Kogan KAMN26FUSA Manuel utilisateur

26 WFHD 21:9 ULTRAWIDE

IPS FREESYNC MONITOR

(2560 x 1080)

KAMN26FUSA

• Read all instructions before using the monitor and retain for future reference.

• Unplug the monitor before cleaning it.

• Use a clean, slightly dampened cloth to wipe the main monitor body.

• To c l e a n t h e s c r e e n , t u r n i t o f f u n p l u g i t a n d w a i t f o r i t to c o o l c o m p l e t e l y, t h e n w i p e

it with a dry micro-fibre cloth.

• Do not use cleaning alcohol, ammonia-based liquids or other harsh cleaners.

• This monitor is designed with ventilation holes on the back of the casing. Do not

cover or block them.

• Do not insert any object or spray any liquid into the vents.

• Avoid placing the monitor near heaters, stoves, fireplaces or other sources of heat.

• Place monitor in well ventilation room.

• Do not position the monitor in unsafe locations. If the monitor falls, it may be

damaged and may injure nearby people.

• Unplug the monitor if it is not going to be used for an extended period.

• Do not place heavy objects on the monitor, its power cord or any connected cable.

• Do not open the back panel of the monitor, as it contains a high-voltage current

even when not plugged in.

• Before disposing of any packaging, place all items on a soft, clean and flat surface

to ensure all components are accounted for.

The terms HDMI and HDMI High-Definition Multimedia

Interface and the HDMI Logos are trademarks or registered

trademarks of HDMI Licensing Administrator, Inc. in the

United States and other countries.

SAFETY & WARNINGS

Monitor

Stand Arm

Stand base

Stand base screw

(M4 x 14mm)

VESA screws (x4)

Display port cable

Power adapter

Power cable

User guide

COMPONENTS

Power socket

Directional keys

Power connector

HDMI 3 connector

HDMI 2 connector

HDMI 1 connector

DP connector

Audio out (3.5mm jack)

OVERVIEW

Before disposing of any packaging, place all items on a soft, clean and flat surface to

ensure all components are accounted for.

Carefully remove the monitor, stand

arm and stand base from the box.

Attach the stand base to the stand

arm using the provided M4 screw.

Insert the stand arm into the rear of

the monitor and push down until it is

firmly connected.

Lift the monitor up straight and

remove the bottom foam. Stand the

monitor up on the installed base.

ASSEMBLY

WARNING: The panel of the monitor is fragile. Keep the foam

underneath the monitor screen while assembling the stand.

1. Open the box, remove the monitor keeping the protection foam attached and gently

place it on a desktop or table.

2. Remove the foam covering the rear of the monitor. Press the release button to remove

the stand plate. If the monitor is already attached to the stand, remove the stand.

3. Assemble the mount as per the instructions provided with the mount.

VESA mounting pattern 100 x 100mm, screw size M4.

Note:

VESA mount or mounting accessories are NOT included.

Stand base

Monitor

Stand connector

Stand plate

Button

Foam

VESA MOUNT

Power

1. Connect the included power cable to the monitor power port.

2. Connect the power cable to the power adapter.

3. Connect the power adapter to the power outlet.

Audio

1. Connect a 3.5mm audio cable to the audio port on the monitor.

2. Connect the audio cable to the 3.5mm port headphones or speakers.

Note: The monitor may need to be set as the PC’s default sound output device.

CONNECTIVITY

Power cable

Power adapter

Earphones (not included)

DisplayPort

Use the included DisplayPort cable to connect the monitor to your computer.

HDMI

Use a HDMI cable to connect the monitor to your computer.

DP cable (included)

HDMI cable (not included)

Monitor Control

You can easily control the functions of the monitor by pressing the Power button or moving

it left/right ( / ) with your finger.

Button

Action

Description

Press in

Turn the monitor on/off.

Push left

Enable the main menu or select the menu item.

Push right

Exit from the main menu or return to the upper

menu.

Push up

Select menu items or increase the setting values

of the selected menu item.

Push down

Select menu items or decrease the setting

values of the selected menu item.

Shortcuts:

• Source menu: Press RIGHT twice to access the signal source selection menu, use

the directional buttons to select the desired source and press Power to confirm.

• Display mode menu: Press LEFT twice to access the display mode menu, use the

directional buttons to select the desired display mode and press Power to confirm.

• Gameplus timer menu: Press the UP twice to access the Gameplus timer menu.

Select the desired timing length and press Power to confirm.

• Gameplus sight menu: Press DOWN twice to access the Gameplus sight menu.

Select the desired sight and press Power to confirm.

FreeSync

• In order to use this feature, ensure your hardware has FreeSync capability and the

graphics drivers are fully up to date.

• After connecting, you may receive a prompt to enable the feature on your

computer. If you do not receive the prompt, you may need to enable the function in

your graphics card menu.

• See your graphics card manufacturer’s documentation for instructions on how to

turn on and/or enable FreeSync.

OPERATION
