Life Span BALANCE Manuel utilisateur

Product may vary slightly from the item pictured due to model upgrades

Read all instructions carefully before using this product. Retain this owner’s manual for

future reference.

BALANCE

OWNER’S MANUAL

BALANCE

TABLE OF CONTENTS

1. IMPORTANT SAFETY INSTRUCTIONS 3

2. IMPORTANT ELECTRICAL INFORMATION 4

3. IMPORTANT OPERATING INSTRUCTIONS 5

4. ASSEMBLY INSTRUCTIONS 6

5. FOLDING INSTRUCTIONS 10

7. GROUNDING METHODS 11

8. OPERATION GUIDE 12

9. EXERCISE GUIDE 15

10. MAINTENANCE GUIDE 17

11. EXPLODED DIAGRAM 21

12. PARTS LIST 22

13. TROUBLE SHOOTING GUIDE 25

14. WARRANTY 27

15. PROGRAM GUIDE 28

BALANCE

1. IMPORTANT SAFETY INSTRUCTIONS

WARNING - Read all instructions before using this treadmill.

It is important your treadmill receives regular maintenance to prolong its useful life. Failing to

regularly maintain your treadmill may void your warranty.

Danger –To reduce the risk of electric shock disconnect your treadmill from the electrical outlet prior to

cleaning and/or service work.

DO NOT USE AN EXTENSION CORD: DO NOT ATTEMPT TO DISABLE THE GROUNDED PLUG BY

USING IMPROPER ADAPTERS OR IN ANY WAY MODIFY THE CORD SET.

Install the treadmill on a flat level surface with access to a 220-240 volt (50/60Hz), grounded outlet.

Do not operate treadmill on deeply padded, plush or shag carpet. Damage to both carpet and

treadmill may result.

Do not block the rear of the treadmill. Provide a minimum of 1 metre clearance between the rear of

the treadmill and any fixed object.

Place your unit on a solid, level surface when in use

Never allow children on or near the treadmill.

When running, make sure the plastic clip is fastened on your clothing. It is for your safety, should

you fall or move too far back on the treadmill.

Keep hands away from all moving parts.

Never operate the treadmill if it has a damaged cord or plug.

Keep the cord away from heated surfaces.

Do not operate where aerosol spray products are being used or where oxygen is being administered.

Sparks from the motor may ignite a highly gaseous environment.

Never drop or insert any object into any openings.

BALANCE

The treadmill is intended for in-home use only and not suitable for long time running.

To disconnect, turn all controls to the off position, remove the safety key, and then remove the plug

from the outlet.

The pulse sensors are not medical devices. Various factors, including the user’s movement, may

affect the accuracy of heart rate readings. The pulse sensors are intended only as exercise aids in

determining heart rate trends in general.

Use the handrails provided; they are for your safety.

Wear proper shoes. High heels, dress shoes, sandals or bare feet are not suitable for use on your

treadmill. Quality athletic shoes are recommended to avoid leg fatigue.

Allowed temperature: 5 to 40 degrees.

Remove the safety key after use to prevent unauthorized treadmill operation.

2. IMPORTANT ELECTRICAL INFORMATION

WARNING!

NEVER use a ground fault circuit interrupt (GFCI) wall outlet with this treadmill. Route the power

cord away from any moving part of the treadmill including the elevation mechanism and transport

wheels.

NEVER remove any cover without first disconnecting AC power.

NEVER expose this treadmill to rain or moisture. This treadmill is not designed for use outdoors,

near a pool, or in any other high humidity environment.

BALANCE

3. IMPORTANT OPERATING INSTRUCTIONS

Be sure to read the entire manual before operating your machine.

Understand that changes in speed and incline do not occur immediately. Set your desired speed on

the computer console and release the adjustment key. The computer will obey the command

gradually.

Use caution while participating in other activities while walking on your treadmill, such as watching

television, reading, etc. These distractions may cause you to lose balance or stray from walking in

the centre of the belt; which may result in serious injury.

In order to prevent losing balance and suffering unexpected injury, NEVER mount or dismount the

treadmill while the belt is moving. This unit starts with at a very low speed. Simply standing on the

belt during slow acceleration is proper after you have learned to operate this machine.

Always hold on to handrail while making control changes.

A safety key is provided with this machine. Remove the safety key will stop the walking belt

immediately; the treadmill will shut off automatically. Inserting the safety key will reset the display.

Do not use excessive pressure on console control keys. They are precision set to function properly

with little finger pressure.

BALANCE

4. ASSEMBLY INSTRUCTIONS

PART LIST

NO.

DES.

Specification

Nos.

NO.

DES.

Specification

Nos.

Main Frame

Lock washer

Strengthening

Pipe

6#Allen Wrench

6mm

Basic right cover

Allen Wrench

S=13\14\15mm

Basic left cover

5#Allen Wrench

5mm

Bolt

M10*60

Safety lock

screw

ST4.2*19

Bolt

M8*48

BALANCE

Lock washer

STEP 1:

STEP 2:

STEP 3:

1. Open the carton

2. Extract the parts listed above

3. Place the Main Frame (#1) onto level

ground

1. Use the #5 Allen wrench to pull up the

M8*45 screw (60), lock the console

frame onto the left & right Upright.

Note: Whilst erecting the uprights, make sure

the upright does not press against and

damage the wires inside the upright tubes.

Keep holding the upright and computer by

hand so they do not fall down and cause

injury

1. Using the #5 Allen Wrench, loosen

the M8 * 45 screws (60) from the left

and right upright tubes.

BALANCE

STEP 4:

STEP 5:

1. Use the 5# Allen wrench (90), M8*48

screw (95) and lock washer (39) to lock

the left upright onto the base frame.

2. Use 6# Allen wrench (88), M8*48 screw

(61) and lock washer (44) to lock the left

upright onto the base frame.

3. Repeat the above to assemble the right

upright

NO.95 is for M8

NO.61 is for M10

1. Use the #5 Allen wrench, M8*55 screw

(58) and lock washer (39) to fix the

computer bracket onto both uprights

(3\4).

BALANCE

STEP 6:

1. Use wrench screw driver and

ST4.2*19 screw (63) to fix the base

right cover (21) onto the left upright

and base.

2. Use wrench screw driver and

ST4.2*19 screw (63) to fix the base

left cover (22) onto the right upright

and base.

BALANCE

5. FOLDING INSTRUCTIONS

Folding:

Unfolding:

Erect the base frame using position A until

you hear the click sound emitted when the

air pressure bar B is locked into the round

tube.

Whilst supporting position A with our

hand, gently push the marked area on

the air pressure bar with your foot.

The base frame will descend

automatically. (Please keep people and

any pets away the machine during

descent)
