Interlogix UVD-XP4DNR(-P) Manuel utilisateur
UVD-XP4DNR(-P)
Camera Quick Start
Guide
P/N 1079205B-EN • REV 1.0 • ISS 15JUN12
Quick Start Guide 1 EN
Description
The UVD-XP4DNR(-P) camera consists of the following parts:
• The camera assembly
• Monitor output cable
• Mounting screws, wall anchors, and hex key
Figure 1: The camera assembly and monitor output cable
1. Lens body 5. Camera body
2. Bubble 6. Monitor output BNC
3. Video monitor output 7. Monitor output RCA
4. OSD control pad
Use the video output BNC and power jack for normal system
operation. Use the monitor output cable for installation and
maintenance.
OSD control pad
The onscreen display (OSD) control pad is a five-direction joystick that
provides the ability to manually control the camera functions.
EN 2 Quick Start Guide
OSD control pad
Table 1 lists the OSD control pad functions and describes their use.
Table 1: OSD control pad functions
Pad directions Description
Up Moves the cursor upward to select an item.
Left Moves the cursor left to select or adjust the parameters
of the selected item.
Right Moves the cursor to the right to select or adjust the
parameters of the selected item.
Down Moves the cursor downward to select an item.
Enter Press the center of the control pad to display the Setup
menu. If the selected item has its own menu, press the
control pad to enter a submenu. Press the control pad for
2 seconds to save all settings and exit the Setup menu.
Installation
Complete all the necessary programming before you install the
camera. This section provides information on how to install the camera
and adjust camera angle and focus.
WARNING: To reduce the risk of fire or electronic shock, do not
expose the camera to rain or moisture and do not remove the cover or
back.
Cable connection
To make cable connections, do the following:
1. Connect a coaxial cable from the camera’s BNC connector to a
CCTV monitor or video recording device.
2. Connect a 12 VDC or 24 VAC power supply to the power input.
The label on the camera gives the following information:
Red cable. Power in.
Black cable. Power in.
Quick Start Guide 3 EN
White cable. Video out.
Black cable. Video ground.
Note: For AC24V or DC12V, Black or Red may be used for ground.
Camera installation
To mount the camera, attach the camera to the mounting surface using
the appropriate fasteners.
Angle adjustment
To adjust the horizontal angle of the platform up to 180 degrees, turn
the platform (1).
To adjust the horizontal angle of the rotor up to 350 degrees, turn the
rotor on the platform (2).
To adjust the vertical angle of the platform up to 90 degrees, turn the
platform (3).
Focus adjustment
To adjust the camera zoom and focus:
1. Zoom ring thumbscrew for VA2 and focus ring for VA9 lens.
2. Focus ring thumbscrew for VA2 and zooming ring for VA9 lens.
EN 4 Quick Start Guide
1. Loosen the zoom ring thumbscrew.
2. Turn the zoom ring to set the desired zoom.
3. Tighten the zoom ring thumbscrew.
4. Loosen the focus ring thumbscrew.
5. Turn the focus ring to set the desired focus.
6. Tighten the focus ring thumbscrew.
Connect the monitor
Program the cameras by attaching a standard video monitor to the
system.
To connect the monitor, do the following:
1. Plug the monitor output cable to the video monitor output
connector.
2. Connect the BNC cable to the video monitor.
3. Press the OK button to display the Setup menu.
Programming
The camera is configured through the setup menus which appear on-
screen. See Figure 2: Main menu
Table 1 lists the main menu options.
Quick Start Guide 5 EN
Table 2: Main menu options
Menu option Function
Presets Configures the preset for the lighting condition.
Setup Configures camera ID, motion detection, and wide
dynamic range options.
Viewing Configures flip and resolution.
Exposure Configures automatic gain control (AGC), AE preferences,
shutter limit, frame report, and B/W control.
White balance Configures automatic white balance (AWB) mode, and
auto tracking white balance (ATW).
Save/restore Saves user settings, restores user settings, and restores
factory settings.
Exit Menu Exits the OSD menu system and returns to live mode.
When in a submenu, you can easily move back to a previous menu,
save changes as well as cancel changes and return to live mode.
Select one of these options:
Prev. Returns to the previous menu.
Save Saves changes.
Cancel Cancels and returns to live mode.
.
Figure 2: Main menu
Table 1 lists the main menu options.
EN 6 Quick Start Guide
Table 2: Main menu options
Menu option Function
Presets Configures the preset for the lighting condition.
Setup Configures camera ID, motion detection, and wide
dynamic range options.
Viewing Configures flip and resolution.
Exposure Configures automatic gain control (AGC), AE preferences,
shutter limit, frame report, and B/W control.
White balance Configures automatic white balance (AWB) mode, and
auto tracking white balance (ATW).
Save/restore Saves user settings, restores user settings, and restores
factory settings.
Exit Menu Exits the OSD menu system and returns to live mode.
When in a submenu, you can easily move back to a previous menu,
save changes as well as cancel changes and return to live mode.
Select one of these options:
Prev. Returns to the previous menu.
Save Saves changes.
Cancel Cancels and returns to live mode.
Quick Start Guide 7 EN
Menu Map
