Precor 903 Manuel utilisateur

Manual

Treadmill

USA

Owner’s Manual

Assembly and Operation

page 2

Manual

Treadmill

Thank you for purchasing one of the innovative additions to the famous Precor

treadmill line. The 903 Manual Treadmill provides you with a safe and effective

workout.

Before using the 903 Manual Treadmill, we urge you to familiarize yourself with

the entire Owner’s Manual. Whether you are a beginner or exercise on

treadmills regularly, understanding this manual will help you use the 903

treadmill safely and successfully.

Safety Information

Please review and observe the following safety guidelines:

• Read the Owner’s Manual and follow all instructions.

• Assemble and operate the 903 treadmill on a solid, level surface. Locate

the treadmill a few feet from walls or furniture. Keep the area behind the

treadmill clear.

• Do not allow children on or near the 903 treadmill. Do not leave children

unsupervised around the treadmill.

• Check the 903 treadmill before each use. Be sure all assembly bolts and

T-knobs are tightened and secure. Do not use the treadmill if it is not

completely assembled or is damaged in any way.

• Keep hands away from the flywheel and other moving parts.

• Wear proper exercise clothing and shoes for your workout—no loose

clothing. Do not wear shoes with heels or leather soles. Check the soles of

your shoes and remove any embedded stones. Tie long hair back.

• Use care and hold onto the handrail when getting on or off the 903

treadmill.

• Keep your body and head facing forward. Do not attempt to turn around

on the treadmill when the belt is moving.

• Do not rock the unit. Do not stand or climb on the handrail. Never place

liquids on any part of the treadmill.

• Do not overexert yourself or work to exhaustion.

• Stop your workout immediately if you feel any pain or abnormal

symptoms, and consult your physician.

Precor treadmills are designed for the enjoyment of the serious runner as well

as the dedicated walker. By following the above precautions and using good

common sense, you will have many safe and pleasurable hours of healthful

exercise with your Precor treadmill.

CAUTION: Before beginning

any fitness program, you

should have a complete

physical examination by your

physician.

USA

page 3

Table of Contents

Unpacking the 903 Manual Treadmill......................................................... 4

Assembling the 903 Manual Treadmill ..................................................... 5

Installation Requirements.................................................................... 5

Assembly Instructions......................................................................... 5

Adjusting the Elevation Tube ............................................................... 7

Checking the Alignment of the Running Belt ....................................... 9

Using the Precor 903 Manual Treadmill. ................................................... 10

Beginning Your Workout ..................................................................... 10

Ending Your Workout .......................................................................... 10

Working Out on the 903 Treadmill....................................................... 10

Adjusting the Resistance Level ............................................................ 12

General Aerobic Training Information ....................................................... 13

How Hard Should I Exercise? .............................................................. 14

How Long Should I Exercise?.............................................................. 15

How Often Should I Exercise? ............................................................. 15

Maintaining the 903 Manual Treadmill ..................................................... 16

Cleaning the Treadmill ......................................................................... 16

Storing the Treadmill ........................................................................... 16

Aligning the Running Belt .................................................................... 17

Lubricating the Running Belt ............................................................... 19

Obtaining Service ................................................................................ 19

page 4

Unpacking the 903 Manual Treadmill

All Precor products are thoroughly tested and inspected before shipment.

Precor ships the 903 treadmill in three pieces:

• deck assembly

• front lift bar

• hardware kit (contents described below) and literature kit

Diagram 1 shows the treadmill parts after the carton has been removed.

Callouts point to the different parts of the treadmill that are discussed in the

assembly instructions. Unpack the treadmill close to the location where you

plan to use it. Save the triangular end blocks for use in the assembly.

Open the hardware kit and make sure that you have the following items. As you

identify the contents of the kit, check them off below.

2 T-knobs—handrail installation

2 washers—handrail installation

1/4" hex key

If any items are missing, contact your authorized Precor dealer. For the dealer

nearest you, call 1-800-4-PRECOR.

Important: The packaging for this equipment was designed to protect it during

shipment. Please store the original packaging in a safe place in case you need

to ship the 903 treadmill in the future.

Handrail

Front lift bar

Lift bar bracket

Height adjustment pin

Running belt

T-knob

Side rail mount

Flywheel

Diagram 1

Unassembled 903 treadmill.

CAUTION: Place the hex key

in a safe and secure place. If

the running belt should move

off-center, you can use the

1/4" hex key to align it.

page 5

Assembling the 903 Manual Treadmill

Follow the instructions in this section to assemble the 903 Manual Treadmill. It

is important to read through the entire procedure before assembling your

treadmill.

If you do not assemble and use this treadmill according to the

following guidelines, you could void the Precor limited warranty.

Installation Requirements

Follow these installation requirements when installing the treadmill:

•Fill out and mail the limited warranty registration card. The serial

number is written on a label underneath the treadmill on the center

crossbeam. During the assembly process, write the serial number on the

limited warranty card and in this Owner’s Manual (see

Obtaining Service

If you want a 903 Service Manual, write to:

ATTN: 903 Service Manual

Precor Customer Service Department

P.O. Box 3004

Bothell, WA 98041-3004

•Set up the 903 treadmill on a solid, flat surface.Do not install the

treadmill on hardwood floors because the wheels might scratch or damage

the surface. If the treadmill is placed on a hardwood floor or a carpeted,

deep-pile surface, place a piece of heavy cardboard, plywood, or other

smooth, flat surface under the unit to protect the floor and treadmill. If the

floor is not flat and even, the running belt may not track properly.

•Locate the treadmill at least 4 feet from walls and furniture.Open space

to the front, sides, and back of the machine make for a safer mount and

dismount and easier belt adjustment.

Assembly Instructions

To assemble the 903 treadmill, review the callouts in Diagram 1 before you take

the following steps:

1. Install the Front Lift Bar assembly.(Diagram 2) With the treadmill base

flat on the floor near the location where you plan to use it, take the

following steps to install the front lift bar:

a. Place the triangular, cardboard end blocks, set aside when you

unpacked the treadmill, under the front of the unit to lift the flywheel

off of the floor.

b. Remove the four bolts and washers from the front lift bar and set

them aside.

c. Slide the front lift bar brackets into the side rail mounts.

Note: You may need to ask for assistance to help you lift the front of

the treadmill to align the front lift bar brackets into the side rail

mounts.

page 6

d. Re-insert the bolts and washers as shown in Diagram 2. Tighten the

bolts securely using the hex key provided.

Flywheel

Diagram 2

Installing the Front Lift Bar assembly.

Side rail mount

Running belt

Elevation tube

Diagram 3

Locking handrail into upright position.

Elevation tube

Height adjustment pin

Side rail

Front lift bar

Handrail

Micro adjustment knob

T-knob

Frame plate

2. Position the Handrail.(Diagram 3) Remove the T-knobs and washers

from the hardware kit and take the following steps to secure the handrail:

a. Pull the handrail into an upright position. See Diagram 3.

Important: Perform the remaining steps on one side of the treadmill

at a time.

b. Hold onto the handrail while you insert a T-knob and washer through

the handrail mount (one on each side of the treadmill). Repeat this

step for the opposite side.

c. Align the T-knob with the hole in the side rail and tighten the T-knob

by turning it clockwise. Alternately tighten the T-knobs until both

washers are tight against the side rails.

3. Adjust the incline of the treadmill and set the running belt to the proper

resistance level, by following the steps in

Adjusting the Elevation Tube

Locking portion of pin

Height adjustment pin

Front lift bar

Washer

Bolt

page 7

Adjusting the Elevation Tube

The elevation tube is set at the factory at the lowest setting. To receive optimal

performance, reposition the height adjustment pin by taking the following steps:

1. Determine the proper Elevation Tube setting. (Table 1) The elevation tube

provides six different settings. Each setting provides a different level of

resistance needed (dependent on your weight) to maintain an efficient

workout. To get optimal performance from your treadmill, refer to settings

shown in Table 1.

To determine if you have set the proper elevation for your height, stand on

the running belt with your hands on the handrail for balance. Your feet

should slide slowly and easily away toward the rear of the treadmill.

Continue walking and when you are comfortable and well-balanced on the

treadmill, release your grip on the handrail. The running belt should

continue to move freely while you maintain your momentum. If the running

belt slows, stops, or becomes more difficult to walk on, consider moving

the elevation tube up one more setting.

Note: Table 1 is an approximation and elevation tube settings may vary

slightly depending on differences in weight and the amount of lubrication

between the running belt and deck. Over time and extended use, you may

need to readjust the elevation tube setting. Remember that you want to be

able to maintain your momentum on the running belt without having to

push off from the handrail. A lubrication kit, available from your local

dealer, can be used as the equipment ages or friction (between the running

belt and deck) increases. If you do lubricate the deck, you may need to

change the elevation setting. See

Obtaining Service

for more information.

200 pounds (lbs) and above

140 through 200 pounds

Table 1

Elevation tube settings

according to user’s weight.

Setting #1

Setting #3

Setting #6

Elevation Tube Settings Dependent on Weight

100 through 140 pounds

80 to 100 pounds

80 lbs and below

below 80 lbs

Height adjustment pin

Locking portion of pin

Elevation tube

page 8

Diagram 4

Placing treadmill onto front lift bar.

Handrail

Running belt

Front lift bar

Micro-adjustment knob

2. Position the Treadmill on Its Side.(Diagram 4) Place your hands on

either side of the handrail and gently tip the treadmill onto its side opposite

the micro-adjustment knob. See Diagram 4. Be sure the treadmill is

balanced and secure on its side and the micro-adjustment knob is

not

resting on the floor, before you let go of the handrail.

Diagram 5

Moving the elevation settings

and height adjustment pins.

3. Adjust the Elevation Tube.(Diagram 5) The elevation tube has six settings

(refer to Table 1). To move the height adjustment pin to another setting,

take the following steps.

Important: Due to the weight of the treadmill, always adjust the elevation

tube while the treadmill is resting on its side. Making adjustments in this

manner also alleviates the possibility of injury.

a. Remove the height adjustment pin by pushing up on the locking

portion that wraps around the tube. Use your fingers to pull the pin

out of the elevation tube hole. Repeat this step on the opposite side.

See Diagram 5. Set the height adjustment pins aside.

b. Slide the elevation tube so that the elevation tube and front lift bar

holes align at the proper setting.

Make sure that the settings are the

same for both sides of the elevation tube.

c. Re-insert the height adjustment pins and push down on the portion

that wraps around the tube to secure the pin into position.

d. Return the treadmill to an upright position, so that the base is flat on

the floor.

CAUTION: Be sure that the

T-knobs are secure and locked

into position on both sides of

the handrail before performing

this step.

CAUTION: To avoid injury, do

not place your fingers

between the locking portion of

the height adjustment pin and

the elevation tube.

Locking portion of pin

Elevation tube

Height adjustment pin

page 9

Checking the Alignment of the Running Belt

Before working out on your treadmill, you need to check the alignment of the

running belt. The running belt on the 903 treadmill has been fully adjusted at

the factory and should track straight on the deck. However, if the running belt

seems to track off center of the deck or you hear a chafing noise, check the belt

alignment by taking the following steps:

1. Walk on the treadmill while holding onto the handrail for balance.

2. Observe the running belt for a couple minutes.

3. If the running belt tracks off center or the belt moves toward either

flywheel, you need to align the belt.

4. If you determine that the belt needs alignment, follow the steps in

Aligning

the Running Belt

found in the maintenance section of this manual.

Once the treadmill is assembled, be sure to check the alignment of the belt

periodically. Adjust the running belt as soon as it needs alignment to prevent

tearing or fraying of the belt. Any damage due to improper maintenance of the

running belt is not covered by the limited warranty.

page 10

Using the Precor 903 Manual Treadmill

In addition to providing an excellent cardiovascular workout, one of the

advantages of the 903 Manual Treadmill is that it is simple to use. With very

little time or practice, you can learn how to use it effectively. This section

provides information about the following areas:

• beginning and ending your workout

• working out on the treadmill

• adjusting the resistance level

Beginning Your Workout

Prior to beginning a workout, make sure that you have completed the following:

• assembled your 903 treadmill—

Assembly Instructions

• adjusted the elevation tube settings—

Adjusting the Elevation Tube

• checked the running belt alignment—

Aligning the Running Belt

• stretched your lower body and back—

Working Out on Your 903 Treadmill

If a procedure has not been fully completed, refer to that section and complete

the tasks involved before beginning your workout.

To begin a workout, hold onto the handrail as you step onto the running belt.

Slowly, turn the micro-adjustment knob to adjust the resistance of the running

belt. You should adjust the resistance so that you can walk comfortably, but

maintain momentum without holding onto the handrail. For more information

about working out, refer to

Working Out on Your 903 Treadmill

and

Adjusting

the Resistance Level

Ending Your Workout

To end your workout, hold onto the handrail as you gradually reduce the speed

of the running belt till it comes to a complete stop. Step off the running belt

onto the floor. If you wish to store the treadmill, refer to the instructions found

Storing the Treadmill

Remember to incorporate a cool-down period into your workout. A cool-down

period helps you to gradually lower your heart rate and lessen excessive muscle

soreness or stiffness.

Working Out on the 903 Treadmill

Before using your treadmill, we recommend that you follow these instructions

and go through a preliminary demonstration of the treadmill. Then, you will be

more familiar with the treadmill when you begin your workout.

When using the treadmill, follow these general guidelines:

• At the beginning of a workout, take several minutes to bring your heart

rate into your training zone, as shown in Diagram 8 later in this manual.

• After your workout, walk slowly for several minutes to cool down your

body and lower your pulse rate.

• Gently stretch your lower body and back before and after a workout to help

prevent stiffness or soreness.

CAUTION: Before beginning

any fitness program, you

should have a complete

physical examination by your

physician.

Autres manuels pour 903

Table des matières

Autres manuels Precor tapis roulant

Precor

Precor Experience Series 700 Line Manuel utilisateur

Precor

Precor 9.31 Manuel du propriétaire

Precor

Precor 9.45 Manuel utilisateur

Precor

Precor Experience Series 700 Line Manuel utilisateur

Precor

Precor Experience 700 line Series Manuel utilisateur

Precor

Precor M 9.2s Manuel utilisateur

Precor

Precor C960 Manuel utilisateur

Precor

Precor M9.57 Manuel utilisateur

Precor

Precor M9.45 Manuel utilisateur

Precor

Precor Treadmills 932i Manuel du propriétaire

Precor

Precor TRM 800 Instructions de montage

Precor

Precor TRM 211 Manuel utilisateur

Precor

Precor ENERGY SERIES Manuel utilisateur

Precor

Precor M9.55 Manuel utilisateur

Precor

Precor Electronic M9.4 Manuel utilisateur

Precor

Precor Teambike 800 Manuel utilisateur

Precor

Precor C934 Manuel utilisateur

Precor

Precor Move Beyond 966i Manuel du propriétaire

Precor

Precor C954i Instructions d'installation et d'utilisation

Precor

Precor TRM 800 Instructions de montage

Precor

Precor 9.35 Manuel du propriétaire

Precor

Precor M9.33i Manuel utilisateur

Precor

Precor M9.41si Manuel utilisateur

Precor

Precor 9.35 Manuel utilisateur

Manuels tapis roulant populaires d'autres marques

Treadly

Treadly TREADLY 2 Manuel utilisateur

HEALTH ONE

HEALTH ONE Walk Ro Manuel utilisateur

NordicTrack

NordicTrack NTL12941 Manuel utilisateur

NordicTrack

NordicTrack T7.5 S Manuel utilisateur

Gold's Gym

Gold's Gym ADVANTAGE GGTL12920 Manuel utilisateur

Merax

Merax MS282992 Manuel utilisateur

FYTTER

FYTTER RU-2SX Manuel utilisateur

FitLogic

FitLogic freewill d225 Manuel utilisateur

HOP-SPORT

HOP-SPORT ESTIMA HS-3200LB Manuel utilisateur

Horizon Fitness

Horizon Fitness Adventure 5 Plus Manuel utilisateur

Stamia

Stamia InMotion II Manuel utilisateur

Smooth Fitness

Smooth Fitness EVO 3i Manuel utilisateur

NordicTrack

NordicTrack NETL81810.0 Manuel utilisateur

Schwinn

Schwinn 830/Journey 8.0 Manuel utilisateur

Keys Fitness

Keys Fitness HealthTrainer HT-740T Manuel utilisateur

Spirit

Spirit XT8 Manuel utilisateur

NordicTrack

NordicTrack T 14.0 Treadmill Manuel utilisateur

Master

Master F22 Manuel utilisateur
