Interlogix TVP-6102 Manuel utilisateur

TruVision

HD-TVI PTZ

Camera (TVP

-6101/

TVP

-6102/ TVP-6103)

Installation Guide

P/N 1073485-EN • REV B • ISS 08OCT18

Interlogix is part of UTC Climate, Controls & Security, a unit

Disclaimer

Information in this document is subject to change without

notice. No part of this document may be reproduced or

transmitted in any form or by any means, electronic or

mechanical, for any purpose, without the express written

permission of UTC Fire & Security Americas Corporation, Inc.

Trademarks and

patents

Trade names used in this document may be trademarks or

registered trademarks of the manufacturers or vendors of the

respective products.

Manufacturer

Interlogix

2955 Red Hill Avenue, Costa Mesa, CA 92626-5923, USA

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6003 DH Weert, The Netherlands

Certification

FCC compliance

Class A: This equipment has been tested and found to

comply with the limits for a Class A digital device, pursuant to

part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference

when the equipment is operated in a commercial

environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used

in accordance with the instruction manual, may cause

harmful interference to radio communications. Operation of

this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct

the interference at his own expense.

FCC conditions

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This Device must accept any interference received,

including interference that may cause undesired operation.

ACMA compliance

Notice! This is a Class A product. In a domestic environment

this product may cause radio interference in which case the

user may be required to take adequate measures.

Canada

This Class A digital apparatus complies with CAN ICES-003

(A)/NMB-3 (A).

Cet appareil numérique de la classe A est conforme à la

norme CAN ICES-003 (A)/NMB-3 (A).

European Union

directives

This product and - if applicable - the supplied accessories

too are marked with "CE" and comply therefore with the

applicable harmonized European standards listed under

the EMC Directive 2014/30/EU, the RoHS Directive

2011/65/EU.

2012/19/EU (WEEE directive): Products marked with this

symbol cannot be disposed of as unsorted municipal

waste in the European Union. For proper recycling, return

this product to your local supplier upon the purchase of

equivalent new equipment, or dispose of it at designated

collection points. For more information see:

www.recyclethis.info.

2013/56/EU &2006/66/EC (battery directive): This

product contains a battery that cannot be disposed of as

unsorted municipal waste in the European Union. See the

product documentation for specific battery information. The

battery is marked with this symbol, which may include

lettering to indicate cadmium (Cd), lead (Pb), or mercury

(Hg). For proper recycling, return the battery to your

supplier or to a designated collection point. For more

information see: www.recyclethis.info.

Product warnings

and disclaimers THESE PRODUCTS ARE INTENDED FOR SALE TO AND

INSTALLATION BY QUALIFIED PROFESSIONALS. UTC

FIRE & SECURITY CANNOT PROVIDE ANY

ASSURANCE THAT ANY PERSON OR ENTITY BUYING

ITS PRODUCTS, INCLUDING ANY “AUTHORIZED

DEALER” OR “AUTHORIZED RESELLER”, IS

PROPERLY TRAINED OR EXPERIENCED TO

CORRECTLY INSTALL FIRE AND SECURITY RELATED

PRODUCTS.

For more information on warranty disclaimers and product

safety information, please check

www.firesecurityproducts.com/policy/product-warning/or

scan the following code:

Contact information

and manuals/ tools/

firmware

For contact information and to download the latest

manuals, tools, and firmware, go to the web site of your

region.

Americas: www.interlogix.com

EMEA: www.firesecurityproducts.com

Manuals are available in several languages.

Australia/New Zealand: www.utcfs.com.au

Installation Guide 1

Content

Introduction 3

Product overview 3

HD-TVI 1080P PTZ Cameras 3

HD-TVI 1080P IR PTZ Cameras 3

Contact information and manuals/tools/firmware 3

Installation 4

Installation environment 4

Package contents 5

Pendant/Wall HD-TVI PTZ 5

Surface/Flush HD-TVI PTZ 7

Pendant/Wall IR HD-TVI PTZ 10

Cable requirements 11

DIP switch settings including selecting HD-TVI or Analog

output 12

HD-TVI PTZ 12

IR pendant/wall mount HD-TVI PTZ 16

Termination resistor settings 32

Camera description 35

IR illuminators 38

Mounting the outdoor HD-TVI PTZ 38

Mount the wall mount on the wall 38

Mount the camera on the wall mount 40

Flush mount the camera 42

Surface mount the camera 45

2 Installation Guide

Using the camera with a TruVision recorder or another

system 50

Programming 50

Change the video format (NTSC/PAL) 51

Menu tree 51

Specifications 53

TruVision Pendant/Wall HD-TVI PTZ Camera (TVP-6101) 53

TruVision Surface/Flush HD-TVI PTZ (TVP-6102) 53

TruVision Pendant/Wall IR HD-TVI PTZ (TVP-6103) 54

Installation Guide 3

Introduction

Product overview

This is the installation guide for TruVision HD-TVI PTZ

Camera (TVP-6101/ TVP-6102/ TVP-6103) models:

HD-TVI 1080P PTZ Cameras

TVP-6101 (32X, Pendant/Wall mount)

TVP-6102 (32X, Surface/Flush mount)

HD-TVI 1080P IR PTZ Cameras

TVP-6103 (32X, Pendant/Wall mount, IR)

The installation guide and configuration manual are available

on our web site.

Contact information and

manuals/tools/firmware

For contact information and to download the latest manuals,

tools, and firmware, go to the web site of your region.

Americas: www.interlogix.com

EMEA: www.firesecurityproducts.com

Manuals are available in several

languages.

Australia/

New Zealand:

www.utcfs.com.au

4 Installation Guide

Installation

This section provides information on how to install the

cameras.

Installation environment

When installing your product, consider these factors:

•Electrical: Install electrical wiring carefully. It should be

done by qualified service personnel. Always use a CE

certified power supply (24VAC) to power the camera. Do

not overload the power cord or adapter.

•Ventilation: Ensure that the location planned for the

installation of the camera is well ventilated.

•Temperature: Do not operate the camera beyond the

specified temperature, humidity or power source ratings.

Humidity is below 90%. For the outdoor cameras that

feature built-in heaters, the operating temperature range

is -30 to 65°C (-22 to149°F)

•Moisture: Do not expose the camera to rain or moisture

or try to operate it in wet areas. Turn the power off

immediately if the camera is wet and ask a qualified

service person for servicing. Moisture can damage the

camera and also create the danger of electric shock.

•Servicing: Do not attempt to service this camera

yourself. Any attempt to dismantle or remove the covers

from this product will invalidate the warranty and may

also result in serious injury. Refer all servicing to qualified

service personnel.

•Cleaning: Do not touch the sensor modules with fingers.

If cleaning is necessary, use a clean cloth with some

ethanol and wipe the camera gently. If the camera will not

Installation Guide 5

be used for an extended period of time, put on the lens

cap to protect the sensors from dirt.

Package contents

Check the package and contents for visible damage. If any

components are damaged or missing, do not attempt to use

the unit; contact the supplier immediately. If the unit is

returned, it must be shipped back in its original packaging.

Pendant/Wall HD-TVI PTZ

•Camera

•Foam pad (3 pcs)

(Place it at the top of

the housing where the

harness exits).

•Safety lanyard

•Wrench (T20)

6 Installation Guide

•Desiccant 1

(Two small bags.

Used as the spare

desiccant for the PTZ.

To use this desiccant,

place it inside the cup

base and tie it with the

zip tie below.)

•Desiccant 2

(One large bag. Used

to keep the two bags

of desiccant away

from moisture prior to

use).

•Zip tie (2 pcs)

(Used to tie the

desiccant 1 bags

inside the PTZ)

•Spare rubber plugs (2

pcs)

•Screws (3 pcs)

(Used to attach the

PTZ to the wall mount

bracket)

•Installation guide
