Kogan KAMN32RQ1LA Manuel utilisateur

32" CURVED QHD 165HZ FREESYNC

HDR GAMING MONITOR

(2560 X 1440)

KAMN32RQ1LA

• Read all instructions before using the appliance and retain for reference.

• Unplug the monitor before cleaning it.

• Use a clean, slightly dampened cloth to wipe the main monitor body.

• To c l e a n t h e s c r e e n : Turn it off, unplug it and wait for it to cool completely, then

wipe it with a dry microfibre cloth.

• Do not use cleaning alcohol, ammonia-based liquids or other harsh cleaners.

• This monitor is designed with ventilation holes on the back of the casing. Do not

cover or block them.

• Do not insert any object or spray any liquid into the vents.

• Avoid placing the monitor near heaters, stoves, fireplaces or other sources of heat,

as well as in rooms lacking adequate ventilation.

• Do not position the monitor in an unsafe location. If the monitor falls, it may be

damaged and may injure nearby people.

• Unplug the monitor if it is not going to be used for an extended period.

• Do not place heavy objects on the monitor, its power cord or any connected cable.

• Do not open the back panel of the monitor, as it contains a high-voltage current

even when not plugged in.

The terms HDMI and HDMI High-Definition Multimedia Interface,

and the HDMI Logo are trademarks or registered trademarks of

HDMI Licensing Administrator, Inc. in the United States and other

countries.

SAFETY & WARNINGS

Monitor

Stand Stem

Stand Base

Headphone Clip

Screws

VESA Connectors

DP Cable

Power Cable

User Guide

COMPONENTS

Controls

Menu/Enter

Volume/Down

Brightness/Up

Input select/Exit

Power On/Off

LED indicator

Ports

Power Connector

Audio output

DisplayPort Connector (x2)

HDMI Connector (x2)

OVERVIEW

Installing the Stand Base

1. Installation method:

Open the carton, remove the bracket and the base and lock them with one screw,

then take out the rotating shaft assembly and install the two screws on the

bracket.

Removal method:

Use a screwdriver to unscrew the screws of lock bracket, rotating shaft and base.

2. Remove the monitor from the carton, lay it flat with the back facing upwards and

clamp the base assembly to the rotating shaft of the monitor.

The base assembly can be taken out by directly pulling the quick release button

upwards by hand.

ASSEMBLY

Dismantle

Headphone Clip

Shaft Assembly

Screws*2

Assembly

Stand

Screw

Base

Quick Release Button

Follow the steps below to install onto a monitor arm or wall mount (not included)

1. Open the package, take out the product with foam still attached and gently place

it on a desktop or table. Remove the extra parts and the foam covering the back of

the monitor. Press the release button to remove the stand plate. If the monitor was

already attached to the stand, remove the stand.

2. Remove the original screws x4 (①) from the opening in the back of the monitor.

3. Follow the directions received with your mount, stand or accessory and install the

monitor on the wall or fixture as desired. Remember to use the included 4 screws

when mounting the monitor. Refer to the image (②) for correct screw placement.

4. Follow the directions received with your mount, stand or accessory and install the

monitor on the wall or fixture as desired.

VESA MOUNT

Screw * 4

Use the 35mm

Mount

(not included)

Foam

Release Button

Stand Plate

Removable Rear Panel

This monitor features a removable rear panel that covers the input ports. It may be easier to

remove this panel before attempting to connect or remove cables from the monitor.

Power Cable

Connect the included power cable to the power connector and then plug the other end into

a power outlet.

CONNECTIVITY

Power Cable

Rear Panel

Earphones

Plug in your earphones to receive audio signals from your monitor. If your earphones are

connected to the monitor and audio devices are connected to your computer at the same

time, the audio devices will not produce sound. Earphones and other audio devices not

included.

DisplayPort

For the monitor to receive DisplayPort signals from the computer, use the DisplayPort cable

to connect the monitor to the computer.

Earphone (Not Included)

DP Output

DP Cable (Included)

HDMI

For the monitor to receive HDMI signals from the computer, use the HDMI cable to connect

the monitor to the computer.

HDMI

Output PC

HDMI Cable (Included)
