GENERAL SPECIFICATIONS

Klein Tools CL800E is an automatically ranging true root mean

square (TRMS) digital clamp meter that measures AC/DC current

via the clamp and measures AC/DC voltage, resistance, continuity,

frequency and capacitance. It tests diodes via test leads and

temperature via a thermocouple probe. It also features a Low

impedance (LoZ) mode for identifying and eliminating ghost or

stray voltages.

• Operating altitude: 2000 m

• Relative humidity: <80% non-condensing

• Operating temp: 0°C to 40°C

• Storage temp: -10°C to 60°C

• Accuracy: Values stated at 18°C to 28°C

• Temp coefcient: 0.1 × (quoted accuracy) per °C above 28°C

or below 18°C. Corrections are required when the ambient

working temp is outside the accuracy temp range

• Dimensions: 231 mm × 97 mm × 39 mm

• Weight: 354 g including batteries

• Calibration: Accurate for one year

• Standards: Conforms to: UL STD 61010-1, 61010-2-032

and 61010-2-033.

Certified to: CSA STD C22.2 No. 61010-1,

61010-2-032 and 61010-2-033.

IEC EN 61010-1, 61010-2-032

and61010-2-033, 61326-1.

• Pollution degree: 2

• Accuracy: ± (% of reading + number of least significant digits)

• Drop protection: 2m

• Safety rating: CAT IV 600 V, CAT III 1,000 V, Class 2,

Double insulation

CAT III: Measurement category III is applicable to test and

measuring circuits connected to the distribution part of the

building’s low-voltage MAINS installation.

CAT IV: Measurement category IV is applicable to test and

measuring circuits connected at the source of the building’s

low-voltage MAINS installation.

• Electromagnetic environment: IEC EN 61326-1. This

equipment meets the requirements for use in basic and

controlled electromagnetic environments, such as residential

properties, business premises and light-industrial locations.

Specifications subject to change.

ENGLISH

ELECTRICAL SPECIFICATIONS

Function Range Resolution Accuracy (50/60 Hz)

AC voltage

(V AC)

6.000 V 1 mV ±(1.5% + 5 digits)

60.00 V 10 mV ±(1.2% + 5 digits)

600.0 V 100 mV

1000 V 1 V ±(1.5% + 5 digits)

DC voltage

(V DC)

600 mV 0.1 mV ±(1.0% + 8 digits)

6.000 V 1 mV

±(1.0% + 3 digits)60.00 V 10 mV

600.0 V 100 mV

1000 V 1 V ±(1.2% + 3 digits)

Input impedance: 10 MΩ Frequency range: 50 to 400 Hz

Maximum input: 1,000 V AC RMS or 1,000 V DC

AC current

(A AC)

60.00 A 10 mA ±(2.0% + 8 digits)

600.0 A 100 mA ±(2.0% + 5 digits)

DC current

(A DC)

60.00 A 10 mA ±(2.0% + 8 digits)

600.0 A 100 mA ±(2.0% + 5 digits)

Frequency range: 50 to 60 Hz

Function Range Resolution Accuracy

Resistance

600.0 Ω 0.1 Ω

±(1.5% + 5 digits)

6.000 KΩ 1 Ω

60.00 kΩ 10 Ω

600.0 kΩ 100 Ω

6.000 MΩ 1 kΩ

60.00 MΩ 10 kΩ ±(2.0% + 10 digits)

Maximum input: 600 V AC RMS or 600 V DC

Capacitance

60.00 nF 0.010 nF ±(5.0% + 35 digits)

600.0 nF 0.1 nF

±(3.0% + 5 digits)6.000 µF 0.001 µF

60.00 µF 0.01 µF

600.0 µF 0.1 µF ±(5.0% + 5 digits)

6,000 µF 1 µF

Maximum input: 600 V AC RMS or 600 V DC

Temperature

(Fahrenheit)

-14°F to 32°F

0.1°F to 1

°F

±(2.0% + 9

°F

)

33°F to 752°F

±(1.0% + 5.4

°F

)

753°F to 1,000°F

±(2.0% + 9

°F

)

Temperature

(Celsius)

-26°C to 0°C

0.1°C to 1

°C

±(2.0% + 5

°C

)

1°C to 400°C

±(1.0% + 3

°C

)

401°C to 538°C

±(2.0% + 5

°C

)

ELECTRICAL SPECIFICATIONS

FREQUENCY (AUTO-RANGING)

9.999 Hz 0.001 Hz

±(1.0% + 5 digits)

99.99 Hz 0.01 Hz

999.9 Hz 0.1 Hz

9.999 kHz 1 Hz

99.99 kHz 10 Hz

500.00 kHz 100 Hz

Sensitivity: >8 V RMS

Maximum input: 600 V DC or 600 V AC RMS

DUTY CYCLE

1% to 99.9%

0.1% ±(1.2% + 2 digits)

Pulse width: 0.1 ms - 100 ms

Frequency width: 5 Hz to 10 kHz

Sensitivity: >8 V RMS

Maximum input: 600 V DC or 600 V AC RMS

OTHER MEASUREMENT APPLICATIONS

Maximum input: 600 V AC RMS or 600 V DC

• Diode test: Max. 1.5 mA, open circuit voltage ~3.0 V DC

• Continuity check: Audible signal <50 Ω, test current <0.35 mA

• Sampling frequency: 3 samples per second

• Low impedance (Low Z): Input impedence >3 kΩ

Max input 600 V RMS

• Auto power off: After ~30 minutes of inactivity

• Overload:

'OL' indicated on display, overload protection

1,000 V in Voltage setting, 600 V RMS in all other settings

• Polarity: '-' on the display indicates negative polarity

• Display: 3-5/6 digit, 6,000 count LCD

ENGLISH

WARNINGS

To ensure safe operation and service of the meter, please follow

these instructions. Failure to observe these warnings can result

in severe injury or death.

• Before every use, verify meter operation by measuring a known

voltage or current.

• Never use the meter on a circuit with voltages that exceed the

category-based rating of this meter.

• Do not use the meter during electrical storms or in wet weather.

• Do not use the meter or test leads if they appear to be damaged.

• Only use with CAT IV-rated test leads.

WARNINGS

• Ensure that meter leads are fully seated and keep fingers away

from the metal probe contacts when taking measurements.

• Do not open the meter to replace batteries while the probes

areconnected.

• Use caution when working with voltages above 25 V AC RMS

or60 V DC. Such voltages pose a shock hazard.

• To avoid false readings that can lead to electric shock, replace

batteries when a low-battery indicator appears.

• Do not attempt to measure resistance or continuity on a live circuit.

• Always adhere to local and national safety codes. Use personal

protective equipment to prevent shock and arc blast injury where

hazardous live conductors are exposed.

SYMBOLS ON THE METER

AC/DC

Resistance (in ohms) Audible continuity

Double-insulated Class II Ground

Diode Capacitance

Frequency

Duty cycle

Temperature (Fahrenheit /Celsius)

Low impedance

V Voltage (volts) A Amperage (amps)

Warning or caution

To ensure the safe operation and service of this meter, follow all

warnings and instructions detailed in this manual.

Risk of electric shock

Improper use of this meter can lead to risk of electric shock. Follow

all warnings and instructions detailed in this manual.

Risk of electric shock

Application around, and removal from, UNINSULATED HAZARDOUS

LIVE conductors is permitted.

SYMBOLS ON THE LCD

AC measurement

DC measurement

Negative reading Data hold

Auto-ranging MAX Maximum value hold

MIN Minimum value hold Low battery

Auto power off Audible continuity

Diode test

kilo (value × 10

)

Mega (value × 10

)

mili (value × 10

-3

)

micro (value × 10

-6

)

nano (value × 10

-9

)

Ohms

Volts

Amps

Farads

Frequency (hertz)

Duty cycle

Degrees (Fahrenheit)

Degrees (Celsius)

ENGLISH

FEATURE DETAILS

1. 6,000 count LCD display 8. 'MAX/MIN' button

2. Function selector switch 9.

'SEL' (select) button

3. Clamp 10.

Clamp trigger (press to open clamp)

4. 'COM' jack 11. Arrow markings

5. 'VΩ' jack 12. N

on-contact voltage testing button

6. Data hold/Backlight/Work-

light button 13. Test lead holder for test probe

14.

Non-contact voltage testing sensor

7. 'RANGE' button 15.

Polarity markings (for DC current)

16.

Work light

(back of meter)

NOTE: There are no user-serviceable parts inside the meter.

FUNCTION BUTTONS

ON/OFF

To switch the meter ON, rotate the Function selector switch

from the OFF setting to any measurement setting. To switch the

meter OFF, rotate the Function selector switch

to the OFF

setting. By default, the meter will automatically switch itself OFF

after 30 minutes of inactivity. If the meter automatically switches

itself OFF while in a measurement setting, rotate the Function

selector switch

to any other setting (excluding the OFF setting)

to switch the meter ON. To deactivate the OFF switch functionality,

press and hold the 'SEL' button

before switching ON from the

OFF setting. When auto power OFF is deactivated, the Auto power

off icon will not be visible in the display.

'SEL' (SELECT) BUTTON (FOR SECONDARY FUNCTIONS)

The 'SEL' button

activates the secondary function for each

application accessible by the Function selector switch

. For

current, voltage and low impedance, it toggles between AC and DC.

For the other functions, it switches between °F and °C, between Hz

and % duty cycle, and between Continuity, Resistance and Diode

test. The default function for each application is printed on the meter

in white. The secondary function (or functions) for each setting is

printed on the meter in orange.

DATA HOLD

Press the Data hold/Backlight/Work light button

to hold the

measurement on the display. Press again to release the display

toreturn to live measuring.

BACKLIGHT & WORK LIGHT

Press and hold the Data hold/Backlight/Work light button

for

more than one second to turn the backlight and work light ON

simultaneously. The backlight and work light will both automatically

switch OFF after 3 minutes of inactivity.

RANGE

The meter defaults to auto-ranging mode . This mode

automatically determines the most appropriate measurement range

for the testing that is being conducted. To manually force the meter

to measure in a different range, use the Range button

1. Press the 'RANGE' button

to select the measurement range

manually ( will be deactivated on the LCD). Press the

'RANGE' button repeatedly

to cycle through the ranges

available, stopping once the desired range has been reached.

2. To return to auto-ranging mode, press and hold the 'RANGE'

button

for more than one second ( will be reactivated).

ENGLISH

FUNCTION BUTTONS

MAX/MIN

When the 'MAX/MIN' button

is pressed, the meter keeps track

of the maximum and minimum values, and the difference between

the maximum and minimum values, as the meter continues to take

samples.

1. When measuring, press the 'MAX/MIN' button

to toggle

between the maximum value (MAX) and the minimum value

(MIN). If a new maximum or minimum occurs, the display will

update with the new value.

2. Press the 'MAX/MIN' button

for more than one second to

return to normal measuring mode.

NON-CONTACT VOLTAGE TESTING

Press the NCV button

to test for AC voltage using the integrated

non-contact voltage meter. Approach the conductor under test

leading with the sensing antenna

. The meter delivers visual

warning signals when AC voltage is detected.

TEST LEAD HOLDER

When working with test leads, one test probe may be mounted in

the test lead holder

to facilitate natural two-handed operation,

with the clamp in one hand and a single test probe in the other.

OPERATING INSTRUCTIONS

CONNECTING TEST LEADS

Do not test if the leads are improperly seated. Results could cause

intermittent display readings. To ensure a proper connection, press

the leads firmly into the input jack.

TESTING IN CAT III/CAT IV MEASUREMENT LOCATIONS

Ensure that the test lead shield is pressed firmly into place. Failure

to use the CATIII/CATIV shield increases the risk of arc flash.

TESTING IN CAT II MEASUREMENT LOCATIONS

CAT III/CAT IV shields may be removed for CAT II locations. This

will allow testing on recessed conductors such as standard wall

outlets. Take care not to lose the shields.

5/32"

(4 mm)

.7" (18 mm)

INCORRECT

CORRECT

ENGLISH

OPERATING INSTRUCTIONS

AC/DC CURRENT (LESS THAN 600 A)

AC current is measured by pressing the clamp trigger

to open

the clamp

and placing it around a wire carrying a current. When

measuring, care should be taken to ensure that the clamp is

completely closed, with the trigger

fully released, and that the

wire passes perpendicularly through the centre of the clamp

line with the arrow markings

To measure current:

1. Rotate the Function selector switch

to the AC/DC current A

setting.

NOTE: The meter defaults to AC measurement. Press the 'SEL'

button

to toggle between AC and DC modes. The AC or DC

iconon the LCD indicates which mode is selected.

2. Place the clamp

around the wire. When measuring DC current,

align the polarity markings

on the clamp with the polarity of

the wire to avoid negative readings. The current measurement will

be shown in the display. The meter will auto-range to display the

measurement in the most appropriate range.

Disconnect test leads when measuring with the clamp.

NOTE: If non-zero values are displayed prior to measuring in DC

current mode, an offset correction is required. With the meter in DC

current mode, press and hold the 'SEL' button

to activate the DC

current ZERO function. Subsequent DC current measurements will

automatically subtract the offset correction for improved accuracy.

WIRE

Table des matières

Langues :

Autres manuels Klein Tools Instrument de mesure

Klein Tools

Klein Tools ET920 Manuel utilisateur

Klein Tools

Klein Tools CL2200 Manuel utilisateur

Klein Tools

Klein Tools LAN Scout Jr. 2 Manuel utilisateur

Klein Tools

Klein Tools CL2000 Manuel utilisateur

Klein Tools

Klein Tools VDV501-098 Manuel utilisateur

Klein Tools

Klein Tools 93LDM100C Manuel utilisateur

Klein Tools

Klein Tools CL390 Manuel utilisateur

Klein Tools

Klein Tools CL150 Manuel utilisateur

Klein Tools

Klein Tools ET910 Manuel utilisateur

Klein Tools

Klein Tools CL220 Manuel utilisateur

Klein Tools

Klein Tools CL380 Manuel utilisateur

Klein Tools

Klein Tools MM500 Manuel utilisateur

Klein Tools

Klein Tools CL360 Manuel utilisateur

Klein Tools

Klein Tools ET110 Manuel utilisateur

Klein Tools

Klein Tools 501-915 Manuel utilisateur

Klein Tools

Klein Tools CL900E Manuel utilisateur

Klein Tools

Klein Tools Coax Explorer 2 Manuel utilisateur

Klein Tools

Klein Tools CL2200 Manuel utilisateur

Klein Tools

Klein Tools 935DAGL Manuel utilisateur

Klein Tools

Klein Tools Ranger TDR VDV501-090 Manuel utilisateur

Klein Tools

Klein Tools CL1200 Manuel utilisateur

Klein Tools

Klein Tools VDV500-051 Manuel utilisateur

Klein Tools

Klein Tools PROBEplus Manuel utilisateur

Klein Tools

Klein Tools NCVT-1 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
