Life Span TR2000i Touch Manuel utilisateur

TR2000i Touch

Folding Treadmill

Owner’s Manual

Congratulations on Purchasing Your LifeSpan Treadmill!

At LifeSpan we take pride in the quality, safety, and reliability of our products

as well as the professionalism of our sales support and customer service teams.

Making it our number one priority that you have an exceptional experience using

our products.

In support of this quality focus we pre-assemble parts on the manufacturing line

whenever possible to reduce the number of steps and complexity of customer

assembly, independently certify our products to comply with the latest industry

Safety Standards, and use state of the art production processes and quality

components.

Then we back LifeSpan products with excellent warranties and a responsive

customer service department making it simple and easy to get assistance should

the need arise.

This attention to quality, our high standard for customer service and focus on

innovation has earned LifeSpan numerous awards and consistent praise from

independent review groups, industry authorities and you the consumer.

Thanks for choosing LifeSpan.

Please thoroughly read this manual before you assemble or operate your treadmill.

Neither LifeSpan nor its representatives can accept responsibility for any damages or injury incurred as a

result of information presented in this manual except under the terms of the product warranty.

Welcome

Contents

Welcome

Safety First.........................................................................................................4

Safety Tips

Safety Key

Grounding

Assembling Your Treadmill..................................................................8

Exploded View & Hardware

Assembly Instructions

Console Basics ........................................................................................... 16

Console Overview

Display and Keyboard

Operations ................................................................................................... 23

Home Screen and Personal Settings

Bluetooth, Heart Rate Strap Set-up

QuickSTART and Manual

Preset Programs

Custom User Set-Up Programs

Heart Rate Control Programs

Summary

Equipment Settings

Program Proles

Saving Your Results................................................................................ 46

Maintenance and Tips.......................................................................... 47

Heart Rate Monitoring

Cleaning / Lubrication

Folding & Unfolding

Moving

Belt Tensioning

Belt Alignment

Troubleshooting

About Your Treadmill............................................................................ 56

Unique Features

Specications

Warranty / Registration

When using exercise equipment, basic precautions should always be followed,

including:

• Never drop or insert any object into any opening. If an object falls into an

opening, turn the power o and unplug the power cord from the outlet.

Remove the object or call customer service at 877.654.3837 x4.

• Never operate this treadmill if it has been damaged or partially submersed in

water.

• To reduce the risk of electric shock, unplug the treadmill from the wall outlet

when not in use, before performing any maintenance, or before moving the

treadmill.

• Do not use outdoors or in areas of high humidity or extreme temperature

changes.

• Do not lean against or climb on the treadmill.

• Do not operate where aerosol spray products are being used or where oxygen

is being administered.

• Never place the power cord under carpeting or place any object on top of

the cord, this may pinch or damage the cord causing re damage or personal

injury.

• Use this exercise product for its intended use as described in this Owner’s

Manual. Do not use attachments that are not recommended by LifeSpan.

• Do not leave your treadmill running while not in use.

Children and Pets

• Keep children from playing on your treadmill at all times.

• When in use children and pets should be kept at least 10 feet (3m) away.

• This treadmill can be used by children ages 12 years and above and persons

with reduced physical, sensory or lack of experience and knowledge if they

have been given supervision or instruction concerning use of the appliance in a

safe way and understand the hazards involved.

• Cleaning and user maintenance shall not be made by children without

supervision.

Safety First

2 Feet (.6 m)

7 Feet (2.0 m) 2 Feet (.6 m)

2 Feet (.6 m)

Safety Clearance

Safety Tips While in Use

• Always consult a physician before beginning an exercise program.

• If you experience chest pains, nausea, dizziness or shortness of breath, stop

exercising immediately and consult your physician before continuing. Do not

wear clothing or jewelry that might catch on any part of the treadmill.

• Wear shoes with high traction rubber soles. Do not wear shoes with heals,

leather soles, cleats or spikes.

• In case of emergency, grab onto the side handrails and place your feet on the

side rails located on each side of the running belt.

• Do not walk or run backwards on the treadmill, always face forward.

• Allow the running belt to fully stop prior to getting o the treadmill.

• Keep the treadmill on a solid surface, with the side rails and front of the

treadmill a minimum of 2 feet (0.6m) from any walls or furniture. Make sure that

the area behind the treadmill remains completely clear during use. A minimum

of 7 feet (2m) of clearance is required for safety reasons.

Safety First

NOTE: Read all instructions and save for future reference.

Safety Key

The safety key is required to operate this treadmill. With the safety key installed

the treadmill is operational. With the safety key pulled, power is turned o to the

motor making the treadmill inoperable.

CAUTION: For your safety always attach safety key clip to an article of

clothing prior to use. The safety key clip needs to be securely attached to

clothing parallel to or above the height of the safety key.

WARNING: Heart rate monitoring systems may be

inaccurate. Over exercising may result in serious injury or

death. If you feel faint stop exercising immediately.

Safety First

Insert safety key

Securely attach safety

key clip in case of a fall

Proper Grounding

LifeSpan equipment must be grounded. Improper connection of the equipment’s

grounding conductor can result in the risk of electric shock. Check with a qualied

electrician or service person if you are in doubt as to whether the outlet is

properly grounded. Do not modify the plug provided with the product or use a

ground plug adapter to adapt to a non-grounded outlet. If the plug will not t in

the outlet, have the proper outlet installed by a qualied electrician.

Power Cord Options

This treadmill should only be used with the proper power cord and power outlet.

Several power cord options (shown below) are available from LifeSpan. We do

our best do include the correct power cord with the treadmill for your area. In the

event that the correct power cord is not included in the packaging please contact

your local distributor.

Do not use extension cords between the treadmill and power outlet.

Do not plug into a GFI outlet or circuit as it may trip the breaker.

Safety First

Power Cord Options

Treadmill Outlet

SWITCH

AC POWER

OVERLOAD

SWITCH

POWER

SOCKET

Assembling Your Treadmill

Exploded View

Prior to starting the assembly process take all of the parts out of the box.

Remove plastic bags and lay them out on the oor to become familiar with the

components.

Since your treadmill is a heavy piece of equipment it is recommended you use

two people during assembly and follow these assembly instructions to reduce

any problems that could occur.

910

Hardware Included

Item# Part Description Item# Part Description

1 Right Upright Post 5 Console

2 Left Upright Post 6 Right Cup Holder

3 Right Upright Post Cover 7 Left Cup Holder

4 Left Upright Post Cover

Hardware Bag Contents

Item # Qty. Hardware Description

N/A 1 6mm Allen Wrench

N/A 1 5mm Allen Wrench with Phillips Screw Driver

9 4 M10 x 45L Bolt - (Upright Post Attachment)

10 4 M10 Washer - (Upright Post Attachment)

11 2 M8 x 70L Bolt - (Handlebar Attachment)

Pre-installed Hardware (not shown)

Item # Qty. Hardware Description

12 2 M4 x 8L - Screw (Upright Cover Attachment)

13 4 M4 x 10L Screw - (Console Attachment)

14 6 #8 x 5/8”L Screw - (Cup Holder Attachment)

15 4 M8 x 15L Bolt- (Mounting Bracket)

16 4 M8 Washer - (Mounting Bracket)

Assembling Your Treadmill

#8 x 5/8”L

(x6)

M4 x 8L

(x2)

M4 x10L

(x4)

M8 Washer

(x4)

M10 x 45L

(x4)

6mm Allen

Wrench

5mm Allen

Wrench w/

Phillips

M10 Washer

(x4)

M8 x 70L

(x2)

M8x 15L

(x4)

Step 1: Unpacking Treadmill

A. Cut packaging straps and

remove.

B. Remove the box top.

C. Remove small parts and

packaging material and

unwrap parts.

D. Cut the corners of the bottom box and remove all packaging material to

begin assembly. The treadmill can be assembled in the box. No need to pick

the treadmill up to remove it from box.

Step 2: Upright Post Attachment

A. Carefully fold the uprights

with handlebars up into the

upright position.

B. Carefully lay handlebars

down as the uprights are

brought up into position.

This will protect against any

accidental damage to wires

coming up through the

upright into the handlebars.

C. Align the holes in the lower

portion of the upright with

the threaded holes in the

frame.

D. Install the four M10 x 45L

Bolts(9) and M10 Washers(10),

two in each upright. The

best way to handle this is to

loosely install all four bolts

and washers and then tighten

once all bolts are installed.

Assembling Your Treadmill

Support

handlebars

as you lift

M10 x 45L

(x4)

M10 Washer

(x4)

6mm Allen

Wrench
