Infineon XMC1400 Manuel utilisateur
XMC1400 CPU Card
For XMC1000 Family
CPU-14B-V1
XMC1400 CPU Card
Board User's Manual
Revision 2.0, 2019-09-16
Microcontroller
Edition 2019-09-16
Published by
Infineon Technologies AG
81726 Munich, Germany
© 2019 Infineon Technologies AG
All Rights Reserved.
Legal Disclaimer
The information given in this document shall in no event be regarded as a guarantee of conditions or
characteristics. With respect to any examples or hints given herein, any typical values stated herein and/or
any information regarding the application of the device, Infineon Technologies hereby disclaims any and all
warranties and liabilities of any kind, including without limitation, warranties of non-infringement of intellectual
property rights of any third party.
Information
For further information on technology, delivery terms and conditions and prices, please contact the nearest
Infineon Technologies Office (www.infineon.com).
Warnings
Due to technical requirements, components may contain dangerous substances. For information on the types in
question, please contact the nearest Infineon Technologies Office.
Infineon Technologies components may be used in life-support devices or systems only with the express
written approval of Infineon Technologies, if a failure of such components can reasonably be expected to cause
the failure of that life-support device or system or to affect the safety or effectiveness of that device or system.
Life support devices or systems are intended to be implanted in the human body or to support and/or maintain
and sustain and/or protect human life. If they fail, it is reasonable to assume that the health of the user or other
persons may be endangered.
CPU-14B-V1
XMC1400 CPU Card
Revision History
Page or Item Subjects (major changes since previous revision)
Revision 2.0, 2019-09-16
16,18 Change C210 to 4.7uF
Trademarks of Infineon Technologies AG
AURIXTM, C166TM, CanPAKTM, CIPOSTM, CIPURSETM, EconoPACKTM, CoolMOSTM, CoolSETTM,
CORECONTROLTM, CROSSAVETM, DAVETM, DI-POLTM, EasyPIMTM, EconoBRIDGETM, EconoDUALTM,
EconoPIMTM, EconoPACKTM, EiceDRIVERTM, eupecTM, FCOSTM, HITFETTM, HybridPACKTM, I2RFTM,
ISOFACETM, IsoPACKTM, MIPAQTM, ModSTACKTM, my-dTM, NovalithICTM, OptiMOSTM, ORIGATM,
POWERCODETM, PRIMARIONTM, PrimePACKTM, PrimeSTACKTM, PRO-SILTM, PROFETTM, RASICTM,
ReverSaveTM, SatRICTM, SIEGETTM, SINDRIONTM, SIPMOSTM, SmartLEWISTM, SOLID FLASHTM,
TEMPFETTM, thinQ!TM, TRENCHSTOPTM, TriCoreTM.
Other Trademarks
Advance Design SystemTM (ADS) of Agilent Technologies, AMBATM, ARMTM, MULTI-ICETM, KEILTM,
PRIMECELLTM, REALVIEWTM, THUMBTM, µVisionTM of ARM Limited, UK. AUTOSARTM is licensed by
AUTOSAR development partnership. BluetoothTM of Bluetooth SIG Inc. CAT-iqTM of DECT Forum.
COLOSSUSTM, FirstGPSTM of Trimble Navigation Ltd. EMVTM of EMVCo, LLC (Visa Holdings Inc.). EPCOSTM
of Epcos AG. FLEXGOTM of Microsoft Corporation. FlexRayTM is licensed by FlexRay Consortium.
HYPERTERMINALTM of Hilgraeve Incorporated. IECTM of Commission Electrotechnique Internationale. IrDATM
of Infrared Data Association Corporation. ISOTM of INTERNATIONAL ORGANIZATION FOR STANDARDIZATION.
MATLABTM of MathWorks, Inc. MAXIMTM of Maxim Integrated Products, Inc. MICROTECTM, NUCLEUSTM of
Mentor Graphics Corporation. MIPITM of MIPI Alliance, Inc. MIPSTM of MIPS Technologies, Inc., USA. muRataTM
of MURATA MANUFACTURING CO., MICROWAVE OFFICETM (MWO) of Applied Wave Research Inc.,
OmniVisionTM of OmniVision Technologies, Inc. OpenwaveTM Openwave Systems Inc. RED HATTM Red Hat, Inc.
RFMDTM RF Micro Devices, Inc. SIRIUSTM of Sirius Satellite Radio Inc. SOLARISTM of Sun Microsystems, Inc.
SPANSIONTM of Spansion LLC Ltd. SymbianTM of Symbian Software Limited. TAIYO YUDENTM of Taiyo Yuden
Co. TEAKLITETM of CEVA, Inc. TEKTRONIXTM of Tektronix Inc. TOKOTM of TOKO KABUSHIKI KAISHA TA.
UNIXTM of X/Open Company Limited. VERILOGTM, PALLADIUMTM of Cadence Design Systems, Inc. VLYNQTM
of Texas Instruments Incorporated. VXWORKSTM, WIND RIVERTM of WIND RIVER SYSTEMS, INC. ZETEXTM
of Diodes Zetex Limited.
Last Trademarks Update 2011-11-11
Template: IFX_Template_2011-11-11.dot
CPU-14B-V1
XMC1400 CPU Card
Table of Contents
1 Overview ........................................................................................................................................... 7
1.1 Key Features...................................................................................................................................... 7
1.2 Block Diagram.................................................................................................................................... 7
2
Hardware Description
................................
................................
................................
......................
8
2.1
XMC1400 connector for ARDUINO
TM
................................
................................
................................
................................
..............................
8
2.1.1 Digital IO connector............................................................................................................................ 8
2.1.2 Analog input ...................................................................................................................................... 10
2.1.3 Power connector, POWER................................................................................................................ 10
2.1.4 ICSP (In-Circuit Serial Programming) Header .................................................................................. 11
2.2 LEDs.................................................................................................................................................. 11
2.3 Other connectors............................................................................................................................... 12
3 Production Data............................................................................................................................... 14
3.1 Schematics........................................................................................................................................ 14
3.2 Layout and Geometry........................................................................................................................ 17
3.3 Bill of Material ................................................................................................................................... 17
Board User's Manual 4 Revision 2.0, 2019-09-16
CPU-14B-V1
XMC1400 CPU Card
List of Figures
Figure 1 Block Diagram of XMC1400 CPU Card for ArduinoTM .........................................................................7
Figure 2 XMC1400 CPU Card for ArduinoTM ...........................................................................................................8
Figure 3 Digital IO connectors IOH, IOL.............................................................................................................9
Figure 4 Analog input AD connector......................................................................................................................10
Figure 5 POWER connector..................................................................................................................................11
Figure 6 ICSP connector..................................................................................................................................11
Figure 7 LEDs Circuit .......................................................................................................................................12
Figure 8 AD_AUX and AUX connector..................................................................................................................12
Figure 9 Schematic 1 of 2 XMC1400 CPU Card for ArduinoTM .............................................................................15
Figure 10 Schematic 2 of 2 XMC1400 CPU Card for ArduinoTM ...........................................................................16
Figure 11 XMC1400 CPU Card for ArduinoTM layout and geometry.....................................................................17
Board User's Manual 5 Revision 2.0, 2019-09-16
CPU-14B-V1
XMC1400 CPU Card
List of Tables
Table 1 Digital IO of connector IOH ..................................................................................................................9
Table 2 Digital IO of connector IOL...................................................................................................................9
Table 3 Pinout of the AD connector ................................................................................................................10
Table 4 Pinout of the POWER connector........................................................................................................11
Table 5 Signals of ICSP connector .................................................................................................................11
Table 6 LEDs Signal Description ....................................................................................................................12
Table 7 Signals of connector AD_AUX...........................................................................................................13
Table 8 Signals of connector AUX ..................................................................................................................13
Table 9 XMC1400 CPU Card for ArduinoTM....................................................................................................17
Board User's Manual 6 Revision 2.0, 2019-09-16
CPU-14B-V1
XMC1400 CPU Card
Introduction
This document describes the features and hardware details of the XMC1400 CPU Card for ArduinoTM. This
board is mounted with ARM®CortexTM-M0 based XMC1400 Microcontroller from Infineon Technologies AG and
part of Infineon’s XMC1000 offering of Kits.
1 Overview
The XMC1400 CPU Card for ArduinoTM has two rows of pin headers which fully compatible with ArduinoTM
shield. Hence, user can buy various Arduino shield boards off-the-shelf to test the capabilities of XMC1400
Microcontroller.
1.1 Key Features
The XMC1400 CPU Card for ArduinoTM is equipped with the following features
• XMC1400 (ARM® CortexTM -M0 based) Microcontroller, TSSOP38
• Headers compatible with ArduinoTM shield
• Detachable SEGGER J-Link debugger and UART virtual COM port, with micro USB connector
• Power supply concept compatible with ArduinoTM Uno
• One LED as required from ArduinoTM board specification and 2 additonal LEDs
• XTAL (20MHz) and RTC_XTAL(32768Hz)
1.2 Block Diagram
Figure 1 shows the block diagram of the XMC1400 CPU Card for ArduinoTM. There are following blocks:
Figure 1 Block Diagram of XMC1400 CPU Card for ArduinoTM
Board User's Manual 7 Revision 2.0, 2019-09-16
CPU-14B-V1
XMC1400 CPU Card
2 Hardware Description
The following sections give a detailed description of the hardware and how it can be used.
Figure 2 XMC1400 CPU Card for ArduinoTM
2.1 XMC1400 connector for ARDUINOTM
2.1.1 Digital IO connector
XMC1400 CPU Card for ArduinoTM have 10 pin connector mounting holes and 8 pin connector mounting holes
at IOH and IOL respectively. Sixteen of those pins are digital input or output pins. The pinouts are listed in Table
1 and Table 2.
Board User's Manual 8 Revision 2.0, 2019-09-16
CPU-14B-V1
XMC1400 CPU Card
Figure 3 Digital IO connectors IOH, IOL
Table 1 Digital IO of connector IOH
Pin No. ArduinoTM Signal Name XMC1400 Signal Name Description
10 SCL P2.0 I2C Clock
9 SDA P2.1 I2C Data / Address
8 AREF P2.3 Analog reference voltage
7 GND GND Ground
6 13 - SCK P0.3 SPI-SCK / LED output
5 12 - MISO P0.0 SPI-MISO
4 ~11 - MOSI P0.1 SPI-MOSI / PWM output
3 ~10 - SS P0.4 SPI-SS / PWM output
2 ~9 - P0.7 PWM output
1 8 P0.12 GPIO
Table 2 Digital IO of connector IOL
Pin No. ArduinoTM Signal Name XMC1400 Signal Name Description
8 7 P0.13 GPIO
7 ~6 P0.6 PWM output
6 ~5 P0.2 PWM output
5 4 P1.1 GPIO
4 ~3 P0.0 External interrupt / PWM output
3 2 P1.4 External interrupt
2 1 - TX(IN) P1.3 Device received UART signal
1 0 - RX(OUT) P1.2 Device transmit UART signal
Board User's Manual 9 Revision 2.0, 2019-09-16
CPU-14B-V1
XMC1400 CPU Card
2.1.2 Analog input
XMC1400 CPU Card for ArduinoTM has six analog inputs at connector AD.
Figure 4 Analog input AD connector
Table 3 Pinout of the AD connector
Pin No. ArduinoTM Signal Name XMC1400 Signal Name Description
1 A0 P2.6 ADC Input
2 A1 P2.8 ADC Input
3 A2 P2.9 ADC Input
4 A3 P2.10 ADC Input
5 A4 P2.1 ADC Input
6 A5 P2.0 ADC Input
2.1.3 Power connector, POWER
XMC1400 CPU Card for ArduinoTM can be powered from the micro USB connector or with an external power
supply via the DC power jack. However, the DC power jack is not mounted.
The XMC1400 device can operate by power supply of 1.8V till 5.5Vdc. On this board, 5Vdc is used to power the
XMC1400 device. However, if user wants to power the XMC1400 device with 3.3Vdc, then, please remove
R102 and solder 0 ohm resistor R101.
Board User's Manual 10 Revision 2.0, 2019-09-16
