TR7000i/TR8000i

Treadmill

Owner’s Manual

For safe use and product knowledge, please

completely read this product OWNER’S MANUAL

iPhone 5S, iPhone 5C, iPhone 5, iPhone 4S, iPhone 4, iPad Air, iPad mini with retina

display, iPad (4th generation, iPad mini, iPad (3rd generation), iPad 2

Made for

“Made for iPhone” and “Made for iPad” mean that an electronic accessory has been designed to

connect specically to iPhone and iPad respectively, and has been certied by the developer to

meet Apple performance standards. Apple is not responsible for the operation of this device or its

compliance with safety and regulatory standards. Please note that the use of this accessory with

iPhone and iPad may aect wireless performance.

iPad and iPhone are trademarks of Apple Inc., registered in the U.S. and other countries.

TREADMILL MODEL NUMBER - TR7000i/TR8000i

Made in Taiwan

TR7000i/TR8000i

Treadmill

Welcome to LifeSpan,

Congratulations on choosing the LifeSpan Pro Series for your tness or exercise area. Performance and durability are at

the heart of each Pro Series model, which include commercial warranties that cover institutional use up to nine hours per

day.

We start with a heavy gauge robotically welded steel frame, then add top-of-the-line components like a heavy-duty motor

and heavy duty deck. e results are treadmills that deliver a smooth and consistent workout for every user that will last

for years to come.

To make the Pro Series easy to use, we include our Intelli-KeyTM system that simply and easily steps the user through the

program set-up process. For motivation, we include a variety of pre-set programs, including heart rate control programs.

is gives your customers the programming variety they appreciate.

Please read this manual thoroughly before assembly and operation of your LifeSpan Pro Series treadmill. It includes

assembly and maintenance information, as well as a detailed operation guide.

To keep your treadmill in optimal condition, please pay attention to the maintenance and cleaning section of this manual.

Remember that some kinds of service should only be performed by a qualied service technician. If service is required,

please contact your authorized LifeSpan dealer. If a question or problem arises that cannot be answered by your dealer,

U.S. and Canada:

P.O. Box 981316

Park City, Utah 84098-1316

Phone: 801.973.9993

Fax: 801.973.9923

www.lifespantness.com

International:

Contact your local distributor

or visit: www.lifespantness.com

Neither LifeSpan nor its representatives can accept responsibility for any damages or injury incurred as a

result of information presented in this manual except under the terms of the product warranty.

TR7000i/TR8000i

Treadmill

Welcome

Specications

Warranty Information

Important Safety Precautions

Grounding and Power Requirements

Assembly Instructions

Display Console Overview

Reading Your Heart Rate

Operating Your Treadmill

Innovative Features

Cleaning and Maintenance

Belt Tension and Alignment

Moving Your Treadmill

Troubleshooting

Engineering Mode

Test Mode

Table of Contents

Large 6.5” backlit LCD screen with scrolling alphanumeric messaging,

program prole, showing workout progress, and simultaneous display

of all readouts. Three additional LED displays with readouts for time,

speed, and incline

Program name, date and time, speed, incline, distance, calories, steps,

heart rate, and pace

Two heart rate control programs, and 17 programs grouped by

exercise motivation type for weight loss, healthy living, and sports

training

Yes

2 USB ports to automatically save your exercise data and charge your

wireless mobile device simultaneously

Wirelessly connect to your supported iPad or Android device for

additional console readouts and functionality.

Grip pulse and heart rate receiver

Book, magazine, and tablet computer holder

Button lighting system prompts users through program set-up and

operations

Magnetic safety clip, when detached, immediately turns o power,

bringing the treadmill to a gentle stop

Standard and metric settings

English

22”W x 62” L (56cm W x 157.5cm L)

3.5 HP Continuous Duty 220 VAC

Multi-ply polyester belt with PVC non-slip surface

1000 lbs. (453.6 kg) thrust

3.0” (7.5cm) crown rollers keep belt centered

0.5 - 12 MPH (0.8 - 20 KPH)

0 - 15

4 Variable Density Elastomers

1” (2.54cm) melamine laminated reversible deck medium-density

ber board

80.5” L x 33.25”W x 61” H (204.5cm L x 84.4cm W x 154.9cm H)

8” (20cm)

368 lbs. (167 kg)

400 lbs. (181.4 kg)

Specications (TR7000i)

Display:

Readouts:

Programs:

Quickstart:

USB Ports:

Bluetooth:

Heart Rate:

Media Holder:

Intelli-Key™:

Emergency Stop:

Units of Measure:

Language Support:

Belt Size:

Drive Motor:

Belt Type :

Incline Motor:

Rollers:

Speed:

Incline:

Deck Suspension:

Deck:

Dimensions:

Step-Up Height:

Max. User Weight:

Net Weight:

Gross Weight:

TR7000i/TR8000i

Treadmill

Large 6.5” backlit LCD screen with scrolling alphanumeric messaging,

program prole, showing workout progress, and simultaneous display

of all readouts. Three additional LED displays with readouts for time,

speed, and incline

Program name, date and time, speed, incline, distance, calories, avg.

heart rate, heart rate, and pace

Two heart rate control programs, reverse walking, and 17 programs

grouped by exercise motivation type for weight loss, healthy living,

and sports training

Yes

2 USB ports to automatically save your exercise data and charge your

wireless mobile device simultaneously

Wirelessly connect to your supported iPad or Android device for

additional console readouts and functionality.

Grip pulse and heart rate receiver

Book, magazine, and tablet computer holder

Button lighting system prompts users through program set-up and

operations

Magnetic safety clip, when detached, immediately turns o power,

bringing the treadmill to a gentle stop

Standard and metric settings

English

22”W x 60”L (56cm W x 152.4cm L)

5 HP Permanent Magnet AC

Multi-ply polyester belt with PVC non-slip surface

1000 lbs. (453.6 kg) thrust

3.0” (7.5cm) crown rollers keep belt centered

Forwards: 0.1 to 12 MPH / 0.2 to 20 KPH

Backwards: -0.1 to -3 MPH / -0.2 to -5KPH

3 decline - 12 incline

Independent shock absorbers

1” (2.54cm) melamine laminated reversible deck medium-density

ber board

89.7” L x 41”W x 20” H (230cm L x 105cm W x 51cm H)

9.5” (24cm)

500 lbs. (225 kg)

408 lbs. (185 kg)

454 lbs. (206 kg)

Specications (TR8000i)

Display:

Readouts:

Programs:

Quickstart:

USB Ports:

Bluetooth:

Heart Rate:

Media Holder:

Intelli-Key™:

Emergency Stop:

Units of Measure:

Language Support:

Belt Size:

Drive Motor:

Belt Type :

Incline Motor:

Rollers:

Speed:

Incline:

Deck Suspension:

Deck:

Dimensions:

Step-Up Height:

Max. User Weight:

Net Weight:

Gross Weight:

Warranty Information

The LifeSpan TR7000i/TR8000i Treadmill comes with the following limited warranty, valid in the US and Canada

only.

Residential Commercial

Treadmill Usage: - 6 hrs/day

Treadmill Frame: Lifetime 10 Years

Motor: Lifetime 5 Years

Parts: 5 Years 5 Years

Labor: 2 Years 1 Year

LifeSpan warrants that the equipment it manufactures is free from defects in materials and workmanship under

normal use and services. The periods above are based on the date of purchase. During these periods, LifeSpan

will repair or replace any defective part. Free labor is included on all parts that are not normally assembled or

replaced by the customer, within the labor period.

If within the time frames specied above, any part fails to operate properly, log on to our website at

www.lifespantness.com, click on Customer Support and complete the form to request assistance. Or call

877.654.3839 x4 for a Customer Support Agent.

LifeSpan reserves the right to make changes and improvements to our product without incurring any obligations

to similarly alter any product purchased. In order to insure our product warranty and to ensure the safe and

ecient operation of your LifeSpan product, only authorized parts can be used. The warranty is void if any parts

other than those provided by LifeSpan are used.

Exclusions and Limitations:

• This warranty does not apply to any defects caused by negligence, misuse, improper assembly, or

maintenance, accident, or “act of god.”

• This warranty does not apply to discoloration of paints or plastics.

• LifeSpan shall not be responsible for incidental or consequential damages.

• This warranty is nontransferable form the original owner.

Registration

You must register your LifeSpan product before a warranty claim can be processed. To complete your registration

online go to www.lifespantness.com and click on product registration or ll out the warranty card provided and

mail it today. Registration cards must be completed and sent to LifeSpan within 30 days of purchase to activate

the Product Warranty. Product Warranties are not valid unless the registration is properly completed and received

within 30 days.

TR7000i/TR8000i

Treadmill

Important Safety Precautions

When using exercise equipment, basic precautions should always be followed, including:

• Never drop or insert any object into any opening. If an object falls into an opening, turn the power

o and unplug the power cord from the outlet. Remove the object or call customer service.

• Never operate this treadmill if it has been damaged or even partially submersed in water.

• To reduce the risk of electric shock, unplug the treadmill from the wall outlet when not in use,

before performing any maintenance, or before moving the treadmill.

• Do not use outdoors or in areas of high humidity or extreme temperature changes.

• Do not lean against or climb on the treadmill.

• Wear shoes with high traction rubber soles. Do not wear shoes with heals, leather soles, cleats or

spikes.

• Do not operate where aerosol spray products are being used or where oxygen is being

administered.

• Never place the power cord under carpeting or place any object on top of the cord, this may pinch

or damage the cord causing re damage or personal injury.

• Use this exercise product for its intended use as described in this Owner’s Manual. Do not use

attachments that are not recommended by LifeSpan.

• Do not leave your treadmill running while not in use.

• Keep the treadmill on a solid surface, with the side rails and front a minimum of two feet (0.61m)

from any walls or furniture. Make sure that the area behind the treadmill remains completely clear

during use. A minimum of 4 feet (1.2m) of clearance is required for safety reasons.

4 feet

1.22m

2 feet

0.61m

eet

0.61m

Running

Surface

55” x 21”

138cm x 53cm

2 f

Children and Pets

• Keep children from playing on your treadmill at all times.

• When in use children and pets should be kept at least 10 feet (3m) away.

• This appliance can be used by children ages 8 years and above and persons with reduced

physical, sensory or mental capabilities or lack of experience and knowledge if they have been

given supervision or instruction concerning use of the appliance in a safe way and understand

the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance

shall not be made by children without supervision.

Other Safety Tips

• Always consult a physician before beginning this or any exercise program.

• If you experience chest pains, nausea, dizziness or shortness of breath, stop exercising immediately

and consult your physician before continuing.

• Do not wear clothing or jewelry that might catch on any part of the treadmill.

• This treadmill is equipped with a safety key. Always clip the cord that is attached to the safety key to

a part of your clothing so the key will be pulled, stopping the treadmill, in case of emergency.

• Warning! Heart rate monitoring may be inaccurate. Over exercising may result in serious injury

or death. If you feel faint stop exercising immediately.

Note: Read all instructions and save for future use.

Caution:

• While walking or running always use the correct

ergonomic position.

• In case of emergency, grab on to the side hand

rails and place your feet on the side rails located

on each side of the running belt.

• Do not walk or run backwards on the treadmill,

always face forward while using the reverse

program.

• Allow the running belt to fully stop prior to

getting o the treadmill.

TR7000i/TR8000i

Treadmill

CORD SOCKET

SWITCH-

AC POWER

OVERLOAD

SWITCH

FIG. 1

FIG. 2

Grounding and Power Requirements

LifeSpan equipment must be grounded. Improper connection of the equipment’s grounding conductor

can result in the risk of electric shock. Check with a qualied electrician or service person if you are

in doubt as to whether the outlet is properly grounded. Do not modify the plug provided with the

product or use a ground plug adaptor to adapt to a non-grounded outlet. If the plug will not t in the

outlet, have the proper outlet installed by a qualied electrician.

An extension cord should not be used between the equipment and the wall outlet.

The unit should not be plugged into a GFI plug or on a GFI circuit. The unit may not work as it may trip

the GFI circuit.

This product should only be run on the proper power designed for this unit. To locate the proper power

outlet for your area please refer to FIG. 2 (example for the U.S. and Canada, these units require a 115 V

NEMA 5 - 15 non GFI circuit.)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Life Span tapis roulant

Life Span

Life Span STREAM Manuel utilisateur

Life Span

Life Span Trail Manuel utilisateur

Life Span

Life Span Treadmill Manuel utilisateur

Life Span

Life Span EXPLORER Manuel utilisateur

Life Span

Life Span TURBO PLUS Manuel utilisateur

Life Span

Life Span Workplace DT-3 Manuel utilisateur

Life Span

Life Span TR1000-TV Manuel utilisateur

Life Span

Life Span TEMPEST CR Manuel utilisateur

Life Span

Life Span Walkstation L1 Manuel utilisateur

Life Span

Life Span Dash Manuel utilisateur

Life Span

Life Span CORSAIR FREERUN 200 Manuel utilisateur

Life Span

Life Span PRO 1 Manuel utilisateur

Life Span

Life Span Chaser 3 Manuel utilisateur

Life Span

Life Span LFT 05 WalkingPad M2 Manuel utilisateur

Life Span

Life Span TR6000i Manuel utilisateur

Life Span

Life Span Power-S Manuel utilisateur

Life Span

Life Span Traction II Manuel utilisateur

Life Span

Life Span Reformer 2 Safety Manuel utilisateur

Life Span

Life Span TR2000-HRC Manuel utilisateur

Life Span

Life Span Pursuit 2 Manuel utilisateur

Life Span

Life Span SPRINTER XL Manuel utilisateur

Life Span

Life Span GOLD Manuel utilisateur

Life Span

Life Span SPIRIT Manuel utilisateur

Life Span

Life Span Dymo Manuel utilisateur

Manuels tapis roulant populaires d'autres marques

Treadly

Treadly TREADLY 2 Manuel utilisateur

HEALTH ONE

HEALTH ONE Walk Ro Manuel utilisateur

NordicTrack

NordicTrack NTL12941 Manuel utilisateur

NordicTrack

NordicTrack T7.5 S Manuel utilisateur

Gold's Gym

Gold's Gym ADVANTAGE GGTL12920 Manuel utilisateur

Merax

Merax MS282992 Manuel utilisateur

FYTTER

FYTTER RU-2SX Manuel utilisateur

Precor

Precor 903 Manuel utilisateur

FitLogic

FitLogic freewill d225 Manuel utilisateur

HOP-SPORT

HOP-SPORT ESTIMA HS-3200LB Manuel utilisateur

Horizon Fitness

Horizon Fitness Adventure 5 Plus Manuel utilisateur

Stamia

Stamia InMotion II Manuel utilisateur

Smooth Fitness

Smooth Fitness EVO 3i Manuel utilisateur

NordicTrack

NordicTrack NETL81810.0 Manuel utilisateur

Schwinn

Schwinn 830/Journey 8.0 Manuel utilisateur

Keys Fitness

Keys Fitness HealthTrainer HT-740T Manuel utilisateur

Spirit

Spirit XT8 Manuel utilisateur

NordicTrack

NordicTrack T 14.0 Treadmill Manuel utilisateur
