Kogan FreeSync KAMN24FLSB Manuel utilisateur

24" FULL HD FREESYNC 75HZ

FRAMELESS MONITOR

(1920 x 1080)

KAMN24FLSB

•Read all instructions before using the appliance and retain for reference.

•Unplug the monitor before cleaning it.

•Use a clean, slightly dampened cloth to wipe the main monitor body.

•To clean the screen: turn it OFF, unplug it and wait for it to cool completely, then

wipe it with a dry micro-fibre cloth.

•Do not use cleaning alcohol, ammonia-based liquids or other harsh cleaners.

•This monitor is designed with ventilation holes on the back of the casing. Do not

cover or block them.

•Do not insert any object or spray any liquid into the vents.

•Avoid placing the monitor near heaters, stoves, fireplaces or other sources of heat,

as well as in rooms lacking adequate ventilation.

•Do not position the monitor in unsafe locations. If the monitor falls, it may be

damaged and may injure nearby people.

•Unplug the monitor if it is not going to be used for an extended period.

•Do not place heavy objects on the monitor, its power cord or any connected cable.

•Do not open the back panel of the monitor, as it contains a high-voltage current

even when not plugged in.

The terms HDMI and HDMI High-Definition Multimedia Interface

and the HDMI Logos are trademarks or registered trademarks of

HDMI Licensing Administrator, Inc. in the United States and other

countries.

SAFETY & WARNINGS

Monitor

Stand connector

Stand base

Screws (x2)

VESA screws (x4)

HDMI cable

Power cable

User guide

COMPONENTS

Monitor Controls

Menu button

Press to display the OSD menu or enter sub-menus.

Down button

Press to move down in the menu.

Up button

Press to move up in the menu.

Exit button

Press to exit.

Power button

Press to turn the monitor on/off.

Monitor Ports

Power connector

Audio In

VGA connector

HDMI connector

OVERVIEW

Attention: Panel is fragile. Keep the foam underneath the monitor while assembling

the stand.

1. Carefully remove the monitor from the packaging with foam attached and place it

face down on a soft cloth spread across a stable surface such as a table.

2. Remove and assemble the stand base and connector.

STAND ASSEMBLY

3. Remove the connection block from the back of the monitor by pressing the detach

button.

4. Insert the Connection Block into the back of the monitor, then push down until it

snaps into place.

5. Remove the bottom foam and place the monitor on the desk or other location

intended for use: installation is complete.

Connection Block

Close Open

1. Carefully remove the monitor from the packaging with foam attached and place it

face down on a soft cloth spread across a stable surface such as a table.

2. Remove the connection block from the back of the monitor by pressing the detach

button. If the stand is attached, remove it.

3. Remove the original screws ( ) from the opening in the back of the monitor.

4. Follow the directions with your mount, stand or accessory and install the monitor

on the wall or future as desired, using the included 4 screws when mounting the

monitor. Refer to the image ( ) for correct screw placement.

VESA MOUNT

Stand stem

Stand base

Monitor

Foam

Stand plate

Button

Mount (Not included)

Power Cable

Connect the included power cable to the monitor power port and then connect the other

end to a power outlet.

Audio In

Connect an audio cable to the 3.5mm audio port on the monitor (Audio In) and the 3.5mm

audio port on your computer.

CONNECTIVITY

Power cable

HDMI

Connect an HDMI cable from the computer’s display output to the monitor’s display input.

VGA

Connect a VGA cable from the computer’s display output to the monitor’s display input.

HDMI cable (Included)

HDMI Output

VGA cable (Not Included)

VGA Output
