

STEP 1:

STEP 2:

1. Open the carton

2. Extract the parts listed above

3. Place the Main Frame onto level

ground

1. Position the computer according to the

diagram.

2. Using the 5# Allen wrench, secure the

Computer frame to Left Upright and

Right Upright by using Bolt M8*16(55)

and Lock washer(67).

Note: Support the upright with your hands to

prevent it falling down and causing injury.

CHASER

STEP 3:

STEP 4:

1. Carefully erect the computer and the

upright tubes

2. Do not damage the computer wire

when doing so

Note: Support the upright with your hand

to avoid the display falling down and

causing injury

1. Using the 5# Allen wrench (12), screw in

the Bolt M8*16 (70) and Lock washer(67).

2. Attach the Right Upright Tube to the Main

Frame;

3. Use the 5# Allen wrench (13) to screw

Bolt M8*16 (55) and Lock washer (67) to

the base frame through base and right

upright tube. Reference the picture left.

Repeat this method for the left side

assembly.

Note: Support the upright with your hands to

prevent it falling down and causing injury.

CHASER

STEP 5:

1. Place the safety key (38) into its dock on

the display and switch the power switch

on.

CHASER

5. FOLDING INSTRUCTIONS

Unfolding:

Folding:

Whilst supporting position (A) with our

hand, gently push position (B), the marked

area on the air pressure bar, with your foot.

The base frame will descend automatically.

(Please keep people and pets away the

machine during descent)

Place your hand on position (A), then pull

up the base frame until you hear the click

sound emitted when the air pressure bar

(B) is locked into the round tube.

Video Tutorial Available at:

http://youtu.be/TcuPbJ7KuxQ

Lifespan Fitness YouTube Channel:

http://www.youtube.com/user/treadmillsvideos
